Dell 210-AWZO 8 Ports Managed Ethernet Switches

DELL 210-AWZO EMC Powerswitch N3208PX-ON Specifications

Product Features

• Type of Device: Managed Switch with 8 Ports
• Form Factor: 1U Rack-Mountable with Front-to-Back Airflow
• Network Type: 5 Gigabit Ethernet

Port Configuration

• Port Breakdown:
  • 4 x 10/100/1000/2.5G/5G (PoE++ enabled)
  • 4 x 10/100/1000 (PoE++ enabled)
  • 2 x 10 Gigabit SFP+
• Power Over Ethernet: Yes, supports PoE++

Performance Metrics

• Switching Capacity: 88 Gbps
• Forwarding Rate: 122 Mpps

Routing Capacity

• Static IPv4 Routes: 1024
• Static IPv6 Routes: 1024
• Dynamic IPv4 Routes: 8160
• Dynamic IPv6 Routes: 4096
• Maximum Member Ports Per LAG: 8
• Dynamic Ports in a Switch Stack: 144
• OSPF Routes: 8158
• RIP Routes: 512
• Maximum MAC Address Table Size: 32k Entries

Supported Routing Protocols

• Compatible with OSPF, RIP, IGMPv2, and IPv4-to-IPv6 Multicast

Remote Management Protocols

• Management Options: SNMP (1, 2, and 3), RMON (1, 2, 3, 9), Telnet, HTTP, TFTP, SSH-2

Security and Authentication Features

• Encryption Standards: MD5, AES, SSL, TLS
• Authentication Mechanisms: RADIUS, TACACS+, Secure Shell Version 2 (SSH2)

Advanced Networking Capabilities

• Includes features such as Flow Control, MDI/MDI-X Switching, Auto-negotiation, and ARP Support
• VLAN capabilities, Port Mirroring, and Quality of Service (QoS)
• Support for Energy Efficient Ethernet and Dynamic VLANs (GVRP)
• Compliance with Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP)

Standards Compliance

• Follows various IEEE standards, including 802.2, 802.3, 802.1Q
• Efficiency Certification: 80 Plus Platinum Certification

Hardware Specifications

• RAM: 4 GB
• Flash Memory: 8 GB

Power Management Capabilities

• Power Supply Type: Internal Hot-Plug Power Supply
• Installed Units: 1 (expandable to 2)
• Power Redundancy: Optional, with a 1+1 redundancy configuration
• Power Output: 320 Watts
• Operational Power Usage: 827 Watts

Ports

The Dell 210-AWZO Managed Ethernet Switches are equipped with 8 ports, making them a versatile and reliable choice for businesses of all sizes. These ports serve as the crucial connection points that enable communication between various devices on a network. Whether you need to connect computers, printers, servers, or other network devices, having 8 ports at your disposal ensures that you have enough room to accommodate all your networking needs.

Increased Connectivity

With 8 ports, the Dell 210-AWZO Managed Ethernet Switches allow for increased connectivity within your network infrastructure. Each port can be used to establish a direct connection between devices, eliminating the need for additional networking equipment. This not only simplifies your network setup but also reduces the overall cost and complexity associated with expanding your network.

Flexibility in Network Design

The availability of 8 ports provides flexibility when designing your network. You can easily connect multiple devices in different locations, ensuring efficient data transfer across various departments or floors within your organization. Whether you have a small office or a large enterprise, the Dell 210-AWZO Managed Ethernet Switches offer the scalability required to accommodate your growing network demands.

Improved Network Performance

Having 8 ports on the Dell 210-AWZO Managed Ethernet Switches contributes to improved network performance. By distributing the network traffic across multiple ports, these switches prevent bottlenecks and congestion that can occur when devices compete for bandwidth on a single connection. This results in faster and more efficient data transmission, enabling smoother communication and enhanced productivity for your business.

Enhanced Security

The Dell 210-AWZO Managed Ethernet Switches also provide enhanced security features that are crucial in today's digital landscape. With 8 ports, you have the ability to create separate virtual LANs (VLANs) for different departments or user groups. This segmentation helps to isolate sensitive data and restrict access, reducing the risk of unauthorized access or data breaches. By implementing VLANs, you can enhance the overall security posture of your network infrastructure.

Granular Control and Management

The 8 ports on the Dell 210-AWZO Managed Ethernet Switches offer granular control and management options. With features such as Quality of Service (QoS) and port mirroring, you can prioritize network traffic, allocate bandwidth to critical applications, and monitor network activity for troubleshooting purposes. This level of control allows you to optimize your network performance according to your specific requirements, ensuring a seamless user experience.

Improved Reliability

Redundancy is a critical aspect of network design, and the Dell 210-AWZO Managed Ethernet Switches deliver in this regard. With 8 ports, you have the ability to create link aggregation groups (LAGs) or implement redundant connections to ensure high availability and fault tolerance. In the event of a port failure, the remaining ports can seamlessly handle the network traffic, minimizing downtime and ensuring uninterrupted connectivity.

Scalability for Future Growth

The availability of 8 ports on the Dell 210-AWZO Managed Ethernet Switches provides scalability for future growth. As your business expands and your network requirements evolve, having additional ports allows you to easily integrate new devices or expand your network infrastructure without the need to replace your existing switches. This scalability not only saves costs but also ensures that your network can accommodate future demands without compromising performance or security.

In conclusion, the Dell 210-AWZO Managed Ethernet Switches' 8 ports offer numerous benefits and are of utmost importance for users. The increased connectivity, flexibility in network design, improved network performance, enhanced security, granular control and management options, improved reliability, and scalability for future growth make these switches a reliable choice for any organization. With 8 ports at your disposal, you can seamlessly connect and manage your network devices, ensuring efficient and secure communication across your entire network infrastructure.
