Product Specifications
Dell N1124T EMC Networking Managed Switch
Model Overview
The Dell N1124T-ON is a robust 24-port managed switch designed for efficient networking in various environments. Its rack-mountable form factor and advanced features make it a reliable choice for IT professionals.
Device Type
- Managed Switch
- Stackable Design
- 24 Ports
Form Factor
- 1U Rack-Mountable Enclosure
Technical Specifications
Port Configuration
- 24 x 10/100/1000 Mbps Ethernet Ports
- 4 x 10 Gigabit SFP+ Ports
Performance Metrics
- Switching Fabric Bandwidth: 128 Gbps
- Forwarding Rate: 96 Million Packets Per Second (Mpps)
Capacity and Limits
- MAC Address Table: Supports up to 16,000 entries
- Dynamic Aggregated Links: Up to 144
- Link Aggregation Groups: 64
- Queues Per Port: 8
- Supported VLANs: 512
- ARP Entries: 2048
- NDP Entries: 400
- System-Wide ACL Rules: 4000
- Per Interface ACL Rules (IPv4): Ingress - 1023, Egress - 1023
Routing and Management Protocols
Supported Protocols
- Routing Protocols: IGMPv2, IGMPv3, IGMP
- Remote Management: SNMP v2, SNMP, RMON, Telnet, HTTP, TFTP, SSH-2
Security Features
- Encryption: AES, SSL, TLS 1.0
- Authentication: RADIUS, TACACS+, LDAP
Advanced Features
Switching Capabilities
- Layer 2 Switching
- MDI/MDI-X Compatibility
- Auto-Negotiation
- Port Mirroring
- IP Address Filtering
- Access Control List (ACL) Support
- Quality of Service (QoS)
- Front-to-Back Airflow Design
- LLDP Support
- Remote Switch Port Analyzer (RSPAN)
- Management Information Base (MIB)
- Dual Firmware Images for Redundancy
- Redundant Fan Configuration
- MAC and IP-Based ACLs
- Time-Controlled ACLs
Compliance and Standards
This switch adheres to a variety of industry standards, ensuring reliability and compatibility:
- IEEE 802.2, 802.3, 802.3u, 802.3z
- IEEE 802.1d, 802.1q, 802.3ab, 802.1p
- IEEE 802.3x, 802.3ad (LACP), 802.1w, 802.1x
- IEEE 802.3ae, 802.3ac, 802.1s, 802.1v
- ANSI/TIA-1057, IEEE 802.1ab (LLDP)
- IEEE 802.3az, 802.3ax
Memory and Connectivity
Specifications
- RAM: 1 GB
- Flash Memory: 1 GB
Interface Options
- 24 x Gigabit LAN RJ-45 Ports
- 4 x 10 Gigabit LAN SFP+ Ports
- 1 x USB Type A Port
- 1 x Micro-USB Port
Power Supply
Equipped with an internal power supply, the switch provides:
- Power Capacity: 40 Watts
- Installed Quantity: 1
Ports
Highly Versatile and Efficient Networking Solution
The Dell EMC N1124T-ON Managed Network Switch is equipped with an impressive 24 ports, making it an ideal choice for businesses of all sizes. These ports provide the essential connectivity needed to establish a robust and efficient network infrastructure. With such a high number of ports, this switch offers remarkable flexibility and scalability, ensuring that your network can easily adapt to the changing needs of your organization.
Seamless Connectivity for Enhanced Collaboration
In today's fast-paced business environment, connectivity is key to fostering collaboration among employees. The 24 ports offered by the Dell EMC N1124T-ON Managed Network Switch enable seamless connectivity between various devices, such as computers, servers, printers, and IP phones. This facilitates smooth data transfer, file sharing, and real-time communication, enabling your team to work together more efficiently and effectively.
Increased Bandwidth for High-Speed Data Transfer
With 24 ports at your disposal, the Dell EMC N1124T-ON Managed Network Switch ensures an ample supply of bandwidth for high-speed data transfer. Each port supports Gigabit Ethernet connectivity, allowing for lightning-fast file transfers and data-intensive applications. Whether you're transferring large files or streaming high-definition media, this switch provides the necessary bandwidth to maintain optimal performance without any bottlenecks.
Enhanced Network Performance and Reliability
The Dell EMC N1124T-ON Managed Network Switch's 24 ports contribute significantly to improving overall network performance and reliability. Distributing the network load across multiple ports prevents congestion and minimizes the chances of network downtime. This means that even during peak usage periods, your network will continue to operate smoothly and efficiently, ensuring uninterrupted connectivity for all users.
Simplified Network Management
Managing a network with numerous devices can be a challenging task. However, with the Dell EMC N1124T-ON Managed Network Switch's 24 ports, network management becomes significantly easier. Each port can be individually configured and managed, allowing for granular control over network settings. This ensures that you can tailor the network to suit your specific requirements, optimizing performance and security.
Seamless Network Expansion
As your business grows, so does the need for additional network connectivity. The 24 ports of the Dell EMC N1124T-ON Managed Network Switch provide ample room for expansion without the need for additional hardware investments. This switch can accommodate the increasing demands of your organization, allowing you to seamlessly add new devices to your network infrastructure as needed.
Cost-Effective Solution
Investing in a network switch with a sufficient number of ports is a cost-effective decision. The Dell EMC N1124T-ON Managed Network Switch's 24 ports eliminate the need for purchasing multiple switches or additional networking equipment. By consolidating your network infrastructure into a single switch, you not only save on equipment costs but also reduce maintenance and management complexities.
Future-Proofing Your Network
With technology advancing at a rapid pace, it's crucial to future-proof your network infrastructure. The 24 ports of the Dell EMC N1124T-ON Managed Network Switch provide room for growth and technological advancements. As new devices and technologies emerge, this switch ensures that your network can accommodate them without requiring a complete overhaul. By investing in this switch, you can stay ahead of the curve and seamlessly integrate future innovations into your network.
In conclusion, the Dell EMC N1124T-ON Managed Network Switch's 24 ports offer numerous benefits for users. From enhanced collaboration and high-speed data transfer to improved network performance and simplified management, these ports provide the foundation for a robust and scalable network infrastructure. With seamless network expansion and cost-effectiveness, this switch is an excellent choice for businesses aiming to optimize their network connectivity. Additionally, by future-proofing your network with this switch, you can ensure that your infrastructure can adapt and grow alongside technological advancements.
