Dell N3132PX-ON Managed Rack Mountable L3 Stackable Network Switches

N3132PX-ON
Hover on image to enlarge

Brief Overview of N3132PX-ON

Dell Managed Rack Mountable L3 Stackable Network Switches - N3132PX-ON. Excellent Refurbished with 6-Month Replacement Warranty
QR Code of Dell N3132PX-ON Managed Rack Mountable L3 Stackable Network Switches
$2,749.95
$1,705.00
You save: $1,044.95 (38%)
Ask a question
180 days
+
Quote
Additional 7% discount at checkout
SKU/MPNN3132PX-ONAvailability✅ In StockProcessing TimeUsually ships same day ManufacturerDell Product/Item ConditionExcellent Refurbished ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30
Description

Overview of the Dell N3132PX-ON EMC Networking Switch

Specifications and Features

Device Classification

  • Type: 32-Port L3 Managed Stackable Switch
  • Enclosure: Rack-mountable 1U
  • Subtype: Gigabit Ethernet

Port Configuration

  • 24 x 10/100/1000 Mbps (Power over Ethernet)
  • 8 x 100/1000/2.5G/5G (Power over Ethernet)
  • 4 x 10 Gigabit SFP+

Performance Metrics

Switching Capabilities

  • Switching Fabric Bandwidth: 328 Gbps
  • Forwarding Rate: 428 Mpps

Capacity Details

  • MAC Address Capacity: 32,000
  • Dynamic Aggregated Links: 144
  • LAG Groups: 128
  • Queues per Port: 8
  • VLANs Supported: 4,094
  • ARP Entries: 6,144
  • NDP Entries: 400
  • Maximum ACL Rules (System-wide): 4,096
  • Maximum ACL Rules per Interface:
    • IPv4 Ingress: 3,072
    • IPv4 Egress: 1,024
    • IPv6 Ingress: 1,021
    • IPv6 Egress: 512
  • Multicast Entries:
    • IPv4: 1,536
    • IPv6: 512
  • OSPF Routes: 8,160

Routing and Management Protocols

  • Routing Protocols: IGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, MLDv2, MLD
  • Remote Management Protocols: SNMP (v1, v2, v3), RMON (v1, v2, 3, 9), Telnet, HTTP, TFTP, SSH-2
  • Encryption Standards: AES, SSL, TLS 1.0
  • Authentication Mechanisms: RADIUS, TACACS+, LDAP

Advanced Features

  • MDI/MDI-X Switching
  • Auto-negotiation Support
  • Port Mirroring Functionality
  • IP Address Filtering Capabilities
  • Quality of Service (QoS) Implementation
  • Front-to-Back Airflow Design
  • Remote Switch Port Analyzer (RSPAN)
  • Management Information Base (MIB) Support
  • Dual Firmware Images for Enhanced Reliability
  • Redundant Fan System
  • MAC and IP-based ACL Support
  • Time-controlled ACL Capabilities

Standards Compliance

  • IEEE 802.2
  • IEEE 802.3 Series (802.3u, 802.3z, 802.3ab, etc.)
  • IEEE 802.1 Series (802.1d, 802.1q, etc.)
  • ANSI/TIA-1057
  • IEEE 802.3at, 802.3az, 802.3ax

Hardware Specifications

  • RAM: 2 GB
  • Flash Memory: 512 MB

Connectivity Options

  • 24 x Gigabit LAN (RJ-45) with PoE
  • 8 x 5 Gbit LAN (RJ-45) with PoE
  • 4 x 10 Gbit LAN (SFP+)
  • 1 x 1000Base-T (RJ-45) for Management
  • 1 x USB Type A

Power Requirements

  • Power Supply: Internal, Hot-plug
  • Installed Power Supply Units: 1 (max: 2)
  • Power Output: 1100 Watts

Dell N3132PX-ON Managed Rack Mountable L3 Stackable Network Switches

Overview

The Dell N3132PX-ON Managed Rack Mountable L3 Stackable Network Switches are the perfect solution for organizations looking to enhance their network performance and security. These switches offer advanced features, scalability, and high-density port configurations, making them ideal for data centers, campus networks, and small to medium-sized businesses.

Key Features

1. Advanced Layer 3 Features

With advanced Layer 3 features, the Dell N3132PX-ON switches provide enhanced routing capabilities, enabling efficient traffic management and network optimization. These switches support dynamic routing protocols such as OSPF and BGP, making them suitable for complex network environments.

2. High-Density Port Configurations

The N3132PX-ON switches come equipped with 32 ports, including 24 10/100/1000BASE-T ports and 8 SFP+ ports. This high-density port configuration allows organizations to connect multiple devices and servers to the network without compromising performance.

3. Stackable Design

These switches feature a stackable design that allows for easy scalability and simplified management. With stackable capabilities, organizations can expand their network by adding more switches without the need for additional management interfaces or IP addresses.

4. Enhanced Security

Security is a top priority for any organization, and the Dell N3132PX-ON switches deliver robust security features to protect your network infrastructure. These switches support features such as Access Control Lists (ACLs), Secure Shell (SSH) Protocol, and Secure Sockets Layer (SSL) encryption, ensuring secure data transmission and preventing unauthorized access.

5. Power over Ethernet (PoE) Support

The N3132PX-ON switches offer Power over Ethernet (PoE) support, allowing organizations to power devices such as IP phones, wireless access points, and surveillance cameras directly from the switch. This eliminates the need for separate power supplies and simplifies the deployment of network devices.

6. Energy-Efficient Design

Dell is committed to sustainability, and these switches reflect that commitment with their energy-efficient design. The N3132PX-ON switches are ENERGY STAR certified, consuming less power and reducing carbon footprint without compromising performance.

Benefits

1. Improved Network Performance

The Dell N3132PX-ON Managed Rack Mountable L3 Stackable Network Switches provide advanced features such as Layer 3 routing, high-density port configurations, and stackable design. These features contribute to improved network performance, ensuring smooth data transmission and reducing latency.

2. Scalability

With the stackable design of the N3132PX-ON switches, organizations can easily expand their network infrastructure as their needs grow. Adding more switches to the stack is a seamless process, allowing for efficient scalability without disrupting network operations.

3. Enhanced Security Measures

Protecting sensitive data and ensuring network security is crucial for any organization. The N3132PX-ON switches offer robust security features such as ACLs, SSH Protocol, and SSL encryption, providing a secure environment for your network infrastructure.

4. Cost Savings

The PoE support of these switches eliminates the need for separate power supplies for connected devices, reducing costs and simplifying deployment. Additionally, the energy-efficient design helps organizations save on electricity bills while maintaining optimal network performance.

5. Simplified Management

The stackable feature of the N3132PX-ON switches simplifies network management by providing a single management interface for the entire stack. This streamlines configuration, monitoring, and troubleshooting tasks, saving time and resources for IT administrators.

6. Reliability

Dell is renowned for its high-quality products, and the N3132PX-ON switches are no exception. Built with reliability in mind, these switches are designed to deliver consistent performance, ensuring uptime and minimizing network downtime.

Conclusion

The Dell N3132PX-ON Managed Rack Mountable L3 Stackable Network Switches offer advanced features, scalability, and enhanced security measures. With their high-density port configurations, stackable design, and energy-efficient operation, these switches provide improved network performance while reducing costs. Whether you need a reliable solution for your data center or a scalable network infrastructure for your business, the N3132PX-ON switches are an excellent choice. Invest in Dell's trusted technology to optimize your network and stay ahead in today's digital landscape.

Features
Product/Item Condition:
Excellent Refurbished
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
