HPE 804602-X21 800GB SATA 6GBPS 3.5" RI SSD
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
HPE 804602-X21 Solid State Drive Specifications
General Information
- Brand: HPE
- Model Number: 804602-X21
- Type: Hot-swappable Solid State Drive (SSD)
Key Features
- Storage Capacity: 800GB
- NAND Technology: MLC (Multi-level Cell)
- Form Factor: 3.5-inch Large Form Factor (LFF)
- Interface: SATA 6Gbps
- Firmware Security: Digitally Signed
- Carrier Type: HPE Smart Carrier Converter
- Workload Suitability: Optimized for Read-Intensive Tasks
- Hot Swap Capability: Yes
Performance Specifications
- Drive Endurance: 0.3 DWPD (Drive Writes Per Day)
- Data Transfer Speed: 6 Gb/sec (external)
- Sequential Read Speed: Up to 480 MiB/s
- Sequential Write Speed: Up to 465 MiB/s
- Random Read Latency: 110 µs (4KiB, Q1)
- Random Write Latency: 70 µs (4KiB, Q1)
- Random Read IOPS: 61,500 (4KiB, Q=16)
- Random Write IOPS: 15,500 (4KiB, Q=16)
- Max Random Read IOPS: 64,000 (4KiB, Q=32)
- Max Random Write IOPS: 15,500 (4KiB, Q=4)
- Mixed Performance (70% Read / 30% Write): 33,000 IOPS (4KiB, Q=32)
- Balanced Performance (50% Read / 50% Write): 24,500 IOPS (4KiB, Q=32)
Expansion & Connectivity
- Interface: SATA 6Gbps
- Compatible Drive Bay: 3.5" LFF (Large Form Factor)
Power Consumption
- Idle Power: 1.18 Watts
- Random Read Power: 3.83 Watts
- Random Write Power: 3.83 Watts
- Sequential Read Power: 2.82 Watts
- Sequential Write Power: 5.01 Watts
- Maximum Power Consumption: 3.83 Watts
Environmental Specifications
- Operating Temperature Range: 32°F to 158°F
- Shock Resistance (Operating): 1000 g @ 0.5 ms
Compatibility Information
Designed for HPE ProLiant DL Series
- DL180 Gen9 (3.5" LFF), DL180 Gen9 Base (3.5" LFF)
- DL180 Gen9 Entry (3.5" LFF), DL180 Gen9 Storage (3.5" LFF)
- DL20 Gen9 (3.5" LFF), DL20 Gen9 Entry (3.5" LFF)
- DL20 Gen9 Performance (3.5" LFF), DL320e Gen8 (3.5" LFF)
- DL320e Gen8 Base, Entry, Performance, and Special Server (3.5" LFF)
- DL320e Gen8 v2 (Base, Entry, Performance) (3.5" LFF)
- DL360e Gen8 (3.5" LFF), DL385p Gen8 Series
- DL388 Gen9 (Base, Storage) (3.5" LFF), DL80 Gen9 Entry (3.5" LFF)
Compatible with HPE ProLiant ML Series
- ML110 Gen9 (Base, Entry) (3.5" LFF)
- ML310e Gen8 (3.5" LFF), ML310e Gen8 Base and Entry
- ML310e Gen8 Performance (3.5" LFF), ML310e Gen8 v2 Series
- ML310e Gen8 v2 Base, Entry, Performance (3.5" LFF)
Capacity
The HPE 804602-X21 SSD offers a remarkable storage capacity of 800GB. This impressive amount of storage space ensures that users can store a wide range of data, including large files, applications, and multimedia content. With such a high capacity, users can have peace of mind knowing that they have ample space to accommodate their growing data needs.
Enhanced Performance
One of the key benefits of the 800GB capacity is the enhanced performance it provides. With a larger capacity, users can experience faster data transfer rates and quicker access to their stored files. This is particularly beneficial for professionals who work with large datasets or perform resource-intensive tasks. The increased storage capacity allows for smoother workflow and improved productivity.
Flexibility and Scalability
The 800GB capacity of the HPE 804602-X21 SSD offers users the flexibility to store a diverse range of data without worrying about running out of space. Whether it's documents, images, videos, or applications, users can conveniently manage their files and seamlessly expand their data storage as needed. This scalability is crucial for businesses and individuals who anticipate future growth or have fluctuating storage requirements.
Data Security and Reliability
Having a larger storage capacity allows users to keep important data on hand without the need for external drives or cloud storage. This reduces the risk of data loss, as it eliminates the reliance on external sources that may be susceptible to failures or security breaches. The 800GB capacity ensures that users can have their critical data readily accessible and protected within the reliable confines of the HPE 804602-X21 SSD.
Improved Efficiency
The ample storage space provided by the 800GB capacity allows users to organize their files more efficiently. With enough room to categorize and separate data based on relevance or usage, users can easily locate and retrieve specific files whenever needed. This streamlined workflow promotes efficiency and saves valuable time that would otherwise be spent searching for files in cluttered storage systems.
Cost-Effective Solution
By offering a substantial 800GB capacity, the HPE 804602-X21 SSD provides a cost-effective storage solution. Users can avoid the need to invest in multiple smaller capacity drives or frequent upgrades to accommodate their growing data needs. The 800GB capacity offers a balance between affordability and functionality, making it an ideal choice for both personal and professional users.
Future-Proof Storage
In today's fast-paced digital world, data storage requirements are constantly increasing. The 800GB capacity of the HPE 804602-X21 SSD ensures that users can future-proof their storage needs to a certain extent. With this higher capacity, users can confidently store their data without worrying about running out of space shortly.
Conclusion
The HPE 804602-X21 SSD's impressive 800GB capacity offers users enhanced performance, flexibility, scalability, data security, and improved efficiency. With its cost-effective nature and future-proof storage capabilities, this SSD is an excellent choice for individuals and businesses alike.
Interface
The HPE 804602-X21 SSD features a SATA 6GBPS interface, providing users with high-speed data transfer capabilities. This interface is widely recognized as one of the fastest and most reliable options available in the market today.
Fast Data Transfer
The SATA 6GBPS interface enables rapid data transfer rates, allowing users to move large files quickly between their SSD and other devices. Whether it's transferring multimedia content, backing up important files, or performing data-intensive tasks, the high-speed interface ensures minimal waiting time and swift completion of tasks.
Compatibility
The SATA 6GBPS interface is widely supported by various devices, making the HPE 804602-X21 SSD compatible with a wide range of systems. It offers seamless connectivity with desktop computers, laptops, servers, and other devices that have SATA interfaces. This compatibility ensures that users can easily integrate the SSD into their existing setups without any compatibility issues or additional hardware requirements.
Reliability and Durability
The SATA 6GBPS interface is known for its reliability and durability. It provides a stable connection between the SSD and the host device, minimizing the risk of data corruption or connection failures. The robust design of the interface ensures long-lasting performance, making it ideal for heavy users or demanding environments where data integrity and system stability are crucial.
Improved System Performance
The high-speed data transfer capabilities of the SATA 6GBPS interface contribute to improved overall system performance. With faster data transfers, applications load quicker, system boot times are reduced, and file access becomes almost instantaneous. This enhanced performance allows users to make the most out of their systems and enjoy a smooth computing experience.
Efficient Data Management
The SATA 6GBPS interface enables efficient data management by supporting advanced features such as Native Command Queuing (NCQ) and hot-swapping. NCQ optimizes the order in which commands are executed, reducing latency and improving overall performance. Hot-swapping allows users to connect or disconnect drives without restarting the system, enhancing convenience and flexibility in managing storage devices.
Backward Compatibility
The SATA 6GBPS interface is backward compatible with previous SATA generations, such as SATA 3GBPS and SATA 1.5GBPS. This means that users can still benefit from the high-speed interface even if their system or device only supports lower SATA versions. The backward compatibility ensures that the HPE 804602-X21 SSD can be used with a wide range of systems, regardless of their SATA interface capabilities.
Conclusion
The SATA 6GBPS interface of the HPE 804602-X21 SSD offers users fast data transfer rates, compatibility with various devices, reliability, and durability, improved system performance, efficient data management, and backward compatibility. With its high-speed capabilities and seamless integration into existing systems, this SSD is a reliable choice for users seeking optimal performance and connectivity.
Form Factor
The HPE 804602-X21 SSD features a 3.5-inch form factor, making it suitable for a wide range of applications and environments. The form factor refers to the physical dimensions and shape of the SSD, which plays a significant role in its compatibility and installation options.
Easy Installation
The 3.5-inch form factor allows for easy installation of the HPE 804602-X21 SSD in desktop computers or servers that have dedicated drive bays designed for this size. The standardized dimensions ensure a seamless fit without the need for additional adapters or modifications. Users can simply slide the SSD into the designated bay and secure it using standard mounting screws.
Compatibility
The 3.5-inch form factor is widely supported by various computer cases, server chassis, and storage systems. This compatibility ensures that users can easily integrate the HPE 804602-X21 SSD into their existing setups without any compatibility issues or the need for specialized hardware. Whether it's upgrading an existing system or building a new one, the 3.5-inch form factor provides flexibility and peace of mind.
Optimal Airflow and Cooling
The larger physical size of the 3.5-inch form factor allows for better airflow and cooling within the system. This is particularly important for high-performance systems or servers that generate significant heat during operation. The increased surface area of the SSD facilitates efficient heat dissipation, reducing the risk of overheating and extending the lifespan of the drive.
Space Utilization
The 3.5-inch form factor offers users an advantage in terms of space utilization. While smaller form factors may be more compact, they often sacrifice storage capacity or cooling capabilities. The larger size of the 3.5-inch form factor allows for a balance between storage capacity and efficient heat dissipation, making it a practical choice for users who prioritize both space utilization and optimal system performance.
Future Expansion
The 3.5-inch form factor provides users with ample room for future expansion. As technology advances and storage requirements increase, users may need to add additional drives to their systems. The 3.5-inch form factor ensures that users have sufficient space to accommodate future expansion without compromising on performance or compatibility.
Standardization
The 3.5-inch form factor is a widely adopted industry standard, ensuring that users can easily find compatible accessories or replacement drives when needed. This standardized size simplifies the process of upgrading or replacing SSDs, as users can choose from a wide range of options available in the market.
Conclusion
The 3.5-inch form factor of the HPE 804602-X21 SSD offers users easy installation, compatibility with various systems, optimal airflow and cooling, efficient space utilization, future expansion capabilities, and standardization. With its practical design and versatility, this SSD is an excellent choice for users seeking a reliable and adaptable storage solution.
Usage
The HPE 804602-X21 SSD is specifically designed for read-intensive workloads, making it ideal for applications that involve frequent data access and retrieval. This specific usage classification ensures that the SSD delivers optimal performance and durability in scenarios where read operations outnumber write operations.
Enhanced Read Performance
The read-intensive design of the HPE 804602-X21 SSD allows for enhanced read performance, ensuring quick access to stored data. Whether it's opening files, launching applications, or accessing databases, users can experience faster response times and reduced latency. This improved read performance significantly enhances overall system efficiency and user experience.
Data-Centric Applications
The read-intensive nature of the HPE 804602-X21 SSD makes it well-suited for data-centric applications that heavily rely on fast data access. This includes database servers, content delivery networks (CDNs), virtualization environments, and big data analytics platforms. In these applications, where read operations are dominant, the SSD can provide significant performance gains and improved data processing speeds.
Longevity and Endurance
The read-intensive design of the HPE 804602-X21 SSD ensures high endurance and longevity. Optimizing the SSD's architecture for read operations, it minimizes the wear and tear associated with frequent write operations. This extended lifespan is particularly beneficial for users who require consistent and reliable performance over an extended period without compromising on durability.
Reduced Total Cost of Ownership (TCO)
The read-intensive usage classification of the HPE 804602-X21 SSD offers users a reduced total cost of ownership (TCO) compared to other SSDs designed for mixed or write-intensive workloads. Since read-intensive applications primarily involve read operations, which are less demanding on the SSD's resources, the drive experiences less wear and require fewer replacements or upgrades. This results in lower maintenance costs and a longer lifespan, ultimately reducing the TCO for users.
Energy Efficiency
The read-intensive design of the HPE 804602-X21 SSD contributes to energy efficiency. Since read operations consume less power compared to write operations, the SSD's power consumption is optimized for maximum efficiency. This energy-efficient design not only reduces operating costs but also minimizes environmental impact by reducing carbon footprint.
Consistent Performance
The read-intensive design of the HPE 804602-X21 SSD ensures consistent performance even under heavy workloads. Whether it's handling multiple simultaneous read requests or dealing with high data access rates, the SSD maintains a high level of performance without compromising on data integrity or system stability. This reliability is crucial for users who rely on consistent and predictable performance for their critical applications or workflows.
Conclusion
The read-intensive usage classification of the HPE 804602-X21 SSD offers users enhanced read performance, suitability for data-centric applications, longevity, and endurance, reduced total cost of ownership, energy efficiency, and consistent performance. With its optimized design for read operations, this SSD is a reliable choice for users seeking exceptional performance and durability in read-intensive workloads.
