Cisco MDS 9513 DS-C9513 Multilayer Switch Chassis

Overview of the Cisco DS-C9513 Switch

The Cisco DS-C9513 is a robust rack-mountable Fibre Channel switch designed to meet demanding connectivity and performance requirements. Ideal for data centers and enterprise environments, this switch offers exceptional scalability and reliability.

Key Features

• Manufacturer: Cisco
• Part Number: DS-C9513
• Device Type: High-performance Switch

Device Specifications

Physical Characteristics

• Enclosure: Rack-mountable, 14U
• Interfaces: Fibre Channel
• Subtype: Fibre Channel switch

Expansion and Connectivity

• Total Expansion Slots: 13
• Available Expansion Slots: 13
• Installed Modules: 0 (supports up to 13)

Environmental Specifications

Operating Conditions

• Maximum Operating Temperature: 104 °F
• Minimum Operating Temperature: 32 °F
• Humidity Range: 10 – 90% operating

Power and Redundancy

Power Supply Features

• Power Device: Hot-plug / redundant power supply
• Installed Power Supplies: 0 (supports up to 2)
• Redundant Power: Yes

Cisco MDS 9513 Multilayer Switch Chassis (DS-C9513)

Introduction

The Cisco MDS 9513 Multilayer Switch Chassis, also known as the DS-C9513, is a high-performance and reliable solution designed to meet the demanding needs of modern data centers. This switch chassis offers exceptional performance, scalability, and versatility, making it an ideal choice for organizations that require a robust and feature-rich networking solution. With its advanced capabilities and cutting-edge technology, the DS-C9513 delivers a seamless networking experience while ensuring maximum uptime and data integrity.

Unparalleled Performance

The DS-C9513 is built to deliver unparalleled performance, enabling organizations to handle even the most demanding workloads with ease. Equipped with powerful switching engines, this switch chassis offers high-density 10 Gigabit Ethernet (GbE) and 40 GbE connectivity options. It supports wire-speed performance on all ports, ensuring fast and efficient data transfer across the network. The DS-C9513 also incorporates advanced traffic management features such as Quality of Service (QoS) and intelligent load balancing, enabling organizations to prioritize critical applications and ensure optimal network performance.

Scalability

One of the key advantages of the DS-C9513 is its exceptional scalability. This switch chassis supports up to 528 line-rate 10 GbE ports or 132 line-rate 40 GbE ports in a single system. With its high port density and ability to accommodate a large number of devices, the DS-C9513 can easily scale to meet the evolving needs of growing organizations. Whether you are expanding your data center infrastructure or adding new applications, this switch chassis provides the flexibility and scalability required to support your business's growth.

Versatility

The DS-C9513 offers exceptional versatility, making it suitable for a wide range of networking environments. It supports various protocols and technologies, including Fibre Channel, Fibre Channel over Ethernet (FCoE), and Ethernet, providing organizations with the flexibility to integrate different types of storage and networking devices seamlessly. The DS-C9513 also supports virtualization technologies such as Virtual SAN (VSAN) and Virtual Device Context (VDC), enabling organizations to optimize resource utilization and simplify network management.

Reliability and Redundancy

The DS-C9513 is designed to deliver the highest levels of reliability and redundancy, ensuring uninterrupted network connectivity and data availability. It incorporates redundant power supplies and fans, as well as hot-swappable modules, allowing for non-disruptive maintenance and upgrades. The switch chassis also supports advanced features like Virtual Router Redundancy Protocol (VRRP) and Hot Standby Router Protocol (HSRP), providing failover capabilities and minimizing the risk of network downtime. With its robust hardware design and advanced redundancy features, the DS-C9513 offers peace of mind to organizations that cannot afford any network disruptions.

High Availability

The DS-C9513 is equipped with features that enhance network availability, making it an excellent choice for mission-critical environments. It supports Cisco's Fabric Shortest Path First (FSPF) protocol, which optimizes network paths and ensures reliable data transmission. The switch chassis also offers In-Service Software Upgrade (ISSU) capabilities, allowing organizations to perform software upgrades without interrupting traffic flow. With its high availability features, the DS-C9513 minimizes the risk of data loss or service interruptions, ensuring continuous operations for critical applications.

Data Integrity

Data integrity is crucial for organizations that deal with sensitive information or rely on accurate data for their operations. The DS-C9513 addresses this concern by incorporating advanced data protection mechanisms. It supports features such as Fibre Channel Write Acceleration (FC-WA), which enhances write performance and reduces the risk of data corruption. The switch chassis also offers end-to-end data integrity with features like Data Integrity Extension (DIX) and T10 Protection Information (T10 PI), ensuring that data remains intact during transit and storage.

Management and Security

The DS-C9513 provides robust management and security features, enabling organizations to efficiently manage and secure their network infrastructure.

Simple Network Management Protocol (SNMP)

With SNMP support, the DS-C9513 allows organizations to monitor and manage their network devices from a central location. SNMP provides real-time visibility into device performance, status, and utilization, facilitating proactive troubleshooting and ensuring optimal network performance.

Role-Based Access Control (RBAC)

RBAC allows organizations to enforce granular access controls, ensuring that only authorized personnel can access and configure the switch chassis. This feature enhances network security by preventing unauthorized access or configuration changes that could compromise the integrity of the network.

Auditing and Logging

The DS-C9513 offers comprehensive auditing and logging capabilities, allowing organizations to track and monitor network activities. This feature enables organizations to identify security breaches, detect anomalies, and investigate potential threats or vulnerabilities.

Secure Remote Management

The DS-C9513 supports secure remote management protocols such as Secure Shell (SSH) and Secure Socket Layer (SSL), ensuring that management traffic is encrypted and protected from unauthorized access or interception. This feature allows administrators to securely manage the switch chassis from remote locations, enhancing operational efficiency and reducing the risk of security breaches.

In conclusion, the Cisco MDS 9513 Multilayer Switch Chassis (DS-C9513) is a highly versatile and reliable networking solution that offers exceptional performance, scalability, and security. With its advanced features and robust design, this switch chassis provides organizations with the flexibility to meet their evolving networking needs while ensuring maximum uptime and data integrity. From its unparalleled performance and scalability to its advanced management and security features, the DS-C9513 is an invaluable asset for organizations seeking a high-performance networking solution for their data centers.
