HPE Proliant DL360 Server Xeon Gold 6132 / 2.6 GHz, 32GB DDR4 SDRAM

Processor

The HPE Proliant DL360 Server Xeon 14-core is equipped with the powerful Intel Xeon Gold 6132 processor, running at a speed of 2.6 GHz. This processor is specifically designed to deliver exceptional performance and reliability, making it an ideal choice for businesses and organizations that require high computing power.

Main Information of Xeon 14-core

The Proliant DL360 Gen10 by Hewlett Packard Enterprise (HPE) is a high-performance 1U rack-mountable server designed for flexibility and reliability. This Smart Buy model, part number 874462-S01, delivers exceptional processing power and extensive memory support.

Processor & Chipset

• Processor: 1st Generation Intel Xeon Gold 6132 at 2.6 GHz
• Max Turbo Frequency: Up to 3.7 GHz
• Cores: 14-core processor
• Quantity: 1 (expandable up to 2)
• Upgradability: Yes, supports CPU upgrades
• Features: Includes Hyper-Threading and Intel Turbo Boost Technology 2
• Chipset: Intel C621

Cache Memory

• Installed Cache Size: 19.25 MB L3 Cache
• Cache Per Processor: 19.25 MB

Memory Configuration

• Installed Size: 32 GB, expandable up to 384 GB
• Type: DDR4 SDRAM with Advanced ECC
• Effective Memory Speed: 2666 MHz
• Form Factor: DIMM 288-pin
• Slots: 12 total (10 empty)
• Features: Registered, Dual Rank, HPE SmartMemory, 6-channel Memory Architecture
• Supported RAM: Up to 1.5 TB Load-reduced PC4-20800, 192 GB Non-volatile

Storage & Controllers

• Hard Drive: Not included
• Optical Drive: Not included

Storage Controllers

• Type: RAID Controller
• Interface: SATA 6 Gb/s / SAS 12 Gb/s
• Controller Name: HPE Smart Array P408i-a
• Channels: 8
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
• Buffer Size: 2 GB

Network & Communication

• Ethernet Ports: 4 Gigabit Ethernet ports
• Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5 (iLO 5)
• Features: Wake On LAN (WOL), PXE Support

Expansion & Connectivity

• External: 1 free bay
• Hot-swap: 8 x 2.5" SFF free bays

Slots

• FlexibleLOM Slot: 1 (full-height, low-profile)
• PCIe 3.0 x16 Slot: 1 (full-height)
• PCIe 3.0 x8 Slot: 1 (low-profile)
• MicroSD Card Slot: 1 (internal)
• DIMM Slots: 12 total (10 free)

Interfaces

• LAN: 4 x RJ-45 (Gigabit Ethernet) - Rear
• PoweredUSB 3.0: 1 (front)
• HP iLO: 1 x RJ-45 (rear), 1 x Type A (front)
• USB 3.0: 4 (2 rear, 2 internal)
• SATA/SAS: 8 x SATA-600 / SAS 3.0
• VGA: 1 (rear)

Power Description

• Type: Hot-plug Power Supply
• Redundancy: Optional, 1+1 with additional power supply
• Installed Qty: 2
• Max Supported Qty: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watt

Dimensions & Weight

• Width: 17.1 inches
• Depth: 27.8 inches
• Height: 1.7 inches
• Weight: 28.75 lbs

Compliance & Standards

• AES, FIPS 140-2
• IPv6 Ready
• PCI DSS
• TLS v1.2
• ASHRAE Class A3/A4
• WEEE 2002/95/EC
• ACPI 6.1

Included Accessories

• HP Easy Install Rail Kit
• Standard CPU Heatsink
• 5 Standard Hot Plug Fans
• Power Cable

Enhanced Performance

The Gold 6132 processor is built on the Intel Scalable Processor architecture, which provides significant enhancements in performance compared to previous generations. With 14 cores and 28 threads, this processor can handle demanding workloads with ease, ensuring smooth and efficient operation.

Increased Productivity

The high core count of the Xeon Gold 6132 enables it to handle multiple tasks simultaneously, allowing for increased productivity. Whether you are running complex applications, virtualization workloads, or performing data-intensive tasks, this processor ensures that your system operates at peak performance, minimizing downtime and maximizing productivity.

Advanced Security Features

The Xeon Gold 6132 incorporates advanced security features to protect your data and ensure the integrity of your system. With Intel's Trusted Execution Technology (TXT) and Intel Software Guard Extensions (SGX), you can rest assured that your critical business data remains secure, even in virtualized environments.

Optimized Energy Efficiency

In addition to its impressive performance capabilities, the Xeon Gold 6132 is designed to be energy-efficient. It features Intel's Advanced Vector Extensions (AVX-512), which allows for faster processing while consuming less power. This not only reduces your energy costs but also helps to minimize your carbon footprint.

Ram

The HPE Proliant DL360 Server Xeon 14-core comes equipped with 32GB of DDR4 SDRAM. This high-capacity memory module plays a crucial role in the overall performance and efficiency of the server.

Improved System Responsiveness

With 32GB of RAM, the server can handle multiple tasks simultaneously, ensuring smooth and responsive operation. Whether you are running resource-intensive applications, virtual machines, or databases, the ample amount of memory prevents performance bottlenecks and allows for seamless multitasking.

Enhanced Data Handling

The DDR4 SDRAM technology offers higher memory bandwidth compared to its predecessors. This means that data can be transferred more quickly between the processor and memory, resulting in improved overall system performance. With faster data access and retrieval times, your critical business data can be processed efficiently, optimizing workflow and reducing latency.

Scalability and Future-Proofing

With 32GB of RAM, the HPE Proliant DL360 Server provides ample headroom for future expansion. As your business grows and demands increase, you have the flexibility to upgrade the server's memory capacity to meet evolving requirements. This scalability ensures that your investment in the server is future-proofed and can adapt to changing business needs.

Reliability and Error Correction

DDR4 SDRAM incorporates advanced error correction capabilities, such as ECC (Error Correcting Code) technology. These features detect and correct memory errors in real time, ensuring data integrity and minimizing the risk of system crashes or data corruption. The reliability offered by ECC memory is crucial for businesses that require mission-critical operations and cannot afford any downtime or data loss.

Drive Bays

The HPE Proliant DL360 Server Xeon 14-core is equipped with 8SFF (Small Form Factor) drive bays. This feature provides flexibility and scalability in terms of storage options, allowing you to tailor the server to your specific needs.

High Storage Capacity

The 8SFF drive bays offer ample space to accommodate multiple hard drives or solid-state drives, allowing for high storage capacity. This is especially advantageous for businesses that deal with large amounts of data, such as media files, databases, or virtual machines. The ability to store a vast amount of data directly within the server enhances accessibility and reduces the need for external storage devices.

Improved Data Redundancy

The 8SFF drive bays support various RAID (Redundant Array of Independent Disks) configurations, enabling data redundancy and increased fault tolerance. By using RAID technology, you can ensure that your critical data is protected from drive failures. The ability to configure RAID arrays within the server provides an added layer of data security and minimizes the risk of data loss.

Hot-Swappable Drives

One of the key advantages of the 8SFF drive bays is their hot-swappable design. This means that you can remove and replace drives without shutting down the server or interrupting its operation. Hot-swapping drives simplify maintenance and upgrades, as they eliminate the need to power down the server and reduce downtime.

Flexible Storage Configuration

The 8SFF drive bays offer flexibility in terms of storage configuration. You have the freedom to mix and match different drive sizes and types according to your specific requirements. Whether you need high-performance SSDs for speedy data access or larger-capacity HDDs for cost-effective storage, the 8SFF drive larger-capacity creates a storage solution that aligns with your needs and budget.

Power Supply

The HPE Proliant DL360 Server Xeon 14-core is equipped with two 800W power supplies. The power supply unit (PSU) is a critical component that ensures the server receives a stable and reliable power source.

Redundancy and High Availability

The inclusion of dual power supplies in the server provides redundancy, ensuring uninterrupted operation even in the event of a single power supply failure. The redundant power supplies automatically take over if one fails, preventing downtime and minimizing the risk of data loss or system failure. This high level of availability is crucial for businesses that require continuous operation and cannot afford any disruptions.

Energy Efficiency

The 800W power supplies are designed to be energy-efficient, complying with industry standards for energy consumption. This helps to reduce operating costs and minimize environmental impact. By utilizing efficient power supplies, you can optimize energy usage without compromising on performance or reliability.

Modular Design

The modular desiof the power supplies allows for easy installation and maintenance. In case of a power supply failure or the need for an upgrade, you can simply replace the faulty unit with a new one without having to replace the entire server. This modularity enhances serviceability and reduces downtime during maintenance operations.

Power Monitoring and Management

The power supplies in the HPE Proliant DL360 Server incorporate advanced monitoring and management capabilities. You can monitor power usage, temperature, and other vital system parameters through integrated management tools or software. This allows for proactive identification of potential issues and enables effective power management, ensuring optimal performance and reliability.

Part Number

The HPE Proliant DL360 Server Xeon 14-core has a unique part number, 874462-S01. This alphanumeric identifier plays a crucial role in identifying and ordering specific server configurations, making it easier for businesses to procure the exact model they require.

Accurate Configuration Identification

With a specific part number assigned to each configuration, it becomes effortless to identify and verify the exact server model you are looking for. Whether you are ordering additional units or requesting support, having the correct part number ensures that you receive the right server with the desired specifications. This eliminates any confusion or potential mismatch during procurement or troubleshooting processes.

Efficient Ordering and Inventory Management

The part number serves as a standardized reference for ordering and inventory management. With the unique identifier, you can easily communicate your requirements to suppliers or resellers, streamlining the procurement process. The part number also helps in maintaining accurate inventory records, making it easier to keep track of server models and configurations within your organization.

Compatibility and Firmware Updates

The part number is also useful for ensuring compatibility with various hardware components and firmware updates. Server manufacturers often release specific firmware updates or patches tailored to certain part numbers. By using the correct part number, you can easily identify and apply the appropriate updates, ensuring compatibility and optimal performance.

Warranty and Support

The part number is crucial when it comes to warranty and support services. It allows manufacturers and service providers to quickly identify the specific server model and configuration, ensuring that you receive the appropriate level of support. Whether you need technical assistance, warranty coverage, or spare parts, having the correct part number ensures a smooth and efficient support experience.
