ND4PT Dell Intel X710-T4L Quad Port Adapter

Dell Intel X710-T4L Quad Port Adapter

The Dell ND4PT Intel X710-T4L Quad Port Adapter is a high-performance networking solution built to deliver reliable wired connectivity across multiple Ethernet speeds, making it ideal for enterprise environments and advanced data centers.

Main Information

• Manufacturer: Dell
• Model Number: ND4PT
• Device Type: Network Interface Adapter

Technical Specifications

Form Factor & Design

• Card Type: Plug-in Card
• Profile: Low Profile

Interface & Bus

• Bus Type: PCI Express 3.0 x8
• Specification Revision: PCIe 3.0

Port Configuration

• Ethernet Ports: Four (Quad Port)
• Supported Speeds: 100M / 1G / 2.5G / 5G / 10G Ethernet
• Connector Type: RJ-45

Connectivity & Protocols

Networking Technology

• Connection Mode: Wired
• Data Link Protocols: Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet
• Maximum Data Transfer Rate: 10 Gbps

Interface Standards

• Supported Interfaces: 4 x 1/2.5/5/10GBASE-T
• Connector Format: RJ-45

Transport Protocols

• Supported Protocols: iSCSI, NFS

Advanced Features

Virtualization Support

• Virtual Machine Device Queues (VMDq)
• Virtualization Technology for Connectivity (VT-c)
• Data Direct I/O Technology (DDIO)
• Flexible Port Partitioning (FPP)
• Intelligent Offloads for optimized performance

Dell ND4PT Intel X710-T4L Quad Port PCIE Adapter Overview

The Dell ND4PT Intel X710-T4L Quad Port 10GBE Base-T PCIe Adapter is a high-performance network interface card engineered to meet the demands of modern data centers, virtualization clusters, and enterprise IT infrastructures. Designed around the advanced Intel X710 Ethernet controller, this quad-port 10 Gigabit Ethernet adapter delivers exceptional throughput, low latency, and intelligent offloading capabilities for mission-critical workloads. As organizations continue to transition toward software-defined networking, hyperconverged infrastructure, and cloud-ready architectures, the need for reliable and scalable 10GbE connectivity becomes essential. This PCIe adapter provides seamless integration with Dell PowerEdge servers, offering a cost-effective path to high-speed copper-based networking.

Advanced 10GbE Base-T Connectivity

Featuring four 10GBase-T RJ45 ports, the Dell ND4PT network adapter enables high-speed data transfer over standard Cat6a and Cat7 copper cabling. This flexibility reduces infrastructure costs by leveraging existing Ethernet cabling systems while delivering up to 10Gbps per port. With auto-negotiation support for 100Mbps, 1Gbps, and 10Gbps speeds, the adapter ensures backward compatibility and smooth migration from legacy networks to high-bandwidth 10 Gigabit environments.

Flexible Copper-Based Networking

Unlike fiber-based NICs that require additional transceivers and optical modules, the 10GBase-T interface simplifies deployment in rack-mounted servers and enterprise environments. Copper Ethernet offers ease of installation, shorter lead times, and simplified cable management, making it a practical solution for high-density data centers. The quad-port design allows administrators to consolidate multiple connections, improving redundancy and load balancing across the network fabric.

Optimized for High-Throughput Applications

The Intel X710-T4L controller inside the Dell ND4PT adapter is optimized for bandwidth-intensive applications such as virtualization, big data analytics, database clustering, and enterprise resource planning systems. By delivering consistent 10Gbps per port performance, this network card ensures stable communication between servers, storage arrays, and core switches.

PCIe 3.0 Interface for Maximum Data Bandwidth

Built with a PCI Express 3.0 x8 interface, the Dell ND4PT 10GbE adapter provides high-speed data lanes to prevent bottlenecks between the server motherboard and network interface. PCIe Gen3 architecture enhances throughput and ensures balanced performance across all four ports. This capability is especially valuable in high-performance computing environments where simultaneous multi-stream data transfers occur.

Enhanced Throughput with PCIe Gen3

The PCIe 3.0 x8 configuration provides sufficient bandwidth headroom to support quad 10GbE operations without congestion. This ensures that even under peak network loads, data packets are transmitted efficiently, maintaining application responsiveness and system stability.

Enterprise-Grade Virtualization Support

Virtualized environments demand intelligent network adapters capable of handling multiple virtual machines without performance degradation. The Dell ND4PT Intel X710-T4L adapter incorporates advanced virtualization features to improve resource allocation and network efficiency within hypervisor-based infrastructures.

Support for SR-IOV and VMDq

Single Root I/O Virtualization (SR-IOV) enables direct assignment of virtual functions to individual virtual machines, reducing CPU overhead and latency. Virtual Machine Device Queues (VMDq) further optimize traffic flow by distributing network workloads across multiple processor cores. These technologies allow enterprises to scale virtualization deployments while maintaining predictable network performance.

Improved VM Density and Efficiency

By offloading network processing tasks from the host CPU, the Intel X710 controller enhances overall system efficiency. Organizations can increase virtual machine density per server without compromising throughput or responsiveness, making this adapter ideal for cloud service providers and private cloud infrastructures.

Compatibility with Leading Hypervisors

The Dell ND4PT adapter supports major hypervisor platforms, including VMware ESXi, Microsoft Hyper-V, and open-source KVM environments. Broad driver support ensures seamless integration with modern operating systems, simplifying deployment across heterogeneous data centers.

Comprehensive Offload and Acceleration Technologies

Modern enterprise networking requires more than raw bandwidth. Intelligent hardware acceleration features are essential for reducing CPU utilization and enhancing network efficiency. The Intel X710-T4L controller provides multiple advanced offload capabilities to optimize performance.

TCP/IP Offload Engine and Checksum Offload

TCP segmentation offload (TSO), large receive offload (LRO), and checksum offloading reduce the computational burden on server processors. By handling packet segmentation and validation at the hardware level, the Dell ND4PT adapter frees CPU resources for application workloads.

Data Center Bridging Support

Data Center Bridging (DCB) enhances traffic management by enabling priority-based flow control and bandwidth allocation. This ensures reliable transport of storage and data traffic over converged Ethernet networks, making the adapter suitable for iSCSI and FCoE deployments.

Energy Efficient Ethernet

The Intel X710 controller incorporates Energy Efficient Ethernet (EEE) capabilities to reduce power consumption during periods of low network activity. This feature helps organizations optimize energy usage across large-scale server deployments while maintaining consistent connectivity.

Scalable Networking for Data Centers and Cloud Environments

As enterprises expand digital services and hybrid cloud strategies, network scalability becomes a core requirement. The Dell ND4PT Intel X710-T4L Quad Port 10GbE Adapter supports scalable networking architectures by delivering consistent bandwidth and redundancy.

High Availability and Redundancy

With four independent 10GbE ports, the adapter allows for link aggregation, failover configurations, and load balancing. Network administrators can design resilient architectures that minimize downtime and ensure continuous service availability.

Link Aggregation for Bandwidth Expansion

IEEE 802.3ad link aggregation enables multiple ports to function as a single logical connection, increasing throughput and improving redundancy. This feature is particularly beneficial for database clusters and high-performance storage systems.

Ideal for Hyperconverged Infrastructure

Hyperconverged systems rely on robust east-west traffic between nodes. The Dell ND4PT network adapter supports rapid inter-node communication, reducing latency and enhancing storage replication efficiency in distributed computing environments.

Broad Operating System and Server Compatibility

The Dell ND4PT Intel X710-T4L adapter is engineered for compatibility with a wide range of Dell PowerEdge rack and tower servers. Certified drivers and firmware updates ensure reliable integration with enterprise Linux distributions, Windows Server editions, and virtualization platforms.

Seamless Integration with Dell PowerEdge Servers

Optimized firmware and hardware alignment enable smooth deployment within Dell server ecosystems. This compatibility simplifies lifecycle management, firmware updates, and system monitoring through Dell management tools.

Support for Modern Operating Systems

The adapter is compatible with contemporary operating systems, ensuring organizations can deploy it in both legacy and next-generation server environments without compatibility concerns.

Enhanced Security and Traffic Isolation

Security is paramount in enterprise networking. The Intel X710-T4L controller includes hardware-based features that strengthen traffic segmentation and data integrity.

Advanced Packet Filtering

Hardware-level packet filtering and VLAN tagging enable secure segmentation of network traffic. This ensures that different departments, tenants, or application tiers remain logically isolated within shared infrastructures.

Secure Boot and Firmware Integrity

Firmware-level protections safeguard against unauthorized modifications, helping maintain compliance with enterprise security standards.

Key Optimization for Storage and Big Data Workloads

High-speed storage networks and big data analytics platforms require consistent low-latency connectivity. The Dell ND4PT 10GbE adapter enhances data flow between compute and storage nodes, supporting rapid backup operations, data replication, and large-scale processing tasks.

Efficient iSCSI and NAS Connectivity

The 10GBase-T architecture is ideal for IP-based storage networks, including iSCSI SAN and NAS environments. Consistent throughput ensures stable access to shared storage resources.

Optimized for Database and Analytics Platforms

Large transactional databases and analytics engines benefit from reliable high-bandwidth connectivity. The adapter maintains stable packet delivery even under heavy parallel workloads.

Future-Ready 10 Gigabit Ethernet Expansion

Investing in the Dell ND4PT Intel X710-T4L Quad Port 10GbE Base-T PCIe Adapter provides a forward-looking networking upgrade path. As data traffic continues to increase across enterprise infrastructures, 10 Gigabit Ethernet remains a widely adopted standard for balancing cost and performance. This adapter supports scalable deployments while protecting existing cabling investments.

Cost-Effective 10GbE Deployment Strategy

By utilizing copper-based Ethernet connections, organizations can upgrade server connectivity without extensive fiber infrastructure investments. This makes the adapter suitable for mid-sized enterprises, large corporations, and cloud providers seeking efficient high-speed networking solutions.
