Dell 463-7701 48-Port Layer 3 Managed Ethernet Switch.

Dell 463-7701 N2048 Switch Overview

The Dell 463-7701 Networking N2048 Switch is a highly versatile and reliable solution for enterprises seeking advanced management and scalability. Designed to meet the rigorous demands of modern networks, this rack-mountable switch ensures seamless integration with existing infrastructures.

Key Specifications

• Device Type: Layer 2+ Managed, Stackable 48-Port Switch
• Enclosure: 1U Rack-mountable design
• Network Protocol: Gigabit Ethernet, 10GbE SFP+ support
• Port Configuration: 48 x 10/100/1000 Mbps and 2 x 10Gb SFP+
• Performance: 220 Gbps Switching Fabric, 164 Mpps forwarding rate

Performance and Capacity

• Switching Fabric: 220 Gbps
• Forwarding Rate: 164 Mpps
• Stacking Bandwidth: 84 Gbps
• VLAN Capacity: 4096 VLANs
• ARP and NDP Entries: ARP: 1024, NDP: 400
• Dynamic Routing: RIP v1/v2, Static IPv4/IPv6 Routing

Advanced Features

• Priority Queues: 8 per port
• ACL Capabilities: Up to 2048 rules system-wide
• IP Routing: Static IPv4: 256, Static IPv6: 128, Dynamic IPv4: 256
• Link Aggregation: Support for up to 8 member ports per LAG
• Dynamic VLAN Support: GVRP with 24 VLAN interfaces supporting ACLs

Security and Management

• Remote Management Protocols: SNMP 1/2/3, RMON, Telnet, TFTP
• Encryption Algorithms: MD5, AES, SSL, TLS
• Authentication Methods: SSH, RADIUS, TACACS+
• Access Control: Supports Access Control Lists (ACLs) for enhanced network security

Layer 2 and Layer 3 Features

• VLAN Support: Extensive VLAN support including protocol-based VLANs
• Multicast Protocols: IGMP v2/v3
• Link Aggregation Control Protocol (LACP): 802.3ad compliance for link redundancy
• Spanning Tree Protocol (STP): Rapid STP, Per-VLAN Spanning Tree Plus (PVST+)

Hardware and Connectivity

• Interfaces: 48 x RJ-45 Gigabit Ethernet, 2 x SFP+ 10GbE, 1 x RS-232, 1 x USB Type A
• Stacking Capability: Supports up to 2 stack devices
• Redundant Power System: RPS connector for uninterrupted operations

Power Specifications

• Power Supply: Internal, 100W output
• Power Consumption: 53.9W during operational use
• Energy Efficiency: Supports Energy Efficient Ethernet standards

Compliance and Certifications

• Compliant Standards: IEEE 802.3, 802.1D, 802.1Q, 802.3ad (LACP), 802.3X, and more
• Management Information Base (MIB): Supports MIB for simplified network management

Sku: 463-7701

Introduction

The Dell 48-Port Layer 3 Managed Ethernet Switch is a powerful networking solution designed to meet the demands of modern businesses. One of its standout features is its number, which is 463-7701. In this section, we will explore the benefits and importance of the thiSKUku feature for users.

What is a Sku?

A Sku, short for Stock Keeping Unit, is a unique identifier assigned to each product to distinguish it from others in a company's inventory. The SKU number 463-7701 specifically refers to the Dell 48-Port Layer 3 Managed Ethernet Switch. This alphanumeric code allows users and retailers to easily identify and track this particular product.

Easy Identification

The SKU number serves as a convenient way for users to identify the Dell 48-Port Layer 3 Managed Ethernet Switch amidst a wide range of other networking devices. By simply remembering or noting down the thSKUku number 463-7701, users can quickly find and order this specific model without confusion or mistakes.

Efficient Inventory Management

For businesses that deal with multiple products, efficient inventory management is crucial. The SKU numbers 463-7701 play a significant role in streamlining inventory operations. With each product having a unique SKU, businesses can accurately track stock levels, monitor sales trends, and reorder products as needed. This helps prevent stockouts, minimize backorders, and ensure smooth business operations.

Accurate Order Fulfillment

When customers place an order for the Dell 48-Port Layer 3 Managed Ethernet Switch, thSKUku number 463-7701 becomes essential in accurately fulfilling their requirements. By including the SKU number in the order details, businesses can avoid any confusion or errors that may arise from similar-looking products. This results in improved customer satisfaction and reduces the chances of returns or exchanges due to incorrect shipments.

Warranty and Support

The SKU number 463-7701 is also essential for warranty and support purposes. By providing the SKU number when seeking assistance from Dell's customer support, users can ensure that they receive the appropriate guidance and service specific to their product. Moreover, the SKU number helps determine the warranty period and eligibility for any additional services or upgrades, allowing users to make the most of their investment

Introduction

Another important feature of the Dell 48-Port Layer 3 Managed Ethernet Switch is its impressive number of ports. With a total of 48 ports, this switch offers extensive connectivity options for businesses of all sizes. Let's delve into the benefits and importance of this feature for users.

Enhanced Connectivity

The 48 ports of the Dell Managed Ethernet Switch provide users with a wealth of connectivity options. Each port serves as a connection point for various devices, such as computers, servers, printers, and other networking equipment. With 48 ports at their disposal, users can connect numerous devices simultaneously, creating a robust and efficient network infrastructure.

Scalability

As businesses grow and expand, their networking requirements also increase. The Dell 48-Port Layer 3 Managed Ethernet Switch addresses this need for scalability by offering an ample number of ports. Users can easily add or replace devices without worrying about running out of connectivity options. This scalability ensures that the switch can accommodate future expansion plans without any hassle.

Flexibility

The 48 ports on this switch provide users with flexibility in designing their network layout. They can connect devices in various configurations, such as point-to-point, star, or even complex mesh topologies. This flexibility allows businesses to tailor their network infrastructure to suit their specific requirements, optimizing performance and efficiency.

Improved Data Transfer Speeds

With 48 ports, the Dell Managed Ethernet Switch ensures smooth and high-speed data transfer between connected devices. Each port supports high-bandwidth connections, enabling rapid data transmission and reducing latency. Whether it's transferring large files, streaming multimedia content, or running bandwidth-intensive applications, users can rely on the switch to maintain optimal network performance.

Network Segmentation

The ample number of ports also enables effective network segmentation. Businesses can separate different departments or user groups into different ports, creating isolated network segments. This segregation enhances security by limiting access to sensitive information and resources. Moreover, network segmentation helps optimize network traffic flow and improves overall network performance.

Management: Managed

Introduction

The Dell 48-Port Layer 3 Managed Ethernet Switch is categorized as a "Managed" switch, indicating that it offers extensive management capabilities. In this section, we will explore the benefits and importance of this management feature for users.

Advanced Configuration and Control

As a Managed switch, the Dell Ethernet Switch provides users with advanced configuration and control options. It offers a comprehensive web-based management interface that allows users to customize various network settings according to their specific requirements. This level of control ensures that businesses can optimize their network performance and security.

Quality of Service (QoS) Prioritization

One of the key benefits of a Managed switch is its ability to prioritize network traffic through Quality of Service (QoS) settings. With QoS prioritization, businesses can assign bandwidth priorities to different applications or services. This ensures that critical operations, such as voice or video conferencing, receive higher priority, guaranteeing a smooth and uninterrupted user experience.

Enhanced Security

Managed switches like the Dell 48-Port Layer 3 Managed Ethernet Switch offer advanced security features to protect the network and its connected devices. Users can implement VLANs (Virtual Local Area Networks) to segregate traffic, preventing unauthorized access to sensitive information. Additionally, features like Access Control Lists (ACLs) enable fine-grained control over network traffic, allowing businesses to define and enforce security policies.

Remote Monitoring and Troubleshooting

The management capabilities of the Dell Managed Ethernet Switch extend to remote monitoring and troubleshooting. Users can remotely access the switch's management interface to monitor network performance, identify potential issues, and make necessary adjustments. This remote accessibility saves time and effort by eliminating the need for physical access to the switch, especially in large-scale deployments.

Firmware Upgrades and Feature Enhancements

Another advantage of a Managed switch is the ability to perform firmware upgrades and benefit from feature enhancements. Dell regularly releases firmware updates that address security vulnerabilities, improve performance, and introduce new functionalities. With a Managed switch like the Dell 48-Port Layer 3 Managed Ethernet Switch, users can easily upgrade the firmware and take advantage of these enhancements, ensuring their network remains up-to-date and secure.

Layer: 3

Introduction

The Dell 48-Port Layer 3 Managed Ethernet Switch operates at Layer 3 of the OSI model, making it a powerful networking solution. In this section, we will explore the benefits and importance of this Layer 3 feature for users.

Enhanced Routing Capabilities

By operating at Layer 3 of the OSI model, the Dell Managed Ethernet Switch offers enhanced routing capabilities compared to switches operating at lower layers. Layer 3 switches can make routing decisions based on IP addresses, allowing for more intelligent and efficient data forwarding. This enables businesses to create complex network architectures and implement advanced routing protocols to optimize traffic flow.

Greater Network Scalability

The Layer 3 capabilities of the Dell 48-Port Managed Ethernet Switch contribute to greater network scalability. Layer 3 switches can handle larger networks with multiple subnets and facilitate communication between them. This scalability is particularly beneficial for growing businesses or those with geographically dispersed locations that require seamless connectivity across different networks.

Improved Network Performance

Layer 3 switches offer improved network performance by reducing unnecessary network traffic. With their ability to route traffic based on IP addresses, Layer 3 switches can direct data packets along the most efficient paths, avoiding unnecessary hops and reducing congestion. This results in faster data transmission reduced latency, and overall improved network performance.

Enhanced Security Features

Layer 3 switches provide enhanced security features compared to lower-layer switches. They can implement Access Control Lists (ACLs) at the IP level, enabling granular control over inbound and outbound traffic. This allows businesses to enforce strict security policies, ensuring that only authorized data flows through the network.

Inter-VLAN Routing

Inter-VLAN routing is a critical feature offered by Layer 3 switches like the Dell Managed Ethernet Switch. It enables communication between different VLANs, breaking down the boundaries between isolated network segments. This feature allows businesses to create logical connections between VLANs, facilitating seamless collaboration and resource sharing while maintaining security.

In conclusion, the Dell 48-Port Layer 3 Managed Ethernet Switch offers a range of powerful features that cater to the networking needs of modern businesses. The SKU number 463-7701 ensures easy identification, efficient inventory management, accurate order fulfillment, and streamlined warranty and support. With 48 ports, users benefit from enhanced connectivity, scalability, flexibility, improved data transfer speeds, and network segmentation. The Managed feature provides advanced configuration and control, QoS prioritization, enhanced security, remote monitoring and troubleshooting capabilities, and firmware upgrades. Operating at Layer 3 of the OSI model, the switch offers enhanced routing capabilities, greater network scalability, improved network performance, enhanced security features, and inter-VLAN routing. By understanding and leveraging these features, businesses can establish a robust and efficient network infrastructure to meet their growing demands.
