345-BCMR Dell 400GB SAS 12Gbps SSD Hot-Plug 3D TLC BICS Flash

Main Specifications of Dell 345-BCMR 400GB SAS SSD

• Manufacturer: Dell
• Part Number / SKU: 345-BCMR
• Product Category: Solid State Drive (SSD)
• Drive Variant: 400GB SAS-12Gbps, Write-Intensive

Technical Details

Drive Structure

• Storage Type: Internal Solid State Drive
• Capacity: 400GB
• NAND Technology: BiCS Flash™ 3D TLC
• Form Factor: 2.5-inch with 15mm thickness

Interface and Speed

• Connection Interface: SAS-3
• Bandwidth: 12.0 Gb/s
• Endurance Rating: Write-intensive workload design

Performance Characteristics

Sequential Operations

• Read Speed: Up to 4,150 MB/s
• Write Speed: Up to 1,450 MB/s

Random Operations

• Random Read IOPS: 595,000
• Random Write IOPS: 300,000

Reliability Metrics

Durability & Lifespan

• MTTF: 2,500,000 hours
• DWPD (Drive Writes Per Day): 10 DWPD

Compatibility with Dell PowerEdge Servers

Rack Servers

• PowerEdge R440, R450, R550
• PowerEdge R640, R650, R650xs
• PowerEdge R6515, R6525
• PowerEdge R740, R740xd, R7425
• PowerEdge R750, R750xa, R750xs, R7515, R7525
• PowerEdge R840, R940, R940xa

High-Density & Modular Servers

• PowerEdge C6420, C6520, C6525

Tower Servers

• PowerEdge T550

Overview of the Dell 345-BCMR 400GB SAS-12Gbps SSD

The Dell 345-BCMR is a high-performance 2.5-inch solid-state drive (SSD) designed to meet the demanding requirements of enterprise environments. With a capacity of 400GB, this drive utilizes SAS-12Gbps interface technology, ensuring rapid data transfer speeds and enhanced reliability. It is optimized for write-intensive applications, offering a remarkable 10 drive writes per day (DWPD) endurance, making it suitable for data centers and high-transaction workloads.

Key Features

• Interface: SAS-12Gbps for high-speed data transfer.
• Capacity: 400GB, ideal for applications requiring fast read/write operations.
• Endurance: 10 DWPD, ensuring longevity under heavy write workloads.
• Flash Type: 3D TLC NAND, balancing performance and cost-effectiveness.
• Form Factor: 2.5-inch, compatible with a wide range of servers.
• Hot-plug Capability: Allows for easy replacement without shutting down the system.
• Compatibility: Certified for use with Dell PowerEdge 14G and 15G servers.

Performance and Endurance

Data Transfer Speeds

The SAS-12Gbps interface provides a significant bandwidth increase over previous generations, facilitating faster data access and improved overall system performance. This is particularly beneficial in environments where quick data retrieval is critical.

Write Endurance

With an endurance rating of 10 DWPD, the Dell 345-BCMR SSD is engineered to handle intensive write operations, making it suitable for applications such as databases, virtualization, and analytics that involve frequent data modifications.

Reliability and Data Integrity

Utilizing 3D TLC NAND flash technology, this SSD offers a balance between performance and endurance. The advanced architecture enhances data integrity and reduces the risk of data loss, ensuring consistent performance over time.

Compatibility and Integration

Server Compatibility

The Dell 345-BCMR SSD is specifically certified for use with Dell PowerEdge 14G and 15G servers. Its 2.5-inch form factor and hot-plug capability ensure seamless integration into existing server infrastructures without the need for system downtime.

Ease of Installation

Designed with the end-user in mind, the Dell 345-BCMR SSD comes with a tray, simplifying the installation process. The hot-plug feature allows for easy replacement or addition of drives without interrupting server operations, minimizing maintenance windows.

Applications and Use Cases

Enterprise Data Centers

In enterprise data centers, the Dell 345-BCMR SSD can be utilized to accelerate data access speeds, improving the performance of applications and services hosted on PowerEdge servers. Its high endurance ensures reliable operation under heavy workloads.

Virtualization Environments

Virtualization platforms benefit from the high IOPS (Input/Output Operations Per Second) capabilities of the Dell 345-BCMR SSD, enabling efficient handling of multiple virtual machines and reducing latency in virtualized applications.

Database Management Systems

For database management systems that require rapid read and write operations, the 10 DWPD endurance of the Dell 345-BCMR SSD ensures consistent performance, even under high transaction volumes.

High-Performance Computing (HPC)

In HPC environments, where large datasets are processed, the Dell 345-BCMR SSD provides the necessary speed and reliability to handle intensive computational tasks, contributing to overall system efficiency.

Advantages of Choosing Dell 345-BCMR SSD

Optimized for Dell Servers

Being certified for Dell PowerEdge servers, the 345-BCMR SSD is tailored to work seamlessly with Dell's hardware and firmware, ensuring optimal performance and compatibility.

Cost-Effective Solution

While offering enterprise-grade performance, the Dell 345-BCMR SSD provides a cost-effective solution for businesses looking to upgrade their storage infrastructure without significant capital expenditure.

Scalability

The 2.5-inch form factor and hot-plug capability allow for easy scalability, enabling businesses to expand their storage capacity as needed without major disruptions to operations.

Energy Efficiency

Designed with energy efficiency in mind, the Dell 345-BCMR SSD helps reduce power consumption, contributing to lower operational costs and a smaller environmental footprint.
