Cisco N9K-C93180YCFX3 Nexus 93180YC-FX3 Switch L3 Managed 48 X 1/10/25 Gigabit SFP+

Key Features

• 48 x 1/10/25 Gigabit SFP+ ports
• 6 x 40/100 Gigabit QSFP28 ports
• Internal power supply with hot-plug capability
• Compliant with multiple standards like IEEE 802.1ae and ITU-T G.8275.1

Performance and Capacity

Bandwidth and Processing Power

Delivers a remarkable bandwidth of 3.6 Tbps to handle demanding networking tasks efficiently.

Routing and Capacity

• Buffer Capacity: 40 MB
• IP Host Entries: 1.79 million
• Multicast Routes: 128,000
• Maximum VRF Instances: 16,000
• Max Port Channels: 512
• ECMP Paths: 64
• Number of VLANs Supported: 4,096
• Maximum IGMP Snooping Groups: 32,000

Routing Protocols

Supported Protocols

• OSPF, RIP-2, BGP, EIGRP, HSRP
• PIM-SM, PIM-SSM, MSDP, ECMP, MPLS
• RSVP and more

Remote Management

Access Methods

Manage remotely with protocols such as HTTP, HTTPS, CLI, NETCONF, RESTCONF, and JSON for flexible, secure management across different network infrastructures.

Special Features

Advanced Capabilities

• Flow Control, NAT, DCBX, and RDMA support
• Enhanced capabilities with VXLAN, EVPN, and MACsec
• Advanced traffic management using PFC, ECN, and SyncE
• Support for high availability with vPC technology and SPAN

Security and Compliance

This device ensures security and high operational standards through compliance with multiple certifications such as RoHS, UL 60950-1, and FCC CFR47 Part 15 A.

Hardware Specifications

Memory and Storage

• RAM: 32 GB
• Built-in 128 GB SSD for storage

Interfaces and Expansion

• 48 x 1/10/25G SFP+ and 6 x 40/100G QSFP28 ports
• Additional management and serial interfaces available

Power Requirements

Power Consumption

• Operational Power Consumption: 375W
• Hot-plug internal power supply with optional N+1 redundancy

Environmental Conditions

Temperature and Humidity

• Operating Temperature: 32 °F to 104 °F
• Storage Temperature: -40 °F to 158 °F
• Humidity Range: 5% to 95% (non-condensing)

Dimensions and Weight

Size and Weight

• Width: 17.3 inches
• Depth: 19.5 inches
• Height: 1.7 inches
• Weight: 20.99 lbs

Cisco N9K-C93180YCFX3 Nexus 93180YC-FX3 Switch: High-Performance Networking for Enterprises

The Cisco N9K-C93180YCFX3 Nexus 93180YC-FX3 Switch is a high-performance, Layer 3 managed network switch designed to meet the demands of modern data centers and enterprise networking environments. This switch provides 48 ports of 1/10/25 Gigabit SFP+ and 6 ports of 40/100 Gigabit QSFP28, ensuring ultra-fast connectivity, reliability, and scalability. Built for flexibility, security, and efficiency, the remanufactured Nexus 93180YC-FX3 switch offers a cost-effective solution for organizations seeking robust networking infrastructure.

Key Features and Benefits of Cisco Nexus 93180YC-FX3

High-Density and Scalable Architecture

The Cisco N9K-C93180YCFX3 is engineered for high-density networking environments, offering:

• 48 SFP+ ports: Supporting 1/10/25GbE speeds, ensuring flexibility in connectivity.
• 6 QSFP28 ports: Supporting 40/100GbE for high-bandwidth uplinks.
• Rack-mountable design: Efficient use of data center space.

Layer 3 Managed Switch Capabilities

This switch provides Layer 3 routing functionalities, including advanced IPv4 and IPv6 routing, making it suitable for large-scale enterprise and cloud environments. Features include:

• OSPF, EIGRP, BGP, and ISIS routing protocols.
• VXLAN support for network segmentation.
• Comprehensive security policies and access control lists.

Energy Efficiency and Sustainability

The remanufactured Cisco N9K-C93180YCFX3 switch is an eco-friendly alternative that reduces e-waste and promotes sustainability. Key benefits include:

• Lower power consumption compared to legacy switches.
• Extended product lifecycle through refurbishment.
• Reduced carbon footprint while maintaining Cisco reliability.

Applications of Cisco Nexus 93180YC-FX3 in Different Environments

Enterprise Data Centers

Organizations require scalable networking solutions to support virtualization, cloud computing, and large-scale applications. The Cisco Nexus 93180YC-FX3 delivers:

• High-speed connectivity for virtual machines and storage.
• Support for cloud-based applications with minimal latency.
• Enhanced security features for enterprise-grade networking.

Cloud Service Providers

Cloud environments demand high-speed, resilient, and secure networking solutions. This switch offers:

• Enhanced scalability to accommodate cloud expansion.
• Quality of Service (QoS) policies for prioritizing critical applications.
• Seamless integration with software-defined networking (SDN) solutions.

High-Performance Computing (HPC)

High-performance computing environments, including research institutions and AI-driven applications, require robust networking infrastructure. The Cisco N9K-C93180YCFX3 provides:

• Low-latency networking for real-time processing.
• High-throughput performance to handle complex computations.
• Advanced security mechanisms to safeguard sensitive data.

Comparing Cisco Nexus 93180YC-FX3 with Other Nexus Switches

Cisco Nexus 93180YC-FX3 vs. Cisco Nexus 92300YC

While both switches provide high-speed connectivity, the Nexus 93180YC-FX3 offers:

• More advanced security features.
• Higher scalability with additional uplink ports.
• Better energy efficiency and sustainability benefits.

Cisco Nexus 93180YC-FX3 vs. Cisco Nexus 9336C-FX2

The Nexus 9336C-FX2 is optimized for ultra-high-speed environments, but the Nexus 93180YC-FX3 provides a more balanced approach with:

• Lower power consumption.
• Greater versatility in enterprise and cloud deployments.
• Cost-effective pricing for mid-to-large enterprises.

Why Choose a Remanufactured Cisco N9K-C93180YCFX3?

Cost Savings and Performance

Purchasing a remanufactured Cisco Nexus 93180YC-FX3 switch allows businesses to save significantly on costs while maintaining high-performance standards.

Reliability and Warranty

All remanufactured Cisco switches undergo rigorous testing and come with warranties, ensuring reliability and peace of mind.

Environmental Impact

Choosing remanufactured networking equipment helps reduce environmental impact while providing enterprise-grade performance.
