N9K-C9316D-GX Cisco Switch L3 16 Prot 10 Gigabite Rack-mountable

High-Density Cisco Nexus 9316D-GX Switching Platform

The Cisco N9K-C9316D-GX is a data center–class Layer 3 switch designed for environments that demand ultra-high throughput, low latency, and scalable connectivity. Built for rack-mount deployment, this Nexus series model delivers advanced performance for modern spine, leaf, and aggregation architectures.

Manufacturer & Product Identity

• Brand: Cisco
• Model Series: Nexus 9000
• SKU / Part Number: N9K-C9316D-GX
• Device Category: Enterprise & Data Center Switch
• Form Factor: Rack-mountable chassis

Port Configuration & Connectivity Options

Ultra-Fast Ethernet Interfaces

• 16 high-speed QSFP-DD ports supporting 400 Gigabit Ethernet
• Optimized for next-generation data center fabrics
• Ideal for spine-leaf, AI/ML workloads, and high-performance computing

Supported Port Breakout & Speed Flexibility

• Native support for 40G, 100G, and 400G Ethernet
• Breakout configurations across ports 1–16
• Multiple fan-out options including:
  • 2x200G, 4x100G, and 2x100G
  • 8x50G, 4x50G, and 2x50G
  • 4x25G and 4x10G with QSA support

Management, Storage & System Access

Out-of-Band Management Interfaces

• 1x RJ45 management port for dedicated control access
• 1x SFP management interface for flexible monitoring
• USB port for local configuration and maintenance
• RS232 console port for serial connectivity

Integrated Storage & System Resources

• Embedded 128 GB solid-state drive for system files and logs
• 32 GB DRAM for high-speed packet processing
• Multi-core CPU architecture with 4 processing cores

Cooling Architecture & Airflow Design

Efficient Thermal Management

• Default front-to-back airflow for hot-aisle/cold-aisle layouts
• Includes six NXA-FAN-35CFM-PI fan modules
• Optimized cooling for continuous high-load operations

Fan Module Alternatives

• NXA-FAN-35CFM-PI for front-to-back airflow
• NXA-FAN-35CFM-PE for back-to-front airflow scenarios

Power Supply Configuration & Redundancy

Pre-Installed Power Modules

• Two redundant 1100W power supplies included
• Model: NXA-PAC-1100W-PI2
• Designed for high availability and fault tolerance

Available Power Supply Options

• Port-side intake power supplies:
  • NXA-PAC-1100W-PI2 (AC)
  • NXA-PDC-1100W-PI2 (DC)
  • NXA-PHV-1100W-PI (HV AC/DC)
• Port-side exhaust power supplies:
  • NXA-PAC-1100W-PE2 (AC)
  • NXA-PDC-1100W-PE2 (DC)
  • NXA-PHV-1100W-PE (HV AC/DC)

Switching Performance & Throughput

High-Capacity Data Handling

• Total switching bandwidth of up to 12.8 Tbps
• Forwarding rate reaching 4.3 billion packets per second
• Engineered for low-latency, non-blocking performance

Scalability & Network Intelligence

• MAC address table capacity of 256,000 entries
• Supports up to 896,000 IPv4 host routes with longest prefix match
• IPv4 LPM routing scale up to 896,000 routes
• Multicast route support for up to 32,000 entries
