HPE Proliant DL380 Gen9 1x Intel Xeon E5-2650V4/ 2.2GHz, 32GB DDR4 SDRAM, P440AR 2GB FBWC, 8SFF, 4X HPE 331i Gigabit Ethernet, 2X 500W PS 2U Server - 850519-S01

Processor

The HPE Proliant DL380 Gen9 Smart Buy Server is equipped with an impressive Intel Xeon 12-Core E5-2650V4/ 2.2GHz processor, making it a powerful and efficient choice for a variety of computing needs.

Product Overview of DL380 Gen9

Discover the Hewlett Packard Enterprise Proliant DL380 Gen9 server, a versatile 2U rack-mountable solution designed for performance and reliability. Ideal for businesses needing robust computing power.

General Specifications

• Manufacturer: Hewlett Packard Enterprise
• Part Number: 850519-S01
• Model: Proliant DL380 Gen9 - Smart Buy

Processor and Chipset

• Processor: Intel Xeon E5-2650v4
• Base Clock Speed: 2.2 GHz
• Max Turbo Speed: 2.9 GHz
• Number of Cores: 12 cores
• Quantity: 1 (upgradable to 2)
• Key Technologies: Hyper-Threading, Intel Turbo Boost Technology 2.0

Cache Memory

• Cache Type: Smart Cache
• Installed Size: 30 MB
• Per Processor Cache: 30 MB

Memory Specifications

• Installed Capacity: 32 GB (expandable up to 768 GB)
• Memory Technology: DDR4 SDRAM with Advanced ECC
• Speed: 2400 MHz
• Compliance: PC4-19200
• Form Factor: DIMM 288-pin
• Features: Registered, Online Spare, Quad Channel Architecture, HP SmartMemory

Storage and Controllers

• Hard Drive: Not included

Storage Controller

• Controller: Smart Array P440ar
• Buffer Size: 2 GB
• Supported Drives: Up to 26 drives
• Supported RAID Levels: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM

Graphics and Display

• Graphics Controller: Integrated Matrox G200eh2
• Video Memory: 16 MB

Network and Communication

• Ethernet Ports: 2 x 10 Gigabit Ethernet, 4 x Gigabit Ethernet
• Controller: HP 331i
• Protocols Supported: Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4
• Features: Wake on LAN (WoL), PXE Support
• Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Expansion and Connectivity

• Hot-Swap Bays: 8 total (all free) for 2.5" SFF drives

Expansion Slots

• CPU Slots: 2 total, 1 free
• DIMM Slots: 24 total, 22 free
• PCIe Slots: 2 x PCIe 3.0 x16 (half-length, full-height, X8 mode), 1 x PCIe 3.0 x8 (half-length, full-height)
• MicroSD Card Slot: 1 internal, free

Interfaces and Ports

• LAN Ports: 4 x Gigabit Ethernet (RJ-45)
• HP iLO Port: 1 (RJ-45)
• VGA Port: 1
• USB Ports: 5 x USB 3.0 (1 front, 2 rear, 2 internal)

Miscellaneous Information

• Compliance Standards: ACPI 2.0b, FCC Class A, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
• Manufacturer's Program: HPE Smart Buy

Power Specifications

• Type: Hot-plug Power Supply
• Redundancy: Yes, 1+1 scheme
• Installed Quantity: 2
• Maximum Supported: 2
• Nominal Voltage: AC 120/230 V
• Power Output: 500 Watts
• 80 Plus Certification: 80 Plus Platinum
• Efficiency: 94%

Dimensions and Weight

• Width: 17.5 inches
• Depth: 26.7 inches
• Height: 3.4 inches
• Weight: 32.54 lbs

Enhanced Performance

The Intel Xeon 12-Core E5-2650V4/ 2.2GHz processor delivers exceptional performance, allowing for faster data processing and improved multitasking capabilities. With its high clock speed and multiple cores, this processor can handle demanding workloads with ease.

Increased Productivity

By utilizing the power of the Intel Xeon processor, users can experience enhanced productivity. The processor's efficient performance enables faster response times and smoother operation, allowing users to complete tasks more quickly and efficiently.

Improved Scalability

The HPE Proliant DL380 Gen9 Smart Buy Server's Intel Xeon 12-Core E5-2650V4/ 2.2GHz processor offers excellent scalability, providing room for growth and future expansion. Whether you're running resource-intensive applications or handling large amounts of data, this processor can handle the workload without compromising on performance.

Memory

The HPE Proliant DL380 Gen9 Smart Buy Server features 32GB(2X16) DDR4 SDRAM memory, offering significant benefits in terms of speed, capacity, and reliability.

Fast and Efficient Data Processing

With 32GB of DDR4 SDRAM memory, this server can efficiently process large amounts of data at high speeds. The increased memory capacity allows for smoother multitasking and faster response times, ensuring that your applications run smoothly without any delays or performance bottlenecks.

Improved System Stability

DDR4 SDRAM memory provides improved system stability by reducing the chances of data corruption and system crashes. This ensures that your server remains reliable and operational even under heavy workloads, allowing you to focus on your tasks without worrying about system failures.

Future-Proofing

The 32GB DDR4 SDRAM memory in the HPE Proliant DL380 Gen9 Smart Buy Server offers future-proofing capabilities. As technology advances and applications become more demanding, having ample memory ensures that your server can meet the requirements of future software updates and expansions.

Storage

The HPE Proliant DL380 Gen9 Smart Buy Server is equipped with a P440AR with 2GB FBWC and 8SFF storage configuration, providing ample storage capacity and advanced features for data management.

High Storage Capacity

With the P440AR storage controller and 8SFF drive bays, this server offers significant storage capacity for your data-intensive applications. Whether you need to store large databases, media files, or virtual machine images, the HPE Proliant DL380 Gen9 can accommodate your needs.

Improved Data Protection

The P440AR storage controller with 2GB FBWC (Flash Backed Write Cache) provides advanced data protection features. The FBWC ensures that any writes to the storage are safely stored in cache before being written to the drives, reducing the risk of data loss in case of power failures or system crashes.

Enhanced Data Management

The P440AR storage controller also offers advanced data management features such as RAID support, allowing you to configure your drives for improved performance or data redundancy. This enables you to optimize your storage setup based on your specific needs and provides peace of mind knowing that your data is protected.

Networking

The HPE Proliant DL380 Gen9 Smart Buy Server is equipped with 4X HPE 331i Gigabit Ethernet, offering reliable and high-speed networking capabilities for your business needs.

Fast and Reliable Network Connectivity

With four HPE 331i Gigabit Ethernet ports, this server provides fast and reliable network connectivity. Whether you need to transfer large files, host virtual machines, or run network-intensive applications, the HPE Proliant DL380 Gen9 can handle the workload without compromising on performance.

Optimized Network Performance

The HPE 331i Gigabit Ethernet adapter offers advanced features such as TCP/IP Offloading and jumbo frame support, optimizing network performance and reducing CPU utilization. This ensures that your server can efficiently handle network traffic without impacting overall system performance.

Scalable Networking Solution

With four Gigabit Ethernet ports, the HPE Proliant DL380 Gen9 provides scalability for your networking needs. You can easily expand your network infrastructure by adding additional switches or connecting to higher-speed networks, ensuring that your server can accommodate future growth and demands.

Power Supply

The HPE Proliant DL380 Gen9 Smart Buy Server is equipped with two 500W power supplies, ensuring reliable and efficient power delivery to the system.

Redundancy and Reliability

The dual power supply configuration provides redundancy and enhances system reliability. In the event of a power supply failure, the second power supply will seamlessly take over, preventing any downtime or data loss. This feature is crucial for businesses that require constant availability and cannot afford interruptions or hardware failures.

Efficient Power Management

The 500W power supplies in the HPE Proliant DL380 Gen9 are designed for efficient power management. With high-efficiency ratings, these power supplies consume less energy and generate less heat, resulting in lower operating costs and a reduced environmental footprint.

Modular and Upgradeable

The modular design of the power supplies allows for easy replacement or upgrade without disrupting the server's operation. This flexibility ensures that you can adapt the power supply configuration to your changing needs, whether it's adding more power supplies for increased redundancy or upgrading to higher-capacity units as your server requirements grow.

Form Factor

The HPE Proliant DL380 Gen9 Smart Buy Server features a 2U form factor, offering a balance between compactness and expandability.

Space Efficiency

With its 2U form factor, the HPE Proliant DL380 Gen9 can fit into standard server racks without occupying excessive space. This is especially beneficial for businesses with limited server room or data center space, allowing them to maximize their capacity and efficiently utilize the available resources.

Expandability

Despite its compact size, the 2U form factor of the HPE Proliant DL380 Gen9 doesn't compromise on expandability. It provides ample room for additional storage drives, expansion cards, and other peripherals, ensuring that you can scale your server according to your evolving needs without facing any constraints.

Ease of Maintenance

The 2U form factor also facilitates easy maintenance and servicing. The server components are easily accessible, allowing for quick replacement or upgrades without the need to disassemble the entire system. This reduces downtime and enhances the overall manageability of the server, saving valuable time and resources for your IT team.
