540-BDQB Dell Emulex 1-Port PCI-E 4.0 32G/64G Host Bus Adapter

Dell 540-BDQB Emulex Single-Port HBA

The Dell 540-BDQB Emulex Host Bus Adapter delivers advanced connectivity with PCI-Express 4.0 technology, offering high-speed Fibre Channel performance for enterprise environments. Designed with a full-height bracket, this single-port adapter ensures reliable data transfer and seamless integration into modern infrastructures.

Product Information

• Brand Name: Dell
• Part Number: 540-BDQB
• Product Type: Single-Port Fibre Channel HBA

Technical Attributes

• Compact PCIe card with low-profile design
• Dimensions: 167.64mm x 68.91mm (6.60” x 2.71”)
• Seventh-generation Fibre Channel technology
• Supports 64GFC and 32GFC speeds

Cable Compatibility

• OM4 MMF: 0.5m to 100m at 64GFC/32GFC
• OM5 MMF: 0.5m to 100m at 64GFC/32GFC
• OM3 MMF: 0.5m to 70m at 64GFC/32GFC
• Singlemode Fiber: Up to 10km at 32GFC/16GFC with approved longwave transceivers

Optical Data Rates

• 28.05 Gb/s (3200 MB/s)
• 14.025 Gb/s (1600 MB/s)
• 8.5 Gb/s (800 MB/s)
• Automatic detection of supported speeds

Hardware Compatibility

• Intel x64 architecture
• Intel x86 systems
• PowerPC platforms

Connectivity Features

• Single port configuration
• Short-wave laser optics with LC-type connectors
• PCIe Gen4 x8 host bus interface

Controller Details

• Integrated XE601 I/O controller

Environmental Conditions

• Operating humidity: 5% to 95% non-condensing
• Operating temperature: 0°C to 55°C
• Storage temperature: -20°C to 85°C (-4°F to 185°F)

Operating System Support

• Microsoft Windows
• Oracle Linux (including UEK)
• Oracle Solaris
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware vSphere
• Additional OEM and partner support available
