872305-B21 HPE Proliant Ml110 4.5U Rack Gen10 PCIE 4LFF DDR4 Non-Hot-plug Gigabit Ethernet Server

HPE 872305-B21 ProLiant ML110 Gen10 Tower Server Overview

The HPE ProLiant ML110 Gen10 delivers enterprise-class performance in an affordable tower model. Designed with scalability and security in mind, this server accommodates a single Intel Xeon Scalable processor, robust DDR4 SmartMemory, and flexible storage solutions. Easily convertible to a rack system, it provides both versatility and efficiency for modern business environments.

Key Features and Benefits

• Reliable single-processor tower configuration for small to medium enterprises.
• Supports up to 192 GB DDR4 ECC Smart Memory for enhanced performance.
• Expansion flexibility with five PCIe slots for future upgrades.
• Adaptable storage supporting up to eight LFF or sixteen SFF drives.
• Integrated TPM security chip for improved protection.
• Convertible to a rack system with 4.5U rack space.

General Information

Form Factor & Design

• Type: Tower Server
• Rack Compatibility: 4.5U space requirement
• Embedded Security: Trusted Platform Module (TPM)
• Scalability: 1-way processor support
• Drive Bays: 4 internal, 1 front-accessible
• Global Availability: Optimized for worldwide deployment

Memory Capabilities

DDR4 Smart Memory Technology

• Installed Memory: 0 GB (factory base)
• Maximum Capacity: 192 GB
• Technology: DDR4 ECC Registered SDRAM
• Form Factor: 288-pin DIMM
• Slots Available: 6 DIMM slots (all free at base configuration)
• Features: Advanced ECC with HPE Smart Memory support

Processor & Chipset

Scalable CPU Options

• Processor Support: Intel Xeon Scalable family
• Socket: FCLGA3647
• Chipset: Intel C621
• CPU Quantity: Supports 1 processor
• Upgrade Capability: Fully upgradable processor support

Storage Options

Flexible Disk Drive Support

• Hard Drive: No pre-installed HDD
• Supported Configurations: Up to 8 LFF or 16 SFF drives
• Storage Controller: HPE Smart Array S100i SR
• Controller Interface: SATA 6Gb/s
• Channels: 10
• RAID Support: RAID 0, 1, 5, and 10

Networking Features

Built-in Connectivity

• Ethernet Ports: Dual Gigabit Ethernet (2x RJ-45)
• Ethernet Controller: HPE 332i
• Protocols Supported: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 5 (iLO 5)
• Advanced Features: PXE support, Wake-on-LAN (WoL)
• Compliance: IEEE 802.3, 802.3u, 802.3ab

Expansion & Connectivity

Slot and Bay Options

• External Bay: 1 x 5.25”
• Internal Bays: 4 x 3.5” LFF
• PCIe Slots:
  • 3 x PCIe 3.0 x8 (half-length, full-height)
  • 1 x PCIe 3.0 x16 (three-quarter length, full-height)
  • 1 x PCIe 3.0 x16 (full-length, full-height)
  • 1 x microSD internal slot

Interfaces

• Video: 1 x VGA (rear)
• LAN: 2 x Gigabit Ethernet (RJ-45)
• iLO Port: 1 x RJ-45 (rear), 1 x Type-A (front)
• USB: 5 x USB 3.0 (2 front, 2 rear, 1 internal)
• USB 2.0: 3 x USB 2.0 (2 rear, 1 internal)

Power Specifications

• Base Configuration: No pre-installed PSU
• Input Voltage: AC 120/230 V, 50/60 Hz

Dimensions & Physical Characteristics

Compact Tower Design

• Width: 7.7 in (19.5 cm)
• Depth: 18.9 in (48 cm)
• Height: 17.3 in (44 cm)
• Weight: 29.76 lbs (13.5 kg)
