HPE P04175-004 3.2TB SAS12GBPS Smart SSD

Specifications Overview of P04175-004

Brand Information

• Brand: HPE
• MPN: P04175-004
• Option Part Number: P04547-B21
• Spare Part Number: P06605-001
• Model Number: EO003200JWTCC
• Assembly Number: P04175-004

General Device Details

• Device Type: Hot-swap Solid State Drive
• Capacity: 3.2 TB
• Form Factor: 2.5 inch SFF (Small Form Factor)
• Interface: SAS 12Gbps
• Flash Memory Type: Multi-level cell (MLC)
• Plug Type: Hot Pluggable
• Carrier Type: HPE Smart Carrier (SC)
• Workload Type: Write Intensive
• Firmware: Digitally Signed (DS)
• Supported Platforms: HPE ProLiant Rack, Tower, BladeSystem Servers, Synergy
• Height: 15 mm (0.6 inches)

Performance Specifications

• Lifetime Writes: 58,400 TB
• Endurance: 10.00 Drive Writes Per Day (DWPD)
• Data Transfer Rate: 12 Gb/sec (external)
• Max Sequential Read Throughput: 1,075 MiB/s
• Max Sequential Write Throughput: 1,030 MiB/s
• Average Random Read Latency: 135 µs (4KiB, Q1)
• Average Random Write Latency: 35 µs (4KiB, Q1)
• Random Read IOPS: 110,000 (4KiB, Q=16)
• Random Write IOPS: 120,000 (4KiB, Q=16)
• Max Random Read IOPS: 165,000@Q32
• Max Random Write IOPS: 120,000@Q16

Connectivity and Expansion

• Interface: SAS 12 Gb/s
• Bay Compatibility: 2.5" SFF

Power Consumption

• Idle: 5.00 Watts
• Random Read: 6.17 Watts
• Random Write: 6.17 Watts
• Sequential Read: 8.56 Watts
• Sequential Write: 8.56 Watts
• Random Read/Write Average: 5.90 Watts
• Maximum Power Draw: 8.56 Watts

Physical Dimensions and Weight

• Height: 5.00 inches (12.70 cm)
• Width: 7.00 inches (17.78 cm)
• Depth: 9.00 inches (22.86 cm)
• Weight: 1.10 lbs (0.50 kg)

Compliance and Miscellaneous Features

• Compliance Standards: WEEE

Compatibility Information

• Designed for HPE Nimble Storage dHCI and various HPE ProLiant models including DL325 Gen10, DL360 Gen10, DL380 Gen10, and many more. This drive is also compatible with HPE Synergy and HPE ProLiant ML Series servers.

Capacity

The HPE P04175-004 SSD is an extraordinary storage solution with a remarkable capacity of 3.2TB. This immense storage capability allows users to store an extensive amount of data, making it ideal for businesses and individuals who require substantial storage space.

Increased Storage Efficiency

With a capacity of 3.2TB, this SSD offers users the ability to store a vast amount of data without worrying about running out of space. This is particularly beneficial for businesses that deal with large volumes of data, such as media production companies or data centers. The increased storage efficiency ensures that users can store all their important files, documents, videos, and images without any limitations.

Seamless Workflow

The large capacity of the HPE P04175-004 SSD allows for a seamless workflow without the need for constant file management or transferring data to external storage devices. Users can conveniently access all their data from a single drive, reducing the time spent on file organization and improving productivity. This is especially important for professionals who work with resource-intensive applications, as they can keep all their projects and files readily available.

Future-Proofing

In today's technology-driven world, data storage requirements are constantly increasing. By investing in a high-capacity SSD like the HPE P04175-004, users can future-proof their storage needs. The 3.2TB capacity ensures that users have ample space to accommodate their growing data demands, providing a long-term storage solution that can adapt to evolving requirements.

Interface

The HPE P04175-004 SSD boasts an impressive interface featuring SAS12GBPS technology. This cutting-edge interface offers significant benefits and importance for users seeking fast and reliable data transfer capabilities.

High-Speed Data Transfer

The SAS12GBPS interface of the HPE P04175-004 SSD enables lightning-fast data transfer speeds. This is of utmost importance for users who work with large files and need to transfer data quickly and efficiently. Whether it's transferring high-definition videos, complex 3D models, or extensive databases, the high-speed interface ensures minimal waiting time and enhances overall productivity.

Reduced Latency

The SAS12GBPS interface also contributes to reduced latency, allowing for near-instantaneous access to stored data. This is particularly beneficial for applications that require real-time access, such as online transaction processing or video editing software. The low latency ensures that users can access their data rapidly, resulting in seamless performance and enhanced user experience.

Compatibility and Scalability

The SAS12GBPS interface offers excellent compatibility with various systems and devices. Users can effortlessly integrate the HPE P04175-004 SSD into their existing infrastructure without any compatibility issues. Additionally, this interface provides scalability options, allowing users to expand their storage capacity by adding more drives in the future.

Form Factor

The HPE P04175-004 SSD features a small form factor design that brings numerous benefits and importance to users looking for a compact storage solution.

Space-Saving Design

The small form factor design of this SSD is exceptionally advantageous for users with limited physical space. It allows for efficient utilization of available space, making it suitable for small offices or compact server environments. The compact size also enables easy integration into existing systems without requiring significant modifications or additional space allocation.

Improved Airflow and Cooling

The small form factor design contributes to improved airflow and cooling within the system. With less space occupied by the drive, there is more room for air circulation, reducing the risk of overheating. This is especially crucial in server rooms or data centers where multiple drives are operating simultaneously. The improved airflow ensures optimal performance and prolongs the lifespan of the drive.

Portability

The small form factor design makes the HPE P04175-004 SSD highly portable. Users can easily transport the drive between different locations or use it with portable devices. This portability is particularly beneficial for professionals who need to work on multiple devices or travel frequently. They can carry their data conveniently, ensuring access to important files wherever they go.

Firmware

The firmware of the HPE P04175-004 SSD is digitally signed, which offers significant benefits and importance for users concerned about data security and integrity.

Data Integrity

The digitally signed firmware ensures that the SSD's firmware has not been tampered with or modified by unauthorized sources. This enhances data integrity, providing users with confidence that their stored data remains secure and unaltered. With the increasing prevalence of cyber threats and data breaches, digitally signed firmware offers an additional layer of protection against unauthorized access.

Secure Boot Process

The digitally signed firmware contributes to a secure boot process, preventing the execution of malicious code during system startup. This protects the drive from potential malware attacks that may attempt to compromise the system's integrity. By ensuring a secure boot process, users can trust that their system is starting up in a safe and protected environment.

Compliance and Auditing

Digitally signed firmware also aids in compliance and auditing processes. Organizations often have strict regulatory requirements regarding data security and integrity. By utilizing an SSD with digitally signed firmware like the HPE P04175-004, businesses can demonstrate their commitment to maintaining secure systems and adherence to compliance standards. This is particularly important for industries such as finance, healthcare, or government, where data security is of paramount importance.

In conclusion, the HPE P04175-004 SSD's features, including its 3.2TB capacity, SAS12GBPS interface, small form factor, and digitally signed firmware, offer significant benefits and importance to users. The immense storage capacity ensures efficient data management and future-proofing, while the high-speed interface facilitates fast and reliable data transfer. The small form factor design provides space-saving advantages and improved airflow, making it suitable for various environments. Lastly, the digitally signed firmware guarantees data integrity, enhances system security, and aids in compliance efforts. Overall, the HPE P04175-004 SSD is a powerful storage solution that meets the diverse needs of users seeking high-performance and secure storage options.
