HPE 776934-B21 Proliant ML110 Gen9 4Lff Smart Array B140I Tower Server

CPU: No CPU

When it comes to servers, the CPU (Central Processing Unit) is the brain that powers all operations and processes. It is responsible for executing instructions, performing calculations, and managing data flow. The HPE Proliant ML110 G9 CTO Model 776934-B21 Tower Server offers the unique feature of "No CPU." While this may seem counterintuitive at first, there are several benefits and important considerations to take into account.

Product Overview of Tower Server

Manufacturer: Hewlett Packard Enterprise

Part Number: 776934-B21

Product Name: Proliant ML110 Gen9 - 4.5U Tower Server (CTO Model-4LFF HP)

Processor and Chipset

• Processor Type: No CPU
• 64-bit Computing: Yes
• Compatible Processor Socket: FCLGA2011-3
• Installed Quantity: 0
• Maximum Supported Quantity: 1
• Chipset Type: Intel C610 Series

Cache Memory

• Cache Memory Type: Smart Cache
• Installed Size: 0 MB

Memory Specifications

• Installed Size: 0 GB / 256 GB (max)
• Technology: DDR4 SDRAM - Advanced ECC
• Memory Specification Compliance: PC4-17000
• Form Factor: DIMM 288-pin
• Slots: 8 (total) / 8 (empty)
• Features: Registered, Online Spare Memory, HP SmartMemory
• Supported RAM: PC4-17000 - 128 GB Load-Reduced; PC4-17000 - 256 GB Registered

Storage Configuration

• Hard Drive: No HDD
• Optical Drive: None

Storage Controllers

• Controller Name: Smart Array B140i
• Buffer Size: None
• Disk Drive Speed: Up to 6 GB/s SATA
• Connectors: 10 Internal SATA Connectors
• Server Interface: x4 PCIe 2.0
• SATA Speed: 6 GB/s SATA Links
• Logical Drives Supported: Up to 8 Logical Volumes (6 Physical Drives)
• Host Memory Addressing: 64-bit, Supporting Greater Than 4 GB Server Memory Space
• RAID Support: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50

Graphics and Display

• Graphics Processor: Matrox G200EH
• Video Memory: 16 MB

Network and Communication

• Type: Integrated
• Interface Type: PCI Express x2
• Ethernet Ports: 2 x Gigabit Ethernet
• Ethernet Controller: HP 330i
• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Protocol: IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 4
• Features: Wake On LAN (WOL), PXE Support
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion and Connectivity

• 1 x External 5.25" (total) / 1 (free)
• 4 x Hot-swap 3.5" LFF (total) / 4 (free)

Expansion Slots

• 8 x DIMM 288-pin (total) / 8 (free)
• 1 x CPU (total) / 1 (free)
• 2 x PCIe 3.0 x8 - Half-length, Full-height (total) / 2 (free)
• 2 x PCIe 3.0 x4 - Half-length, Full-height (total) / 2 (free)
• 1 x PCIe 3.0 x16 - Three-quarter-length, Full-height (total) / 1 (free)
• 1 x MicroSD Card (internal) (total) / 1 (free)

Interfaces and Ports

• 1 x VGA (rear)
• 2 x LAN (Gigabit Ethernet)
• 1 x HP iLO
• 5 x USB 3.0 (2 front, 2 rear, 1 internal)
• 3 x USB 2.0 (2 rear, 1 internal)

Miscellaneous Features

• Administrator Password
• Power-on Password
• Serial Port I/O Control
• Setup Password
• UEFI BIOS

Compliance Standards

• ACPI 2.0b
• FCC Class B Certified
• CISPR 24
• ICES-003
• EN 61000-3-3
• CISPR 22
• FCC CFR47 Part 15
• IEC 60950-1
• EN 60950-1
• GB 9254
• CNS 13438

Manufacturer Selling Program

CTO, Factory Integrated

Power Description

• Device Type: Power Supply
• Installed Quantity: 1
• Maximum Supported Quantity: 2

Dimensions and Weight

• Depth: 18.9 inches
• Width: 7.7 inches
• Height: 17.3 inches
• Weight: 27.6 lbs

Flexible Customization

One of the primary advantages of a server without a CPU is the flexibility it provides for customization. By not including a pre-installed CPU, users have the freedom to choose a processor that best suits their specific needs and budget. This allows for greater control over performance capabilities, power consumption, and compatibility with other hardware components.

Performance Optimization

Every organization has different computing requirements, and having the ability to select an appropriate CPU ensures optimal performance for specific workloads. Whether you need a server for virtualization, data analysis, or web hosting, having the freedom to choose the right CPU can significantly enhance processing power and efficiency.

Cost Efficiency

Another benefit of a server without a CPU is cost efficiency. In many cases, purchasing a server with a pre-installed CPU may include additional costs for hardware that may not be necessary or may not meet your requirements. By opting for a server without a CPU, you have the opportunity to allocate your budget more efficiently by investing in other critical components or upgrading existing ones.

Future-Proofing

Technology evolves rapidly, and future-proofing your infrastructure is essential for long-term success. By choosing a server with no pre-installed CPU, you have the flexibility to upgrade or replace the processor as needed without having to replace the entire server. This saves both time and money, allowing you to adapt to changing technological demands without unnecessary hardware costs.

Compatibility and Versatility

The HPE Proliant ML110 G9 CTO Model 776934-B21 Tower Server's "No CPU" feature provides compatibility and versatility for various user scenarios. It allows users to leverage their existing CPU investments or choose from a wide range of processors available in the market.

Multiple Generation Support

As technology advances, newer generations of CPUs are introduced into the market with improved performance and efficiency. By opting for a server without a CPU, you can take advantage of the latest processor technologies without being limited to a specific generation. This ensures that your server remains up-to-date and capable of handling demanding workloads.

Multi-Vendor Compatibility

The absence of a pre-installed CPU also means that users can select CPUs from different vendors. This opens up opportunities for comparing specifications, performance benchmarks, and price points, ultimately allowing users to make an informed decision based on their unique requirements and preferences.

Enhanced System Integration

The HPE Proliant ML110 G9 CTO Model 776934-B21 Tower Server's "No CPU" feature ensures seamless integration within existing infrastructure. By allowing users to choose their own CPU, they can ensure compatibility with other hardware components such as motherboards, memory modules, and expansion cards. This compatibility ensures efficient communication and data transfer between different system elements, leading to improved overall system performance.

Customization for Specialized Workloads

Certain industries or applications may require specific CPU architectures or features. With the flexibility provided by a server without a pre-installed CPU, users can tailor their server's processing power to meet the unique demands of specialized workloads. Whether it is for scientific simulations, artificial intelligence, or high-performance computing, having the ability to select the ideal CPU ensures optimal performance and efficiency.

In conclusion, the HPE Proliant ML110 G9 CTO Model 776934-B21 Tower Server's "No CPU" feature offers numerous benefits and advantages for users. The flexibility to choose a CPU that aligns with specific requirements, along with cost efficiency, future-proofing capabilities, and compatibility with various vendors and generations, makes this server an excellent choice for organizations seeking customization and versatility.
