HPE ML110 Gen10 Intel Xeon 6-core 1.7 GHz 4.5u Tower Server P03684-S01.

Processor

The HPE Proliant Ml110 Gen10 Entry Model Tower Server is equipped with a powerful 1x 1st Gen Intel Xeon 6-core Bronze 3104 processor, clocked at 1.7 GHz. This processor is designed to deliver exceptional performance and reliability, making it an ideal choice for businesses and organizations that require a robust and efficient server solution.

Main Information of P03684-S01

• Brand: Hewlett Packard Enterprise
• Part Number: P03684-S01

Product Overview

• Model: Proliant ML110 Gen10
• Type: 4.5U Tower Server (Entry Model)

Processor & Chipset

• CPU: 1st Gen Intel Xeon Bronze 3104
• Clock Speed: 1.7 GHz (Max Turbo Speed)
• Core Count: 6-core
• CPU Quantity: 1
• Upgrade Potential: Upgradable
• Main Features: Intel Smart Cache
• Socket Type: FCLGA3647
• Chipset: Intel C621

Cache Memory

• Installed Size: 8.75 MB L3 Cache
• Cache per Processor: 8.75 MB

Memory

• Installed Size: 8 GB (expandable to 192 GB)
• Memory Technology: DDR4 SDRAM
• Effective Speed: 2133 MHz
• Rated Speed: 2666 MHz
• Compliance: PC4-21300
• Form Factor: DIMM 288-pin
• Slots: 6 (total), 5 (available)
• Memory Configuration: 1 x 8 GB
• Supported RAM: PC4-21300, up to 192 GB Registered

Storage Controllers

• Type: SATA
• Interface: SATA 6Gb/s
• Controller Name: HPE Smart Array S100i SR Software RAID
• Channel Quantity: 10
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 10

Graphics Controller

• Video Memory: 16 MB
• Video Interface: VGA

Network & Communication

• Ethernet Ports: 2 x Gigabit Ethernet
• Ethernet Controller: HPE 368i
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out Advanced Management (ASIC)
• Additional Features: Wake On LAN (WOL), PXE Support
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az

Expansion & Connectivity

• External Bays: 1 x 5.25" (occupied)
• Internal Bays: 4 x 3.5" LFF (all available)
• PCIe Slots:
  • 2 x PCIe 3.0 x8 (Half-length, Full-height, x4 Mode)
  • 1 x PCIe 3.0 x16 (Three-quarter-length, Full-height)
  • 1 x PCIe 3.0 x16 (Full-length, Full-height)
  • 1 x MicroSD Card (internal)
  • 1 x PCIe 3.0 x8 (Half-length, Full-height)

Interfaces

• Video: 1 x VGA (rear)
• Ethernet: 2 x Gigabit Ethernet (RJ-45)
• HP iLO: 1 x RJ-45 (rear), 1 x Type A (front)
• USB Ports:
  • 5 x USB 3.0 (2 front, 2 rear, 1 internal)
  • 3 x USB 2.0 (2 rear, 1 internal)

Miscellaneous

• 2 x Fans

Compliance Standards

• WEB
• PCI DSS
• ASHRAE Class A3
• ACPI 6.1

Manufacturer Selling Program

• HPE Smart Buy

Power Description

• Device Type: Power Supply
• Quantity Installed: 1
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Output: 350 Watts

Dimensions & Weight

• Width: 7.7 inches
• Depth: 18.9 inches
• Height: 17.3 inches
• Weight: 29.76 lbs

Improved Performance

The 1st Gen Intel Xeon 6-core Bronze 3104 processor offers superior performance capabilities compared to previous generations. With six cores and a base clock speed of 1.7 GHz, this processor can handle demanding workloads efficiently, ensuring smooth operation even during peak usage periods. Its advanced architecture enables faster data processing, allowing for quicker response times and improved overall performance.

Enhanced Multitasking

Thanks to its multi-threading capabilities, the Intel Xeon processor can handle multiple tasks simultaneously, increasing productivity and reducing processing time. This is particularly beneficial for businesses that rely on complex applications or run multiple virtual machines. Users can expect improved efficiency and reduced downtime with the HPE Proliant Ml110 Gen10 server.

Optimized Power Efficiency

The Intel Xeon Bronze processors are designed with power efficiency in mind, minimizing energy consumption without compromising performance. This not only helps reduce operational costs but also contributes to a greener environment by lowering the server's carbon footprint.

The 1x 1st Gen Intel Xeon 6-core Bronze 3104 processor provides users with a reliable and powerful solution for their server needs. Its improved performance, enhanced multitasking capabilities, and optimized power efficiency make it an excellent choice for businesses of all sizes.

Memory

The HPE Proliant Ml110 Gen10 Entry Model Tower Server comes equipped with 8GB DDR4 SDRAM, providing users with ample memory capacity to handle their workload efficiently. This server memory is designed to enhance the overall performance and reliability of the server, offering numerous benefits for users.

Improved Performance and Responsiveness

The 8GB DDR4 SDRAM ensures smooth and efficient operation, even when dealing with resource-intensive tasks. With its high bandwidth and low latency, this memory module allows for faster data access, resulting in improved overall performance and responsiveness. Users can expect reduced loading times and improved system stability when utilizing the HPE Proliant Ml110 Gen10 server.

Seamless Multitasking

With 8GB of memory, users can run multiple applications simultaneously without experiencing a significant performance drop. This is particularly beneficial for businesses that rely on data-intensive applications or virtualization technology. The increased memory capacity enables seamless multitasking, enhancing productivity and minimizing downtime.

Scalability and Future-Proofing

The HPE Proliant Ml110 Gen10 server is designed to accommodate future growth and expansion. The 8GB DDR4 SDRAM can be easily upgraded to meet changing business needs, ensuring the server's longevity and reducing the need for costly hardware upgrades. This scalability allows businesses to adapt to evolving demands without compromising performance or reliability.

The inclusion of 8GB DDR4 SDRAM in the HPE Proliant Ml110 Gen10 Entry Model Tower Server guarantees improved performance, seamless multitasking, and scalability for businesses looking to maximize their productivity.

Storage

The HPE Proliant Ml110 Gen10 Entry Model Tower Server features the Smart Array S100i controller, providing users with reliable and efficient storage capabilities. The storage solution plays a crucial role in server performance and data management, offering several benefits for businesses of all sizes.

Enhanced Data Protection

The Smart Array S100i controller ensures the safety and integrity of your data by providing advanced RAID functionality. This technology allows for data redundancy and automatic data recovery in the event of a drive failure. With the Smart Array S100i, businesses can enjoy peace of mind knowing that their critical data is protected against potential losses.

Improved Storage Efficiency

The Smart Array S100i supports various RAID levels, including RAID 0, 1, 5, and 10. These RAID configurations optimize storage capacity and performance, ensuring efficient use of available resources. By utilizing RAID technology, businesses can achieve higher storage efficiency, reducing costs associated with unused storage space.

Flexibility and Expandability

The Smart Array S100i controller offers flexibility and expandability options to meet the evolving needs of businesses. It supports multiple drive types, including SATA and SAS, allowing users to choose the most suitable storage solution for their specific requirements. Additionally, the controller supports up to four LFF (non-hot plug) drive bays, providing ample storage space for critical data.

The inclusion of the Smart Array S100i in the HPE Proliant Ml110 Gen10 server ensures enhanced data protection, improved storage efficiency, and flexibility for businesses seeking reliable storage capabilities.

Networking

The HPE Proliant Ml110 Gen10 Entry Model Tower Server is equipped with a 1GB 2p 368i Adapter, offering robust networking capabilities for businesses. A reliable and efficient networking solution is essential for seamless communication and data transfer within an organization, providing numerous benefits for users.

High-Speed Data Transfer

The 1GB 2p 368i Adapter enables high-speed data transfer between the server and connected devices. With its Gigabit Ethernet interface, businesses can enjoy fast and reliable network connectivity, ensuring smooth communication and efficient data transfer. This is particularly important for businesses that rely on real-time collaboration or handle large amounts of data.

Improved Network Performance

The 1GB 2p 368i Adapter supports advanced networking features, such as TCP/IP Offloading and jumbo frames, to enhance network performance. These features optimize network utilization, reduce CPU overhead, and minimize latency, resulting in improved overall network performance. Users can expect faster data transfers and reduced network congestion with the HPE Proliant Ml110 Gen10 server.

Scalability and Flexibility

The 1GB 2p 368i Adapter offers scalability and flexibility options to adapt to changing business needs. It supports multiple network protocols and can be easily integrated into existing network infrastructures. Whether businesses require local network connectivity or remote access capabilities, the 1GB 2p 368i Adapter ensures seamless integration and reliable network performance.

The inclusion of the 1GB 2p 368i Adapter in the HPE Proliant Ml110 Gen10 Entry Model Tower Server guarantees high-speed data transfer, improved network performance, and scalability for businesses looking to optimize their networking capabilities.

Drive Bays

The HPE Proliant Ml110 Gen10 Entry Model Tower Server features four LFF (non-hot plug) drive bays, providing users with ample storage space for their critical data. Drive bays play a crucial role in server storage capacity and data management, offering several benefits for businesses of all sizes.

Increased Storage Capacity

With four LFF drive bays, the HPE Proliant Ml110 Gen10 server offers significant storage capacity for businesses. These drive bays allow users to install multiple hard drives or solid-state drives, enabling them to store large amounts of data. The increased storage capacity ensures that businesses can accommodate their growing data needs without worrying about running out of space.

Flexible Storage Configuration

The four LFF drive bays offer flexibility in storage configuration, allowing users to tailor the server's storage capabilities to their specific requirements. Businesses can choose to configure the drives in RAID arrays or utilize them individually, depending on their data redundancy and performance needs. This flexibility ensures that businesses can optimize their storage configuration according to their unique demands.

Easy Maintenance and Expansion

The HPE Proliant Ml110 Gen10 server's drive bays are designed for easy maintenance and expansion. The non-hot plug nature of these bays allows users to replace or upgrade drives without disrupting the server's operation. This feature is particularly beneficial for businesses that require frequent drive replacements or expansions, as it minimizes downtime and ensures continuous data availability.

The inclusion of four LFF (non-hot plug) drive bays in the HPE Proliant Ml110 Gen10 Entry Model Tower Server guarantees increased storage capacity, flexible storage configuration, and easy maintenance for businesses seeking reliable storage capabilities.

Power Supply

The HPE Proliant Ml110 Gen10 Entry Model Tower Server is equipped with a 350W ATX power supply, providing users with a reliable and efficient power solution. The power supply unit plays a crucial role in server performance and stability, offering several benefits for businesses of all sizes.

Reliable Power Delivery

The 350W ATX power supply ensures reliable power delivery to the server's components, minimizing the risk of unexpected shutdowns or system failures. It provides a stable power source, protecting critical data and ensuring uninterrupted operation even during peak usage periods. Businesses can rely on the HPE Proliant Ml110 Gen10 server to deliver consistent performance without the worry of power-related issues.

Energy Efficiency

The 350W ATX power supply is designed with energy efficiency in mind, minimizing power consumption and reducing operational costs. It adheres to industry standards and regulations, such as 80 PLUS certification, ensuring high-efficiency ratings. By utilizing an energy-efficient power supply, businesses can significantly reduce their electricity bills and contribute to a greener environment.

Scalability and Future-Proofing

The HPE Proliant Ml110 Gen10 server's power supply offers scalability and future-proofing options to accommodate changing business needs. It provides sufficient power for the server's current configuration while allowing for potential expansions or hardware upgrades. This scalability ensures that businesses can adapt to evolving demands without compromising performance or stability.

The inclusion of a 350W ATX power supply in the HPE Proliant Ml110 Gen10 Entry Model Tower Server guarantees reliable power delivery, energy efficiency, and scalability for businesses seeking a robust power solution.

Form Factor

The HPE Proliant Ml110 Gen10 Entry Model Tower Server features a 4.5u Tower form factor, providing users with a compact and versatile server solution. The form factor plays a crucial role in server deployment and space utilization, offering several benefits for businesses of all sizes.

Space Efficiency

The 4.5u Tower form factor of the HPE Proliant Ml110 Gen10 server ensures efficient use of space, making it suitable for businesses with limited rack space or office environments where space is at a premium. Its compact design allows for easy deployment in various locations without compromising performance or functionality. Businesses can maximize their available space while enjoying the benefits of a powerful server solution.

Versatile Deployment Options

The Tower form factor offers versatile deployment options for businesses. It can be placed on a desktop, mounted on a rack shelf, or deployed in a server rack, depending on the specific requirements of the organization. This flexibility allows businesses to adapt to their unique infrastructure and deployment needs without limitations.

Easy Accessibility and Maintenance

The Tower form factor of the HPE Proliant Ml110 Gen10 server ensures easy accessibility for maintenance and upgrades. Its design allows for convenient access to internal components, simplifying hardware replacements or additions. Businesses can easily maintain and expand their server without the need for specialized tools or extensive downtime.

The inclusion of a 4.5u Tower form factor in the HPE Proliant Ml110 Gen10 Entry Model Tower Server guarantees space efficiency, versatile deployment options, and easy accessibility for businesses seeking a compact and flexible server solution.

Part Number

The HPE Proliant Ml110 Gen10 Entry Model Tower Server is identified by the part number P03684-S01. The part number serves as a unique identifier for the server model, offering several benefits for businesses and organizations.

Accurate Identification

The part number P03684-S01 ensures accurate identification of the HPE Proliant Ml110 Gen10 server model. This is particularly important when ordering replacement parts, accessories, or software licenses specific to this particular model. It eliminates any confusion or compatibility issues that may arise from using incorrect part numbers.

Standardization and Consistency

The use of a standardized part number across various systems ensures consistency in documentation, support materials, and product listings. Businesses can easily locate relevant information or resources related to the HPE Proliant Ml110 Gen10 server by referencing its unique part number. This standardization streamlines processes and enhances overall efficiency.

Warranty and Support Services

Part number P03684-S01 is associated with the warranty and support services provided by HPE for the Proliant Ml110 Gen10 Entry Model Tower Server. By referencing the part number, businesses can easily access and manage their warranty coverage, ensuring timely support and assistance when needed. This simplifies the process of obtaining technical support or arranging repairs, minimizing downtime, and maximizing productivity.

The inclusion of part number P03684-S01 for the HPE Proliant Ml110 Gen10 Entry Model Tower Server guarantees accurate identification, standardization, and easy access to warranty and support services for businesses seeking a reliable server solution.
