777280-001 HPE ProLiant DL380 Gen9 SAS/SATA SFF Backplane Board

Product Overview of HPE 777280-001 ProLiant Backplane Board

This component is architected to support a high-density storage configuration. Its design is pivotal for maintaining optimal data flow and system stability within the server chassis.

Key Specifications

• Manufacturer: HPE
• Part Number: 777280-001
• Product Type: Backplane Board

Interface and Drive Support Capabilities

The board natively accommodates both SAS (Serial Attached SCSI) and SATA (Serial ATA) hard disk drives (HDDs) and solid-state drives (SSDs). This dual-interface support provides administrators with significant leeway in selecting storage media based on performance needs and budgetary constraints.

• Enables seamless integration of SAS and SATA storage devices concurrently.
• Facilitates advanced features like hot-plug functionality for drive swaps without system shutdown.
• Supports high-speed data transmission protocols to prevent bottlenecks.

Physical Design and Integration

• The SFF form factor is specifically engineered for 2.5-inch drives, allowing a greater number of storage units to be housed within the limited physical space of the DL380 Gen9 server bay. This design maximizes storage capacity without expanding the server's physical footprint.

Connector Layout and Keyed Components

• Precision-molded connectors ensure a secure and error-free linkage to the server's motherboard and storage controller. The board is meticulously keyed to prevent incorrect installation, safeguarding the hardware from potential damage during maintenance or upgrades.

Primary Functional Advantages and Applications

• Integrating this genuine HPE backplane ensures full compatibility and unlocks the complete suite of features offered by the ProLiant DL380 Gen9 platform.

Enhanced Data Integrity and System Management

The board is instrumental in preserving data reliability. It works in concert with HPE Smart Array controllers to enable drive status monitoring, predictive failure analysis, and other alerts through the integrated iLO (Integrated Lights-Out) management system.

• Provides critical telemetry data for proactive storage health monitoring.
• Helps in implementing robust RAID configurations for data redundancy.
• Ensures signal integrity across all connected storage devices.

Deployment Scenarios and Ideal Use Cases

This component is indispensable for enterprises that depend on the DL380 Gen9 for critical operations. Its typical deployments include:

• Corporate data centers requiring high-availability storage arrays.
• Virtualized environments demanding fast and reliable access to numerous virtual machines.
• Database servers where speed and data integrity are non-negotiable.

777280-001 HPE ProLiant DL380 SAS/SATA Backplane Board

The 777280‑001 HPE ProLiant DL380 Gen9 2‑Bay SFF Rear SAS/SATA Backplane Board represents a critical component for enterprise‑level server storage reliability. Designed exclusively for the HPE ProLiant DL380 Gen9 platform, this backplane supports both SAS and SATA hard drives in a compact two‑bay SFF (Small Form Factor) configuration. Engineered to deliver seamless connectivity and optimal data throughput, it ensures high‑availability and simplified serviceability in demanding IT environments.

Functionality and Key Features

Dual‑Interface Support With SAS And SATA

Featuring compatibility with both SAS (Serial Attached SCSI) and SATA (Serial ATA) drives, this backplane board offers maximum versatility. It enables users to mix and match compatible drive types, facilitating cost‑effective scaling of storage infrastructure while ensuring high performance and reliability.

Efficient Small Form Factor (SFF) Design

Its two‑bay SFF design allows for dense storage in server rack deployments where space is at a premium. This compact layout supports 2.5‑inch drives while preserving airflow and thermal efficiency, keeping the overall chassis layout streamlined.

Rear Backplane Mounting for Improved Airflow

The rear‑mounted placement of the backplane ensures unobstructed front‑to‑rear cooling within the chassis. This positioning contributes to effective heat dissipation and helps maintain optimal operating temperatures even under heavy workloads.

Compatibility and Integration Details

Designed for HPE ProLiant DL380 Gen9 Servers

This backplane board is engineered specifically for use with HPE ProLiant DL380 Gen9 servers. Compatibility with this server model ensures that firmware integration, mechanical fit, and power delivery are fully aligned with the platform’s specifications, minimizing compatibility issues.

Firmware Awareness and Auto‑Detection

HPE ProLiant systems typically include firmware routines that detect installed backplanes like the 777280‑001. Upon installation, the server’s system ROM recognizes the backplane and configures drive settings accordingly, enabling features such as hot‑plug support, drive monitoring, and drive failure alerts.

Performance and Optimization Strategies

Leveraging SAS and SATA Strengths

For high‑transaction workloads, SAS drives deliver superior throughput and reliability, while SATA drives offer cost‑effective bulk storage. Strategically deploying a mix based on workload profiles can help optimize performance and budget.

Enhancing Cooling and Airflow

Optimizing internal airflow by minimizing cable clutter and ensuring clean intake and exhaust paths allows the backplane and drives to run at optimal temperatures, enhancing longevity and reliability.
