HDNTJ Dell PERC H345 SAS SATA 12GBPS PCIE 3.0 Internal Raid Adapter

Dell PERC H345 SAS SATA RAID Adapter

The Dell HDNTJ PERC H345 SAS SATA 12Gbps PCIe 3.0 Internal RAID Controller is designed to provide dependable storage management, high-speed connectivity, and robust hardware RAID functionality for enterprise-level systems.

General Information

Manufacturer Details

• Brand Name: Dell
• Part Number: HDNTJ
• Device Category: SAS SATA Host Bus Adapter

Technical Specifications

Controller Model

• Model: PERC H345

Interface Compatibility

• PCI Express Support: PCIe 3.0

Connector Options

• SAS Ports: 2x8 Internal Connectors

Memory Features

• Cache Memory: Not Available
• Write Back Cache: Not Supported

RAID Capabilities

• RAID Type: Hardware RAID
• Supported RAID Levels: 0, 1, 10

Drive Support

• Maximum Drive Capacity: Up to 63 Drives

Key Advantages

Performance Benefits

• 12Gbps SAS/SATA throughput for faster data access
• Optimized for enterprise-grade storage environments
