Dell VVF32 32GB Dual Ports Fiber Channel Host Bus Adapter

VVF32
Hover on image to enlarge

Brief Overview of VVF32

Dell VVF32 LPE35002-M2 Emulex 32GB Dual Ports PCIe Gen4 x8 Fiber Channel Host Bus Adapter LP. New (System) Pull with 1 Year Replacement Warranty

QR Code of Dell VVF32  32GB Dual Ports Fiber Channel Host Bus Adapter
$1,036.80
$768.00
You save: $268.80 (26%)
Ask a question
Price in points: 768 points
+
Quote
SKU/MPNVVF32Availability✅ In StockProcessing TimeUsually ships same day ManufacturerDell Product/Item ConditionNew (System) Pull ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30
Description

Product Summary

  • The Dell VVF32 Lpe35002-m2 Emulex 32GB Dual-Ports PCIe Gen4 X8 Fiber Channel Host Bus Adapter is a high-performance, reliable connectivity solution designed for advanced storage networking environments. Equipped with robust features and optimized specifications, this adapter ensures seamless, efficient data transfer for enterprise storage solutions.

Technical Specifications

General Information

  • Brand: Dell
  • Part Number: VVF32

Physical Dimensions

  • Short, low-profile PCIe card with dimensions of 167.64mm x 68.91mm (6.60” x 2.71”)

PCIe & Hardware Features

  • Host bus type: PCIe Gen4 X8
  • I/O controller: Xe601
  • Hardware compatibility: Intel X64, Intel X86, and PowerPC environments

Network Specifications

Optical Data Rates

  • 28.05 Gb/s (3200MB/s)
  • 14.025 Gb/s (1600MB/s)
  • 8.5 Gb/s (800MB/s) - Auto-detected

Cable Compatibility

  • Support ranges from 0.5m to 100m for 64GFC/32GFC using 50/125 µm OM4 MMF
  • Up to 100m with 50/125 µm OM5 MMF for 64GFC/32GFC
  • Support extends up to 70m with 50/125 µm OM3 MMF
  • 32GFC/16GFC up to 10 km with 9/125 µm single-mode fiber (Emulex-approved longwave transceivers required)

Environmental Characteristics

Operational Conditions

  • Operating humidity: 5% to 95% (non-condensing)
  • Operating temperature: 0°C to 55°C
  • Storage temperature range: -20°C to 85°C (-4°F to 185°F)

Compatibility & OS Support

Operating System Compatibility

  • Microsoft Windows
  • Oracle Linux and Oracle Linux with Unbreakable Enterprise Kernel (UEK)
  • Oracle Solaris
  • Red Hat Enterprise Linux
  • SUSE® Linux Enterprise Server
  • VMware vSphere

Additional Support

  • Extended OS compatibility options available through partnerships with OEMs and other providers

Technical Highlights

High-Speed Data Transmission

Designed to deliver data rates of up to 28.05 Gb/s for efficient and reliable storage communication. This ensures that organizations can manage storage traffic with exceptional performance.

Dual Port Functionality

With dual ports, this adapter offers dual-channel operation for higher throughput, fault tolerance, and flexibility in enterprise storage infrastructure design.

Advanced Connectivity with Optical Support

Built with optical laser shortwave connectivity through LC-type connectors, the Dell VVF32 ensures compatibility with enterprise-grade fiber optic networks.

Streamlined Storage Management

The Dell VVF32 is specifically engineered for businesses looking to scale storage networks without compromising performance. With its advanced features, users can optimize network bandwidth and storage capacity seamlessly.

Enterprise-Grade Reliability

Designed to operate within diverse environments, the Dell VVF32 offers dependable performance under varying environmental conditions while maintaining data integrity across long distances.

Seamless Integration

Compatible with a wide array of operating systems and storage platforms, this adapter simplifies integration into existing IT infrastructures, ensuring ease of deployment and compatibility for complex use cases.

Dell VVF32 LPE35002-M2 Emulex 32GB Dual Port PCIe Gen4 x8 Fiber Channel Host Bus Adapter LP

The Dell VVF32 LPE35002-M2 Emulex 32GB Dual Port PCIe Gen4 x8 Fiber Channel Host Bus Adapter LP is a state-of-the-art storage connectivity solution designed for modern data centers and enterprise environments. With its advanced features, this host bus adapter ensures seamless, high-speed, and low-latency connectivity for storage networks, helping IT professionals streamline infrastructure performance and scalability. Whether your data storage strategy relies on SANs (Storage Area Networks) or enterprise storage arrays, this adapter serves as a key building block for enterprise-grade connectivity.

Key Features of Dell VVF32 LPE35002-M2 Emulex 32GB Dual Port PCIe Gen4 x8 Adapter

The Dell VVF32 LPE35002-M2 is equipped with several features that make it one of the most reliable and cutting-edge PCIe Gen4 Fiber Channel Host Bus Adapters available. These features are designed to meet the demands of high-performance storage networking and ensure optimized performance across enterprise infrastructures.

32GB Dual-Port Capability for Maximum Bandwidth

The Dell VVF32 LPE35002-M2 Emulex 32GB offers 32GB dual ports, allowing for high-bandwidth connectivity that can handle large data transfers efficiently. With dual ports, it provides redundancy and fault-tolerance while maximizing bandwidth to meet the growing needs of enterprise environments.

PCIe Gen4 x8 Support for Faster Speeds

The PCIe Gen4 x8 interface enables faster and more efficient communication between servers and storage networks. This feature supports higher throughput rates, lower latency, and improved bandwidth utilization, allowing storage-intensive applications to process large amounts of data faster than traditional interfaces.

Low Latency for Enterprise Storage Applications

With its advanced design, the Dell VVF32 LPE35002-M2 minimizes latency for demanding enterprise storage applications. Reduced latency ensures mission-critical operations run smoothly, even during peak periods of activity, making this host bus adapter an excellent choice for large-scale enterprise storage deployments.

Optimized for Scalability and High Availability

The dual-port design, combined with PCIe Gen4 support, offers built-in redundancy and scalability to meet the demands of growing business data needs. This ensures that as your storage infrastructure expands, the Dell VVF32 LPE35002-M2 can scale with it while maintaining performance and reliability.

Understanding Host Bus Adapters (HBAs)

Host Bus Adapters (HBAs) are hardware components that act as communication bridges between servers and storage networks, enabling data to transfer between computing environments and storage systems. The Dell VVF32 LPE35002-M2 is a premium HBA that supports the Fibre Channel protocol for efficient and high-speed storage connectivity.

Advantages of Using the Dell VVF32 LPE35002-M2 as Your Storage Network Adapter

  • High Throughput: With 32GB dual-port capabilities, the Dell VVF32 LPE35002-M2 offers massive throughput, ensuring large-scale data transfers without bottlenecks.
  • Reliability: Dual-port configurations allow for fault-tolerance, ensuring data transfers remain uninterrupted even if a port experiences failure.
  • Scalability: The PCIe Gen4 x8 interface supports scalable storage solutions that grow with business demands.
  • Efficient Resource Management: Offloads the processing burden from servers to the dedicated HBA, freeing up CPU resources for other tasks.

Applications of Dell VVF32 LPE35002-M2 Host Bus Adapter in Modern Data Centers

The Dell VVF32 LPE35002-M2 is an ideal choice for a variety of data center storage applications. Its speed, reliability, and performance make it well-suited for enterprise storage strategies ranging from small business SANs to large-scale cloud data centers.

Storage Area Networks (SANs)

Storage Area Networks (SANs) are high-performance networks dedicated to providing server access to storage devices. The Dell VVF32 LPE35002-M2 integrates seamlessly with SAN environments, ensuring efficient, high-speed communication between servers and storage arrays. By utilizing Fibre Channel technology, it offers fast and secure access to mission-critical enterprise data.

Disaster Recovery and Backup Systems

In enterprise data strategies, disaster recovery and backup are essential. The dual-port capabilities of the Dell VVF32 LPE35002-M2 ensure continuous data availability and fast failover capabilities during disruptions. It allows organizations to implement effective disaster recovery protocols with minimal downtime, protecting critical data from unexpected failures.

Enterprise Virtualization Environments

Virtualization technologies depend heavily on robust and efficient storage networks. The Dell VVF32 LPE35002-M2 is optimized for virtualization environments by enabling multiple virtual servers to access centralized storage systems with high speed and low latency. This makes it an essential tool for environments running VMware, Hyper-V, or other virtualization platforms.

High-Performance Computing (HPC) Storage Connectivity

In HPC environments, speed and throughput are critical for ensuring computations run efficiently. The Dell VVF32 LPE35002-M2 supports high-speed Fibre Channel connections, allowing HPC clusters to access and process vast amounts of data without delay. Its high bandwidth ensures computing nodes can maintain consistent communication with storage arrays, optimizing HPC performance.

How the Dell VVF32 LPE35002-M2 Enhances Data Center Efficiency

Modern enterprise data centers require efficient storage solutions that provide speed, reliability, and scalability. The Dell VVF32 LPE35002-M2 achieves this by leveraging advanced technology to optimize server-to-storage communication. With PCIe Gen4 x8 support, dual-port redundancy, and 32GB bandwidth, it ensures data flows smoothly while meeting stringent performance goals.

Streamlined Communication with PCIe Gen4 Technology

The PCIe Gen4 x8 interface enables higher bandwidth utilization and improved system performance by providing faster communication speeds between servers and storage networks. This technological advancement reduces data transfer delays, supporting the growing data processing needs of modern enterprises.

Enhanced Scalability for Growing Storage Needs

With the ability to scale as data storage demands grow, the Dell VVF32 LPE35002-M2 offers flexibility for future-proofing storage strategies. The dual-port design allows administrators to connect multiple storage targets without impacting system performance, ensuring that businesses can scale their storage infrastructure effectively as their operations expand.

Advanced Fault-Tolerance Features

The dual-port redundancy of the Dell VVF32 LPE35002-M2 ensures continuous system performance, even during hardware failures. Fault-tolerance minimizes downtime, enabling IT teams to manage disruptions without impacting data availability or operations.

Features
Product/Item Condition:
New (System) Pull
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
