Computer & Network Cables830697-S01 HPE Proliant Dl20 G9 Intel Xeon Quad-Core 3.0GHz 8GB DDR4 Server
830697-S01
* Product may have slight variations vs. image
Hover on image to enlarge
Brief Overview of 830697-S01
HPE 830697-S01 Intel Xeon Quad-Core E3-1220v5 Proliant Dl20 G9 - 3.0GHz 8GB DDR4 SDRAM Smart Array B140i 1GB 2-port 332i Network Adapter 290W RPS 1U Rack-Mountable Server. Excellent Refurbished with 1 year replacement warranty
Our Advantages
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
Payment Options
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Bank Transfer (11% Off)
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
Delivery
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Please sign in so that we can notify you about a reply
Description
Product Overview of HPE ProLiant DL20 Gen9 1U Rack Server
The Hewlett Packard Enterprise ProLiant DL20 Gen9 is a compact 1U rack-mountable server designed for small businesses, branch offices, and growing enterprises that require reliable performance, expandability, and efficient remote management. With its balance of computing power, flexible storage options, and advanced networking, this server is an excellent choice for organizations looking to optimize IT resources.
General Information
- Manufacturer: Hewlett Packard Enterprise (HPE)
- Part Number: 830697-S01
- Model Name: ProLiant DL20 Gen9 – 1U Rack Server
Processor & Chipset Specifications
CPU Details
- Processor Family: Intel Xeon E3-1200 Series
- Model: Intel Xeon E3-1220 v5
- Base Clock Speed: 3.0 GHz
- Cores: 4-core processing capability
- Processor Quantity: 1 installed
- Maximum Supported CPUs: 1
- Upgrade Capability: CPU is upgradable
- Chipset Used: Intel C232
Storage Controller
- Controller Type: 1 x RAID (PCIe x4)
- Interface: SATA 6Gb/s
- Model: HPE Dynamic Smart Array B140i
- Available Channels: 10
- Supported RAID Levels: RAID 0, RAID 1, RAID 5, RAID 10
Cache Memory
Advanced Cache Features
- Type: Smart Cache Technology
- Installed Cache: 8 MB
- Per-Processor Allocation: 8 MB
System Memory
Memory Configuration
- Pre-installed Memory: 8 GB
- Maximum Supported Memory: 64 GB
- Memory Type: DDR4 SDRAM
- Speed: 2133 MHz
- Form Factor: 288-pin DIMM
- Architecture: Dual-channel, unbuffered
- Included Module: 1 x 8 GB stick
Expansion & Connectivity
Expansion Bays
- 3.5-inch LFF External Bays: 2 (all available)
Expansion Slots
- DIMM Slots: 4 total / 3 free
- CPU Socket: 1 total / none free
- PCIe 3.0 x8 (half-length, low-profile): 1 / 1 free
- PCIe 3.0 x8 (half-length, full-height): 1 / 1 free
- MicroSD Card Slot: 1 / 1 free
- FlexibleLOM Slot: 1 / 1 free
Storage Options
Internal Storage
- Pre-installed Hard Drives: None included
- Optical Drives: Not provided
Graphics Controller
Integrated Display Capabilities
- Graphics Processor: Matrox G200 (embedded)
Networking and Communication
Ethernet and Remote Management
- Bus Interface: PCI Express x2
- Ethernet Ports: 2 x Gigabit Ethernet
- Controller: HPE NC332i
- Protocols Supported: Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Tool: Integrated Lights-Out 4 (iLO 4)
- Network Features: Wake-on-LAN (WOL), PXE boot support
- Compliance: IEEE 802.3, 802.3u, 802.3ab
Interfaces and Ports
Available Connections
- 1 x VGA port
- 2 x Gigabit LAN ports
- 2 x USB 2.0 (front-facing)
- 3 x USB 3.0 (rear-facing)
Included Accessories & Standards
Package Contents
- HPE Short Friction Rail Kit
Certifications & Standards
- FCC Class A
- EN 61000-3-2, EN 61000-3-3
- EN55022, EN55024
- ICES-003
- CISPR 22
- IEC 60950-1, EN 60950-1
- GB 9254
- ASHRAE
- CNS 13438
- K22, K24 compliance
Manufacturer Program
Supported under HPE Smart Buy program for cost-efficient enterprise procurement.
Power Efficiency
Power Supply Specifications
- Power Device: Single power supply unit
- Quantity Installed: 1
- Maximum Supported Units: 1
- Input Voltage: AC 120/230 V, 50/60 Hz
- Power Output: 290 Watts
Dimensions and Weight
Physical Characteristics
- Width: 17.11 inches
- Depth: 15.05 inches
- Height: 1.7 inches
- Weight: 17.37 lbs
Key Highlights of HPE 830697-S01 ProLiant DL20 G9
- Equipped with Intel Xeon Quad-Core 3.0GHz processor for efficient performance
- 8GB DDR4 RAM ensuring faster multitasking and smooth operation
- Compact 1U rack design to save space in data centers
- Energy-efficient components for reduced operational costs
- High scalability options for future business growth
Performance Capabilities
This server is engineered for demanding workloads with cutting-edge processor architecture and next-generation memory. The Intel Xeon CPU delivers reliable processing, while DDR4 technology ensures faster response times and reduced latency.
Processor Features
- Intel Xeon Quad-Core 3.0GHz for consistent computing power
- Improved instruction sets for intensive applications
- Optimized cache memory to enhance data handling
Memory Advantages
- 8GB DDR4 RAM pre-installed with expansion slots available
- Increased memory bandwidth compared to DDR3 technology
- Lower energy consumption while maintaining speed and performance
Design and Build Quality
The HPE ProLiant DL20 Gen9 combines compactness with durability. Its 1U chassis allows easy installation in standard rack environments, while the build quality ensures long-term reliability in business-critical tasks.
Space-Saving Rack Format
- 1U rackmount chassis suitable for limited-space server rooms
- Easy maintenance with modular components
- Flexible design supporting various configurations
Storage and Expansion Options
The DL20 G9 offers multiple storage configurations, allowing IT professionals to select between HDD or SSD options depending on performance needs. Expandability ensures the system can adapt as your business grows.
Scalable Storage Choices
- Support for hot-swappable drives
- Multiple storage bays for HDD and SSD integration
- RAID support for improved data protection
Network Connectivity and Management
Integrated network interfaces provide smooth connectivity for data exchange. The DL20 G9 also supports remote management features, enabling IT staff to monitor performance efficiently.
Connectivity Features
- Multiple Gigabit Ethernet ports for seamless networking
- Optional upgrades for improved bandwidth
- Enhanced data security features
Management Tools
- HPE Integrated Lights-Out (iLO) for remote server management
- Advanced monitoring and troubleshooting capabilities
- User-friendly interface for quick deployment
Energy Efficiency and Reliability
HPE prioritizes sustainability with components that reduce power consumption without compromising performance. Reliability ensures consistent uptime, making it a dependable server for mission-critical operations.
Efficiency Features
- Energy-efficient power supply units
- Optimized cooling systems to maintain stable operation
- Cost savings on long-term energy consumption
Reliability Standards
- Proven enterprise-grade durability
- Rigorous quality testing from HPE
- Enhanced server uptime with robust hardware
Features
Manufacturer Warranty:
None
Product/Item Condition:
Excellent Refurbished
ServerOrbit Replacement Warranty:
1 Year Warranty
