HPE Proliant ML110 Gen9 840665-S01 Tower Server, 1x Intel Xeon 6-core E5-2603v4, 8SFF, 1TB HDD, B140i, 550w

Processor

The HPE Proliant ML110 Gen9 Tower Server is equipped with an impressive Intel Xeon 6-core E5-2603v4 processor, making it a powerful and reliable choice for businesses of all sizes. This processor offers a range of benefits and features that are essential for users looking for high-performance computing.

General Details

Manufacturer Information

• Manufacturer: Hewlett Packard Enterprise
• Manufacturer Part Number: 840665-S01
• Product Name: Proliant ML110 Gen9 - 5U Tower Server (Smart Buy)

Processor & Chipset Details

Processor Specifications

• Processor Type: Intel Xeon E5-2603v4, 1.7 GHz
• Quickpath Interconnect Speed: 6.4 GT/s
• Core Count: 6-core
• 64-bit Architecture: Yes
• Compatible Socket: FCLGA2011-3
• Installed Quantity: 1
• Maximum Supported Quantity: 1

Cache Memory Specifications

Cache Details

• Cache Memory Type: Smart Cache
• Installed Size: 15 MB
• Cache Per Processor: 15 MB

Memory Configuration

Memory Details

• Installed Memory Size: 8 GB / 256 GB (maximum)
• Memory Technology: DDR4 SDRAM - Advanced ECC
• Memory Speed: 1866 MHz
• Memory Specification Compliance: PC4-19200
• Form Factor: DIMM 288-pin
• Features: Registered, Online Spare Memory, HP SmartMemory
• Configuration: 1 x 8 GB
• Supported RAM: PC4-17000 - 128 GB - Load-reduced; PC4-19200 - 256 GB - Registered

Storage Options

Hard Drive Specifications

• Type: HDD - Hot-swap
• Capacity: 1 x 1 TB
• Interface: SATA 6 Gb/s
• Spindle Speed: 7200 RPM
• Features: Midline

Optical Drive

• Type: DVD-RW - SATA

Storage Controllers

• Controller Name: Smart Array B140i
• Buffer Size: None
• Disk Drive: Up to 6 Gb/s SATA (Serial ATA)
• Connectors: 10 Internal SATA Connectors
• Server Interface: x4 PCIe 2.0
• SATA Speed: 6 Gb/s SATA Links
• Logical Drives Supported: Up to 8 Logical Volumes (6 Physical Drives)
• Host Memory Addressing: 64-bit, Supporting Greater Than 4 GB Server Memory Space
• RAID Support: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50

Display & Graphics

Graphics Processor

• Graphics Processor: None

Network & Communication

Networking Features

• Networking Type: Integrated
• Interface (Bus) Type: PCI Express x2
• Ethernet Ports: 2 x Gigabit Ethernet
• Ethernet Controller: HP 330i
• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 4
• Features: Wake On LAN (WOL), PXE Support
• Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Power Specifications

Power Supply Details

• Device Type: Power Supply
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• Nominal Voltage: AC 100-230V (50/60 Hz)
• Power Provided: 550 Watt

Expansion & Connectivity

Expansion Bays

• Total Bays (Free): 1 (total) / 0 (free) x External 5.25
• Total Bays (Free): 8 (total) / 7 (free) x Hot-swap 2.5 SFF

Expansion Slots

• Total Slots (Free): 8 (total) / 7 (free) x DIMM 288-pin
• Total Slots (Free): 1 (total) / 0 (free) x CPU
• Total Slots (Free): 2 (total) / 2 (free) x PCIe 3.0 x8 - Half-length, Full-height
• Total Slots (Free): 2 (total) / 2 (free) x PCIe 3.0 x4 - Half-length, Full-height
• Total Slots (Free): 1 (total) / 1 (free) x PCIe 3.0 x16 - Three-quarter-length, Full-height
• Total Slots (Free): 1 (total) / 1 (free) x MicroSD Card (internal)

Interfaces & Ports

• VGA Port: 1 (rear)
• LAN Ports: 2 x Gigabit Ethernet
• HP iLO Port: 1
• USB 3.0 Ports: 5 (2 front, 2 rear, 1 internal)
• USB 2.0 Ports: 3 (2 rear, 1 internal)

Dimensions & Weight

• Depth: 23.62 inches
• Width: 12.99 inches
• Height: 22.24 inches
• Weight: 33.28 lbs

Enhanced Performance

The Intel Xeon 6-core E5-2603v4 processor provides exceptional performance capabilities. With a base clock speed of 1.7 GHz and a maximum turbo frequency of 2.6 GHz, this processor delivers fast and efficient processing power, allowing users to handle demanding workloads with ease. Whether you're running complex applications, performing data analysis, or managing multiple virtual machines, this processor can handle it all.

Improved Multitasking

Multitasking is an essential requirement for many businesses, and the Intel Xeon 6-core E5-2603v4 processor excels in this area. With its six cores and twelve threads, this processor can efficiently handle multiple tasks simultaneously. This means you can run multiple applications without experiencing any lag or performance issues, ensuring smooth and uninterrupted workflow.

Energy Efficiency

Energy efficiency is a crucial consideration for any modern server. The Intel Xeon 6-core E5-2603v4 processor is designed with power-saving features that help reduce energy consumption without sacrificing performance. This not only helps businesses save on their energy bills but also minimizes their environmental impact.

Intel Turbo Boost Technology

The Intel Xeon 6-core E5-2603v4 processor features Intel Turbo Boost Technology, which dynamically increases the processor's frequency as needed. This technology allows the processor to deliver extra performance when required, ensuring optimal performance during peak workloads.

Intel Hyper-Threading Technology

Intel Hyper-Threading Technology enables each core of the processor to handle two threads simultaneously. This technology effectively doubles the number of execution threads, allowing for improved multitasking and faster task completion.

Smart Cache

The Intel Xeon 6-core E5-2603v4 processor comes with a smart cache of 15MB. Smart cache is a shared pool of memory that the processor can access quickly, reducing data latency and improving overall performance. This ensures that data-intensive tasks and applications can be processed efficiently, resulting in faster response times.

Reliability and Stability

The Intel Xeon 6-core E5-2603v4 processor is renowned for its reliability and stability. It is built with high-quality components and undergoes rigorous testing to ensure maximum uptime and minimal system failures. This level of reliability is critical for businesses that rely on their servers to operate without interruption.

Future Proofing

Investing in a server with the Intel Xeon 6-core E5-2603v4 processor ensures future-proofing your infrastructure. As technology advances, having a powerful processor becomes increasingly important. The Intel Xeon 6-core E5-2603v4 processor provides enough processing power to handle future software advancements and increasing workloads, ensuring your server remains relevant and capable for years to come.

Drive Bays

The HPE Proliant ML110 Gen9 Tower Server features 8SFF (Small Form Factor) drive bays, providing users with versatile storage options. The drive bays offer numerous benefits and are essential for businesses seeking efficient storage solutions.

Flexible Storage Configuration

The 8SFF drive bays allow for flexible storage configuration options, enabling users to customize their server's storage capacity according to their specific needs. Whether you require high-capacity storage for large files or need to set up a RAID configuration for data redundancy, the 8SFF drive bays provide the necessary flexibility to accommodate various storage requirements.

Space Efficiency

With 8SFF drive bays, the HPE Proliant ML110 Gen9 Tower Server maximizes space efficiency. The small form factor design allows for a compact storage solution without compromising on storage capacity. This is particularly beneficial for businesses with limited physical space or those looking to optimize their server room layout.

Easy Hot-Swap Capability

The 8SFF drive bays feature hot-swap capability, allowing users to replace or upgrade drives without shutting down the server. This feature significantly reduces downtime and improves system availability. It is particularly valuable in scenarios where uninterrupted access to data is critical, such as in enterprise environments or mission-critical applications.

Efficient Data Management

The 8SFF drive bays enable efficient data management through various features and technologies. Users can easily implement RAID configurations to enhance data protection and improve performance. Additionally, the small form factor design of the drive bays allows for efficient cable management, reducing clutter and ensuring optimal airflow within the server.

Scalability

The 8SFF drive bays provide scalability options for future storage expansion. As your business grows and your storage needs increase, you can easily add more drives to accommodate the additional data. This scalability ensures that your server can adapt to changing requirements without the need for significant hardware upgrades or replacements.

High-Speed Storage

The 8SFF drive bays support high-speed storage technologies such as solid-state drives (SSDs). SSDs offer significantly faster read and write speeds compared to traditional hard disk drives (HDDs), resulting in improved overall system performance. By utilizing the 8SFF drive bays for SSD storage, users can experience faster data access and reduced latency.

Reliability and Data Redundancy

The 8SFF drive bays allow for the implementation of RAID configurations, which provide data redundancy and increased reliability. RAID (Redundant Array of Independent Disks) allows multiple drives to work together, ensuring that data remains accessible even if one drive fails. This redundancy is critical for businesses that cannot afford to lose valuable data due to drive failures.

Storage Capacity

The HPE Proliant ML110 Gen9 Tower Server is equipped with a 1TB HDD (Hard Disk Drive), offering ample storage capacity for a wide range of applications and data storage needs. The storage capacity of this server is important for users who require significant storage space for their files and applications.

Large Data Storage

The 1TB HDD provides a substantial amount of storage space, allowing users to store large amounts of data without running out of capacity. This is particularly beneficial for businesses that work with large files, such as multimedia content, databases, or virtual machine images. With 1TB of storage, you have sufficient room to accommodate your growing data requirements.

Cost-Effective Solution

The 1TB HDD offers a cost-effective storage solution compared to other high-capacity storage options such as solid-state drives (SSDs). HDDs generally have a lower cost per gigabyte compared to SSDs, making them an ideal choice for businesses on a budget or those needing large amounts of storage without the need for ultra-fast access speeds.

Data Security and Backup

Having ample storage capacity enables users to maintain proper data security and backup practices. With a 1TB HDD, you can create regular backups of critical files and applications, ensuring that your data remains safe and easily recoverable in the event of data loss or system failures. This is crucial for business continuity and minimizing downtime.

Performance Optimization

The 1TB HDD is designed to deliver reliable and consistent performance. Although HDDs are generally slower than SSDs, they still provide sufficient speed for most business applications and data storage needs. With proper optimization and efficient storage management, you can ensure that your server's performance remains optimal, even with a large amount of data stored on the 1TB HDD.

Expandable Storage

The 1TB HDD offers expandable storage options for future growth. If your storage requirements increase over time, you can easily add additional hard drives to the server, either by utilizing available drive bays or through external storage solutions. This scalability ensures that your server can accommodate your evolving storage needs without the need for significant hardware upgrades or replacements.

Data Accessibility

The 1TB HDD provides easy access to stored data, allowing users to retrieve files and applications quickly when needed. Whether you're running databases, hosting websites, or storing multimedia content, having fast and reliable access to your data is essential for efficient business operations. The 1TB HDD ensures that your data remains accessible without any significant delays or performance bottlenecks.

Data Organization and Management

Efficient data organization and management are vital for businesses dealing with large amounts of data. The 1TB HDD allows users to create logical partitions and folders, making it easier to organize and manage files based on their relevance or specific projects. This improves overall productivity and ensures that data is easily locatable when required.

RAID Controller

The HPE Proliant ML110 Gen9 Tower Server comes with a B140i RAID controller, offering users enhanced data protection, improved performance, and increased storage flexibility. The RAID controller is a critical feature for businesses that require robust data management and storage capabilities.

Data Protection and Redundancy

The B140i RAID controller provides data protection and redundancy through various RAID configurations. RAID (Redundant Array of Independent Disks) allows multiple drives to work together, creating a logical unit that offers increased reliability and data redundancy. In the event of a drive failure, the RAID controller ensures that data remains accessible, minimizing potential downtime and data loss.

Improved Performance

The B140i RAID controller enhances server performance by utilizing multiple drives in parallel. By spreading data across multiple drives, the RAID controller allows for faster read and write speeds, resulting in improved overall system performance. This is particularly beneficial for applications that require fast data access, such as databases or virtual machines.

Storage Flexibility

The B140i RAID controller offers storage flexibility by supporting various RAID levels. Users can choose the appropriate RAID level based on their specific requirements, balancing data protection, performance, and storage capacity. Whether you need maximum redundancy with RAID 1 or increased performance with RAID 0, the B140i RAID controller allows you to configure your storage solution accordingly.

RAID Levels

The B140i RAID controller supports multiple RAID levels, including RAID 0, RAID 1, and RAID 5. Each RAID level offers different advantages:

- RAID 0: This level provides improved performance by striping data across multiple drives. However, there is no redundancy, so a single drive failure can result in data loss.
- RAID 1: This level mirrors data across two drives, providing complete redundancy. If one drive fails, the other drive can still function without any loss of data.
- RAID 5: This level combines striping and parity for improved performance and data protection. Data is distributed across multiple drives, and parity information is stored for redundancy. If one drive fails, the system can rebuild the data using the parity information.

Hot-Swap Capability

The B140i RAID controller supports hot-swapping, allowing users to replace or add drives without shutting down the server. This feature minimizes downtime and ensures uninterrupted access to data. Hot-swapping is particularly valuable in environments where continuous data availability is crucial, such as in enterprise settings or mission-critical applications.

Easy Configuration and Management

The B140i RAID controller offers an intuitive interface for easy configuration and management of RAID arrays. Users can access the controller's settings and options through a user-friendly interface, allowing for hassle-free setup and maintenance of their storage solution. This simplifies the overall management process and reduces the time required for routine tasks.

Scalability

The B140i RAID controller provides scalability options for future storage expansion. As your storage needs grow, you can easily add more drives to your RAID configuration, increasing storage capacity without significant hardware upgrades or replacements. This scalability ensures that your server can adapt to changing requirements without compromising data integrity or system performance.

Power Supply

The HPE Proliant ML110 Gen9 Tower Server is equipped with a 550w power supply, offering users a reliable and efficient power source. The power supply is a critical component of any server, ensuring stable operation and preventing unexpected downtime.

Stable Power Delivery

The 550w power supply provides stable and consistent power delivery to the server's components. A stable power supply is crucial for reliable server operation, as fluctuations or interruptions in power can lead to system crashes, data corruption, or even hardware failures. With a 550w power supply, you can be confident that your server will receive the necessary power for optimal performance.

Energy Efficiency

The 550w power supply is designed with energy efficiency in mind. It meets industry standards for energy efficiency, helping businesses reduce their carbon footprint and save on energy costs. Energy-efficient power supplies convert more of the incoming power into usable energy, minimizing wasted energy and reducing heat generation. This results in lower electricity bills and a more environmentally friendly server infrastructure.

Redundant Power Supply Option

The HPE Proliant ML110 Gen9 Tower Server offers the option for redundant power supplies. Redundant power supplies provide an additional layer of protection against power failures. In the event of a power supply failure, the redundant power supply automatically takes over, ensuring uninterrupted server operation. This is particularly important for businesses that cannot afford any downtime or data loss due to power-related issues.

Power Monitoring and Management

The 550w power supply features integrated power monitoring and management capabilities. This allows users to monitor power consumption, voltage levels, and other power-related parameters to ensure optimal performance and efficiency. Additionally, the power supply supports remote management, enabling users to control and manage power settings remotely, further enhancing convenience and ease of use.

Reduced Heat Generation

Efficient power supplies like the 550w unit help minimize heat generation within the server. Excessive heat can damage components and degrade system performance. By efficiently converting incoming power into usable energy, the 550w power supply reduces heat output, ensuring that your server operates within optimal temperature ranges. This improves overall system reliability and extends component lifespan.

Compatibility and Reliability

The 550w power supply is specifically designed for the HPE Proliant ML110 Gen9 Tower Server, ensuring compatibility and reliable operation. It undergoes rigorous testing to meet industry standards for quality and reliability. Investing in a high-quality power supply is essential for maintaining server uptime and preventing unexpected power-related issues.

Power Redundancy

With the option for redundant power supplies, the HPE Proliant ML110 Gen9 Tower Server can achieve power redundancy. Redundant power supplies ensure that your server remains operational even if one power supply fails. This redundancy is critical for businesses that require continuous availability and cannot afford any downtime or data loss due to power failures.

Protection Against Power Surges

The 550w power supply provides protection against power surges and fluctuations. Power surges can occur due to lightning strikes, utility issues, or other external factors. These surges can damage sensitive electronic components and lead to system failures. The 550w power supply is equipped with built-in surge protection mechanisms, safeguarding your server against sudden voltage spikes and ensuring its long-term reliability.

In conclusion, the HPE Proliant ML110 Gen9 Tower Server offers an impressive range of features and capabilities, making it an ideal choice for businesses in need of a reliable and powerful server solution. From the Intel Xeon 6-core E5-2603v4 processor to the 8SFF drive bays, and from the 1TB HDD to the B140i RAID controller and 550w power supply, each feature plays a crucial role in delivering exceptional performance, storage flexibility, data protection, and system reliability. With its emphasis on performance, scalability, and energy efficiency, the HPE Proliant ML110 Gen9 Tower Server meets the demands of modern businesses while providing a future-proof solution for evolving IT requirements.
