HPE Aruba JL805A#ABA 12 Ports Instant On Managed Network Switches.

JL805A#ABA
Hover on image to enlarge

Brief Overview of JL805A#ABA

HPE Aruba 12 Ports Instant On 1960 4sfp+ Managed Network Switches JL805A#ABA. New (System) Pull with 6-Month Replacement Warranty
QR Code of HPE Aruba JL805A#ABA 12 Ports Instant On Managed Network Switches.
$1,377.00
$1,200.00
You save: $177.00 (13%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPNJL805A#ABAAvailability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Product/Item ConditionNew (System) Pull ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Product Summary

HPE JL805A#ABA Aruba Instant On 1960 Switch

Switch Features and Specifications

  • Device Type: 12-Port Layer 2+ Smart Switch, Stackable
  • Mounting: Rack-Mountable, 1U Design
  • Networking Type: 10 Gigabit Ethernet

Port Configuration

  • Total Ports: 12 x 100/1000/10000 Mbps
  • SFP+ Ports: 4 x 10 Gigabit SFP+

Performance Metrics

  • Latency:
    • 100 Mbps: 7.4 µs
    • 1 Gbps: 4.2 µs
    • 10 Gbps: 1.1 µs
  • Throughput: 238 Mpps
  • Switching Capacity: 320 Gbps

Routing Capabilities

  • IPv4 Routing Table Entries: 512
  • IPv6 Routing Table Entries: 512
  • MAC Address Table Size: 16,000 Entries

Additional Features

  • Jumbo Frame Support: Up to 9216 Bytes
  • Routing Protocols:
    • IGMPv2, IGMPv3, Static IPv4 Routing
    • MLDv2
  • Remote Management Protocols:
    • SNMP (Versions 1, 2c, 3)
    • RMON, HTTP, HTTPS, TFTP, SCP, RADIUS

Enhanced Networking Features

  • Flow Control and Auto-Negotiation
  • VLAN Support and Auto-Uplink (Auto MDI/MDI-X)
  • IGMP Snooping and Port Mirroring
  • Broadcast and Multicast Storm Control
  • Firmware Upgradeable
  • Quality of Service (QoS) Implementation
  • Energy Efficient Ethernet (EEE) Support

Security and Management

  • Access Control List (ACL) Support
  • Port Security and Port-Based Access Control
  • DHCP Snooping and IP Source Guard
  • Loop Protection and DHCP Relay
  • Trusted Platform Module (TPM)

Standards Compliance

  • IEEE 802.3, 802.3u, 802.3ab, 802.1d, 802.1q, 802.3ad (LACP), and more

Expansion and Connectivity Options

  • Interface Options:
    • 12 x 10Gbit LAN RJ-45
    • 4 x 10Gbit LAN SFP+

Power Requirements

  • Power Supply: Internal Power Supply
  • Voltage Input: AC 100-240 V (50/60 Hz)
  • Operational Power Consumption: 80 Watts

Number Of Ports

The HPE Aruba 1960 Managed Network Switches offer a remarkable feature in the form of its 12 ports. This significant number of ports provides users with numerous benefits, making it an essential aspect to consider when choosing a network switch for your business or organization.

Increased Connectivity

With 12 ports, the HPE Aruba 1960 Managed Network Switches offer ample connectivity options for various devices in your network infrastructure. Whether you need to connect computers, printers, servers, or other network devices, this switch provides you with the flexibility to accommodate multiple connections simultaneously. This ensures that all your devices can communicate efficiently and effectively, improving productivity and collaboration within your organization.

Scalability

The 12 ports on the HPE Aruba 1960 Managed Network Switches also allow for scalability. As your business grows and you add more devices to your network, having additional ports becomes crucial. With these switches, you can easily expand your network without the need for additional hardware or complicated configurations. This scalability feature saves you time and money while ensuring a seamless transition as your network requirements evolve.

Reduced Network Congestion

One of the significant benefits of having 12 ports on the HPE Aruba 1960 Managed Network Switches is the ability to distribute network traffic effectively. By providing multiple ports, this switch allows for better load balancing across the network. Each port can handle a certain amount of traffic, reducing congestion and preventing bottlenecks. This results in faster and more reliable data transfer, ensuring that your network operates smoothly even during peak usage periods.

Improved Network Performance

The HPE Aruba 1960 Managed Network Switches' 12 ports contribute to enhanced network performance. With more ports available, you can create separate VLANs (Virtual Local Area Networks) to segregate network traffic based on specific requirements. This segregation helps prioritize critical applications and services, ensuring optimal performance for each device connected to the switch. Whether you need to prioritize voice or video traffic, or specific departments within your organization, the 12 ports allow you to allocate network resources efficiently.

Flexibility in Network Design

Having 12 ports on the HPE Aruba 1960 Managed Network Switches also provides flexibility in network design. You can create different network topologies based on your organization's needs. For example, you can use some ports for connecting devices within a department while using other ports for interconnecting switches to create a larger network infrastructure. This versatility allows you to design a network that suits your specific requirements, ensuring optimal performance and efficiency.

Cost-Effective Solution

The 12 ports on the HPE Aruba 1960 Managed Network Switches offer a cost-effective solution for small to medium-sized businesses. Instead of investing in multiple switches or more expensive enterprise-grade switches with excess ports, these switches provide just the right number of ports needed for most business networks. By eliminating unnecessary ports, you can save on upfront costs while still enjoying the benefits of a managed switch.

Management Type

Another notable feature of the HPE Aruba 1960 Managed Network Switches is its management type, specifically the Instant On management system. This management type offers users a range of benefits and plays a crucial role in simplifying network administration and enhancing overall network performance.

Simplified Network Configuration

With Instant On management, configuring and managing your network becomes incredibly straightforward. The user-friendly interface provides intuitive controls that allow even non-technical users to set up and configure their network quickly. You can easily create VLANs, set up access controls, and manage Quality of Service (QoS) settings, all through a simple and streamlined web-based interface. This simplicity reduces the learning curve and empowers businesses to manage their networks efficiently without the need for extensive IT knowledge or expertise.

Centralized Network Management

The Instant On management type also offers centralized network management capabilities. You can monitor and control multiple switches from a single interface, providing a holistic view of your network infrastructure. This centralized management streamlines troubleshooting, configuration changes, and firmware updates, saving time and effort for network administrators. With Instant On management, you can quickly identify and resolve any network issues, ensuring uninterrupted connectivity and minimizing downtime.

Enhanced Security Features

Security is a paramount concern for any network environment. The Instant On management system includes robust security features to protect your network from unauthorized access and potential threats. You can implement user-based access controls, ensuring that only authorized personnel can access sensitive network resources. Additionally, the management system supports advanced security protocols such as 802.1X authentication and Access Control Lists (ACLs) to safeguard your network from external threats. With these enhanced security features, you can have peace of mind knowing that your network is protected against unauthorized access and potential data breaches.

Efficient Troubleshooting

The Instant On management system simplifies troubleshooting processes by providing comprehensive network visibility. You can monitor network performance, track bandwidth usage, and identify any bottlenecks or anomalies easily. Real-time alerts and notifications enable proactive troubleshooting, allowing you to address potential issues before they affect network performance or user experience. By having complete visibility into your network, you can optimize its performance and ensure a seamless user experience.

Seamless Integration with Existing Network Infrastructure

The Instant On management system is designed to seamlessly integrate with existing network infrastructure. Whether you have other Aruba switches or third-party devices in your network, this management type allows for interoperability and smooth integration. You can easily expand your network by adding HPE Aruba 1960 Managed Network Switches without disrupting your current setup. This flexibility ensures that you can leverage the benefits of Instant On management while maintaining compatibility with your existing network infrastructure.

Scalability for Future Growth

As your business grows and your network requirements evolve, the Instant On management system provides scalability to accommodate future growth. You can effortlessly add more switches to your network and manage them seamlessly through the same interface. This scalability ensures that your network can adapt to increased demands without facing any administrative or operational challenges. Whether you need to expand your network to support additional devices or integrate new technologies, the Instant On management system offers the flexibility required for long-term scalability.

Sku

The HPE Aruba 1960 Managed Network Switches come with the unique SKU JL805A#ABA, which holds its own significance and benefits for users. Understanding the importance of the SKU can help users make informed decisions when selecting and managing their network infrastructure.

Product Identification

The SKU, or Stock Keeping Unit, serves as a unique identifier for the HPE Aruba 1960 Managed Network Switches. This alphanumeric code allows users, distributors, and resellers to easily identify and differentiate this specific model from other switches in the market. By referencing the SKU, users can ensure that they are purchasing the exact product they require, avoiding any confusion or compatibility issues.

Inventory Management

The SKU also plays a vital role in inventory management for businesses and organizations. With a unique SKU like JL805A#ABA associated with the HPE Aruba 1960 Managed Network Switches, businesses can track their inventory accurately. The SKU simplifies the process of managing stock levels, reordering products, and organizing assets within a network infrastructure. By having a standardized SKU system in place, businesses can streamline their inventory management processes, ensuring they have the right number of switches available when needed.

Warranty and Support

The SKU is often used to identify specific product variations and configurations, including warranty and support details. By referring to the SKU JL805A#ABA, users can ensure that they are purchasing a switch that comes with the appropriate warranty coverage and support options. This enables businesses to make informed decisions about their network infrastructure investments, knowing that they will receive the necessary assistance and coverage in case of any issues or technical difficulties.

Compatibility with Accessories

The SKU also helps users identify compatible accessories and components for the HPE Aruba 1960 Managed Network Switches. Whether you need additional transceivers, cables, or mounting brackets, referring to the SKU ensures that you select the right accessories that are specifically designed to work seamlessly with this switch model. This compatibility eliminates any guesswork or potential compatibility issues, allowing for a hassle-free installation and integration process.

Product Differentiation

In a market flooded with various network switches, the SKU provides a means to differentiate the HPE Aruba 1960 Managed Network Switches from competitors' offerings. Users can easily identify and compare this specific model based on its unique SKU JL805A#ABA. This differentiation allows users to make informed decisions by considering the specific features, capabilities, and benefits associated with this particular switch model.

Standardization and Documentation

The SKU JL805A#ABA also aids in standardizing product documentation and specifications. Manufacturers and vendors often use SKUs to refer to specific models in their technical documentation, user manuals, and marketing materials. This standardization ensures clarity and consistency when referring to the HPE Aruba 1960 Managed Network Switches across different platforms. Users can easily access relevant information, such as datasheets or user guides, by searching for the SKU associated with this switch model.

In conclusion, the HPE Aruba 1960 Managed Network Switches offer a range of features that cater to the needs of businesses and organizations seeking efficient and reliable network connectivity. The 12 ports provide increased connectivity, scalability, reduced network congestion, improved network performance, flexibility in network design, and a cost-effective solution. The Instant On management system simplifies network configuration, offers centralized management, enhances security features, enables efficient troubleshooting, and ensures seamless integration with existing network infrastructure. The SKU JL805A#ABA serves as a unique identifier that aids in product identification, inventory management, warranty and support tracking, compatibility with accessories, product differentiation, and standardization of documentation. By considering these features and their benefits, users can make informed decisions when selecting the HPE Aruba 1960 Managed Network Switches for their networking needs.

Features
Product/Item Condition:
New (System) Pull
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
