HPE 5215l Xeon Gold 10 Core 2.5ghz Processor - P02533-B21

Product Overview

General Information

• Processor Collection: 2nd Generation Xeon® Scalable Processors, designed for advanced server applications.
• Code Name: Cascade Lake, a server-grade processor line optimized for performance and scalability.
• Target Segment: Server, suited for high-demand enterprise and data center use.
• Processor Number: 5215L, an efficient model within the Xeon® family.
• Manufacturing Process: Built on a 14 nm lithography process for optimal power efficiency.

CPU Specifications

Core and Thread Configuration

• Total Cores: 10 cores, enabling parallel processing and multitasking capabilities.
• Total Threads: 20 threads, maximizing performance in multi-threaded applications.

Performance and Clock Speeds

• Max Turbo Frequency: Reaches up to 3.40 GHz, suitable for handling peak workloads.
• Base Frequency: Operates at a steady 2.50 GHz, balancing power consumption with performance.
• Cache Size: 13.75 MB, improving data retrieval speed for smoother operations.
• UPI Links: Supports 2 UPI links, enhancing data transfer rates across processors.
• Thermal Design Power (TDP): Rated at 85 W, optimized for energy-efficient performance.

Memory Specifications

Memory Capacity and Speed

• Maximum Memory Size: Supports up to 4.5 TB, dependent on the memory type for extensive data handling.
• Memory Type: DDR4-2667, ideal for high-speed data transfer.
• Maximum Memory Speed: Operates at up to 2667 MHz, enhancing application responsiveness.
• Memory Channels: Supports 6 memory channels, allowing efficient data distribution.

Additional Memory Features

• Optane™ Persistent Memory: Supported, providing additional data persistence capabilities.
• ECC Memory: ECC-supported for error correction and data integrity.

Expansion Options

Scalability and PCI Express

• Processor Scalability: 4S, supporting up to four processors for enhanced scalability in complex systems.
• PCI Express Revision: 3.0, providing faster communication between system components.
• PCI Express Lanes: Supports up to 48 lanes, ensuring sufficient bandwidth for expansion needs.

Package Specifications

Socket and Size

• Sockets Supported: FCLGA3647, compatible with modern server boards.
• Thermal Profile (Tcase): Rated up to 77°C, suitable for enterprise-level cooling systems.
• Package Dimensions: Measures 76.0 mm x 56.5 mm, a standard fit for server configurations.

Advanced Technologies

Performance Enhancements

• Deep Learning Boost (DL Boost): Included, enhancing AI and machine learning workloads.
• Intel Speed Shift Technology: Improves processor responsiveness for real-time processing.
• Turbo Boost Technology 2.0: Supported, automatically boosts processing power as needed.
• Hyper-Threading Technology: Enables more threads per core, increasing throughput.

Instruction Set and Extensions

• Supported Instruction Set: 64-bit, with instruction set extensions such as SSE4.2, AVX, AVX2, and AVX-512.
• Enhanced SpeedStep® Technology: Included, adjusting power to balance performance with energy efficiency.
• Volume Management Device (VMD): Integrated, enhancing SSD management for efficient storage operations.

Security & Reliability Features

Security Technologies

• Intel vPro® Platform: Supported, providing advanced security and remote manageability.
• AES New Instructions: Built-in, enabling faster encryption and decryption for secure data handling.
• Trusted Execution Technology: Supported, ensuring secure operation in virtualized environments.

Reliability Enhancements

• Execute Disable Bit: Reduces exposure to malicious software attacks.
• Run Sure Technology: Enhances system reliability for critical data center applications.
• Mode-Based Execute Control (MBEC): Included, adding an extra layer of protection against certain security vulnerabilities.

Virtualization Support

• Virtualization Technology (VT-x): Enables multiple virtual environments on a single platform.
• Virtualization Technology for Directed I/O (VT-d): Supported, enhancing I/O virtualization.
• Extended Page Tables (EPT): Reduces latency and improves memory management in virtualized environments.

HPE Xeon Gold 5215l 10 Core 2.5ghz 13.75mb Cache Socket Fclga3647 Processor - P02533-B21

Core: 10

The Power of 10 Cores

The HPE 5215l Xeon Gold Processor is equipped with a powerful 10-core configuration. This feature sets it apart from other processors in its class and provides users with unparalleled performance and capabilities.

Increased Processing Power

The 10 cores of the HPE 5215l Xeon Gold Processor allow for increased processing power, enabling users to handle demanding tasks and applications with ease. Whether you are running complex simulations, analyzing large datasets, or performing intensive calculations, the 10 cores ensure that your system can keep up with your workload.

Improved Multitasking

With 10 cores at your disposal, multitasking becomes a breeze. You can run multiple applications simultaneously without experiencing any lag or slowdown. This is especially beneficial for professionals in fields such as video editing, 3D rendering, and data analysis, where multitasking is crucial for productivity.

Enhanced Virtualization Performance

If you are operating virtual machines or running virtualization software, the 10 cores of the HPE 5215l Xeon Gold Processor provide enhanced performance. Virtualization relies on efficient resource allocation, and the additional cores enable smoother operation and improved responsiveness.

Future-Proofing Your System

Investing in a processor with 10 cores ensures that your system is future-proofed. As software and applications become increasingly resource-intensive, having more cores will allow your system to meet the demands of future technologies without the need for immediate upgrades.

Conclusion

The Core feature of the HPE 5215l Xeon Gold Processor is not only impressive in terms of numbers but also delivers tangible benefits to users. With 10 cores, you can enjoy increased processing power, improved multitasking capabilities, enhanced virtualization performance, and future-proofing for years to come.

Speed: 2.5GHz

Unleash the Power of 2.5GHz

The HPE 5215l Xeon Gold Processor boasts an impressive clock speed of 2.5GHz. This high-speed capability ensures that your system operates at optimal performance levels, enabling you to accomplish tasks quickly and efficiently.

Rapid Task Execution

The 2.5GHz clock speed allows the processor to execute tasks rapidly. Whether you are launching applications, loading large files, or performing calculations, the speed at which the processor operates ensures minimal waiting time and maximum productivity.

Seamless Multimedia Experience

If you work with multimedia content such as video editing or graphic design, the 2.5GHz speed of the HPE 5215l Xeon Gold Processor enhances your experience. You can render videos faster, apply complex effects in real-time, and manipulate high-resolution images without any noticeable lag.

Improved Gaming Performance

Gamers will appreciate the 2.5GHz speed of this processor. It allows for smooth gameplay, quick loading times, and seamless transitions between game environments. The high clock speed ensures that you can fully immerse yourself in the gaming experience without any performance bottlenecks.

Efficient Data Processing

Data-intensive tasks require a processor that can handle large volumes of information quickly. The 2.5GHz speed of the HPE 5215l Xeon Gold Processor enables efficient data processing, making it ideal for professionals working with big data analytics, database management, and scientific simulations.

Conclusion

The Speed feature of the HPE 5215l Xeon Gold Processor, with its impressive 2.5GHz clock speed, offers users numerous benefits. With rapid task execution, seamless multimedia experiences, improved gaming performance, and efficient data processing, this processor ensures that your system operates at peak performance.

Part Number: P02533-B21

The Significance of Part Number P02533-B21

The HPE 5215l Xeon Gold Processor is identified by its unique part number, P02533-B21. This part number holds valuable information about the specific configuration and features of the processor, making it essential for users who want to ensure compatibility and optimize their system.

Easy Identification and Compatibility

The part number P02533-B21 makes it easy to identify the HPE 5215l Xeon Gold Processor among other models. This is particularly important when purchasing or upgrading hardware, as it ensures compatibility with your existing system or motherboard. By referencing the part number, you can be confident that you are selecting the correct processor for your needs.

Access to Detailed Specifications

The part number P02533-B21 unlocks access to detailed specifications of the HPE 5215l Xeon Gold Processor. By referring to the part number, users can access information such as clock speed, cache size, power consumption, and supported technologies. This level of detail enables users to make informed decisions based on their specific requirements.

Warranty and Support

Part numbers are often used to identify products for warranty and support purposes. By referencing the part number P02533-B21, users can easily communicate with customer support or service centers, ensuring a smooth and efficient resolution to any issues that may arise.

Future Upgrades and Expansion

The part number P02533-B21 is crucial for future upgrades and expansion of your system. By knowing the specific part number of your processor, you can easily identify compatible hardware and make informed decisions when expanding your system's capabilities.

Conclusion

The Part Number feature of the HPE 5215l Xeon Gold Processor, represented by P02533-B21, offers users a range of benefits. It ensures easy identification and compatibility, provides access to detailed specifications, facilitates warranty and support interactions, and assists in future system upgrades and expansions. Paying attention to the part number is essential for optimizing your system's performance and ensuring seamless integration of hardware components.
