DS-X2-FC10G-SR Cisco 10GBPS 10GBase-SR Transceiver Module

Overview of Cisco DS-X2-FC10G-SR MM Fiber Optic Transceiver

The Cisco DS-X2-FC10G-SR is a high-performance 10 Gigabit Ethernet fiber optic transceiver module engineered for reliable short-range data transmission in enterprise and data center networking environments. Designed to deliver stable, high-speed connectivity, this module supports multi-mode fiber infrastructure with optimized signal clarity and minimal latency.

General Specification

• Manufacturer: Cisco
• Part Number: DS-X2-FC10G-SR
• Device Type: Optical Fiber Transceiver Module

Technical Highlights

• 10GBase-SR compliant fiber optic module
• Multi-mode optical transmission support
• 850nm wavelength for short-range efficiency
• SC Duplex connector interface
• Up to 300 meters transmission distance capability

Advanced Networking Capabilities

• Supports 10GBase-SR standard for short-range optical communication
• Optimized for enterprise-grade networking infrastructure
• Reduces latency for high-demand data operations

Optical Fiber Technology Specifications

Connector and Interface Configuration

• Connector Type: SC Duplex
• Port Configuration: 1 x SC 10GBase-SR interface
• Transmission Medium: Multi-mode fiber optic cable

Wavelength and Signal Characteristics

• Operating Wavelength: 850nm
• Stable short-range optical signal transmission
• Enhanced compatibility with modern multi-mode fiber systems

Distance and Coverage Efficiency

Transmission Range Performance

• Maximum transmission distance: up to 300 meters
• Ideal for server rooms, enterprise networks, and structured cabling systems
• Maintains signal integrity across multi-mode fiber links

Key Advantages and Functional Benefits

• Delivers consistent 10Gbps bandwidth performance
• Reduces network congestion in high-traffic environments
• Supports scalable enterprise network expansion
• Ensures reliable optical communication between network devices

Deployment Flexibility

• Compatible with various Cisco networking systems
• Suitable for data centers, enterprise LANs, and backbone networks
• Easy integration into existing fiber infrastructure

Application Scenarios

• High-performance data centers requiring fast interconnects
• Enterprise network backbone upgrades
• Storage area network (SAN) environments
• Server-to-switch high-speed connectivity

Outline of Cisco DS-X2-FC10G-SR 10GBase-SR X2 Transceiver

High-Speed Optical Networking for Enterprise and Data Center Infrastructure

The Cisco DS-X2-FC10G-SR 10GBPS 10GBase-SR Multi-mode Fiber transceiver module is engineered to deliver high-performance optical connectivity for modern enterprise networks, storage area networks, and data center environments where high bandwidth, low latency, and reliable short-range communication are essential. This module operates on the 10 Gigabit Ethernet standard using the 10GBase-SR specification, optimized for short-range multimode fiber transmission over distances up to 300 meters depending on fiber grade. Designed with an 850nm wavelength vertical-cavity surface-emitting laser (VCSEL), it ensures stable signal integrity and efficient optical transmission across compatible infrastructure.

Purpose and Role in Modern Network Architecture

In contemporary network design, optical transceivers serve as critical interface components between switching equipment and fiber optic cabling. The Cisco DS-X2-FC10G-SR plays a central role in enabling high-speed data exchange between core switches, distribution layers, and storage systems. Its deployment is particularly common in environments requiring high-throughput data replication, virtualization traffic handling, cloud service delivery, and large-scale enterprise communications. By converting electrical signals into optical signals and vice versa, it ensures seamless interoperability between hardware devices across optical fiber backbones.

Technical Specifications and Engineering Characteristics

10 Gigabit Ethernet 10GBase-SR Standard

The 10GBase-SR standard defines short-range optical transmission over multimode fiber using an 850nm wavelength. It is one of the most widely deployed standards in high-speed local area networks due to its balance between cost efficiency and performance. The Cisco DS-X2-FC10G-SR complies with this standard to provide consistent 10Gbps throughput, making it suitable for aggregation switches and high-density data center switches.

850nm VCSEL Laser Technology

At the core of this transceiver module is an 850nm VCSEL laser source, which provides high modulation speeds and energy-efficient optical signal generation. VCSEL technology is preferred in short-reach multimode fiber applications because it offers lower power consumption, reduced heat output, and stable signal performance even in densely populated networking environments. This allows the module to maintain reliable communication with minimal signal degradation over supported distances.

300 Meter Transmission Capability

The Cisco DS-X2-FC10G-SR supports data transmission distances of up to 300 meters when used with OM3 multimode fiber and optimized cabling infrastructure. This range makes it suitable for intra-building connections, data center inter-rack communication, and campus network backbones. With OM4 fiber, performance can be further enhanced in certain deployment scenarios, allowing better signal integrity and reduced attenuation over extended short-range links.

X2 Form Factor Design

The X2 form factor is a hot-swappable optical module design used in Cisco networking equipment. It provides a robust and modular interface that enables easy installation and replacement without network downtime. The DS-X2-FC10G-SR integrates seamlessly into compatible Cisco switches and routers equipped with X2 ports. This design supports scalability in enterprise networks where modular expansion is required to accommodate increasing bandwidth demands.

Fiber Optic Compatibility and Cabling Infrastructure

Multimode Fiber Optimization

This transceiver is specifically optimized for multimode fiber (MMF) environments, which utilize a larger core diameter compared to single-mode fiber. The increased core size allows multiple light paths to propagate simultaneously, making it ideal for short-range communication within buildings and data centers. The DS-X2-FC10G-SR is commonly deployed with OM2, OM3, and OM4 fiber types, with OM3 and OM4 providing superior performance due to reduced modal dispersion.

Duplex SC Connector Interface

The module uses a duplex SC connector interface for optical connectivity. SC connectors are widely recognized for their push-pull coupling mechanism, which ensures secure and stable physical connections while reducing insertion loss. The duplex configuration allows simultaneous transmission and reception of data streams, enabling full-duplex communication essential for high-speed networking applications.

Signal Integrity and Loss Management

Maintaining signal integrity in optical communication is critical for preventing data corruption and ensuring efficient throughput. The DS-X2-FC10G-SR incorporates advanced optical design principles to minimize insertion loss, reflectance, and modal dispersion. When deployed with properly installed multimode fiber cabling, the module delivers consistent performance with minimal bit error rates even under heavy network load conditions.

Performance in Enterprise and Data Center Environments

High Bandwidth Network Aggregation

In enterprise environments, the demand for high-speed data aggregation continues to increase due to virtualization, cloud computing, and big data analytics. The Cisco DS-X2-FC10G-SR supports efficient aggregation of multiple lower-speed links into high-capacity uplinks, reducing congestion and improving overall network throughput. Its 10Gbps capacity ensures that large volumes of data can be transmitted with minimal latency.

Low Latency Communication

Latency is a critical factor in applications such as financial trading systems, real-time analytics, and storage replication. This transceiver module is designed to minimize transmission delay by optimizing optical conversion processes and maintaining a stable signal path. The result is near-instantaneous data transfer across connected devices within the same network infrastructure.

Data Center Interconnectivity

Modern data centers rely on high-speed optical links to connect server racks, storage arrays, and switching fabrics. The DS-X2-FC10G-SR is particularly effective in top-of-rack and end-of-row switching architectures. Its ability to maintain stable 10Gbps communication over multimode fiber makes it suitable for high-density computing environments where space efficiency and performance are equally important.

Operational Considerations

Hot-Swappable Deployment

One of the key advantages of the Cisco X2 transceiver design is its hot-swappable capability. This allows network administrators to install or replace modules without shutting down the entire system. This feature is essential for maintaining uptime in mission-critical environments such as enterprise data centers and service provider networks.

Compatibility with Cisco Networking Hardware

The DS-X2-FC10G-SR is designed for use with Cisco networking platforms that support X2 interfaces. This ensures tight integration with Cisco switching and routing ecosystems, enabling optimized performance and seamless interoperability. Proper compatibility ensures that firmware and hardware synchronization functions correctly, minimizing operational issues.

Engineering Design and Internal Architecture

Optoelectronic Conversion System

The module contains an integrated optoelectronic system responsible for converting electrical signals into optical signals and vice versa. This system includes laser drivers, photodetectors, and signal conditioning circuits that ensure accurate data transmission. The precision engineering of these components contributes to the module’s reliability and long operational lifespan.

Thermal Efficiency and Power Management

Efficient thermal management is essential in high-density networking environments. The DS-X2-FC10G-SR is designed with low-power consumption architecture that minimizes heat generation. This allows it to operate effectively within temperature ranges typical of enterprise networking equipment racks without requiring additional cooling mechanisms beyond standard airflow systems.

Error Reduction and Signal Correction

To maintain data integrity, the module incorporates mechanisms that reduce transmission errors caused by noise, dispersion, and attenuation. These include precise modulation control and receiver sensitivity optimization. As a result, the transceiver achieves low bit error rates even in demanding operational conditions.

Use Cases Across Industry Sectors

Enterprise IT Infrastructure

Large enterprises utilize the DS-X2-FC10G-SR for internal network backbones that connect departments, data centers, and branch offices. Its high throughput capacity supports business-critical applications such as ERP systems, internal communication platforms, and centralized storage systems.

Cloud Computing and Virtualization

Cloud environments require high-speed interconnects to manage virtual machine migration, distributed storage access, and load balancing. This transceiver module supports these requirements by providing consistent bandwidth and low latency connectivity between virtualization hosts and storage nodes.

Telecommunications Networks

Telecommunication providers use optical transceivers like the DS-X2-FC10G-SR to support metro networks and aggregation layers. Its ability to handle large volumes of traffic makes it suitable for backbone infrastructure supporting internet service delivery and mobile network operations.

Storage Area Networks (SAN)

In storage environments, high-speed connectivity is essential for data replication, backup operations, and real-time storage access. The DS-X2-FC10G-SR supports Fibre Channel and Ethernet-based SAN architectures, ensuring reliable and fast data transfer between storage arrays and compute nodes.

Reliability

This transceiver module is engineered for long-term operational stability in demanding environments. Its robust construction ensures resistance to physical stress, signal degradation, and environmental variations commonly found in enterprise data centers.

Scalability and Future Network Expansion

Supporting Growing Bandwidth Demands

As organizations continue to expand their digital infrastructure, the need for scalable networking solutions becomes increasingly important. The DS-X2-FC10G-SR supports scalable deployment strategies by enabling incremental expansion of network capacity without requiring complete infrastructure replacement.

Integration into Hybrid Network Architectures

Modern networks often combine legacy systems with advanced cloud-based infrastructure. This transceiver module facilitates hybrid integration by providing reliable 10Gbps connectivity that bridges older systems with newer high-speed architectures.

Future-Proof Optical Networking Design

Although newer transceiver standards continue to evolve, 10GBase-SR remains widely used due to its cost efficiency and proven reliability. The DS-X2-FC10G-SR continues to serve as a dependable component in network designs that prioritize stability, compatibility, and predictable performance.
