HPE DL380p Gen8 Xeon 6 Core 2.1GHz 16GB DDR3 8SFF SSD Server 734790-S01

Processor

The HPE Proliant DL380p Gen8 Server is equipped with a powerful Xeon 6 Core 2.1GHz processor. This processor is a key component of the server, providing exceptional performance and reliability to meet the demanding needs of modern businesses.

General Information

• Manufacturer: Hewlett Packard Enterprise (HPE)
• Part Number: 734790-S01
• Product Name: Proliant DL380p G8 2U Rack Server S-Buy

Processor and Chipset

Processor Specifications

• Type: Intel Xeon E5-2620 V2
• Clock Speed: 2.1 GHz
• Socket Type: LGA2011
• Core Count: 6 Cores (Hexa-core)
• 64-Bit Computing: Supported
• Installed Processor: 1
• Maximum Supported Processors: 2
• Chipset Model: Intel C600

Cache Memory

• Type: L3 Cache
• Installed Size: 15 MB
• Cache Per Processor: 15 MB

Memory Specifications

Installed Memory

• Size: 16 GB (expandable to 768 GB)
• Type: DDR3 SDRAM
• Speed: 1600 MHz
• Compliance: PC3-10600
• Form Factor: DIMM 240-pin
• Memory Slots: 24
• Features: Registered, Dual Rank, Quad Channel Architecture, HP Smart Memory

Supported RAM Configurations

• PC3-12800: Up to 384 GB (Registered)
• PC3-10600: Up to 768 GB (Registered)
• PC3-10600: Up to 128 GB (Unbuffered, Advanced ECC)

Storage Capabilities

Internal Storage

• Drive Bays: 8 SFF SAS/SATA HDD bays
• Optical Drive Bay: Optional Slim Optical Bay (SATA DVD-RW/ROM)

Storage Controllers

• Controller Type: RAID Plug-in Card (PCI Express 3.0 x8)
• Controller Interface: SATA 6 Gb/s, SAS 6 Gb/s
• Controller Name: Smart Array P420i with 512 MB FBWC
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50
• Buffer Size: 512 MB

Graphics and Display

• Graphics Type: Integrated
• Graphics Controller: Matrox G200

Networking and Communication

Networking Features

• Type: Plug-in Card
• Interface: PCIe x4
• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: HP 331FLR
• Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4 (iLO4)
• Additional Features: Wake On LAN (WoL), PXE Support
• Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)

Expansion and Connectivity

Expansion Bays

• Total Bays: 9
• Free Bays: 9
• Front Accessible: 1 x 5.25in Slim Line
• Hot-Swap Bays: 8 x 2.5in SFF

Expansion Slots

• Total Slots: 24
• Free Slots: 23
• Memory Slots: 24 DIMM 240-pin
• Processor Slots: 2
• PCI Express Slots:
  • 2 x PCI Express 3.0 x16 (Full-length, Full-height)
  • 3 x PCI Express 3.0 x8 (Half-length, Full-height)
  • 1 x PCI Express 2.0 x8 (Half-length, Full-height, x4 Mode)
  • 1 x FlexibleLOM (x4 Mode)

Interfaces and Ports

• Serial Port: 1 x RS-232 (9-pin D-sub)
• Display/Video: 2 x VGA (15-pin HD D-sub, 1 Front, 1 Rear)
• USB Ports: 7 x USB 2.0 (4 Rear, 2 Front, 1 Internal)
• Network Ports: 4 x Ethernet (RJ-45)
• Management Port: 1 x HP iLO (RJ-45)

Power Specifications

• Device Type: Hot-Plug Power Supply
• Redundancy: Yes, 1+1
• Installed Power Supplies: 1
• Maximum Supported Power Supplies: 2
• Voltage Required: AC 120/220 V
• Power Provided: 460 Watts
• Certification: 80 Plus Platinum

Dimensions and Weight

• Width: 17.5 inches
• Depth: 27.5 inches
• Height: 3.4 inches
• Weight: 41 lbs

Enhanced Performance

The Xeon 6 Core 2.1GHz processor offers enhanced performance capabilities, allowing the server to handle intensive workloads and complex tasks with ease. With its multiple cores and high clock speed, it can efficiently process multiple threads and deliver faster results. This is particularly important for businesses that rely on data-intensive applications, such as databases, virtualization, and analytics.

Improved Efficiency

In addition to its impressive processing power, the Xeon 6 Core 2.1GHz processor also features advanced power management technologies. These technologies optimize power consumption based on workload demands, ensuring efficient utilization of resources and reducing energy costs. By minimizing power wastage, businesses can achieve substantial savings in their operational expenses.

Scalability and Flexibility

The Xeon 6 Core 2.1GHz processor is designed to support scalability and flexibility in server deployments. It offers support for advanced virtualization technologies, such as Intel Virtualization Technology (VT) and Intel VT-d, allowing businesses to create virtual environments with ease. This enables efficient resource allocation, improved server consolidation, and simplified management of virtual machines.

Moreover, the Xeon 6 Core 2.1GHz processor supports Intel Turbo Boost Technology, which dynamically adjusts the processor's clock speed to deliver an extra performance boost when needed. This feature ensures that the server can handle sudden spikes in workload without compromising overall performance.

Overall, the Xeon 6 Core 2.1GHz processor provides businesses with a reliable and high-performance computing platform. Its enhanced performance, improved efficiency, and scalability capabilities make it an ideal choice for businesses that require a server solution capable of handling demanding workloads efficiently.

Memory

The HPE Proliant DL380p Gen8 Server is equipped with 16GB DDR3 memory, a crucial component that plays a significant role in the server's overall performance and responsiveness.

Increased Efficiency

With 16GB of DDR3 memory, the server can efficiently handle multiple tasks simultaneously. This increased memory capacity allows for smoother multitasking, enabling businesses to run resource-intensive applications and processes without experiencing performance bottlenecks. Whether it's running complex databases, virtual machines, or high-volume web services, the ample memory capacity ensures optimal performance and responsiveness.

Improved Reliability

The use of DDR3 memory in the HPE Proliant DL380p Gen8 Server enhances the system's reliability. DDR3 memory modules are known for their robustness and error-correcting capabilities. They can detect and correct data errors, reducing the risk of data corruption and system crashes. This is particularly important for businesses that rely on mission-critical applications and cannot afford any downtime.

Scalability and Future-Proofing

The 16GB DDR3 memory configuration provides scalability options for businesses that anticipate future growth or increased workload demands. The server's architecture allows for easy expansion of memory capacity by adding additional modules. This flexibility ensures that the server can adapt to changing business needs without requiring a complete hardware upgrade.

Furthermore, DDR3 memory technology is widely supported across various server platforms and operating systems. This ensures compatibility and ease of integration with existing IT infrastructures, minimizing deployment complexities.

In summary, the 16GB DDR3 memory in the HPE Proliant DL380p Gen8 Server offers increased efficiency, improved reliability, scalability options, and future-proofing capabilities. It provides businesses with the necessary resources to handle demanding workloads and ensures smooth and reliable operation.

Storage

The HPE Proliant DL380p Gen8 Server is equipped with 8SFF SSD storage, offering high-performance storage capabilities to meet the demands of modern businesses.

Fast and Responsive

The 8SFF SSD storage provides lightning-fast data access and transfer speeds. Compared to traditional hard disk drives (HDDs), SSDs offer significantly higher read and write speeds, resulting in faster application loading times, improved data retrieval, and reduced latency. This is particularly beneficial for businesses that require quick access to large datasets or frequently access data-intensive applications.

Increased Reliability

SSDs have no moving parts, unlike HDDs, which rely on spinning disks and mechanical read/write heads. This makes SSDs more resistant to physical shock and vibration, reducing the risk of data loss due to accidental impacts. Additionally, SSDs are less susceptible to mechanical failures, such as disk platter damage or head crashes. This increased durability and reliability minimize the risk of data corruption and system downtime.

Efficient Space Utilization

The 8SFF form factor of the SSD storage allows for efficient space utilization within the server chassis. It enables the installation of multiple SSDs in a compact footprint, maximizing storage capacity without occupying excessive physical space. This is particularly advantageous for businesses with limited rack space or those looking to scale their storage capacity without expanding their infrastructure footprint.

Furthermore, the use of SSD storage reduces power consumption compared to traditional HDDs. SSDs require less energy to operate as they do not have spinning disks or moving parts. This translates into lower energy costs and contributes to overall environmental sustainability efforts.

In conclusion, the 8SFF SSD storage in the HPE Proliant DL380p Gen8 Server offers fast and responsive performance, increased reliability, and efficient space utilization. It provides businesses with the necessary storage capabilities to handle data-intensive workloads, improve productivity, and reduce operational costs.

Part Number

The HPE Proliant DL380p Gen8 Server has a part number of 734790-S01, which is an essential identifier for this particular server model.

Product Identification

The part number serves as a unique identifier for the HPE Proliant DL380p Gen8 Server. It enables businesses and IT professionals to accurately identify and differentiate this server model from other variations or generations. This is particularly important when procuring replacement parts, upgrading components, or seeking technical support.

Compatibility Assurance

The part number also ensures compatibility between various server components and accessories. When selecting additional hardware or expansion options for the HPE Proliant DL380p Gen8 Server, matching the part number guarantees that the chosen components are designed to work seamlessly with this specific server model. This eliminates the risk of compatibility issues or performance limitations that may arise from using incompatible components.

Warranty and Support

The part number is closely tied to warranty and support services provided by HPE. By referencing the part number, businesses can easily determine the warranty status of their server and ensure they receive appropriate support when needed. This simplifies the process of filing warranty claims or obtaining technical assistance, minimizing potential downtimes and disruptions to business operations.

Furthermore, the part number can be used as a reference when searching for relevant documentation, software updates, or drivers specific to the HPE Proliant DL380p Gen8 Server. This ensures that businesses have access to the latest resources and can keep their server environment up to date with the latest advancements and security patches.

In summary, the part number 734790-S01 serves as a crucial identifier for the HPE Proliant DL380p Gen8 Server. It enables accurate product identification, ensures compatibility with server components, facilitates warranty and support services, and simplifies access to relevant documentation and updates.
