Product Specifications of HPE JL256-61001
Overview
The HPE 2930f Switch is a managed, stackable solution designed for high-performance networking. With a robust 48-port configuration, it is suitable for rack-mounted installations, providing exceptional flexibility and efficiency for enterprise environments.
Core Features
- Device Type: Managed Switch with 48 Ports, Layer 3 capabilities
- Rack Enclosure: 1U rack-mountable design
- Network Subtype: Gigabit Ethernet
- Power Over Ethernet: Supports PoE+
Performance Metrics
Throughput and Capacity
- Throughput: 112 Mpps
- Switching Capacity: 176 Gbps
- Latency:
- 3.8 µs at 1 Gbps
- 1.6 µs at 10 Gbps
- Jumbo Frame Size: 9220 bytes
Routing and Protocols
- IPv4 and IPv6 Routing Table Entries: 10,000 (IPv4) and 5,000 (IPv6)
- MAC Address Table Size: 32,000 entries
- Supported Protocols: OSPF, RIP, BGP, IGMP, and more
Management and Security Features
Remote Management Protocols
- SNMP versions 1, 2, and 3
- SSH, Telnet, and CLI support
- RMON support for enhanced monitoring
Encryption and Authentication
- Encryption Algorithms: MD5, SSL
- Authentication Methods: RADIUS, PAP, CHAP, TACACS+
Advanced Features
- Flow Control and Full Duplex Capability
- DHCP, BootP, and ARP Support
- VLAN and Jumbo Frames Support
- Quality of Service (QoS) and Spanning Tree Protocol (STP) functionalities
- Dynamic ARP Protection and DHCP Protection mechanisms
Technical Specifications
Hardware Configuration
- Processor: ARM Cortex-A9 at 1.016 GHz
- RAM: 1 GB DDR3 SDRAM
- Flash Memory: 4 GB
Connectivity Options
- Interfaces:
- 48 x 1000Base-T (RJ-45) PoE+
- 4 x Gigabit/10G SFP+
- 1 x Serial Console
- Expansion Slots: 1 total (1 available)
- Maximum Installed Modules: 0 installed, up to 4 max
Compliance and Standards
This switch meets numerous IEEE standards including:
- IEEE 802.1D, 802.1Q, 802.1P, 802.3af
- IEEE 802.3x, 802.3ad (LACP), 802.1w, 802.1x
- IEEE 802.1s, 802.1ad, 802.1v, 802.1ab (LLDP), 802.3at
- IEEE 802.3az, 802.1ax
Ports
The HPE Aruba 2930F Managed Network Switches come equipped with an impressive 48 ports, making them an ideal choice for businesses and organizations requiring a high-density network infrastructure. With such a substantial number of ports, these switches offer a host of benefits and play a critical role in ensuring smooth and efficient network operations.
Increased Connectivity
One of the primary advantages of having 48 ports on the HPE Aruba 2930F Managed Network Switches is the ability to connect numerous devices simultaneously. Whether it's computers, servers, printers, or other network equipment, these switches provide the necessary connectivity to accommodate a large number of devices. This makes them particularly suitable for medium to large-sized businesses that have extensive networking requirements.
Scalability
The inclusion of 48 ports on these switches ensures scalability, allowing businesses to expand their network infrastructure as their needs grow. With each port capable of supporting high-speed data transfer rates, organizations can easily add new devices without worrying about bottlenecks or performance degradation. This scalability feature offers businesses the flexibility to adapt to changing requirements without the need for significant infrastructure overhauls.
Versatility
The HPE Aruba 2930F Managed Network Switches with 48 ports are versatile devices that can be used in various network setups. From traditional wired networks to more advanced configurations like VLANs (Virtual Local Area Networks) and link aggregation, these switches can handle diverse networking scenarios. The multiple ports allow for the creation of separate networks or the aggregation of multiple connections for increased bandwidth.
Improved Network Performance
With 48 ports at their disposal, users of the HPE Aruba 2930F Managed Network Switches can expect superior network performance. The abundance of ports minimizes congestion and ensures that each device connected to the switch receives optimal bandwidth. This results in faster data transfer speeds, reduced latency, and improved overall network responsiveness. Whether it's transferring large files, streaming media, or running bandwidth-intensive applications, these switches can handle the demands of modern business networks.
Enhanced Network Security
The inclusion of 48 ports on these switches also has significant implications for network security. Each port can be individually configured and monitored, allowing for the implementation of granular security policies. With the ability to assign access controls and apply traffic filtering rules at the port level, businesses can ensure that only authorized devices and users have access to their network resources. This helps protect sensitive data and prevents unauthorized access, mitigating the risk of potential security breaches.
Reduced Equipment Costs
By providing 48 ports in a single device, the HPE Aruba 2930F Managed Network Switches eliminate the need for multiple switches or additional networking equipment. This not only simplifies the network infrastructure but also reduces equipment costs. Consolidating multiple devices into a single switch reduces power consumption, cabling requirements, and maintenance efforts. It also frees up valuable rack space in server rooms or data centers.
Part Number
The HPE Aruba 2930F Managed Network Switches are identified by their part number JL256-61001. This unique identifier plays a crucial role in ensuring compatibility, providing support, and facilitating easy procurement of replacement parts or additional units when needed.
Compatibility Assurance
The part number JL256-61001 acts as a guarantee that the HPE Aruba 2930F Managed Network Switch is a genuine product manufactured by Hewlett Packard Enterprise (HPE). It ensures that the switch is designed to meet the highest quality standards and is fully compatible with other HPE networking equipment. This compatibility is essential for seamless integration within existing network infrastructures, minimizing configuration issues and ensuring optimal performance.
Product Support
The part number provides an easy and accurate way to identify the HPE Aruba 2930F Managed Network Switch when seeking technical support or assistance. Whether it's troubleshooting, firmware updates, or warranty claims, having the correct part number simplifies the process and allows for efficient resolution of any issues that may arise. HPE's support team can quickly identify the specific model associated with the part number, ensuring accurate and targeted assistance.
Procurement and Replacement
The part number JL256-61001 is crucial for procurement purposes. When businesses need to expand their network infrastructure or replace faulty equipment, having the correct part number simplifies the ordering process. It ensures that organizations can easily identify and obtain the exact model they require, reducing the risk of ordering incorrect or incompatible switches. This efficient procurement process saves time, avoids unnecessary delays, and ensures minimal disruption to network operations.
Future Expansion Planning
The part number also plays a vital role in future expansion planning. By documenting and keeping track of the part numbers of existing network switches, businesses can accurately assess their current infrastructure and plan for future growth. This information helps organizations determine compatibility with newer models or upgraded versions of switches and ensures smooth integration when expanding or upgrading their network.
Warranty Validation
The part number is an essential element when validating warranty coverage for the HPE Aruba 2930F Managed Network Switch. With the correct part number, organizations can easily confirm the warranty status of their switch and ensure that any necessary repairs or replacements are covered. This eliminates potential confusion or disputes regarding warranty claims, providing peace of mind to businesses relying on these switches for their critical network operations.
In conclusion, the HPE Aruba 2930F Managed Network Switches with 48 ports offer increased connectivity, scalability, versatility, improved network performance, enhanced network security, reduced equipment costs, and other benefits. The part number JL256-61001 ensures compatibility, facilitates support and procurement, aids in future expansion planning, and validates warranty coverage. Together, these features make the HPE Aruba 2930F Managed Network Switches a reliable and efficient choice for organizations seeking a robust and high-performing network infrastructure solution.
