HPE Aruba 6300F 24-Port Managed Rack-mount Network Switches JL668A.

Product Overview of HPE JL668A Aruba 6300F Switch

Main Features and Specifications

• Brand: HPE
• Model: JL668A
• Type: Layer 3 Managed Switch
• Design: Stackable, 24 Ports, Rack-mountable (1U)
• Port Configuration:
  • 24 x 10/100/1000 Mbps Ethernet
  • 4 x SFP56 (1G/10G/25G/50G Uplink/Stacking)

Performance Highlights

• Switching Capacity: 448 Gbps
• Throughput: 334 Mpps
• Low Latency:
  • 1 Gbps: 2.28 µs
  • 10 Gbps: 1.46 µs
  • 25 Gbps: 1.9 µs
  • 50 Gbps: 3.49 µs
• Stacking Bandwidth: 200 Gbps

Advanced Routing and Management

• Routing Protocols: OSPF, BGP, IGMPv2/v3, VRRP, Static IPv6 Routing
• Remote Management: SSH, HTTPS, SNMPv2c/v3, CLI
• Authentication Methods: RADIUS, TACACS+, Secure Shell (SSH)

Enhanced Capacity

• MAC Address Table: 32,000 entries
• Switched Virtual Interfaces (SVIs): 1,000
• IPv4/IPv6 Host Table: 32,000 entries
• IPv4 Multicast Routes: 8,000
• IPv6 Multicast Routes: 8,000
• IGMP Groups: 8,000
• Jumbo Frames: Supports up to 9,198 bytes

Security and QoS Features

• Access Control: IPv4/IPv6 ACLs, MAC-based ACLs
• Traffic Management: QoS, Deficit Weighted Round Robin (DWRR), Strict Priority (SP)
• Storm Protection: Broadcast, Multicast, and Unicast Storm Control
• Spanning Tree Protocols: PVST, MSTP, RSTP

Connectivity and Ports

• Ethernet Ports: 24 x 10/100/1000 Base-T PoE+
• SFP56 Ports: 4 x 1G/10G/25G/50G
• Additional Interfaces: USB-C Console, USB Type-A, Management Port

Standards Compliance

• Industry Standards:
  • IEEE 802.1D, 802.1Q, 802.1p
  • IEEE 802.3ad (LACP), 802.1s, 802.1x
  • IEEE 802.3ae, 802.1w
• Certifications: Supports extensive Layer 2 and Layer 3 protocols

Ports

The HPE Aruba 6300F Managed Rack-mount Network Switches are equipped with 24 ports, making them an ideal choice for businesses and organizations that require a high-performance and reliable network infrastructure. These switches offer a wide range of benefits and features that ensure smooth operation and seamless connectivity.

Increased Connectivity

With 24 ports, the HPE Aruba 6300F switches provide ample connectivity options for various devices and systems in your network. Whether you need to connect computers, servers, printers, or other network-enabled devices, these switches offer the flexibility to handle multiple connections simultaneously.

Scalability

The 24 ports on the HPE Aruba 6300F switches allow for easy scalability as your network grows. You can add new devices or expand your network infrastructure without worrying about running out of ports. This scalability feature ensures that your network can adapt to changing business requirements without any disruptions.

Efficient Data Transfer

The HPE Aruba 6300F switches support high-speed data transfer rates, ensuring efficient communication between devices connected to the network. With 24 ports, you can achieve fast and reliable data transmission, enabling seamless collaboration and productivity across your organization.

Improved Performance

The 24 ports on these switches are designed to deliver superior performance. They incorporate advanced technologies such as Quality of Service (QoS) and traffic prioritization, allowing you to prioritize critical applications and ensure smooth operation even during peak usage periods. This feature is particularly beneficial for businesses that rely heavily on real-time applications or large data transfers.

Enhanced Security

The HPE Aruba 6300F switches offer advanced security features to protect your network from unauthorized access or malicious activities. With 24 ports, you can implement granular access control policies and segregate network traffic to prevent unauthorized users from gaining access to sensitive data or resources.

Flexibility and Versatility

Having 24 ports on the HPE Aruba 6300F switches provides flexibility and versatility in network design and implementation. You can create separate VLANs (Virtual Local Area Networks) to segment your network based on departments, projects, or security requirements. This segregation ensures efficient resource utilization, minimizes network congestion, and enhances overall network performance.

Management

The "Managed" feature of the HPE Aruba 6300F switches sets them apart from unmanaged switches and offers numerous benefits for network administrators. This feature allows for centralized control and monitoring of the entire network infrastructure, ensuring seamless operation and efficient management.

Centralized Control

The managed nature of the HPE Aruba 6300F switches enables centralized control over all connected devices and network settings. Network administrators can easily configure and manage multiple switches from a single interface, simplifying the overall management process. This centralized control eliminates the need to individually access each switch, saving time and effort.

Enhanced Security

Managed switches provide enhanced security features compared to unmanaged switches. With the HPE Aruba 6300F switches, administrators can implement robust security measures such as access control lists (ACLs), port security, and Secure Shell (SSH) for secure remote management. These features ensure that only authorized personnel can access and configure the switches, protecting your network from potential threats.

Monitoring and Troubleshooting

The managed feature of these switches enables comprehensive monitoring and troubleshooting capabilities. Network administrators can monitor network traffic, analyze performance metrics, and identify potential bottlenecks or issues in real-time. This proactive approach to monitoring allows for timely troubleshooting and ensures optimal network performance.

Network Optimization

Managed switches like the HPE Aruba 6300F offer advanced features such as Spanning Tree Protocol (STP), Virtual Router Redundancy Protocol (VRRP), and link aggregation, which optimize network performance and reliability. These features help prevent network loops, provide redundancy, and improve overall network stability, resulting in a seamless user experience and increased productivity.

Flexibility and Customization

The managed nature of these switches provides flexibility and customization options to meet specific business requirements. Administrators can configure VLANs, implement Quality of Service (QoS) policies, and prioritize network traffic based on application requirements. This flexibility allows for efficient resource allocation, ensures smooth operation of critical applications, and enhances overall network performance.

Rack-mountable

The HPE Aruba 6300F Managed Rack-mount Network Switches come with a rack-mountable design, offering several benefits for organizations looking to maximize their network infrastructure efficiency.

Space Optimization

The rack-mountable design of these switches allows for efficient utilization of space in server rooms or data centers. By mounting the switches in a standard 19-inch rack, businesses can save valuable floor space and organize their network equipment in a compact and tidy manner. This space optimization is especially vital for organizations with limited physical space.

Easy Installation

The rack-mountable design simplifies the installation process of the HPE Aruba 6300F switches. They can be easily mounted in standard server racks using the provided mounting brackets, minimizing installation time and effort. This ease of installation ensures quick deployment, allowing businesses to set up their network infrastructure promptly.

Cable Management

Rack-mountable switches offer cable management features that help keep the network cables organized and tidy. The HPE Aruba 6300F switches come with cable management options, such as cable routing guides and cable management arms, which ensure neat and organized cabling. This not only improves aesthetics but also facilitates easier maintenance and troubleshooting.

Improved Airflow and Cooling

The rack-mountable design promotes better airflow and cooling within the server rack. These switches are designed to fit seamlessly into the rack, allowing for proper ventilation and heat dissipation. This feature helps prevent overheating issues and ensures optimal performance and longevity of the switches.

Scalability

The rack-mountable design of the HPE Aruba 6300F switches enables easy scalability as your network grows. By using rack-mounted switches, businesses can add or replace switches without disrupting the existing network infrastructure. This scalability feature allows for seamless expansion and flexibility in adapting to changing business needs.

In conclusion, the HPE Aruba 6300F Managed Rack-mount Network Switches offer numerous benefits for users. With 24 ports, these switches provide increased connectivity, scalability, efficient data transfer, improved performance, enhanced security, and flexibility. The managed feature allows for centralized control, enhanced security, monitoring, troubleshooting, network optimization, flexibility, and customization. The rack-mountable design optimizes space utilization, simplifies installation, improves cable management, enhances airflow and cooling, and enables scalability. These features make the HPE Aruba 6300F switches a reliable choice for businesses and organizations seeking high-performance and manageable network infrastructure solutions.
