Dell 48 Port Managed L3 Network Switches E06W002 with SFP+ Ports.

Dell E06W002 Networking N3048p Switch - 48 Ports L3 Managed Switch

Device Specifications

• Switch Type: Managed, L3, Stackable
• Rack-mountable: 1U Enclosure
• Subtype: Gigabit Ethernet
• Power Over Ethernet (PoE+): Enabled
• Ports: 48 x 10/100/1000 + 2 x 10 Gigabit SFP+ + 2 x Combo 1000Base-T

Performance and Capacity

Switching Performance

• Switching Fabric Bandwidth: 260 Gbps
• Forwarding Throughput: 193 Mbps
• Stacking Bandwidth: 84 Gbps

Network Capacity

• MAC Addresses: 16,384
• VLAN Interfaces: 128 Supported
• IPv4 Routes (Static): 1,024 | Dynamic: 8,160
• IPv6 Routes (Static): 1,024 | Dynamic: 4,096
• OSPF Routes: 8,160 | RIP Routes: 512
• Multicast Entries: IPv4 - 512 | IPv6 - 256

Advanced Networking Features

• Layer 2 & Layer 3 Switching
• Auto-Negotiation & MDI/MDI-X Switch
• Weighted Round Robin (WRR) Queuing & Port Mirroring
• Spanning Tree Protocol (STP) Support (RSTP, MSTP, PVRST)
• Link Aggregation Control Protocol (LACP)
• Broadcast Storm Control & Load Balancing
• Energy-Efficient Ethernet

Security and QoS

• Access Control List (ACL) with 4,096 Rules
• Quality of Service (QoS) Enabled
• Port Forwarding, Root Guard, and LLDP Support
• Network Access Control (NAC)

Compliance Standards

• IEEE 802.2, 802.3, 802.3u, 802.1d, 802.1q, 802.1p
• IEEE 802.3ad (LACP), 802.1x, 802.3ae, 802.3ac
• Energy Efficiency: IEEE 802.3az
• LLDP Support: IEEE 802.1ab

Remote Management and Protocol Support

• Protocols: SNMP 2, SNMP, RMON, HTTP, SSH
• Routing: OSPF, RIP (v1 & v2), IGMP, PIM-SM, PIM-DM
• Support for IGMPv2, IGMPv3, OSPFv3, MLDv2, VRRP

Power and Cooling

Power Supply

• Single Power Supply Installed
• Redundant Fan Configuration

Environmental Efficiency

• Energy-Efficient Ethernet (EEE) Supported
• Dual Firmware Images for Reliability

Supported VLANs

• VLAN Routing Interfaces: 128
• Supported VLANs: 4,094
• Tagged VLAN, GVRP Protocol-Based VLAN Support

Ports

The Dell E06W002 Managed L3 Network Switches come equipped with an impressive 48 ports, making it a powerhouse for any networking environment. Whether you are setting up a small office network or a large enterprise network, this feature offers immense benefits and plays a crucial role in ensuring smooth and efficient data transmission.

Increased Connectivity

With 48 ports at your disposal, you can easily connect multiple devices to the network without the need for additional switches or hubs. This not only simplifies the network infrastructure but also allows for seamless communication between various devices. Whether it's computers, printers, servers, or other networking equipment, the Dell E06W002 has got you covered with its ample number of ports.

Scalability

The 48 ports on the Dell E06W002 provide scalability options for future expansion. As your business grows and demands increase, you can effortlessly add more devices to the network without worrying about running out of available ports. This scalability ensures that your network can adapt to changing needs without requiring significant infrastructure changes.

Improved Network Performance

Having 48 ports means that each device can have its dedicated connection to the network switch. This eliminates bottlenecks and congestion that can occur when multiple devices share a limited number of ports. Each device can communicate directly with the switch, resulting in faster data transfer speeds and reduced latency. Whether you're transferring large files or streaming high-definition videos, the increased performance offered by 48 ports ensures a smooth experience.

Enhanced Network Security

The Dell E06W002 Managed L3 Network Switches with 48 ports also provide enhanced network security. With more ports available, you can segregate devices into different VLANs (Virtual Local Area Networks), isolating traffic and preventing unauthorized access. This feature is particularly beneficial for organizations that deal with sensitive data or need to comply with strict security regulations.

Simplified Cable Management

Having 48 ports on a single switch means that you can significantly reduce the number of cables required for your network setup. This not only simplifies cable management but also improves the overall aesthetics of your network infrastructure. With fewer cables running around, troubleshooting becomes easier, and the risk of cable-related issues is minimized.

Port Speed

The Dell E06W002 Managed L3 Network Switches offer an impressive port speed of 10Gigabit, ensuring lightning-fast data transfer rates. This feature is particularly important in today's data-driven world where large amounts of information need to be transmitted quickly and efficiently.

High Bandwidth

The 10Gigabit port speed provides a significant increase in bandwidth compared to traditional Gigabit Ethernet connections. This means that you can transfer larger files, stream high-definition media, and handle bandwidth-intensive applications without experiencing any performance degradation. Whether you're working with multimedia content, running virtual machines, or handling big data processing, the high bandwidth offered by the Dell E06W002 ensures smooth and uninterrupted operations.

Reduced Latency

In addition to increased bandwidth, the 10Gigabit port speed also reduces latency, ensuring minimal delay in transmitting data packets. This is especially crucial for real-time applications such as video conferencing or online gaming where even the slightest delay can cause disruptions. With the Dell E06W002's port speed, you can enjoy lag-free communication and seamless user experiences.

Future-Proofing

The 10Gigabit port speed is geared towards future-proofing your network infrastructure. As technology advances and demands increase, having a high-speed network becomes essential. By investing in a switch with 10Gigabit ports, you ensure that your network can handle the requirements of tomorrow without the need for costly upgrades. This feature provides peace of mind and longevity to your network infrastructure.

Efficient Network Utilization

The 10Gigabit port speed allows for efficient network utilization by providing ample capacity for data transmission. With faster speeds, you can accommodate more devices and applications on your network without experiencing congestion or performance issues. This ensures that your network operates at its optimal level, maximizing productivity and minimizing downtime.

Interoperability

The 10Gigabit port speed also offers interoperability with existing network equipment. You can seamlessly integrate the Dell E06W002 into your current infrastructure without having to replace or upgrade other networking components. This compatibility allows for a smooth transition and minimizes disruption during the implementation process.

Interface Type

The Dell E06W002 Managed L3 Network Switches feature an interface type known as SFP+, which brings a range of benefits and importance to users in various networking scenarios.

Versatility and Flexibility

SFP+ (Small Form-Factor Pluggable Plus) is a hot-swappable interface type that allows for versatile connectivity options. It supports a wide range of transceivers, including fiber optic and copper cables, enabling you to choose the most suitable medium for your networking needs. Whether you require long-range connections or short-distance links, the SFP+ interface type provides the flexibility to adapt to different environments.

Higher Data Rates

The SFP+ interface type supports higher data rates compared to its predecessor, SFP. It can handle speeds of up to 10Gbps, allowing for faster and more efficient data transmission. This is particularly important in bandwidth-intensive applications where large amounts of data need to be transferred quickly. With the Dell E06W002's SFP+ interface type, you can enjoy high-speed connectivity and maximize network performance.

Cost-Effective Solution

The SFP+ interface type offers a cost-effective solution for network expansion or upgrades. Instead of investing in new switches or routers, you can simply upgrade the transceivers to take advantage of higher speeds and different connectivity options. This scalability and cost-effectiveness make the Dell E06W002 an ideal choice for businesses looking to optimize their network infrastructure without breaking the bank.

Interoperability

The SFP+ interface type ensures interoperability with a wide range of networking equipment. Whether you have existing switches, routers, or servers from different manufacturers, you can rest assured that the Dell E06W002 will seamlessly integrate with your current infrastructure. This compatibility eliminates potential compatibility issues and simplifies the deployment process.

Reliability

The SFP+ interface type offers enhanced reliability due to its hot-swappable nature. If a transceiver fails or needs to be replaced, it can be done without disrupting the entire network. This feature minimizes downtime and ensures continuous operation, making it ideal for businesses that require high availability and reliability in their network infrastructure.

In conclusion, the Dell E06W002 Managed L3 Network Switches provide an exceptional networking solution with their 48 ports, 10Gigabit port speed, and SFP+ interface type. These features offer increased connectivity, scalability, improved network performance, enhanced security, and simplified cable management. Additionally, the 10Gigabit port speed provides high bandwidth, reduced latency, future-proofing, efficient network utilization, and interoperability. Lastly, the SFP+ interface type brings versatility, flexibility, higher data rates, cost-effectiveness, interoperability, and reliability to users. With the Dell E06W002 Managed L3 Network Switches, users can build a robust and efficient network infrastructure that meets their current needs and adapts to future requirements.
