HPE 800GB Smart Carrier SSD PCIe 765060-001
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Same product also available in:
SKU/MPN | Warranty | Price | Condition | You save |
---|---|---|---|---|
765060-001 | Six-Month (180 Days) | $792.67 | New (System) Pull | You save: $405.86 (34%) |
765060-001 | Six-Month (180 Days) | $110.07 | Excellent Refurbished | You save: $64.97 (37%) |
Main Specifications of Smart Carrier 800GB SSD
Brand Information
- Brand: HPE
- Part Number: 765060-001
- Device Type: Solid State Drive - Hot-Swap
Key Features
Storage Capacity and Dimensions
- Capacity: 800GB
- Form Factor: 2.5 inch SFF
- Plug Type: Hot Pluggable
Interface and Compatibility
- Interface: PCI Express 3.0 x4 (NVMe)
- Carrier Type: Smart Carrier NVMe (SCN)
- Supported Platforms: HPE ProLiant Rack, Tower, BladeSystem Servers, Synergy
Workload and Memory Type
- Workload Type: Write Intensive (WI)
- NAND Flash Memory: Multi-Level Cell (MLC)
- Bundled Accessory: HPE Smart Carrier NVMe (SCN)
Additional Features
- Power Loss Protection
- 15.00 mm (0.60 inch) Height
Performance Details
Endurance and Speed
- DWPD (Drive Writes Per Day): 10
- Max Sequential Read: 2600 MiB/s
- Max Sequential Write: 1700 MiB/s
Input/Output Operations per Second (IOPS)
- Random Read IOPS (4KiB, Q=16): 155,000
- Random Write IOPS (4KiB, Q=16): 99,000
Connectivity and Expansion
Interfaces and Bay Compatibility
- Interface: 1 x PCI Express 3.0 x4 (NVMe)
- Bay Compatibility: 2.5" SFF
Power Consumption
Operational Power Requirements
- Idle: 4.00 Watts
- Random Read: 8.87 Watts
- Random Write: 17.71 Watts
Sequential Power Usage
- Sequential Read: 9.29 Watts
- Sequential Write: 11.20 Watts
- Max Power Draw: 17.71 Watts
Environmental Specifications
Operating Temperature Range
- Minimum Operating Temperature: 32 °F
- Maximum Operating Temperature: 140 °F
Compatibility Information
Designed for the Following Models
HPE Nimble Storage Solutions
- dHCI Large Solution with HPE ProLiant DL380 Gen10 (2.5 inch)
HPE ProLiant DL Series
- DL360 Gen10 (Base, Entry, High Performance, Low, Performance, SMB, Solution)
- DL380 Gen10 (Base, Entry, Entry SMB, High Performance, Network Choice, Performance, SMB, Solution)
- DL388 Gen10 and DL388 Gen9 (Base Models)
- DL580 Gen9 (Database, SAP HANA Scale-out, and Scale-up Configurations)
HPE Synergy Series
- 480 Gen10 (Base, Entry, Performance, Premium Backplane, Standard Backplane, w/o Drives Compute Module)
Capacity: 800GB
One of the standout features of the HPE 765060-001 SSD is its impressive storage capacity of 800GB. This high capacity makes it an ideal choice for users who require ample space for storing their data and applications.
Benefits of a Large Capacity
Having a large storage capacity allows users to store a significant amount of data without worrying about running out of space. This is particularly important for businesses and organizations that deal with vast amounts of data on a daily basis.
With 800GB of storage, users can store a wide range of files, including documents, images, videos, and applications. This ensures that they have easy access to their data whenever they need it, without the need to constantly delete or transfer files to free up space.
Improved Performance
In addition to the convenience of having ample storage space, a larger capacity SSD can also contribute to improved performance. With more storage available, the SSD can distribute data across a larger number of memory cells, reducing the strain on individual cells and increasing overall performance.
Furthermore, larger-capacity SSDs often have higher write and read speeds compared to their lower-capacity counterparts. This means faster data transfer rates and quicker access to stored files, resulting in improved productivity for users.
Scalability and Future-Proofing
The 800GB capacity of the HPE 765060-001 SSD ensures that users have room for growth and future needs. As technology advances and file sizes continue to increase, having a larger capacity SSD allows users to adapt without the need for frequent upgrades or replacements.
By investing in a high-capacity SSD like the HPE 765060-001, users can future-proof their storage needs and avoid the hassle and cost of constantly upgrading to keep up with evolving storage demands.
Form Factor: PCIE
The HPE 765060-001 SSD features a PCI-Express form factor. This form factor offers several benefits and advantages for users seeking high-performance storage solutions.
Enhanced Speed and Performance
The PCIE form factor allows for faster data transfer rates compared to traditional SATA-based SSDs. With a direct connection to the computer's motherboard via the PCIE slot, the HPE 765060-001 SSD can take full advantage of the available bandwidth, resulting in significantly improved speed and performance.
Whether you are running resource-intensive applications, transferring large files, or performing data-intensive tasks, the PCIE form factor ensures that the HPE 765060-001 SSD can keep up with your demands, allowing for smoother and more efficient operations.
Compatibility and Versatility
Another advantage of the PCIE form factor is its widespread compatibility with modern computer systems. Most desktops, workstations, and servers are equipped with PCIE slots, making it easy to integrate the HPE 765060-001 SSD into your existing setup.
Furthermore, the PCIE form factor is also highly versatile. It can be used in a variety of applications and configurations, including RAID arrays, storage servers, and high-performance workstations. Its flexibility ensures that users can utilize the HPE 765060-001 SSD in a way that best suits their specific needs and requirements.
Scalability and Future-Proofing
The PCIE form factor also offers scalability options for users looking to expand their storage capacity in the future. Many motherboards feature multiple PCIE slots, allowing for easy installation of additional SSDs as the need for more storage arises.
By choosing the HPE 765060-001 SSD with the PCIE form factor, users can ensure that their storage solution is future-proofed and can easily accommodate their evolving storage requirements without major hardware changes or replacements.
Carrier: Smart Carrier
The HPE 765060-001 SSD is equipped with a Smart Carrier, adding an extra layer of convenience and functionality to its design.
Easy Installation and Hot-Swapping
The Smart Carrier simplifies the installation process of the HPE 765060-001 SSD. It features a user-friendly design that allows for easy insertion and removal of the SSD from compatible drive bays.
Furthermore, the Smart Carrier supports hot-swapping, which means that users can remove or replace the SSD without having to shut down the system. This is particularly beneficial for businesses and organizations that require uninterrupted operations and minimal downtime.
Enhanced Security and Monitoring
The Smart Carrier also offers enhanced security features. It includes built-in monitoring capabilities that allow users to keep track of important drive statistics, such as temperature, health status, and usage information.
This proactive monitoring helps users identify potential issues and take necessary actions before critical data loss or system failures occur. By staying informed about the health and performance of the HPE 765060-001 SSD through the Smart Carrier, users can ensure the longevity and reliability of their storage solution.
Compatibility and Integration
The Smart Carrier is designed to seamlessly integrate with HPE ProLiant servers and storage systems. This ensures compatibility and ease of integration for users who already have HPE infrastructure in place.
In addition, the Smart Carrier supports various management software tools provided by HPE, allowing for centralized control and monitoring of the HPE 765060-001 SSD alongside other components of the system. This streamlined management capability simplifies administration tasks and enhances overall system efficiency.
Overall, the Smart Carrier feature of the HPE 765060-001 SSD offers users a combination of convenience, security, and compatibility, making it an excellent choice for those seeking a reliable and user-friendly storage solution.
