Computer & Network CablesHPE 778641-B21 ProLiant DL80 G9 2U Rack Server Intel Xeon E5-2609 v3, 6-Core, 1.90GHz
778641-B21
Hover on image to enlarge
Brief Overview of 778641-B21
HPE 778641-B21 ProLiant DL80 G9 2U Rack Server Intel Xeon E5-2609 v3, 6-Core, 1.90GHz. Excellent Refurbished with 6-Month Replacement Warranty
Our Advantages
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
Payment Options
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
Delivery
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Please sign in so that we can notify you about a reply
Description
Product Specifications
Manufacturer and Model Details
- Brand: HPE
- Manufacturer Part Number: 778641-B21
- Product Name: ProLiant DL80 Gen9 - 2U Rack Server (Base Model)
Processor and Chipset Information
- Processor: Intel Xeon E5-2609v3, 1.9GHz
- QuickPath Interconnect Speed: 6.40 GT/s
- Core Count: 6-core
- 64-bit Support: Yes
- Processor Socket: FCLGA2011-3
- Installed Processors: 1
- Maximum Processors Supported: 2
- Chipset: Intel C610 Series
Cache Memory Details
- Type: Smart Cache
- Installed Cache: 15MB
- Cache per Processor: 15MB
Memory Specifications
- Installed Memory: 8GB
- Maximum Memory: 128GB
- Memory Technology: DDR4 SDRAM with Advanced ECC
- Effective Memory Speed: 1600MHz
- Rated Memory Speed: 2133MHz
- Memory Compliance: PC4-17000
- Form Factor: DIMM 288-pin
- Memory Slots: 8 (7 empty)
- Features: Registered, Online Spare Memory, Quad Channel Architecture, HP SmartMemory
- Configuration: 1 x 8GB
- Supported RAM: 128GB Registered, 256GB Load-Reduced
Storage Details
- Hard Drive: Not Included
- Optical Drive: Not Included
Storage Controller Information
- Controller Name: Smart Array H240
- Buffer Size: None
- Disk Drive Support: 12Gb/s SAS, 6Gb/s SATA
- SAS Port Link Rate: 12Gb/s per Physical Link
- Architecture: Serial Attached SCSI (SAS), Serial ATA (SATA)
- SAS Connectors: 2x4 Internal (Mini-SAS)
- Data Transfer Rate: 1.2Gb/s per Port, Up to 9.6Gb/s Combined
- Simultaneous Connections: 2 x 4 SAS Connectors
- Port Transfer Rate: 1.2Gb/s per x8 SAS Port
- Maximum Capacity: 144TB
- Memory Addressing: 64-bit
- RAID Support: RAID 0, 1, 5, 10, 50
Graphics and Display
- Graphics Type: Integrated
- Graphics Processor: Matrox G200eh2
- Video Interface: VGA
Networking and Communication
- Network Type: Integrated
- Interface Type: PCI Express 2.0 x2
- Ethernet Ports: 2 x Gigabit Ethernet
- Ethernet Controller: HP NC361i
- Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management: Integrated Lights-Out 4
- Features: Wake on LAN (WoL), PXE Support
- Compliance: IEEE 802.3, 802.3u, 802.3ab, 802.1as, 802.3az
Expansion and Connectivity
- Expansion Bays: 8 (8 free) x Hot-swap 3.5" LFF
- Expansion Slots:
- 2 (1 free) x CPU
- 8 (7 free) x DIMM 288-pin
- 3 (3 free) x PCIe 3.0 x16 (Low-profile)
- 2 (1 free) x PCIe 3.0 x8 (Low-profile)
- 1 (1 free) x MicroSD Card (Internal)
Interfaces and Ports
- Network Ports: 2 x Gigabit Ethernet
- Video Port: 1 x VGA
- USB Ports:
- 1 x USB 2.0 (Front)
- 2 x USB 3.0 (Rear)
- 1 x USB 3.0 (Internal)
Additional Features
- Included Accessories: HP Easy Install Rail Kit
- Security Features: Administrator Password, Power-on Password, UEFI BIOS
- Compliance: ACPI 2.0b, FCC Class A, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 4943, GB 9254, ASHRAE, CNS 13438, BSMI CNS 14336-1
Power and Dimensions
- Power Supply Type: Flex Slot Platinum Plus
- Installed Power Supplies: 1
- Voltage: AC 120/230V (50/60Hz)
- Power Output: 550W
- Dimensions:
- Depth: 24.97 inches
- Width: 18.98 inches
- Height: 3.45 inches
- Weight: 36.6 lbs
HPE 778641-B21 ProLiant DL80 G9 2U Rack Server
The HPE 778641-B21 ProLiant DL80 Gen9 is a cost-effective, high-performance 2U rack server designed for SMBs and enterprises seeking a balance of computing power, scalability, and efficiency. Powered by the Intel Xeon E5-2609 v3 processor, this server delivers reliable six-core processing at 1.90GHz, ensuring smooth multi-tasking capabilities for various workloads.
Key Features and Specifications
The HPE DL80 Gen9 server is engineered with a focus on affordability without compromising essential enterprise features. Below are its standout specifications:
Processor and Performance
Equipped with an Intel Xeon E5-2609 v3 processor, the HPE DL80 Gen9 offers six-core computing power with a base clock speed of 1.90GHz. Designed for high-efficiency performance, this processor supports demanding applications while maintaining power efficiency.
Intel Xeon E5-2609 v3 Capabilities
- Six cores and six threads for parallel processing.
- Clock speed of 1.90GHz with a 15MB SmartCache.
- Compatible with DDR4 memory technology for enhanced performance.
Memory and Expandability
The DL80 Gen9 supports DDR4 registered memory, providing higher data transfer rates and improved bandwidth over DDR3. It is designed for businesses that need scalable memory solutions.
Memory Expansion Options
- Supports up to 256GB of DDR4 RAM.
- Multiple DIMM slots for flexible memory configurations.
- Lower power consumption with DDR4 efficiency.
Storage Capabilities
The HPE ProLiant DL80 Gen9 offers various storage configurations, making it suitable for different workloads, including virtualization, data archiving, and cloud computing.
Drive Bay and RAID Support
- Supports both 3.5-inch and 2.5-inch drives.
- Compatible with SATA, SAS, and SSD storage options.
- Integrated RAID controller for data protection and redundancy.
Enterprise-Grade Reliability and Security
Designed with robust security features, the HPE DL80 Gen9 ensures data protection, minimal downtime, and efficient IT operations.
Redundant Power and Cooling
With hot-swappable power supplies and intelligent cooling mechanisms, the DL80 Gen9 provides seamless uptime even in high-demand environments.
Key Power and Cooling Benefits
- Redundant power supply units (PSUs) for failover protection.
- Advanced thermal sensors for optimal cooling.
- Reduced energy consumption for cost efficiency.
Security and Management Features
The DL80 Gen9 comes equipped with essential security mechanisms, including remote management capabilities, encryption, and BIOS security options.
Remote Management with iLO
- HPE Integrated Lights-Out (iLO) for remote monitoring and troubleshooting.
- Firmware and BIOS updates via iLO Advanced features.
- Enhanced security features to prevent unauthorized access.
Ideal Use Cases
The HPE ProLiant DL80 Gen9 is ideal for small to medium businesses, cloud environments, and data-intensive applications.
Common Workloads
- Web hosting and cloud applications.
- Virtualization with VMware and Hyper-V.
- File storage and database management.
Choose the HPE ProLiant DL80 Gen9
With enterprise-grade features at an affordable price point, the HPE ProLiant DL80 Gen9 is an excellent choice for businesses seeking performance, scalability, and reliability in a 2U rack server.
Key Advantages
- Cost-effective server solution with enterprise reliability.
- Scalable storage and memory options.
- Efficient power management and cooling.
Features
Manufacturer Warranty:
None
Product/Item Condition:
Excellent Refurbished
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
