IE-9320-22S2C4X-E Cisco 24 Ports SFP Rugged Ethernet Switch

Cisco IE-9320-22S2C4X-E Catalyst Ethernet Switch Overview

The Cisco IE-9320-22S2C4X-E Catalyst 24-Port SFP Rugged Ethernet Switch is purpose-built for harsh industrial and mission-critical environments. As part of the Catalyst IE9300 Rugged Series, this high-performance managed switch delivers advanced Layer 2 and Layer 3 capabilities, industrial-grade durability, and enterprise-class security. Designed for factory automation, transportation systems, power utilities, oil and gas facilities, and smart city deployments, this rack-mountable switch ensures reliable connectivity in extreme temperatures and demanding conditions.

Manufacturer & Product Details

• Manufacturer: Cisco
• Model: IE-9320-22S2C4X-E
• Series: Catalyst IE9300 Rugged
• Product Type: Managed Industrial Ethernet Switch

Total Ports and Downlink Connectivity

• 22 × 100/1000M SFP fiber ports
• 2 × Dual-media ports (SFP/RJ45 combo)
• Total downlink interfaces: 24

High-Speed Uplink Ports

• 4 × 1/10 Gigabit SFP+ uplink ports

Switching and Forwarding Capacity

• Switching Bandwidth: 128 Gbps (full duplex)
• Forwarding Bandwidth: 64 Gbps
• Forwarding Rate: 95.23 Mpps

Layer 2 and Layer 3 Network Capabilities

MAC Address and VLAN Scalability

• 24,000 Unicast MAC addresses
• 4,096 VLAN IDs
• 1,024 Active VLANs

Multicast and Routing Performance

• 1,000 IGMP multicast groups
• IPv4 Routes: 7,000 indirect / 8,192 direct
• IPv6 Routes: 1,522 indirect

Memory and Storage

• 8 GB DRAM
• 8 GB Flash Memory (2.5 GB user accessible)
• Optional 16 GB SD card slot

Industrial-Grade Reliability and Power Redundancy

Dual Power Supply Support

• Dual AC/DC power inputs
• Hot-swappable power supplies
• Redundant power architecture

Alarm Interfaces

• 4 dry-contact alarm inputs
• 1 dry-contact relay alarm output

Management and Console Interfaces

Console and USB Ports

• RS-232 console (RJ-45)
• Micro USB console port
• USB-A host port

Environmental Specifications for Harsh Deployments

Extreme Operating Conditions

• Operating Temperature: -40°C to 75°C
• Storage Temperature: -40°C to 85°C
• Operating Humidity: 5% to 95% (non-condensing)
• Maximum Altitude: 15,000 ft (4,572 m)

Physical Dimensions and Mounting Options

• Height: 1.72 in (43.7 mm)
• Width: 17.5 in (444.5 mm)
• Depth: 14.0 in (355.6 mm)
• Mounting: 1RU rack-mount, wall-mount, ETSI compatible

Advanced Timing Features

• GNSS time synchronization
• IRIG-B support
• IEEE 1588v2 Precision Time Protocol (PTP)

Supported Industrial Ethernet Protocols

• PROFINET
• EtherNet/IP (CIP)
• Modbus TCP
• HSR (High-availability Seamless Redundancy)
• PRP (Parallel Redundancy Protocol)
• REP (Resilient Ethernet Protocol)
• MRP (Media Redundancy Protocol)

Cisco IE-9320-22S2C4X-E Catalyst 24 Ports SFP Switch Outline

The Cisco IE-9320-22S2C4X-E Catalyst 24 Ports SFP Rugged Ethernet Switch is a high-performance, industrial-grade networking solution designed for demanding environments. Built to withstand extreme conditions, it provides secure, reliable, and scalable connectivity for mission-critical applications. This rugged switch belongs to the Cisco Catalyst IE9300 series, which is engineered to deliver enterprise-class features in industrial deployments such as manufacturing plants, transportation systems, energy grids, and smart cities.

Key Features of Cisco IE-9320-22S2C4X-E

Port Configuration

The switch offers 24 SFP ports, 2 combo uplink ports, and 4 10-Gigabit uplink ports. This configuration ensures flexibility in connecting fiber and copper devices, supporting both short-range and long-range communication needs. The inclusion of 10G uplinks allows for high-speed backbone connectivity, making it suitable for bandwidth-intensive applications.

Rugged Design

Designed for harsh industrial environments, the Cisco IE-9320-22S2C4X-E is built with a ruggedized chassis that can withstand extreme temperatures, vibrations, and electromagnetic interference. This makes it ideal for outdoor deployments, factory floors, and transportation systems where traditional enterprise switches would fail.

Advanced Security

Security is a cornerstone of the Cisco Catalyst IE9300 series. The IE-9320-22S2C4X-E integrates Cisco’s advanced security features, including TrustSec, MACsec encryption, and secure boot. These features protect against unauthorized access, data breaches, and cyber threats, ensuring that industrial networks remain resilient and compliant with modern cybersecurity standards.

High Availability

The switch supports redundancy protocols such as HSRP, VRRP, and MSTP, ensuring continuous network availability. With dual power inputs and fanless operation, it minimizes downtime and provides reliable service in mission-critical applications.

Applications of Cisco IE-9320-22S2C4X-E

Manufacturing Automation

In manufacturing plants, the switch enables seamless connectivity between programmable logic controllers (PLCs), sensors, and industrial robots. Its rugged design ensures uninterrupted operation even in environments with high dust, humidity, and temperature fluctuations.

Transportation Systems

The IE-9320-22S2C4X-E is widely used in intelligent transportation systems (ITS). It supports real-time communication between traffic signals, surveillance cameras, and control centers. With its fiber connectivity, it ensures long-distance communication across highways, railways, and airports.

Energy and Utilities

Power grids, oil refineries, and renewable energy plants rely on rugged switches for secure and reliable communication. The Cisco IE-9320-22S2C4X-E provides the necessary bandwidth and security to support SCADA systems, smart meters, and IoT devices in energy networks.

Smart Cities

In smart city deployments, the switch connects IoT sensors, surveillance systems, and public Wi-Fi hotspots. Its scalability and high-speed uplinks make it suitable for handling large volumes of data generated by urban infrastructure.

Benefits of Deploying Cisco IE-9320-22S2C4X-E

Scalability

The switch supports modular expansion, allowing businesses to scale their networks as demands grow. With its 10G uplinks, it can integrate seamlessly into larger enterprise or industrial networks.

Reliability

Ruggedized hardware and redundant power inputs ensure maximum uptime. This reliability is critical for industries where downtime can lead to significant financial losses or safety risks.

Comparison with Other Cisco Industrial Switches

Cisco IE-9320-22S2C4X-E vs IE-3300 Series

While the IE-3300 series is suitable for smaller industrial deployments, the IE-9320-22S2C4X-E offers higher port density and 10G uplinks, making it ideal for large-scale applications. The IE-9320 also provides enhanced security features compared to the IE-3300.

Cisco IE-9320-22S2C4X-E vs IE-3400 Series

The IE-3400 series is compact and designed for edge deployments, whereas the IE-9320-22S2C4X-E is built for core industrial networks requiring high bandwidth and scalability. Both series share rugged designs but differ in performance capabilities.

Deployment Scenarios

Factory Floor Connectivity

The switch can be deployed to connect industrial robots, sensors, and control systems. Its rugged design ensures stable performance even in environments with heavy machinery and electrical interference.

Outdoor Surveillance Networks

With fiber connectivity and high-speed uplinks, the IE-9320-22S2C4X-E supports outdoor surveillance systems in cities, airports, and transportation hubs. It ensures real-time video streaming and secure data transmission.

Utility Substations

In utility substations, the switch provides secure communication between SCADA systems and central monitoring stations. Its advanced security features protect against cyber threats targeting critical infrastructure.

Cisco DNA Center Integration

The IE-9320-22S2C4X-E integrates with Cisco DNA Center, enabling centralized management, automation, and analytics. This simplifies network operations and enhances visibility across industrial deployments.

SNMP and CLI Support

The switch supports SNMP, CLI, and web-based management interfaces, providing flexibility for administrators. These tools allow real-time monitoring, configuration, and troubleshooting.

Zero-Touch Provisioning

With zero-touch provisioning, the switch can be deployed quickly without manual configuration. This reduces installation time and minimizes human error in large-scale deployments.

Power and Energy Efficiency

Dual Power Inputs

The switch supports dual DC power inputs, ensuring redundancy and continuous operation even if one power source fails.

Energy-Efficient Ethernet

Cisco IE-9320-22S2C4X-E supports Energy-Efficient Ethernet (EEE), reducing power consumption during low traffic periods. This makes it suitable for organizations aiming to reduce energy costs and carbon footprint.
