Dell GH9K5 S3124 L3 24Pt 1Gbe 2Pt 10Gbe Switch

GH9K5
Hover on image to enlarge

Brief Overview of GH9K5

Dell GH9K5 S3124 L3 24Pt 1Gbe 2Pt 10Gbe Switch. Excellent Refurbished with 6-Month Replacement Warranty

QR Code of Dell GH9K5 S3124 L3 24Pt 1Gbe 2Pt 10Gbe Switch
$521.10
$381.00
You save: $140.10 (27%)
Ask a question
Price in points: 381 points
+
Quote
SKU/MPNGH9K5Availability✅ In StockProcessing TimeUsually ships same day ManufacturerDell Manufacturer WarrantyNone Product/Item ConditionExcellent Refurbished ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30
Description

Dell GH9K5 S3124 Networking Switch

Key Specifications

  • Manufacturer : Dell
  • Part Number: GH9K5
  • Type: 24-Port Managed Network Switch (Layer 3, Stackable)
  • Form Factor: Rack-mountable (1U)
  • Port Configuration: 24 x 10/100/1000 Ethernet, 2 x 10 Gigabit SFP+, 2 x Combo Gigabit SFP
  • Switching Performance: Fabric Bandwidth: 212 Gbps, Forwarding Rate: 158 Million Packets Per Second (Mpps)
  • Capacity:
    • MAC Addresses: 32,000
    • IPv4 Routes: 1,024
    • IPv6 Routes: 1,024
    • Dynamic IPv4 Routes: 8,160
    • Dynamic IPv6 Routes: 4,096
    • Maximum Links Per Group: 16
    • Priority Queues per Port: 8
    • Layer 2 VLANs: 4,000
    • MSTP Instances: 64
    • VRF-lite Instances: 64
    • IPv4 Host Table Entries: 40,000
    • IPv6 Host Table Entries: 8,000
    • Multicast Table Entries (IPv4): 8,000

Networking Features

  • Supported Protocols: VRRP, OSPFv2, IGMPv3, MSDP
  • Remote Management: SNMP v1, v2, v3; RMON (1, 2, 3, 9)
  • Authentication: RADIUS
  • Additional Features:
    • MDI/MDI-X Auto-sensing
    • Port Mirroring
    • Front-to-back airflow design for efficient cooling

Compliant Standards

  • IEEE 802.3u, 802.3z, 802.1d, 802.1q, 802.3ab, 802.1p, 802.3x
  • IEEE 802.3ad (LACP), 802.1w, 802.1x, 802.3ae, 802.3ac, 802.1s
  • IEEE 802.1ab (LLDP)

Memory and Storage

  • RAM: 2GB

Expansion and Connectivity Options

  • Interfaces:
    • 24 x 1000BASE-T (RJ-45)
    • 2 x 10GBASE-T (SFP+)
    • 1 x Serial (RS-232) RJ-45 for Management
    • 1 x USB Type A
    • 2 x Gigabit Ethernet (SFP)

Power Management

  • Power Supply: Internal, Hot-swappable
  • Installed Power Units: 1 (expandable to 2)
  • Redundant Power Option: Available with 1+1 power supply setup
  • Power Output: 200 Watts

Dell GH9K5 S3124 L3 24-Port 1GbE and 2-Port 10GbE Switch

The Dell GH9K5 S3124 L3 Switch is a powerful and scalable networking solution designed for businesses and organizations of all sizes. Built to support high-performance networking requirements, this switch is equipped with 24 ports of 1 Gigabit Ethernet (1GbE) and 2 ports of 10 Gigabit Ethernet (10GbE), making it ideal for environments that demand high-speed data transmission. Whether you're looking to upgrade your current infrastructure or implement a new solution, the Dell GH9K5 S3124 offers reliability, flexibility, and advanced Layer 3 features for seamless network management.

Key Features of the Dell GH9K5 S3124 Switch

  • 24 x 1GbE Ports: The switch offers 24 1GbE ports, providing a cost-effective solution for networks requiring a large number of Gigabit connections. These ports are ideal for standard networking devices such as workstations, printers, and standard IP cameras.
  • 2 x 10GbE Ports: With 2 high-speed 10GbE uplink ports, the switch allows for high-bandwidth connectivity to other switches, servers, or storage devices, ensuring that your network can handle larger data traffic without lag.
  • Layer 3 Capabilities: As a Layer 3 switch, the Dell GH9K5 supports routing capabilities, allowing you to segment your network into multiple subnets and improve overall traffic management.
  • Enterprise-grade Performance: Designed for small to medium-sized enterprises, the switch supports advanced features like QoS (Quality of Service), VLAN (Virtual Local Area Network) support, and comprehensive network security tools.
  • Energy Efficiency: The Dell GH9K5 switch is designed with energy-efficient components to reduce power consumption, making it an environmentally friendly option for your network infrastructure.
  • Redundant Power Supply (RPS) Support: Ensures continued network operation by providing backup power if the primary power source fails.

Networking Solutions for Your Business

The Dell GH9K5 S3124 L3 switch is perfect for various types of businesses, from growing startups to larger enterprises. Its 24 x 1GbE ports enable seamless connectivity for multiple devices, while the 2 x 10GbE ports offer the throughput required for higher-end applications. Whether you're creating a local area network (LAN), connecting multiple remote offices, or ensuring consistent uptime for critical services, the Dell GH9K5 is a reliable, high-performance solution for your networking needs.

Enhancing Your Network Performance with 10GbE

As businesses increasingly rely on high-bandwidth applications, the need for faster connectivity has never been more important. The inclusion of 2 x 10GbE ports on the Dell GH9K5 S3124 switch allows organizations to connect to faster servers or storage networks, supporting large file transfers, data center applications, and virtualization needs. These 10GbE ports help future-proof your network and ensure it can accommodate growing traffic demands.

Layer 3 Routing and Advanced Network Management

The Dell GH9K5's Layer 3 capabilities are perfect for organizations looking to segment their networks efficiently. With this switch, you can configure routing between different subnets, enhancing network security and reducing network congestion. It also offers advanced management features such as static routing, dynamic routing protocols (OSPF, RIP), and more, making it an excellent choice for businesses needing flexible and scalable routing solutions.

Quality of Service (QoS) for Prioritized Traffic

With QoS features, the Dell GH9K5 ensures that critical network traffic, such as VoIP calls or video conferencing, is given priority over less time-sensitive traffic. This prioritization helps to prevent network congestion and ensures that important applications continue to function optimally even during periods of heavy network usage.

Virtualization Support for a Dynamic IT Environment

The Dell GH9K5 S3124 is designed to work in virtualized environments, supporting technologies like VMware and Hyper-V. With its advanced VLAN tagging, the switch can isolate traffic for virtual machines, improving network security and performance. This makes it an ideal choice for organizations that use virtualization to increase resource utilization and reduce IT infrastructure costs.

Scalability and Future-Proofing

As businesses grow, so too do their networking requirements. The Dell GH9K5 S3124 switch supports scalability, allowing you to add additional switches to expand your network as needed. This is particularly beneficial for businesses that require an adaptable network architecture that can handle increased traffic and a growing number of devices without compromising on performance.

Stackable Configuration for Seamless Expansion

The Dell GH9K5 S3124 supports stacking capabilities, which allows multiple switches to be interconnected and managed as a single entity. This simplifies network management and helps to maintain a consistent and high-performance network as your business expands. The stacking feature also ensures that your network can handle increasing data traffic without the need for individual configuration of each switch.

Modular Design for Flexible Deployment

Another benefit of the Dell GH9K5 S3124 is its modular design, which supports various expansion options. Whether you need to add more 1GbE or 10GbE ports, the modular nature of the switch enables you to adapt to your specific business needs without purchasing an entirely new system. This flexibility makes the switch a smart investment for companies that expect future growth.

Security Features to Protect Your Network

As cyber threats become more sophisticated, protecting your network has never been more critical. The Dell GH9K5 S3124 is equipped with several robust security features to safeguard your organization’s sensitive data and prevent unauthorized access.

Access Control Lists (ACLs)

ACLs are used to control access to network resources, limiting the ability of devices to communicate with certain parts of the network. By implementing ACLs, you can enhance security and prevent unauthorized devices from accessing critical parts of your network.

Port Security

Port security is a feature that helps prevent unauthorized devices from connecting to the network. It allows you to set specific devices or MAC addresses to be allowed to connect to particular ports, thereby increasing network security.

DHCP Snooping and IP Source Guard

These features help protect against various types of attacks, including DHCP spoofing and IP address conflicts, by ensuring that only trusted devices can obtain network information. This increases the integrity and stability of your network, preventing unauthorized devices from disrupting the flow of data.

Energy-Efficient Design

The Dell GH9K5 S3124 is designed with energy efficiency in mind. This switch uses low-power components and incorporates intelligent features that automatically adjust power consumption based on network traffic. As a result, it helps reduce the operational costs associated with running large-scale networking infrastructure while minimizing its environmental impact.

Green IT: Reducing Power Consumption

With the increasing demand for sustainable IT solutions, Dell’s commitment to creating energy-efficient products is evident in the GH9K5 S3124. The switch complies with global energy standards, helping organizations minimize their carbon footprint and reduce energy costs. The power-efficient design also contributes to lower heat generation, reducing the need for extensive cooling systems in the data center.

Advanced Power Management Features

The Dell GH9K5 S3124 includes advanced power management features, such as the ability to shut down unused ports and monitor overall power usage. This ensures that only the required components consume energy, further reducing unnecessary power expenditure.

Ease of Use and Simplified Management

Managing a complex network infrastructure can be challenging, but the Dell GH9K5 S3124 simplifies the process through its intuitive management tools and user-friendly interface.

Web-Based GUI for Simplified Management

The switch features a web-based graphical user interface (GUI) that allows IT administrators to easily configure and manage the network. The GUI is designed for simplicity, with a clean and intuitive layout that minimizes the learning curve and enables quick setup and troubleshooting.

Command Line Interface (CLI)

For advanced users, the Dell GH9K5 S3124 also supports a comprehensive Command Line Interface (CLI) for more granular control over switch configurations. The CLI provides full access to the switch’s extensive feature set, allowing for custom scripts and automation of repetitive tasks.

SNMP for Remote Monitoring

Simple Network Management Protocol (SNMP) support enables remote monitoring of the switch’s health and performance. IT administrators can track metrics such as CPU usage, memory utilization, and port status, providing valuable insights to prevent potential network issues before they occur.
