HPE J9868-61001 10GBase-T RJ-45 PoE+ 10 Gigabit SFP+ 16 Ports Rack-mountable Switch

Overview of the J9868-61001 HPE 10GBase-T RJ-45 PoE+ Managed Switch

The HPE 5406R 8XGT/8SFP+ V2 ZL2 Managed Switch (J9868-61001) is designed to meet the growing demands of high-performance, reliable network infrastructures in large enterprise environments. This 16-port managed switch combines advanced network management features with robust hardware capabilities, ensuring optimal performance for mission-critical applications. With support for 10 Gigabit Ethernet (10GbE) connections, this switch offers both flexibility and scalability, making it an ideal solution for businesses that need to scale their network without compromising on performance.

Key Features of the J9868-61001 HPE 5406R 8XGT/8SFP+ V2 ZL2 Switch

This switch boasts a combination of essential features that make it an excellent choice for a range of enterprise applications, including high-speed data transmission, network monitoring, and flexible connectivity. Some of the key features include:

• 16 Ports: The J9868-61001 model features 16 high-performance ports, including 8 Gigabit Ethernet (10GBase-T) RJ-45 ports and 8 SFP+ ports. This mix of copper and fiber connectivity ensures that the switch can easily integrate into existing network environments.
• PoE+ Support: With Power over Ethernet Plus (PoE+), this switch can provide power to connected devices such as IP phones, security cameras, and wireless access points, streamlining installations and reducing the need for separate power supplies.
• 10GbE and SFP+ Ports: The combination of 10GBase-T and SFP+ ports enables flexible high-speed connections over copper and fiber, making this switch suitable for both short- and long-distance transmission requirements.
• Enhanced Security Features: This managed switch comes with advanced security features, including access control lists (ACLs), dynamic ARP inspection, and DHCP snooping, to protect network infrastructure from unauthorized access and cyber threats.
• Advanced Layer 2/3 Switching: The switch supports advanced Layer 2 and Layer 3 features such as VLANs, routing, and Quality of Service (QoS), providing granular control over traffic management and network performance.

Benefits of the HPE 5406R Switch for Businesses

Organizations of all sizes can benefit from deploying the J9868-61001 HPE 5406R 8XGT/8SFP+ V2 ZL2 switch due to its wide range of advantages. Key benefits include:

Scalability

The modular design of the HPE 5406R allows businesses to scale their networks easily. Whether upgrading existing infrastructure or expanding into new markets, this switch can accommodate future needs without requiring a complete overhaul of the network.

Energy Efficiency

With built-in energy-saving features, including IEEE 802.3az Energy Efficient Ethernet (EEE), the HPE 5406R helps businesses reduce power consumption, resulting in cost savings over time.

Increased Network Uptime

Hewlett Packard Enterprise’s emphasis on high reliability and redundancy ensures that the HPE 5406R switch minimizes downtime. Its high availability features, including dual fans and power supplies, keep the network running smoothly even in case of failure in one of the components.

Applications of the J9868-61001 HPE 5406R Switch

The versatility of the HPE 5406R switch makes it suitable for a wide range of enterprise-level applications, including:

Data Centers

The switch’s high-speed capabilities, combined with its scalability and low latency, make it an excellent choice for data centers. It supports multiple 10GbE connections, ensuring that servers, storage, and networked devices maintain high-performance levels even under heavy workloads.

Enterprise Networks

As part of a core or distribution layer in enterprise networks, the HPE 5406R provides fast and reliable connectivity between various network segments. Its advanced routing capabilities, including static and dynamic routing protocols, ensure that traffic is efficiently directed across the network.

VoIP and Video Surveillance

The PoE+ support is especially beneficial for IP-based devices, such as VoIP phones, cameras, and wireless access points. This allows businesses to reduce cable clutter while simplifying installation and power management for these devices.

Key Specifications

For those considering the HPE 5406R 8XGT/8SFP+ V2 ZL2 switch, it’s crucial to understand the technical specifications that ensure the switch’s reliability and performance. The detailed specs for this product include:

• Performance: 128 Gbps Switching Capacity, 95.23 Mpps Forwarding Rate
• Power Supply: Dual hot-swappable power supplies for redundancy
• Redundancy Features: Dual fans, redundant power supplies
• Operating Temperature: 0°C to 45°C (32°F to 113°F)
• Dimensions: 43.3 x 44.0 x 4.4 cm (17.0 x 17.3 x 1.7 inches)

Advanced Management Features

The J9868-61001 HPE 5406R Managed Switch offers a variety of management tools that help network administrators control traffic, monitor device performance, and optimize the overall network:

Simple Network Management Protocol (SNMP)

SNMP enables the switch to communicate with network management systems (NMS) to provide real-time monitoring and network performance data. This allows IT teams to proactively manage their infrastructure and resolve potential issues before they affect operations.

Web-Based Management

The web-based interface simplifies switch configuration and monitoring. Network administrators can easily manage the switch from anywhere with a browser, making it more convenient for large-scale network deployments.

Command-Line Interface (CLI)

The CLI allows advanced users to configure the switch via a text-based interface. It supports a full set of commands for comprehensive management and troubleshooting, which is particularly useful for experienced network administrators who require granular control.

Security and Access Control

The HPE 5406R switch comes equipped with advanced security features to protect the network from unauthorized access. This includes port security, MAC address filtering, and support for IEEE 802.1X authentication, ensuring only authorized devices can connect to the network.

Compatibility and Integration

One of the standout features of the HPE 5406R is its compatibility with a wide range of HPE modules, transceivers, and accessories. The switch is fully supported by HPE’s Intelligent Resilient Framework (IRF), which allows for the creation of multi-switch logical stacks to provide greater flexibility and redundancy. Additionally, it integrates seamlessly with HPE's network management solutions, ensuring businesses can manage their entire network ecosystem from a single platform.

HPE 5406R vs Other Managed Switches

While there are other managed switches available in the market, the HPE 5406R stands out due to its combination of performance, scalability, and energy efficiency. Unlike traditional switches, the 5406R supports both PoE+ and 10GbE SFP+ ports, allowing businesses to build a more diverse and robust network. When compared to competing models, the HPE 5406R offers superior uptime, better energy savings, and advanced security options that make it an excellent choice for modern enterprises.
