Dell 48 Ports L3 Managed Ethernet Switch - 210-AUFN

Dell 210-AUFN S5248F-ON Networking Switch Overview

Key Manufacturer Information

• Manufacturer: Dell
• MPN: 210-AUFN
• Device Type: Networking Switch
• Port Configuration: 48 Ports

Advanced Technical Specifications

• Port Setup:
  • 48x 25 Gigabit SFP28
  • 4x 100 Gigabit QSFP28
  • 2x 200 Gigabit QSFP28-DD
• Switching Capacity: 2 Tbps
• MAC Address Capacity: 160,000
• ARP Entries: 128,000
• IPv4 Route Entries: 128,000
• IPv6 Route Entries: 64,000
• Multicast Hosts Supported: 32,000
• Link Aggregation Groups: Up to 16
• Layer 2 VLANs: Maximum of 4,000
• MSTP Instances: Up to 64

Comprehensive Routing Protocols

• OSPF (Open Shortest Path First)
• BGP-4 (Border Gateway Protocol)
• OSPFv2 and OSPFv3
• Policy-Based Routing (PBR)

Management and Remote Protocols

• SNMP (v1, v2)
• TFTP (Trivial File Transfer Protocol)
• SSH-2 (Secure Shell)
• CLI (Command Line Interface)
• SCP (Secure Copy Protocol)

Encryption and Security Protocols

• Encryption Algorithm: MD5
• Authentication Methods: RADIUS, TACACS

Advanced Features and Performance

• Flow Control and ARP Support
• Port Mirroring for enhanced diagnostics
• Spanning Tree Protocol (STP) and Rapid Spanning Tree Protocol (RSTP)
• Support for Multiple Spanning Tree Protocol (MSTP)
• Virtual Route Redundancy Protocol (VRRP)
• Access Control List (ACL) for security and traffic control
• Quality of Service (QoS) for prioritizing traffic
• Front-to-Back Airflow Management
• Link Aggregation Control Protocol (LACP)
• LLDP (Link Layer Discovery Protocol)
• Network Access Control (NAC)
• Priority-based Flow Control (PFC)
• Support for ICMP (Internet Control Message Protocol) and DNS Client
• VLAN Tagging for network segmentation

Compliance with Industry Standards

• IEEE 802.1d, 802.1q, 802.1p
• IEEE 802.3x, 802.3ad (LACP)
• IEEE 802.1w, 802.1x
• IEEE 802.3ac, 802.1s
• IEEE 802.1t, 802.1ab (LLDP)
• IEEE 802.1qbb, 802.1qaz

Memory and Storage

• RAM: 16 GB
• Storage: Built-in 32 GB SSD

Connectivity and Interface Expansion

• 48x 25Gbit LAN SFP28 ports
• 4x 100Gbit LAN QSFP28 ports
• 2x 200Gbit LAN QSFP28-DD ports
• 1x Serial (RS-232) RJ-45 Management port

Power Specifications

• Power Supply: Internal, hot-pluggable
• Installed Power Supply Units: 2 (Maximum supported: 2)
• Power Redundancy: Yes
• Voltage Requirement: AC 120/230 V (50/60 Hz)
• Power Consumption (Operational): 400 Watts

Physical Dimensions

• Wheelbase: 115 inches (2,921 mm)
• Length: 195.5 inches (4,966 mm)
• Width: 75 inches (1,905 mm)

Ports

The Dell 48 Ports L3 Managed Ethernet Switch L3 Managed is equipped with an impressive 48 ports, making it a versatile and powerful networking solution for businesses of all sizes. Whether you are a small startup or a large enterprise, having 48 ports at your disposal allows you to connect multiple devices and expand your network infrastructure with ease.

High Scalability

With 48 ports, this Ethernet switch provides high scalability, allowing you to connect a wide range of devices such as computers, servers, printers, IP phones, and more. This level of scalability is crucial for businesses that are constantly growing and need to add new devices to their network. The Dell 48 Ports L3 Managed Ethernet Switch L3 Managed ensures that your network can accommodate your expanding needs without any limitations.

Improved Network Performance

Having 48 ports available on this managed switch means that you can distribute the network traffic more efficiently. By connecting devices directly to the switch instead of relying on daisy-chaining or using additional switches, you can eliminate bottlenecks and improve overall network performance. With each device having its dedicated port, data transfer speeds are optimized, resulting in faster and more reliable connections.

Enhanced Flexibility

The Dell 48 Ports L3 Managed Ethernet Switch L3 Managed offers enhanced flexibility thanks to its abundant port availability. You can easily add or remove devices from the network without disrupting the entire infrastructure. This flexibility allows for easy expansion and reconfiguration of your network as your business requirements change over time. Additionally, the switch supports advanced features such as VLANs (Virtual Local Area Networks) and link aggregation, further enhancing the flexibility and customization options for your network.

Efficient Network Management

With 48 ports, this managed switch provides an efficient network management solution. You can easily monitor and control the connectivity of each device connected to the switch. This level of control allows you to optimize network resources, manage bandwidth allocation, and prioritize critical traffic. Additionally, the switch supports various management protocols such as SNMP (Simple Network Management Protocol) and CLI (Command Line Interface), enabling seamless integration into your existing network management system.

Redundancy and Failover

The 48 ports on this Ethernet switch offer redundancy and failover capabilities. By connecting devices to multiple ports or implementing link aggregation, you can ensure that your network remains operational even if one or more ports or connections fail. This redundancy is crucial for businesses that rely heavily on their network infrastructure for mission-critical operations. The Dell 48 Ports L3 Managed Ethernet Switch L3 Managed provides peace of mind, knowing that your network will remain resilient and dependable.

Cost-Effective Solution

Investing in a managed switch with 48 ports is a cost-effective solution for businesses. Instead of purchasing multiple switches or investing in complex networking setups, having a single switch with ample port availability simplifies your infrastructure and reduces overall costs. With the Dell 48 Ports L3 Managed Ethernet Switch L3 Managed, you can achieve high-performance networking without breaking the bank.

Future-Proofing

Choosing a managed switch with 48 ports ensures that you are future-proofing your network infrastructure. As technology advances and the demand for connectivity grows, having ample port availability allows you to seamlessly integrate new devices without the need for additional hardware investments. By investing in the Dell 48 Ports L3 Managed Ethernet Switch L3 Managed, you are setting yourself up for long-term success and scalability.

SKU

The SKU (Stock Keeping Unit) is an essential feature when it comes to identifying and tracking a specific product. In the case of the Dell 48 Ports L3 Managed Ethernet Switch L3 Managed, the SKU is 210-AUFN. This unique identifier plays a significant role in various aspects of your networking setup.

Efficient Inventory Management

By using the SKU 210-AUFN, businesses can efficiently manage their inventory. This alphanumeric code uniquely identifies the Dell 48 Ports L3 Managed Ethernet Switch L3 Managed, allowing for easy tracking and organization of stock. With accurate inventory management, businesses can avoid overstocking or understocking products, ensuring they have the necessary equipment to meet their networking needs.

Quick and Easy Ordering

When ordering networking equipment, having a specific SKU like 210-AUFN simplifies the process. By providing the SKU to suppliers or resellers, you can quickly and accurately communicate your requirements, avoiding any confusion or potential mistakes. This streamlined ordering process saves time and ensures that you receive the correct Dell 48 Ports L3 Managed Ethernet Switch L3 Managed without any delays.

Compatibility and Support

The SKU 210-AUFN also plays a crucial role in compatibility and support. When seeking assistance or troubleshooting guidance, providing the SKU allows technicians to identify the exact model you are using. This information ensures that you receive accurate and tailored support for your specific Dell 48 Ports L3 Managed Ethernet Switch L3 Managed, minimizing downtime and maximizing productivity.

Warranty and Service

Having a unique SKU for the Dell 48 Ports L3 Managed Ethernet Switch L3 Managed makes it easier to register and manage warranty and service agreements. By providing the SKU during the registration process, you ensure that your product is correctly identified, and you can take full advantage of the warranty coverage and support services offered by Dell. This streamlined process simplifies any potential future service or repair needs.

Product Differentiation

The SKU 210-AUFN allows for easy differentiation of the Dell 48 Ports L3 Managed Ethernet Switch L3 Managed from other similar products in the market. This unique identifier ensures that you receive the exact model and specifications you desire, avoiding any confusion or potential substitutions. The SKU guarantees that you are purchasing a genuine Dell product that meets your specific networking requirements.

Traceability and Documentation

The SKU plays a vital role in traceability and documentation. By including the SKU 210-AUFN in your network infrastructure documentation, you can easily reference and track the specific equipment used in your setup. This documentation becomes invaluable when planning upgrades, expansions, or troubleshooting issues, as it provides a clear record of the Dell 48 Ports L3 Managed Ethernet Switch L3 Managed's presence within your network.
