Description

Product Details

HPE JL828A#ABA Flexnetwork 5140

Overview

The HPE JL828A#ABA Flexnetwork 5140 is an advanced Layer 3 smart switch designed for high performance and reliability. This rack-mountable device offers a combination of 24 Gigabit Ethernet ports and 4 SFP+ 10 Gigabit Ethernet ports, making it suitable for various network environments.

Key Specifications

  • Device Type: Switch with 28 Ports, Layer 3, Smart
  • Enclosure: Rack-mountable, 1U
  • Port Configuration: 24 x 10/100/1000 + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+

Performance Metrics

  • Latency:
    • 1000 Mbps: 5 µs
    • 10 Gbps: 3 µs
  • Throughput: 96 Mpps
  • Routing/Switching Capacity: 128 Gbps

Routing and Addressing Capacity

  • IPv4 Routing Table: 512 entries
  • IPv6 Routing Table: 256 entries
  • VLAN IDs Supported: 4094
  • MAC Address Table: 16,384 entries

Advanced Features

  • Jumbo Frame Support: Up to 9216 bytes
  • Supported Routing Protocols:
    • OSPF, RIP-1, RIP-2
    • IGMP, OSPFv2, IGMPv3, OSPFv3
    • Static IPv4 and IPv6 Routing, CIDR
  • Remote Management Protocols:
    • SNMP v1, v2c, v3
    • RMON (1, 2, 3, 9), Telnet, HTTPS, TFTP, CLI
    • NTP, ICMP, RADIUS
  • Encryption: SSL
  • Authentication Methods:
    • RADIUS, TACACS+
    • Secure Shell V.2 (SSH2), HWTACACS

Operational Features

  • Flow Control, BOOTP Support, ARP Support
  • Load Balancing, VLAN Support
  • Auto-Uplink (Auto MDI/MDI-X)
  • IGMP Snooping, DiffServ Support
  • High Availability Options
  • Half Duplex and Full Duplex Modes
  • SFlow and Spanning Tree Protocol (STP) Support
  • Rapid Spanning Tree Protocol (RSTP) Support
  • Virtual Route Redundancy Protocol (VRRP) Support
  • Access Control List (ACL) Support
  • Quality of Service (QoS) features
  • Dynamic ARP Protection, DHCP Protection
  • Port Security, Energy Efficient Ethernet
  • Link Aggregation Control Protocol (LACP)

Compliance Standards

  • IEEE 802.3, 802.3u, 802.3i, 802.3z
  • IEEE 802.1d, 802.1q, 802.3ab
  • IEEE 802.1p, 802.3x, 802.3ad (LACP)
  • IEEE 802.1w, 802.1x, 802.3ae
  • IEEE 802.3ac, 802.1s, 802.1ad
  • ANSI/TIA-1057, 802.1ab (LLDP), 802.1ak
  • IEEE 802.3az, 802.1ax, 802.1r

Hardware Specifications

  • RAM: 512 MB SDRAM
  • Flash Memory: 256 MB
  • Status Indicators: Port Status, System

Connectivity Options

  • Interfaces:
    • 24 x 1000Base-T RJ-45
    • 4 x Gigabit / 10Gbit LAN SFP+
    • 1 x Console RJ-45 Management Port
    • 1 x Micro-USB 5 Pin USB Header for Management

Power Specifications

  • Power Supply: Internal Power Supply
  • Power Capacity: 24 Watts
  • Voltage Requirements: AC 100-240 V (50/60 Hz)

Sku: JL828A#ABA

Introduction

The HPE FlexNetwork 5140 4SFP+ Switches are renowned for their exceptional performance and advanced features. Among these features, the Sku or Stock Keeping Unit is a crucial aspect that sets this switch apart from its competitors. The JL828A#ABA Sku code specifically represents the HPE FlexNetwork 5140 4SFP+ Switches model, offering numerous benefits and advantages for users in various networking environments.

Enhanced Performance

Uninterrupted Data Transfer

The JL828A#ABA Sku ensures uninterrupted data transfer capabilities, allowing users to experience fast and reliable network connectivity. This switch model is designed to handle high data volumes efficiently, making it ideal for businesses with demanding network requirements. Whether it's handling large file transfers or supporting bandwidth-intensive applications, the JL828A#ABA Sku excels in maintaining smooth and seamless data flow.

High-Speed Connectivity

With the JL828A#ABA Sku, users can benefit from high-speed connectivity options. This switch supports 10 Gigabit Ethernet (GbE) connections with its SFP+ (Small Form-Factor Pluggable Plus) ports. These ports enable lightning-fast data transmission rates and ensure minimal latency, resulting in improved overall network performance. Organizations heavily reliant on speedy data transfers, such as data centers or multimedia production houses, will greatly benefit from this feature.

Advanced Security

Secure Data Transmission

Data security is a paramount concern for any organization. The JL828A#ABA Sku incorporates advanced security measures to safeguard sensitive information during transmission. It supports various encryption protocols, including Advanced Encryption Standard (AES), ensuring secure data transfers between connected devices. This feature is particularly vital for industries dealing with confidential data, such as finance, healthcare, and government sectors.

Access Control

The JL828A#ABA Sku provides robust access control mechanisms, allowing administrators to manage network access effectively. With features like VLAN (Virtual Local Area Network) support and Access Control Lists (ACLs), users can create secure segments within the network, restricting unauthorized access to critical resources. This level of granular control enhances network security and protects against potential threats or unauthorized network intrusions.

Threat Detection and Prevention

In today's digital landscape, network security threats are constantly evolving. The JL828A#ABA Sku incorporates advanced threat detection and prevention capabilities to combat these risks effectively. It includes features like MAC (Media Access Control) address lockdown and Dynamic ARP Inspection (DAI), which help identify and mitigate potential security breaches. By proactively monitoring and preventing unauthorized activities, this switch ensures a secure network environment.

Flexibility and Scalability

Modular Design

The JL828A#ABA Sku offers a modular design, allowing users to customize and expand their network infrastructure according to their specific requirements. With its modular architecture, users can easily add or replace modules as needed, making it a flexible solution for growing businesses. This adaptability ensures that the switch can evolve alongside the organization's changing needs, saving both time and resources in the long run.

Virtualization Support

Virtualization has become an integral part of modern networks, enabling efficient resource utilization and scalability. The JL828A#ABA Sku seamlessly integrates with virtualization technologies, such as VMware and Hyper-V, allowing users to create virtual networks and manage them efficiently. This feature is especially beneficial for businesses relying on virtualized environments, as it simplifies network management and enhances overall productivity.

Scalable Stacking

The JL828A#ABA Sku supports stacking, a feature that enables multiple switches to operate as a single logical unit. This stacking capability enhances network scalability, simplifies management, and optimizes resource utilization. By consolidating multiple switches into a single stack, users can effectively manage their network infrastructure while minimizing complexity and reducing overall costs.

Reliability and Redundancy

Redundant Power Supply

Network downtime can result in significant financial losses and productivity disruptions. The JL828A#ABA Sku mitigates this risk by offering redundant power supply options. With dual power supply slots, users can connect two power supplies simultaneously, ensuring uninterrupted operation even in the event of a power supply failure. This redundancy feature enhances network reliability and minimizes the impact of potential power-related issues.

High Availability Features

The JL828A#ABA Sku incorporates high availability features to maximize network uptime. Features such as Rapid Spanning Tree Protocol (RSTP) and Virtual Router Redundancy Protocol (VRRP) ensure fast failover and seamless network redundancy. In the event of a link failure or equipment malfunction, these protocols facilitate automatic rerouting, preventing service disruption and maintaining continuous connectivity.

Conclusion

The JL828A#ABA Sku is an essential component of the HPE FlexNetwork 5140 4SFP+ Switches, offering enhanced performance, advanced security, flexibility, scalability, and reliability. Its unique features enable businesses to optimize their network infrastructure, reduce operational complexities, and ensure uninterrupted connectivity. Whether it's handling high data volumes, securing sensitive information, or supporting virtualized environments, the JL828A#ABA Sku empowers organizations to build robust and efficient networks that meet their evolving needs.
