HPE Aruba JL661A 48 Port Network Switch - Rack-mountable

JL661A
Hover on image to enlarge

Brief Overview of JL661A

HPE Aruba 48 Port Rack-mountable Network Switch - JL661A. New (System) Pull with 1-Year Replacement Warranty
QR Code of HPE Aruba JL661A 48 Port Network Switch - Rack-mountable
$4,387.50
$3,672.00
You save: $715.50 (16%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPNJL661AAvailability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Manufacturer Warranty1 Year Warranty Original Brand Product/Item ConditionNew (System) Pull ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

HPE JL661A Aruba Networking Overview

The HPE JL661A Aruba Networking Cx 6300m is a state-of-the-art network switch, designed to enhance connectivity and performance in various environments. With its robust features, this device offers a versatile solution for modern networking needs.

Key Specifications

Device Characteristics

  • Type: Switch
  • Ports: 48 ports (1 Gbps)
  • Management: Layer 3 managed switch
  • Form Factor: Rack-mountable 1U, front and side to back
  • Stackable: Yes

Port Details

  • Ethernet Ports: 48 x 10/100/1000 (PoE+)
  • Uplink Options: 4 x SFP56 (1G/10G/25G/50G)

Performance Metrics

Switching and Throughput

  • Switching Capacity: 496 Gbps
  • Throughput: 369 Mpps
  • Latency:
    • 1 Gbps: 2.28 µs
    • 10 Gbps: 1.46 µs
    • 25 Gbps: 1.9 µs
    • 50 Gbps: 3.49 µs
  • Stacking Bandwidth: 200 Gbps

Capacity and Routing

  • Switched Virtual Interfaces (SVIs): 1000
  • IPv4 Host Table: 32,000 entries
  • IPv6 Host Table: 32,000 entries
  • Unicast Routes (IPv4): 64,000
  • Unicast Routes (IPv6): 32,000
  • Multicast Routes (IPv4): 8,000
  • Multicast Routes (IPv6): 8,000
  • IGMP Groups: 8,000
  • MLD Groups: 4,000
  • MAC Address Table: 32,000 entries

Advanced Features

Protocols and Management

  • Supported Protocols: EGP, BGP-4, OSPF, IGMPv2, VRRP, and more.
  • Remote Management: Supports RMON, SNMP, Telnet, and SSH.
  • Authentication: Uses SSH, RADIUS, and TACACS+.

High Availability and Security

  • Features:
    • DHCP and ARP support
    • VLAN support
    • Auto-Uplink (Auto MDI/MDI-X)
    • IGMP Snooping and Syslog Support
    • Access Control List (ACL) Support
    • Quality of Service (QoS) features
    • Jumbo Frame Support (up to 9198 bytes)
  • Protection Mechanisms:
    • Packet Storm Protection
    • Broadcast Storm Protection
    • Unicast Storm Protection

Energy Efficiency and Power Specifications

Power Supply Details

  • Power Device: Internal power supply (not included, max 2 required)
  • Power Supply Options: JL086A, JL087A, JL670A
  • Maximum Power over Ethernet: 1600 W
  • Efficiency Ratings: 80 Plus Silver and Energy Star certified

Device Interfaces

  • RJ-45 Ports: 48 x 10/100/1000 Base-T (PoE+)
  • SFP56 Ports: 4 x 1G/10G/25G/50G
  • USB Connectivity:
    • 1 x USB-C Console
    • 1 x Management USB
    • 1 x USB Type A

Regulatory Compliance and Standards

  • Compliant Standards: IEEE 802.1d, 802.1q, 802.1p, 802.3af, 802.3ad (LACP), and more.
  • Processor: ARM Cortex-A72, 1.78 GHz
  • Memory: 8 GB DDR4 SDRAM
  • Flash Storage: 32 GB

Port Count

The HPE Aruba JL661A Network Switch is equipped with a remarkable port count of 48. This extensive number of ports offers users a wide range of benefits and plays a crucial role in enhancing their networking experience.

Increased Connectivity

With 48 ports, this network switch provides users with the ability to connect a large number of devices simultaneously. Whether you are setting up a small office network or managing a data center, the abundance of ports ensures that you can accommodate all your devices without any limitations.

Scalability

The scalability aspect of the HPE Aruba JL661A Network Switch is also worth highlighting. As your business grows and your network requirements expand, having 48 ports enables you to easily add new devices to your network infrastructure. This scalability ensures that your network can adapt to the changing demands of your organization without any hassle or additional investment in new hardware.

Versatility

The versatility offered by the 48 ports on the HPE Aruba JL661A Network Switch is another significant advantage. You can connect various devices such as computers, printers, servers, IP phones, access points, and many more. This versatility allows you to create a diverse and efficient network environment that caters to your specific needs and supports seamless communication and data transfer across all connected devices.

Mount Type

The HPE Aruba JL661A Network Switch features a rack-mountable design that offers users a range of benefits and plays a crucial role in ensuring efficient network management.

Saves Space

Rack-mountable switches are designed to be placed in a standard equipment rack, which helps optimize space utilization in server rooms or data centers. By securely mounting the switch on a rack, you can eliminate clutter and maintain an organized networking infrastructure. This not only enhances the aesthetics of your setup but also enables easy access and troubleshooting of network connections.

Improved Cooling

One of the advantages of rack-mountable switches is the improved cooling they provide. These switches are designed to fit into racks that facilitate proper airflow management. This ensures that the switch remains cool, reducing the risk of overheating and potential hardware failures. By maintaining an optimal operating temperature, a rack-mounted switch enhances the overall reliability and longevity of your network equipment.

Easier Maintenance

Rack-mountable switches simplify maintenance tasks by providing easy access to cable management and port configurations. The organized layout of the rack allows for quick identification and troubleshooting of any network issues. Additionally, the ability to easily swap or upgrade switches within a rack simplifies future maintenance and upgrades, saving time and effort.

In conclusion, the HPE Aruba JL661A Network Switch's 48-port count offers increased connectivity, scalability, and versatility to meet various networking needs. The rack-mountable design further enhances space utilization, cooling efficiency, and maintenance ease. Whether you are setting up a small office network or managing a large-scale data center, these features ensure optimal performance and hassle-free network management.

Features
Manufacturer Warranty:
1 Year Warranty Original Brand
Product/Item Condition:
New (System) Pull
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
