JL563C HPE Aruba 10 Gigabit Ethernet Optical Network SFP+ Transceiver Module

Overview of JL563C Aruba SFP+ Network Transceiver Module

The HPE JL563C Aruba SFP+ Optical Network 1 X RJ-45 10GBASE-T 10 Gigabit Ethernet Transceiver Module represents a highly advanced networking solution engineered to deliver exceptional speed, reliability, and compatibility for enterprise-grade infrastructures where seamless connectivity and optimized data transfer are critical, and this module integrates cutting-edge technology with robust design to ensure that organizations can achieve superior performance in demanding environments while maintaining compliance with industry standards and reducing overall deployment complexity.

Device Type and Form Factor

This device is categorized as a 10GBASE-T SFP+ transceiver module, and its plug-in form factor allows for hot-swappable installation, meaning network administrators can insert or remove the module without shutting down the system, thereby minimizing downtime and enhancing operational efficiency in mission-critical networks.

Connector and Interface Standards

The transceiver utilizes an RJ-45 connector type, supporting the IEEE 802.3an 10GBASE-T standard, which enables 10 Gigabit Ethernet transmission over copper cabling, and this design choice simplifies deployment by allowing organizations to leverage existing Cat6A or Cat7 cabling infrastructures without requiring expensive fiber optic installations.

Data Rate and Transfer Capabilities

The module supports data rates up to 10 Gbps, ensuring rapid transmission of large volumes of data across enterprise networks, and this capability is particularly beneficial for applications such as virtualization, cloud computing, and high-performance storage systems where bandwidth-intensive operations demand consistent throughput and minimal latency.

Maximum Distance and Cabling Requirements

With a maximum transfer distance of approximately 30 meters or 98.4 feet, the JL563C module is optimized for short-range, high-speed connections within data centers and enterprise environments, and it is recommended to use Cat6A cabling for optimal performance, although Cat7 cables are also supported, providing flexibility in deployment scenarios.

Consumption and Efficiency

The transceiver consumes approximately 2.5 to 3.5 watts of power, striking a balance between performance and energy efficiency, and this low power consumption contributes to reduced operational costs and improved sustainability, aligning with modern enterprise goals of minimizing energy footprints while maintaining high-speed connectivity.

Operating and Storage

The JL563C module is designed to operate within a temperature range of 0°C to 70°C, ensuring reliable performance in typical enterprise environments, and it can be stored at temperatures ranging from -40°C to 85°C, providing resilience and durability during transportation and long-term storage.

Hot-Pluggable Design

The hot-pluggable nature of the module allows administrators to install or replace it without interrupting network operations, which is crucial in environments where uptime is paramount, and this feature enhances flexibility and reduces maintenance-related disruptions.

Compliance and Certifications

The transceiver complies with SFP+ MSA, IEEE 802.3an, RoHS, and CE standards, ensuring interoperability with a wide range of networking equipment and adherence to environmental and safety regulations, thereby providing peace of mind to organizations that prioritize compliance and sustainability.

Switch and Platform Integration

The JL563C module is fully compatible with HPE Aruba Networking switches featuring 10G SFP+ ports, and it is specifically designed for Aruba CX and Aruba OS-Switch platforms, ensuring seamless integration and optimal performance in enterprise-grade networking environments where reliability and scalability are essential.

Use Cases and Applications

This transceiver is ideal for switch-to-switch connections, switch-to-server links, and data center 10GbE connectivity, and it enables organizations to deploy high-speed copper-based Ethernet solutions without the need for fiber optic cabling, thereby reducing infrastructure costs while maintaining superior performance and reliability.

Deployment Advantages

By utilizing standard Cat6A or Cat7 Ethernet cables, the JL563C module simplifies deployment and reduces overall infrastructure expenses, and its compatibility with existing copper cabling makes it an attractive option for enterprises seeking to upgrade their networks to 10GbE without undertaking extensive rewiring projects.

Enhanced Data Center Performance

In data center environments, the JL563C module supports high-speed connections between servers, storage systems, and switches, enabling faster data transfers and improved application performance, and this capability is critical for organizations leveraging virtualization, cloud services, and big data analytics where rapid access to information is essential.

Scalability and Proofing

The module provides a scalable solution for enterprises planning to expand their networks, and its support for 10GbE over copper ensures that organizations can meet current demands while preparing for future growth, thereby protecting investments and ensuring long-term viability of networking infrastructures.

Stable and Consistent

The transceiver is engineered to deliver stable and consistent performance across diverse networking environments, ensuring that data transfers remain reliable even under heavy workloads, and this reliability is essential for mission-critical applications where downtime or data loss can have significant consequences.

Secure Connectivity

By supporting industry-standard protocols and compliance certifications, the JL563C module ensures secure connectivity across enterprise networks, and its robust design minimizes vulnerabilities, thereby protecting sensitive data and maintaining the integrity of organizational communications.
