HPE 804608-B21 1.6TB SATA 3.5" LFF Digitally Signed Firmware Smart Carrier SSD

Overview of HPE 804608-B21 1.6TB SSD

The HPE 804608-B21 is a 1.6TB Solid State Drive (SSD) that is specifically designed for enterprise environments. Engineered for heavy workloads and optimized for read-intensive applications, this SSD provides reliability and performance.

Key Specifications

• Manufacturer: HPE
• Part Number : 804608-B21
• Device Type: Hot-Swap Solid State Drive (SSD)
• Capacity: 1.6 TB
• Form Factor: 3.5 inch LFF (Large Form Factor)
• Interface: SATA 6Gbps
• Flash Memory Type: MLC (Multi-Level Cell)
• Plug Type: Hot Pluggable
• Carrier Type: Smart Carrier Converter (SCC)
• Workload Type: Read Intensive

Advanced Features

• Power Loss Protection (PLP) ensures data safety during power outages
• Digitally Signed Firmware provides an added layer of security
• Bundled with HPE Smart Carrier Converter for enhanced compatibility

Performance Metrics

• Drive Writes Per Day (DWPD): 0.3
• Drive Transfer Rate: 6Gb/sec (external)
• Max Sequential Read Throughput: 480 MiB/s
• Max Sequential Write Throughput: 430 MiB/s
• Random Read IOPS (4KiB, Q16): 61,500
• Random Write IOPS (4KiB, Q16): 15,000

Latency and IOPS Performance

• Average Random Read Latency (4KiB, Q1): 110
• Average Random Write Latency (4KiB, Q1): 70
• Max Random Read IOPS (4KiB, Q32): 64,000
• Max Random Write IOPS (4KiB, Q4): 15,000
• 70% Read / 30% Write (4KiB, Q32): 31,500 IOPS
• 50% Read / 50% Write (4KiB, Q32): 24,000 IOPS

Physical Specifications

• Dimensions:
• Height: 5.63 inches
• Width: 3.75 inches
• Depth: 7.00 inches
• Weight: 1.35 lbs

Expansion & Connectivity

• 1 x SATA 6Gb/s interface
• Compatible Bay: 3.5" LFF (Large Form Factor)

Compatibility with HPE Systems

This HPE SSD is built for seamless integration with various HPE server platforms and storage solutions.

HPE ProLiant Rack & Tower Servers

• BL Series: BL420c (Gen8/Gen9), BL460c (Gen8/Gen9), BL465c (Gen8/Gen9)
• DL Series: DL20 (Gen9), DL60 (Gen9), DL80 (Gen9), DL120 (Gen8/Gen9), DL160 (Gen8/Gen9), DL180 (Gen8/Gen9), DL320e (Gen8/Gen9), DL360e (Gen8/Gen9), DL360p (Gen8/Gen9), DL380e (Gen8/Gen9), DL380p (Gen8/Gen9), DL388 (Gen9)
• ML Series: ML110 (Gen8/Gen9), ML150 (Gen8/Gen9), ML310e (Gen8/Gen9), ML350 (Gen8/Gen9), ML350e (Gen8/Gen9)

HPE Storage Arrays & StoreEasy Systems

• HPE Storage Arrays: D3600, D3700
• HPE StoreEasy: 1430, 1440, 1530, 1540, 1630, 1640

Capacity

The HPE 1.6TB SATA 3.5inch LFF Digitally Signed Firmware Smart Carrier SSD SSD boasts an impressive storage capacity of 1.6TB. This substantial amount of storage space allows users to store large volumes of data, ensuring they have enough room for their critical files and applications.

Increased Storage Flexibility

With a capacity of 1.6TB, users can enjoy increased storage flexibility. They can store a wide range of data types, including documents, images, videos, and applications, without worrying about running out of space. This flexibility is particularly beneficial for businesses that deal with large datasets or require extensive storage for their operations.

Enhanced Performance

The spacious 1.6TB capacity also contributes to enhanced performance. With ample storage space, the SSD can efficiently handle data read and write operations, resulting in faster access times and improved overall system performance. Users can expect quicker file transfers, reduced load times for applications, and smoother multitasking capabilities.

Scalability

The 1.6TB capacity of the HPE SSD allows for scalability. As businesses grow and their data requirements increase, this high-capacity SSD can accommodate their expanding storage needs without the need for frequent upgrades or additional hardware investments. This scalability ensures long-term usability and cost-effectiveness.

Form Factor

The HPE 1.6TB SATA 3.5-inch LFF Digitally Signed Firmware Smart Carrier SSD comes in a form factor of 3.5 inches, specifically designed for Large Form Factor (LFF) drive bays. This form factor offers several benefits and is crucial for users who require a reliable storage solution.

Compatibility

The 3.5-inch LFF form factor ensures compatibility with a wide range of server and storage systems that support this size. Users can easily install the SSD into their existing infrastructure without the need for additional modifications or adapters. This compatibility saves time and effort, enabling a seamless integration process.

Optimal Cooling and Space Utilization

The large form factor allows for better cooling capabilities compared to smaller-sized SSDs. The increased surface area of the 3.5-inch LFF SSD promotes better heat dissipation, ensuring the drive remains cool even during intense usage. Additionally, the large form factor optimizes space utilization within server racks or storage systems, allowing for efficient organization and management of multiple drives.

Higher Capacity Options

The 3.5-inch LFF form factor often supports higher capacity options compared to smaller form factors. This is especially beneficial for users who require extensive storage capabilities but have limited drive bay availability. With the HPE 1.6TB SATA 3.5-inch LFF SSD, users can maximize their storage capacity without sacrificing compatibility or performance.

Firmware

The firmware of the HPE 1.6TB SATA 3.5inch LFF Digitally Signed Firmware Smart Carrier SSD SSD is digitally signed, providing users with enhanced security and reliability.

Data Integrity and Protection

Digitally signed firmware ensures that the SSD operates with verified and authentic firmware, reducing the risk of unauthorized modifications or tampering. This feature enhances data integrity and protection, assuring users that their critical information remains secure and unaltered.

Protection against Malicious Attacks

Digitally signed firmware helps protect against malicious attacks aimed at compromising the SSD's performance or accessing sensitive data. By using authenticated firmware, users can mitigate the risks associated with unauthorized firmware alterations or malware injections, safeguarding their valuable information from potential threats.

Reliable Performance

The digitally signed firmware guarantees reliable performance by ensuring that the SSD operates with the intended firmware version. This eliminates the possibility of using outdated or incompatible firmware, which could result in compatibility issues, decreased performance, or system instability. Users can trust that their HPE 1.6TB SATA 3.5inch LFF SSD will consistently deliver optimal performance and reliability.

Smart Carrier

The HPE 1.6TB SATA 3.5inch LFF Digitally Signed Firmware Smart Carrier SSD SSD features a Smart Carrier design, providing users with added convenience and ease of use.

Effortless Installation

The Smart Carrier design simplifies the installation process, allowing users to quickly and easily install the SSD into their server or storage system. The carrier is designed to fit securely in drive bays, ensuring a snug fit and preventing any movement that could potentially damage the drive or impact its performance.

Hot-pluggable Capability

The Smart Carrier design enables hot-pluggable capability, meaning users can add or remove the SSD while the system is still running. This feature eliminates downtime and allows for easy maintenance or upgrades without interrupting critical operations. Users can seamlessly swap out the SSD as needed, ensuring continuous availability and minimal disruption to their workflow.

LED Indicators

The Smart Carrier is equipped with LED indicators that provide valuable information about the SSD's status. These indicators help users monitor drive activity, health, and potential issues in real time. By quickly identifying any problems or inconsistencies, users can take proactive measures to address them before they escalate, minimizing the risk of data loss or system downtime.

Part Number

The HPE 1.6TB SATA 3.5inch LFF Digitally Signed Firmware Smart Carrier SSD SSD has a unique part number - 804608-B21. This part number serves as an identifier and offers several benefits to users.

Accurate Ordering and Replacement

The part number ensures accurate ordering and replacement of the specific SSD model. It eliminates any confusion or ambiguity by providing a unique identifier that can be easily referenced when placing orders or requesting replacements. Users can be confident that they are receiving the exact product they require, eliminating the possibility of compatibility issues or incorrect substitutions.

Compatibility Verification

The part number allows for easy compatibility verification. Users can cross-reference the part number with their server or storage system's compatibility list to ensure that the SSD is compatible with their specific hardware configuration. This verification step saves time and effort, preventing potential issues that may arise from using incompatible components.

Product Support and Documentation

The unique part number facilitates product support and documentation. Users can easily refer to the part number when seeking assistance or accessing relevant documentation, such as user manuals, technical specifications, or firmware updates. This streamlined process ensures users have access to the necessary resources to maximize the performance and longevity of their HPE 1.6TB SATA 3.5inch LFF Digitally Signed Firmware Smart Carrier SSD SSD.
