HPE J9783A 2530 SFP 8 Ports Managed Gigabit Ethernet Switch

J9783A
Hover on image to enlarge

Brief Overview of J9783A

Managed Gigabit Ethernet Switch HPE J9783A 2530 SFP 8 Ports. Factory-Sealed New in Original Box (FSB) with 3 Years Warranty

QR Code of HPE J9783A 2530 SFP 8 Ports Managed Gigabit Ethernet Switch
$125.00
$92.00
You save: $33.00 (26%)
Ask a question
+
Quote

Additional 7% discount at checkout

SKU/MPNJ9783AAvailability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Manufacturer Warranty3 Years from the Original Brand Product/Item ConditionFactory-Sealed New in Original Box (FSB) ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

General Specifications of Gigabit Ethernet Switch

  • Manufacturer: HPE
  • Part Number / SKU: J9783A
  • Type: Managed Switch

Performance Features

  • Category: Switch
  • Port Count: 8 Ports
  • Port Types: 8 x 10/100 + 2 x Combo Gigabit SFP
  • Throughput: 4.1 Million Packets Per Second (Mpps)
  • Switching Capacity: 5.6 Gigabits Per Second (Gbps)

Enclosure Options

  • Mounting Options: Desktop, Rack-Mountable, Wall-Mountable
  • Rack Units: 1U

Capacity and Management

  • MAC Address Support: 16,000
  • MAC Address Table: 16,000 Entries
  • Jumbo Frame Support: Up to 9,220 Bytes

Remote Management Capabilities

  • Protocols Supported: SNMP v1, SNMP v2c, SNMP v3, RMON v1, v2, v3, v9, Telnet, HTTP, TFTP, SSH-2, CLI
  • Additional Features: Flow Control, DHCP, BOOTP, ARP, VLANs, Port Mirroring, IPv6, Auto-Uplink (Auto MDI/MDI-X)
  • Advanced Support: SNTP, sFlow, MSTP, ACL, QoS, STP Root Guard, LLDP, CoS, GARP

Compliance and Standards

  • Standards Compliance: IEEE 802.3, 802.3u, 802.1d, 802.1q, 802.3ab, 802.1p, 802.3x, 802.3ad (LACP), 802.1w, 802.1x, 802.1s, 802.1ab (LLDP), 802.3az

Power Requirements

  • Input Voltage: AC 120/230V
  • Frequency: 50/60 Hz

Ports

The HPE J9783A Managed Gigabit Ethernet Switch is equipped with 8 ports, making it an ideal choice for small to medium-sized businesses. These ports provide a reliable and high-performance network connectivity solution, allowing users to connect their devices seamlessly.

Increased Connectivity

With its 8 ports, this switch offers users the ability to connect multiple devices simultaneously. Whether it's computers, printers, servers, or other network devices, users can enjoy a hassle-free connectivity experience. This is particularly beneficial for businesses that require a large number of devices to be connected to the network.

Streamlined Network Management

The HPE J9783A Managed Gigabit Ethernet Switch simplifies network management by providing individual ports for each device. This allows for easy organization and troubleshooting of network connections. Users can easily identify and address any issues with specific devices without affecting the entire network.

Improved Performance

The 8 ports on this switch ensure that each connected device receives optimal network performance. With dedicated ports, users can avoid congestion and bottlenecks that can occur when multiple devices share the same port. This results in improved data transfer speeds and reduced latency, providing a seamless user experience.

Scalability

The availability of 8 ports makes the HPE J9783A Managed Gigabit Ethernet Switch highly scalable. As businesses grow and require additional network connections, users can simply add more devices without the need for additional switches. This scalability ensures that the switch can adapt to changing business needs without requiring a complete network infrastructure overhaul.

Cost-Efficiency

Having 8 ports in a single switch eliminates the need for purchasing multiple switches to accommodate a larger number of devices. This not only saves businesses money but also reduces the complexity of managing multiple switches. With fewer devices to maintain, businesses can allocate their resources more efficiently.

Flexibility

The 8 ports offer users the flexibility to connect devices with different network requirements. Whether it's connecting devices that require a wired Ethernet connection or devices that support Gigabit Ethernet, users can easily accommodate various connectivity needs. This ensures compatibility with a wide range of devices and future-proofs the network infrastructure.

Interface

The HPE J9783A Managed Gigabit Ethernet Switch features an SFP (Small Form-factor Pluggable) interface, enhancing its versatility and connectivity options. The SFP interface allows users to connect the switch to a variety of networking equipment, providing numerous benefits for users.

Modular Connectivity

The SFP interface enables users to connect the switch to different types of networking equipment using compatible transceivers. This modular approach allows for flexibility and customization based on specific networking requirements. Users can choose the appropriate transceiver for their needs, whether it's connecting to fiber optic cables or Ethernet cables, without the need to replace the entire switch.

Extended Reach

The SFP interface supports a wide range of distances, allowing users to extend their network reach beyond the limitations of traditional Ethernet connections. By utilizing fiber optic cables, users can connect devices that are located far away from the switch without sacrificing network performance. This is particularly beneficial for businesses with large office spaces or multiple buildings.

Higher Bandwidth

The SFP interface supports higher bandwidth capabilities compared to standard Ethernet interfaces. This enables users to achieve faster data transfer speeds and accommodate bandwidth-intensive applications. Businesses that rely on data-intensive tasks such as video conferencing, large file transfers, or multimedia streaming can benefit from the increased bandwidth provided by the SFP interface.

Hot Swappable

One of the key advantages of the SFP interface is its hot swappable nature. This means that users can replace or upgrade transceivers without the need to power down the switch or disrupt the network. This feature significantly reduces downtime and allows for seamless maintenance and upgrades, ensuring uninterrupted network connectivity for critical business operations.

Interoperability

The SFP interface's standardization ensures interoperability with a wide range of networking equipment from various manufacturers. Users can confidently connect their HPE J9783A Managed Gigabit Ethernet Switch to other devices such as routers, switches, or servers without worrying about compatibility issues. This promotes a flexible and scalable network infrastructure that can grow and adapt to changing business needs.

Future-Proofing

The SFP interface is future-proof, providing users with the ability to upgrade to higher-speed transceivers as technology advances. This allows businesses to keep up with evolving network requirements without the need for extensive infrastructure changes. The modular nature of the SFP interface ensures that the switch remains compatible with future networking technologies, protecting the investment in the HPE J9783A Managed Gigabit Ethernet Switch.

In conclusion, the HPE J9783A Managed Gigabit Ethernet Switch offers 8 ports and an SFP interface, providing users with increased connectivity options, streamlined network management, improved performance, scalability, and cost-efficiency. The 8 ports allow for seamless connectivity of multiple devices, while the SFP interface enhances versatility and accommodates various networking requirements. With its numerous benefits and future-proofing capabilities, this switch is an excellent choice for businesses seeking a reliable and high-performance network solution.
