P22603-001 HPE 24 Fiber 1 Meter Optic MPO to 4xLC SM Assembly Cable

HPE P22603-001 24 Fiber Optic MPO to 4xLC SM 1 Meter Assembly Cable Overview

The HPE P22603-001 24 Fiber Optic MPO to 4xLC SM 1 Meter Assembly Cable is a high-performance fiber optic solution designed to deliver reliable, high-speed connectivity in modern data center and enterprise networking environments. As part of HPE's structured cabling ecosystem, this assembly cable provides efficient and scalable connections for high-density fiber networks, ensuring optimal signal integrity and minimal insertion loss. With a length of 1 meter, this cable is ideal for short interconnect applications in patch panels, switches, and server racks, offering flexibility and precision in fiber management. Its single-mode (SM) construction allows for long-distance transmission with low attenuation, supporting the demanding requirements of enterprise and carrier-class networks.

Technical Specifications and Design

MPO to LC Conversion

This cable converts a 24-fiber MPO connector to four LC connectors, enabling efficient breakout of high-density fiber links into manageable channels. Each LC connector supports individual fiber transmission, allowing network administrators to easily route signals to multiple endpoints or equipment ports without additional cabling complexity. The MPO connector serves as a high-density aggregation point, which is essential for modern data center architectures that require space-saving fiber consolidation.

Single-Mode Fiber Construction

The cable utilizes single-mode (SM) fiber technology, which supports high-bandwidth transmission over long distances with minimal signal loss. SM fibers are ideal for backbone connections and long-reach applications where maintaining data integrity and low latency is critical. The HPE P22603-001 assembly ensures low attenuation rates and excellent return loss performance, making it suitable for high-speed data, voice, and video applications.

Cable Length and Flexibility

With a standardized 1-meter length, this assembly cable provides optimal reach for short connections between network devices and patch panels. Its flexible construction allows for easy routing within racks, minimizing cable congestion while maintaining proper bend radius and optical performance. The cable jacket is designed to withstand repeated handling and installation without compromising fiber integrity.

Performance and Signal Integrity

Low Insertion Loss

The HPE P22603-001 cable is engineered to maintain low insertion loss, ensuring maximum signal strength throughout the network. Low insertion loss is critical in high-speed environments, as it reduces the need for additional amplification or regeneration, leading to more efficient network operation and reduced operational costs.

High Return Loss

The assembly cable provides high return loss, minimizing back reflections that can interfere with signal integrity. This feature is essential for high-bandwidth applications such as 10G, 25G, 40G, and 100G Ethernet, where maintaining a clean signal path is crucial for error-free transmission.

Compatibility with Multi-Rate Networks

Designed for versatility, the MPO to LC assembly supports multi-rate network standards, making it suitable for both legacy 10G infrastructures and modern 25G, 40G, and 100G high-speed networks. This ensures future-proof connectivity and protects investments in fiber infrastructure.

Applications and Deployment Scenarios

Data Center Interconnects

The HPE P22603-001 is ideal for data center interconnect applications, linking high-density patch panels to switches or servers. The MPO connector simplifies consolidation of multiple fibers into a single module, while the LC outputs provide easy distribution to individual ports. This setup reduces installation complexity and maximizes port utilization in dense rack environments.

High-Density Fiber Management

In high-density network environments, managing fiber connections can be challenging. The MPO to LC assembly provides a structured approach, allowing network administrators to deploy and maintain multiple fiber links efficiently. The compact design and breakout configuration enable neat, organized cabling that simplifies troubleshooting and enhances airflow in racks.

Enterprise and Campus Networks

The cable is well-suited for enterprise and campus networks requiring reliable single-mode fiber connections between buildings, wiring closets, or network closets. Its 1-meter length supports flexible routing within racks and cabinets while maintaining optimal optical performance.

Telecommunications and Carrier Applications

Carrier-grade networks benefit from the HPE P22603-001 due to its low attenuation, high return loss, and compatibility with high-speed optical standards. The cable supports long-distance transmission with minimal signal degradation, making it suitable for metro and wide-area network deployments.

Reliability and Durability Features

Rugged Jacket Construction

The cable jacket is designed to resist abrasion, chemicals, and environmental stress, ensuring long-term reliability. Its robust construction allows it to withstand repeated handling, installation, and maintenance without compromising the integrity of the fibers.

Strain Relief and Bend Radius

Each connector features integrated strain relief, protecting the fiber from excessive tension during installation. The cable maintains an optimal bend radius, preventing microbends and macrobends that could lead to increased insertion loss or signal attenuation.

Hot-Plug and Modular Compatibility

The MPO connector supports hot-plug operations within modular network equipment, allowing administrators to add or remove connections without disrupting other fibers or devices. This enhances network flexibility and reduces downtime during maintenance or upgrades.

Easy Identification and Color Coding

The HPE P22603-001 assembly utilizes standardized color-coded connectors and cables for quick identification, reducing errors during installation. Clear labeling of MPO and LC connectors ensures proper mapping of fibers between devices and panels.

Efficient Rack and Panel Deployment

Its compact 1-meter length allows for tidy deployment within racks and patch panels, reducing cable congestion and improving airflow. This contributes to better cooling performance and overall system reliability.

Tool-Less Termination

The MPO and LC connectors are pre-terminated, eliminating the need for field termination and polishing. This minimizes installation time and ensures consistent optical performance across all connections.

Performance Metrics and Standards Compliance

Optical Performance Specifications

The HPE P22603-001 supports typical MPO insertion loss of less than 0.75 dB and LC insertion loss under 0.35 dB, with return loss exceeding 60 dB. These specifications meet or exceed industry standards for single-mode fiber assemblies, ensuring optimal performance in high-speed network environments.

Compliance with Industry Standards

This assembly cable is compliant with TIA/EIA-568 and ISO/IEC 11801 standards, ensuring compatibility with enterprise cabling infrastructures. It supports the latest IEEE Ethernet standards, including 10GBASE-SR, 40GBASE-SR4, and 100GBASE-SR10, making it suitable for modern and future network deployments.

Future-Proof Design

The MPO to LC architecture allows network expansion without extensive re-cabling. As network speeds increase or new equipment is deployed, the existing assembly can accommodate changes with minimal disruption, providing a scalable solution for evolving data center demands.

Business and Operational Value

Reduced Downtime and Maintenance Costs

With pre-terminated connectors, high durability, and easy identification, the HPE P22603-001 reduces the likelihood of installation errors and maintenance interruptions. Network reliability improves, contributing to operational continuity and lower support costs.

Optimized Data Center Performance

By minimizing insertion loss and maintaining low latency, this assembly ensures that data center applications operate at peak efficiency. High-speed, low-error fiber connections support virtualization, cloud computing, and high-performance computing workloads.

Enhanced Scalability and Flexibility

The MPO breakout design allows administrators to scale connections easily as business needs grow. Additional LC ports can be utilized without replacing the entire assembly, ensuring investment protection and simplified infrastructure expansion.

Comparative Advantages Over Alternative Solutions

High-Density MPO Integration

Compared to traditional point-to-point cabling, the MPO to LC assembly supports high-density connections, reducing cable bulk and improving rack space utilization. This is critical in modern data centers where space and airflow are premium considerations.

Superior Signal Integrity

Single-mode fiber combined with high-quality connectors ensures superior signal integrity compared to multimode alternatives in long-reach applications, reducing errors and retransmissions that could affect system performance.

Ease of Deployment

Pre-terminated, color-coded connectors and standardized lengths simplify deployment and troubleshooting. Unlike field-terminated solutions, this cable minimizes labor requirements and potential inconsistencies in optical performance.
