P19890-H21 HPE 480GB SATA-6GBPS Intensive Smart Carrier Solid State Drive

P19890-H21
* Product may have slight variations vs. image
Hover on image to enlarge

Brief Overview of P19890-H21

HPE P19890-H21 Intensive Smart Carrier SSD 480GB SATA-6GBPS. Factory-Sealed New in Original Box (FSB) with 3 Years Warranty

Contact us for a price
Ask a question

Additional 7% discount at checkout

SKU/MPNP19890-H21Availability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Manufacturer Warranty3 Years Warranty from Original Brand Product/Item ConditionFactory-Sealed New in Original Box (FSB) ServerOrbit Replacement Warranty1 Year Warranty
Google Top Quality Store Customer Reviews
Our Advantages
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Bank Transfer (11% Off)
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Overview of the 480GB Solid State Drive

The category dedicated to the HPE P19890-H21 480GB SATA-6Gbps Intensive Smart Carrier Solid State Drive is engineered for enterprise-class read-intensive storage workloads, combining performance, endurance and compatibility in one drive. This SSD is part of the SATA-6Gbps class of server-grade solid state drives, and is optimized for demanding environments such as database caching, big-data analytics, cloud infrastructure, virtualization and other I/O-heavy but read-dominant applications.

Main Specifications

  • Brand: HPE
  • Part Number: P19890-H21
  • Device Type: Solid State Drive (SSD)

Key Information

  • Capacity: 480GB
  • Form Factor: M.2 2280
  • Interface: SATA 6Gbps
  • Flash Memory Type: Triple-Level Cell (TLC)
  • Firmware Security: Digitally Signed Firmware
  • Workload Suitability: Read Intensive
  • Platform Compatibility: HPE Mainstream Compute Platforms
  • Height: 2280 M.2

Performance Metrics

Durability and Transfer Rates

  • Endurance: 1.50 DWPD (Drive Writes Per Day)
  • 30 Days Writes: 1324
  • Drive Transfer Rate: 600 MBps (external)

Sequential Performance

  • Max Sequential Read Throughput: 510 MiB/s
  • Max Sequential Write Throughput: 400 MiB/s

Random Performance and IOPS

  • Random Read IOPS (4KiB, Q=16): 65,000
  • Random Write IOPS (4KiB, Q=16): 38,000
  • Maximum Random Read IOPS (4KiB, Q=64): 76,000
  • Maximum Random Write IOPS (4KiB, Q=256): 39,500
  • Average Latency (Random Read, 4KiB, Q1): 125 μs
  • Average Latency (Random Write, 4KiB, Q1): 37 μs

Expansion & Connectivity

Interface and Bay Compatibility

  • Interface: SATA 6 Gb/s - M.2 Card
  • Compatible Bay: M.2 2280

Power Consumption

Efficient Power Usage

  • Idle Power: 1.03 W
  • Random Read Power: 1.23 W
  • Random Write Power: 1.23 W
  • Sequential Read Power: 1.89 W
  • Sequential Write Power: 2.50 W
  • Maximum Power Usage: 2.50 W

Compatibility Information

  • Designed for: HPE ProLiant Generation10 Servers

Capacity: 480GB

The HPE P19890-H21 SSD is equipped with an impressive storage capacity of 480GB. This substantial amount of storage space allows users to store a wide range of data, including documents, photos, videos, and applications. Whether you are a professional who deals with large files or an average user who wants to have ample storage for personal files, this SSD's capacity ensures that you will never run out of space.

Seamless Multimedia Experience

If you are a content creator or a multimedia enthusiast, the 480GB capacity of this SSD is a game-changer. It allows you to store a vast collection of high-quality photos, videos, and audio files, enabling you to work on your projects without any limitations. You can edit videos seamlessly, manipulate high-resolution images, and enjoy a smooth playback experience for your multimedia content.

Increased Productivity

The ample storage space provided by the 480GB capacity ensures that you can keep all your essential files and applications in one place. This eliminates the need to constantly search for files across multiple storage devices, saving you valuable time and increasing your overall productivity. Whether you are a professional working on multiple projects or a student managing various assignments, having all your files in one location simplifies your workflow.

Reliability and Durability

In addition to its impressive capacity, the HPE P19890-H21 SSD is built with reliability and durability in mind. With its solid-state design, it is more resistant to physical damage compared to traditional hard drives. This means that your data remains safe even if the drive experiences accidental drops or impacts. The SSD's durability ensures that your valuable files are protected and accessible at all times.

Interface: SATA-6GBPS

The HPE P19890-H21 SSD features a SATA-6GBPS interface, which provides several benefits and plays a crucial role in ensuring optimal performance for users.

High Data Transfer Speeds

The SATA-6GBPS interface offers significantly faster data transfer speeds compared to its predecessors. With a maximum transfer rate of 6 gigabits per second, this interface allows for swift and seamless data transfers between the SSD and your computer. Whether you are copying large files, running resource-intensive applications, or booting up your system, the high data transfer speeds provided by the SATA-6GBPS interface ensure minimal waiting time and a smooth user experience.

Enhanced System Responsiveness

With faster data transfer speeds, the SATA-6GBPS interface significantly improves system responsiveness. Your computer will be able to read and write data from the SSD at a much higher rate, resulting in reduced load times for applications and faster overall system performance. This enhanced responsiveness is particularly beneficial for users who work with resource-intensive software, such as graphic designers, video editors, and gamers.

Compatibility and Flexibility

The SATA-6GBPS interface is widely supported by modern computers and motherboards. This ensures compatibility with a broad range of systems, allowing you to easily integrate the HPE P19890-H21 SSD into your existing setup. Whether you have a desktop, laptop, or workstation, the SATA-6GBPS interface provides the flexibility to upgrade your storage without worrying about compatibility issues.

Seamless Upgrades

If you are looking to upgrade your existing storage solution, the SATA-6GBPS interface simplifies the process. You can easily replace your current hard drive or SSD with the HPE P19890-H21 SSD without the need for additional adapters or complex installation procedures. The seamless upgrade process ensures that you can quickly enhance your system's storage capacity and performance without any hassle.

Workload Class: Read-Intensive vs Mixed-Use

This category and sub-categories also distinguish between workload classes. Read-Intensive (RI) drives are optimized for high random read IOPS and moderate writes, making them ideal for read-dominant workloads such as analytics, caching, boot drives and content delivery. Mixed-Use (MU) drives would allow heavier write workloads but at higher cost.

Form-Factor & Carrier Options

Under this category you’ll also encounter multiple physical formats. The primary form-factors include M.2 2280 SSDs and 2.5″ SFF SSDs mounted on a Smart Carrier (sometimes referred to as “Intensive Smart Carrier” packaging). For example, some listing for the P19890-H21 references “M.2 2280” explicitly. :contentReference[oaicite:11]{index=11}

Smart Carrier refers to an integrated drive/sled with status indicators and a “Do Not Remove” button built-in, which helps reduce human error when drives are serviced in server racks. This makes them particularly suited for hot-swap data-center environments.
