Cisco N9K-C93360YC-FX2 96 Ports L3 Managed Qsfp28 Rack-mountable Switch

Product Overview

The Cisco N9K-C93360YC-FX2 is a cutting-edge switch engineered for high-density environments. With its 96 ports, this Layer 3 managed switch supports extensive network demands with advanced routing and switching capabilities. Designed for rack-mount installations, it offers superior performance and scalability for data center and enterprise applications.

Technical Specifications

General Specifications

• Device Type: Managed Switch - 96 Ports - Layer 3
• Form Factor: Rack-mountable, 2U
• Dimensions (WxDxH): 17.4 inches x 22.9 inches x 3.4 inches
• Weight: 54.45 pounds

Memory and Storage

• RAM: 16 GB
• Built-in Storage: 128 GB SSD

Port Configuration

• 1/10/25G SFP+ Ports: 96 ports
• 40/100G QSFP28 Ports: 12 ports
• Additional Interfaces:
  • 1 x Management RJ-45
  • 1 x Management SFP+
  • 1 x USB Port
  • 1 x Serial (RS-232)

Routing Protocols Supported

• OSPF (Open Shortest Path First)
• RIP (Routing Information Protocol) and RIP-2
• BGP (Border Gateway Protocol)
• EIGRP (Enhanced Interior Gateway Routing Protocol)
• HSRP (Hot Standby Router Protocol)
• PIM-SM (Protocol Independent Multicast - Sparse Mode)
• Multiprotocol BGP
• MSDP (Multicast Source Discovery Protocol)
• ECMP (Equal-Cost Multi-Path)
• MPLS (Multiprotocol Label Switching)
• RSVP (Resource Reservation Protocol)

Key Features

Layer 3 Switching and Routing

This switch excels in Layer 3 switching, offering robust routing features to manage complex network traffic effectively. With support for multiple routing protocols and technologies, it ensures high performance and reliability in data center environments.

Advanced Technologies and Support

• MPLS (Multiprotocol Label Switching): Facilitates efficient data forwarding across network segments.
• STP (Spanning Tree Protocol) and MSTP (Multiple Spanning Tree Protocol): Prevents network loops and ensures loop-free topology.
• ACL (Access Control List) Support: Provides granular control over network access and security.
• MACsec Support: Offers network encryption for enhanced security.
• VPC (Virtual Port Channel) Technology: Enhances network redundancy and load balancing.
• VXLAN (Virtual Extensible LAN): Supports scalable virtualized networks.
• POAP (Power On Auto Provisioning): Simplifies initial setup and deployment.
• PSE (Power Supply Efficiency): Ensures efficient power usage and reliability.

Buffer and Cooling

• System Buffer: 40 MB
• Cooling System: Equipped with 3 fans for optimal thermal management.

Standards Compliance

The Cisco N9K-C93360YC-FX2 adheres to IEEE 802.1AE, ensuring compliance with industry standards for network security and performance. This standardization guarantees compatibility with other compliant devices and systems.

Deployment and Usage Scenarios

Data Center Deployments

Designed for data center applications, the N9K-C93360YC-FX2 supports high-density and high-bandwidth requirements. Its versatile port configuration and advanced features make it suitable for large-scale data center networks, providing the necessary performance and scalability.

Enterprise Network Infrastructure

This switch is well-suited for enterprise environments, offering robust Layer 3 capabilities and high-speed connectivity. It supports various network architectures and configurations, making it a reliable choice for expanding enterprise networks and ensuring efficient data management.

High-Bandwidth and Virtualized Environments

With its high-speed QSFP28 and SFP+ interfaces, the Cisco N9K-C93360YC-FX2 can handle high-bandwidth applications and virtualized network environments. Its support for VXLAN and advanced routing protocols ensures smooth performance for demanding applications and services.

Overview of the Cisco N9K-C93360YC-FX2 Switch

The Cisco N9K-C93360YC-FX2 is a high-performance network switch designed for data center environments. It offers 96 ports of L3-managed switching with QSFP28 interfaces, making it a powerful tool for handling substantial network traffic with low latency and high throughput. This switch is rack-mountable, ensuring efficient use of space in data centers and server rooms. Its robust features and advanced capabilities make it ideal for enterprises seeking reliable and scalable network infrastructure solutions.

Key Features and Specifications

High-Density Port Configuration

The Cisco N9K-C93360YC-FX2 features 96 ports of QSFP28, providing high-density connectivity that supports 100G Ethernet. This density is crucial for meeting the demands of modern data centers where bandwidth requirements are continuously increasing. The switch supports a variety of interfaces and allows for flexible deployment scenarios, accommodating diverse networking needs.

Advanced Layer 3 Switching Capabilities

As a Layer 3 managed switch, the N9K-C93360YC-FX2 offers sophisticated routing functionalities. It supports advanced Layer 3 protocols and features, including OSPF, BGP, and multicast routing. This enables efficient data routing across large-scale networks and enhances overall network performance and reliability.

Rack-Mountable Design

The switch’s rack-mountable design allows it to be seamlessly integrated into standard 19-inch server racks. This design maximizes space utilization and simplifies the installation process in data centers and server rooms. The switch is built to be durable and reliable, ensuring stable operation even in demanding environments.

Performance and Scalability

With its high-speed QSFP28 interfaces, the Cisco N9K-C93360YC-FX2 delivers exceptional performance and scalability. It supports high-bandwidth applications and large-scale data transfer, making it suitable for enterprises with growing data and network traffic needs. The switch’s architecture is designed to scale easily, accommodating future network expansions without compromising performance.

Applications and Use Cases

Data Center Networks

The Cisco N9K-C93360YC-FX2 is ideal for data center environments where high performance and reliability are essential. Its high-density port configuration and advanced Layer 3 capabilities make it a perfect fit for handling large volumes of data and managing complex network topologies. It supports various data center architectures, including leaf-spine and end-of-row designs, providing flexibility in deployment.

Enterprise Networks

For enterprise networks, this switch offers the scalability and performance needed to support growing business operations. It can be used in core, distribution, or access layers of enterprise networks, providing high-speed connectivity and robust routing capabilities. Its advanced features help ensure efficient network traffic management and optimized application performance.

High-Bandwidth Applications

Applications requiring high bandwidth, such as video streaming, large-scale data analysis, and cloud services, benefit from the switch’s 100G QSFP28 ports. The switch can handle the increased data rates associated with these applications, delivering seamless performance and minimal latency. It supports a range of high-bandwidth use cases, including big data analytics and virtualized environments.

Software and Management

The Cisco N9K-C93360YC-FX2 supports Cisco NX-OS, a robust network operating system designed for high-performance and high-availability environments. The NX-OS provides comprehensive management features, including CLI, SNMP, and GUI-based interfaces for ease of use. It also supports automation and programmability features, enabling streamlined network operations and enhanced efficiency.

Performance Metrics

• Switching Capacity: Up to 7.2 Tbps
• Forwarding Rate: Up to 5.36 Bpps
• Latency: Low latency design for high-speed data transmission

Benefits of Using Cisco N9K-C93360YC-FX2

Enhanced Network Efficiency

By leveraging the advanced capabilities of the Cisco N9K-C93360YC-FX2, organizations can achieve improved network efficiency. The switch’s high-density ports and Layer 3 routing features enable optimized data traffic management, reducing congestion and enhancing overall network performance. This efficiency translates to better user experiences and more reliable network operations.

Future-Proof Investment

Investing in the Cisco N9K-C93360YC-FX2 is a future-proof decision, as it provides the scalability needed to accommodate growing network demands. The switch’s support for high-speed interfaces and advanced features ensures that it remains relevant and capable of meeting future networking needs. This longevity makes it a cost-effective choice for enterprises looking to invest in long-term network infrastructure solutions.

Reliable Performance

With its robust hardware design and advanced software features, the Cisco N9K-C93360YC-FX2 delivers reliable performance in demanding environments. Its redundant power supplies and cooling systems ensure continuous operation, while its high-performance capabilities support mission-critical applications and services. This reliability is essential for maintaining network uptime and ensuring business continuity.

Installation and Configuration

Installation Process

Installing the Cisco N9K-C93360YC-FX2 involves mounting the switch into a standard 19-inch rack and connecting it to the power supply and network cables. The switch’s rack-mountable design simplifies the installation process, while its front-to-back airflow design ensures efficient cooling. Proper installation is crucial for optimal performance and longevity of the switch.

Configuration Options

Configuring the Cisco N9K-C93360YC-FX2 can be done using Cisco NX-OS, which provides a range of management tools and options. Configuration can be performed via CLI for detailed customization or through a GUI for a more user-friendly experience. The switch supports automation and programmability features, allowing for streamlined and efficient network management.

Best Practices for Maintenance

To ensure the continued reliability and performance of the Cisco N9K-C93360YC-FX2, regular maintenance is recommended. This includes monitoring system performance, updating software to the latest versions, and performing hardware inspections. Regular maintenance helps prevent potential issues and ensures that the switch operates at peak efficiency.
