Overview of Dell 210-ABOG Networking N3048 Switch
Key Features
- Device Type: 48-Port Layer 3 Managed Stackable Switch
- Enclosure Type: Rack-Mountable, 1U Design
- Subtype: Gigabit Ethernet Connectivity
- Ports:
- 48 x 10/100/1000 Mbps
- 2 x 10 Gigabit SFP+
- 2 x Combo 1000Base-T
Performance Specifications
- Switching Fabric Bandwidth: 260 Gbps
- Forwarding Performance: 193 Mbps
- Stacking Bandwidth: 84 Gbps
Capacity Overview
- MAC Address Support: 32,000 Addresses
- IPv4 Static Routes: 1,024
- IPv6 Static Routes: 1,024
- Dynamic IPv4 Routes: 8,160
- Dynamic IPv6 Routes: 4,096
- Max Member Ports Per LAG: 8
- Maximum Dynamic Ports Per Stack: 144
- LAG Groups: 128
- OSPF Routes: 8,160
- RIP Routes: 512
- ECMP Next Hops Per Route: 4
- ECMP Groups: 64
- VLAN Routing Interfaces: 128
- Supported VLANs: 4,094
- IPv4 Multicast Entries: 1,536
- IPv6 Multicast Entries: 512
- ARP Entries: 6,144
- NDP Entries: 400
- ACL Support: 100 Entries
- Max Rules Per ACL: 1,023
- System-Wide ACL Rules: 4,096
- Max ACL Rules Per Interface:
- IPv4 Egress Rules: 1,024
- IPv4 Ingress Rules: 3,072
- IPv6 Egress Rules: 512
- IPv6 Ingress Rules: 1,021
- Max VLAN Interfaces with ACLs Applied: 24
MAC Address Table
- Size: 32,000 Entries
Routing Protocols Supported
- OSPF, RIP-1, RIP-2, IGMPv2
- IGMP, VRRP, OSPFv2, PIM-SM
- PIM-DM, IGMPv3, OSPFv3, MLDv2
Remote Management Protocols
- SNMP Versions 1, 2, and 3
- RMON Versions 1, 2, 3, and 9
- HTTP, SSH-2
Security Features
- Encryption Algorithms: MD5, AES, SSL, TLS
- Authentication Methods: RADIUS, TACACS+, Secure Shell V.2 (SSH2)
Additional Features
- Flow Control and Layer 3 Switching
- Layer 2 Switching and MDI/MDI-X Support
- Auto-Negotiation and Load Balancing
- Port Mirroring and Stackable Configuration
- Weighted Round Robin Queuing
- Broadcast Storm Control
- Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP)
- Access Control List (ACL) Support and Quality of Service (QoS)
- Port Forwarding and STP Root Guard
- LLDP and Link Aggregation Control Protocol (LACP)
- Per-VLAN Rapid Spanning Tree (PVRST) and Energy Efficient Ethernet
- Dynamic VLAN Support (GVRP) and Dual Firmware Images
- Network Access Control (NAC) and Tagged VLAN Support
- Generic VLAN Registration Protocol (GVRP) and Redundant Fans
- Protocol-Based VLAN Support
Compliance Standards
- IEEE 802.2, 802.3, 802.3u, 802.3z
- IEEE 802.1d, 802.1q, 802.3ab, 802.1p
- IEEE 802.3x, 802.3ad (LACP), 802.1w, 802.1x
- IEEE 802.3ae, 802.3ac, 802.1s, 802.1v
- IEEE 802.1ag, 802.1ab (LLDP), 802.3az
Memory Specifications
- RAM: 1 GB
- Flash Memory: 256 MB
Expansion and Connectivity Options
Interfaces
- 48 x Gigabit LAN - RJ-45
- 2 x 10-Gigabit LAN - SFP+
- 2 x Gigabit LAN - RJ-45
- 1 x Serial (RS-232) - RJ-45 (Management)
- 1 x USB - Type A
- 2 x Network Stack Device
Power Specifications
- Power Device: Internal Hot-Plug Power Supply
- Installed Quantity: 1 (installed) / 2 (maximum)
- Power Redundancy: Optional
- Redundancy Scheme: 1+1 (with Optional Power Supply)
- Power Provided: 200 Watts
- Operational Power Consumption: 74.8 Watts
Port Number
The Dell N3048 L3 Managed Network Switch is equipped with an impressive 48 port numbers, making it a reliable and versatile solution for businesses of all sizes. This feature sets it apart from other network switches on the market, as it allows for a significantly higher number of devices to be connected simultaneously.
Increased Connectivity
With 48 port numbers, the Dell N3048 offers an abundance of connectivity options. This is particularly beneficial for businesses that require a large number of devices to be connected to the network, such as offices with multiple workstations, conference rooms with numerous devices, or data centers with extensive server infrastructure. The increased port number ensures that all devices can be seamlessly connected without any limitations or bottlenecks.
Scalability
The 48 port numbers also provide excellent scalability options for growing businesses. As your organization expands and you add more devices to your network, the Dell N3048 can easily accommodate these new additions. This eliminates the need to invest in additional network infrastructure or upgrade your switch, saving both time and money.
Flexibility
Having 48 port numbers gives you the flexibility to connect a wide range of devices with different connectivity requirements. Whether you need to connect computers, printers, servers, IP phones, or other network-enabled devices, the Dell N3048 has more than enough ports available to meet your needs. This flexibility allows you to easily adapt your network setup to changing business requirements without any limitations.
Reduced Cable Clutter
By providing ample port numbers, the Dell N3048 helps reduce cable clutter in your office or data center. With fewer devices sharing each port, you can organize your cables more effectively, improving overall cable management and reducing the risk of accidental disconnections. Additionally, having more ports available means you can avoid using additional network switches or cascading multiple switches together, further simplifying your network setup.
Cost-Effective
The 48 port numbers of the Dell N3048 offer a cost-effective solution for businesses that require a high level of connectivity. Instead of investing in multiple smaller switches to accommodate your devices, the Dell N3048 provides all the ports you need in a single device. This not only saves on the cost of additional hardware but also reduces maintenance and management efforts.
Port Speed
The Dell N3048 L3 Managed Network Switch boasts an impressive port speed of 10G, which ensures lightning-fast data transfer rates and seamless network performance. This feature is crucial for businesses that rely on high-bandwidth applications or handle large volumes of data on a daily basis.
Enhanced Performance
The 10G port speed of the Dell N3048 greatly enhances network performance by providing ultra-fast data transfer rates. This is particularly beneficial for businesses that utilize bandwidth-intensive applications such as video conferencing, multimedia streaming, or large file transfers. With 10G speeds, these applications can run smoothly without any lag or buffering issues, ensuring a seamless user experience.
Improved Productivity
By offering 10G port speeds, the Dell N3048 enables employees to work more efficiently. Large file transfers that used to take minutes can now be completed in seconds, allowing for quicker collaboration and faster decision-making processes. This improved productivity translates into time and cost savings for businesses, ultimately boosting their bottom line.
Future-Proofing
Investing in a network switch with 10G port speeds is a wise decision for businesses looking to future-proof their infrastructure. As technology continues to advance and data requirements increase, having a high-speed network becomes essential. The Dell N3048's 10G port speeds ensure that your network can handle the demands of tomorrow, eliminating the need for costly upgrades or replacements in the near future.
Reduced Network Congestion
With 10G port speeds, the Dell N3048 significantly reduces network congestion. High-bandwidth applications and data-intensive tasks can put a strain on network resources, leading to slower performance for other devices sharing the same network. By providing faster data transfer rates, the Dell N3048 minimizes network congestion and ensures a smooth and uninterrupted user experience for all connected devices.
Compatible with Existing Infrastructure
The 10G port speeds of the Dell N3048 are backward compatible with lower-speed devices, allowing for seamless integration with your existing infrastructure. You can connect devices that require lower speeds, such as computers or printers, to the switch without any issues. This compatibility ensures that you can leverage the benefits of 10G speeds while still supporting legacy equipment.
Interface Type
The Dell N3048 L3 Managed Network Switch features SFP+ (Small Form-factor Pluggable Plus) interfaces, providing users with a reliable and versatile connectivity option. The SFP+ interface type offers numerous benefits and is widely used in various industries.
Flexible Connectivity Options
The SFP+ interface type of the Dell N3048 allows for flexible connectivity options. SFP+ modules are hot-swappable, meaning they can be inserted or removed from the switch without powering it off or disrupting network operations. This flexibility enables easy customization of your network setup and simplifies maintenance tasks. You can choose from a wide range of SFP+ modules based on your specific requirements, such as connecting to fiber optic cables or copper cables.
High-Speed Data Transfer
SFP+ interfaces support high-speed data transfer rates, making them ideal for businesses that handle large volumes of data or require high-bandwidth applications. With SFP+ interfaces, you can achieve speeds of up to 10Gbps, ensuring fast and reliable data transmission across your network. This high-speed capability is crucial for industries like multimedia production, data centers, or research institutions that rely on rapid data transfer for their operations.
Longer Cable Reach
SFP+ interfaces support longer cable reach compared to other interface types. This makes them suitable for businesses that have devices located far apart or in different areas of a building. Whether you need to connect devices within an office complex or across multiple floors, the SFP+ interface of the Dell N3048 ensures that your network can reach even the most distant locations without sacrificing performance.
Network Flexibility
By featuring SFP+ interfaces, the Dell N3048 offers network flexibility. You can mix and match different types of SFP+ modules based on your connectivity needs. This flexibility allows you to connect devices using fiber optic cables for long-distance connections or copper cables for shorter distances. The ability to choose between different interface types gives you the freedom to design your network infrastructure according to your specific requirements and budget.
Cost-Effective Solution
The SFP+ interface type of the Dell N3048 provides a cost-effective solution for businesses that require high-speed and long-distance connectivity. Instead of investing in expensive proprietary interface types or deploying additional network infrastructure, you can leverage the flexibility and affordability of SFP+ modules. This cost-effective solution allows businesses to achieve superior network performance without breaking the bank.
In conclusion, the Dell N3048 L3 Managed Network Switch offers exceptional features that cater to the connectivity needs of modern businesses. With its 48 port numbers, businesses can enjoy increased connectivity, scalability, flexibility, reduced cable clutter, and cost-effectiveness. The 10G port speeds ensure enhanced performance, improved productivity, future-proofing, reduced network congestion, and compatibility with existing infrastructure. Finally, the SFP+ interface type provides flexible connectivity options, high-speed data transfer, longer cable reach, network flexibility, and a cost-effective solution. The Dell N3048 is a reliable and versatile network switch that can meet the demands of any business, making it a valuable investment for organizations of all sizes.
