Proliant Ml350 Intel Xeon Gold 4-port Ethernet Adapter Tower Server HPE P69313-005

Processor

The HPE Proliant ML350 Gen11 Performance Tower Server is equipped with a powerful Xeon Gold 5416s processor. This processor is designed to deliver exceptional performance and reliability for demanding workloads.

Product Overview of Xeon Gold

• Manufacturer: Hewlett Packard Enterprise
• Part Number: P69313-005
• Type: Tower Server
• Height: 4U
• Server Scalability: 2-way
• Hot-swap Bays Quantity: 8
• Product Name: HPE ProLiant ML350

Processor and Chipset

• CPU: Intel Xeon Gold 5416S
• Clock Speed: 2 GHz
• Max Turbo Speed: 4 GHz
• Number of Cores: 16
• CPU Quantity: 1 (upgradable to 2)
• Socket Type: LGA4677 Socket-E
• Chipset: Intel C741
• Key Features: Hyper-threading Technology, Intel Turbo Boost Technology 2

Cache Memory

• Installed Size: 30 MB L3 Cache
• Cache Per Processor: 30 MB

RAM Specifications

• Installed Size: 64 GB (upgradable to 8 TB)
• Technology: DDR5 SDRAM - Advanced ECC
• Effective Memory Speed: 4400 MHz
• Rated Memory Speed: 4800 MHz
• Form Factor: DIMM 288-pin
• Memory Slots: 32 total, 30 available
• Configuration: 2 x 32 GB

Internal Storage

• Type: SSD
• Capacity: 2 x 480 GB
• Interface Type: SATA 6Gb/s

Optical Drive

• Optical Drive: None

Storage Controller

• Type: RAID - OCP
• Controller Interface Type: Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
• Controller Name: HPE MR408i-O Gen11 SPDM
• Channels: 8
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
• Buffer Size: 4 GB

Graphics Controller

• Video Memory: 16 MB
• Video Interfaces: VGA

Networking Capabilities

• Interface Type: Open Compute Project Mezzanine (OCP) 3.0
• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: Broadcom BCM5719
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 6
• Features: Wake On LAN (WoL), PXE Support

Expansion and Connectivity

• Hot-swap Bays: 8 total, 6 free (2.5" SFF)

Slots

• PCIe Slots: 4 x PCIe 5.0 x16 (x8 Mode)

Interfaces

• VGA Port: 1
• DisplayPort 1.1a: 1 (front)
• HPE iLO Type A: 1 (front, service port)
• HPE iLO RJ-45: 1 (rear, management port)
• LAN Ports: 4 x Gigabit Ethernet (RJ-45, rear)
• USB Ports: 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal), 1 x USB 2.0 (internal)

Miscellaneous Features

• Included Accessories: CPU Standard Heatsink, 8 Redundant Fans
• Theft/Intrusion Protection: Security Lock Slot (cable lock sold separately), Padlock Eye
• Security Slot Type: Kensington Security Slot
• Compliant Standards: TLS V1.2, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, Redfish API, SMBIOS 3.1, FIPS 140-3, ERP Lot 9, UEFI 2.7, Active Directory V1.0
• Manufacturer Selling Program: HPE Express Buy

Power Specifications

• Device Type: Power Supply - Hot-plug
• Power Redundancy: Yes
• Redundancy Scheme: 1+1
• Installed Quantity: 2
• Max Supported Quantity: 2
• Voltage Required: AC 100-120/200-240 V (50/60 Hz)
• Power Provided: 800 Watt
• 80 Plus Certification: 80 Plus Platinum

Operating System and Software

• Operating System Provided: None
• Software: HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)

Sustainability and Environmental Parameters

• Energy Star Certified: Yes
• Minimum Operating Temperature: 50 °F
• Maximum Operating Temperature: 95 °F
• Humidity Range: 8 - 90% RH (non-condensing)

Dimensions and Weight

• Width: 6.9 in
• Depth: 28 in
• Height: 18.2 in
• Weight: 54.52 lbs

Enhanced Performance

The Xeon Gold 5416s processor features 16 cores and 32 threads, providing the server with the ability to handle multiple tasks simultaneously. This allows for faster data processing and improved overall performance. Whether you are running resource-intensive applications or virtualizing your infrastructure, this processor can handle the workload with ease.

Increased Efficiency

With a base clock speed of 2.1GHz and a turbo boost frequency of up to 3.7GHz, the Xeon Gold 5416s ensures that your server operates at optimal efficiency. This means faster response times and reduced latency, resulting in a smoother user experience.

Advanced Security Features

Security is a top concern for businesses today, and the Xeon Gold 5416s processor includes advanced security features to protect your data. It supports Intel's Trusted Execution Technology (TXT), which helps safeguard against firmware attacks and unauthorized access. Additionally, it provides hardware-based encryption capabilities for securing sensitive data.

Future-Proofing

Investing in a server with the Xeon Gold 5416s processor ensures that you are prepared for future growth and advancements in technology. With its high core count and robust performance capabilities, this processor can handle the demands of emerging technologies and applications.

Memory

The HPE Proliant ML350 Gen11 Performance Tower Server is equipped with an impressive 64GB DDR5 SDRAM memory. This ample memory capacity allows for seamless multitasking and efficient data processing.

Improved Performance

With 64GB of DDR5 SDRAM memory, the server can handle large data sets and complex calculations without experiencing a performance slowdown. This means faster data access and processing, resulting in improved overall system performance.

Enhanced Multitasking

The generous memory capacity enables the server to handle multiple applications and virtual machines simultaneously. This is particularly beneficial for businesses that rely on virtualization technologies or run resource-intensive applications. The ability to efficiently multitask ensures that your server can handle the demands of your business without compromising performance.

Scalability

The 64GB DDR5 SDRAM memory is also scalable, allowing you to expand your server's memory capacity as your business grows. This scalability ensures that your server can adapt to changing workloads and accommodate future expansion without the need for a complete hardware overhaul.

Reliability and Error Correction

DDR5 SDRAM memory offers enhanced error correction capabilities, ensuring data integrity and system stability. This reduces the risk of data corruption or system crashes, providing a reliable and stable computing environment for your critical business operations.

Networking

The HPE Proliant ML350 Gen11 Performance Tower Server comes equipped with a 4-port Ethernet adapter, offering robust networking capabilities for your business needs.

High-Speed Connectivity

The 4-port Ethernet adapter allows for high-speed network connectivity, ensuring rapid data transfer between the server and other devices on your network. This is particularly important for businesses that rely on data-intensive applications or require seamless communication between multiple systems.

Improved Network Performance

With four Ethernet ports, the server can handle increased network traffic without experiencing a slowdown in performance. This ensures that your network operates at optimal speed, minimizing latency and maximizing productivity.

Flexibility and Scalability

The 4-port Ethernet adapter provides flexibility and scalability, allowing you to easily expand your network infrastructure as your business grows. Whether you need to connect additional devices or increase network capacity, this adapter can accommodate your changing needs.

Enhanced Security

The 4-port Ethernet adapter includes advanced security features to protect your network from unauthorized access and potential threats. It supports various security protocols, such as VLAN tagging and IPsec, ensuring that your data remains secure and confidential.

Storage

The HPE Proliant ML350 Gen11 Performance Tower Server is equipped with two 480GB SSD drives, offering ample storage capacity and high-speed performance.

Fast Data Access

The 480GB SSD drives provide faster data access compared to traditional hard disk drives (HDDs). This means reduced loading times for applications and improved overall system responsiveness. Whether you are accessing large files or running database-intensive applications, the SSD drives ensure that data retrieval is quick and efficient.

Reliability and Durability

SSD drives are more reliable and durable than HDDs, as they do not have any moving parts. This reduces the risk of mechanical failures and data loss, providing a more reliable storage solution for your critical business data. The increased durability of SSDs also makes them better suited for environments with vibration or shock.

Energy Efficiency

SSD drives consume less power compared to HDDs, resulting in lower energy costs and reduced environmental impact. By using SSDs in your server, you can contribute to a greener IT infrastructure while enjoying the benefits of faster storage performance.

Scalability and Data Redundancy

The two 480GB SSD drives offer scalability and data redundancy options. You can configure them in RAID arrays for improved data protection and increased storage capacity. RAID configurations provide redundancy by duplicating data across multiple drives, ensuring that your data remains accessible even in the event of a drive failure.

Power Supply

The HPE Proliant ML350 Gen11 Performance Tower Server features two 800w power supplies, offering reliable and efficient power delivery for your server infrastructure.

Redundancy and Fault Tolerance

With two 800w power supplies, the server has built-in redundancy. This means that if one power supply fails, the other can continue to power the server, ensuring uninterrupted operation. This redundancy is crucial for businesses that cannot afford downtime and need a reliable power supply solution.

Efficient Power Delivery

The 800w power supplies are designed to deliver power efficiently, minimizing energy waste and reducing electricity costs. They comply with energy efficiency standards, such as 80 PLUS certification, ensuring that your server operates in an environmentally friendly manner.

Hot-Swap Capability

The power supplies are hot-swappable, allowing you to replace a faulty unit without shutting down the server. This further enhances the server's availability and reduces maintenance time, as you can replace a failed power supply while the server is still running.

Monitoring and Management

The power supplies are equipped with monitoring and management capabilities, allowing you to track power consumption and manage power distribution. This enables you to optimize power usage and ensure that your server operates within its recommended power limits.

In conclusion, the HPE Proliant ML350 Gen11 Performance Tower Server offers exceptional performance, reliability, and scalability. With its Xeon Gold 5416s processor, 64GB DDR5 SDRAM memory, 4-port Ethernet adapter, 2x 480GB SSD drives, and 2x 800w power supplies, this server is well-equipped to meet the demands of modern businesses. Whether you need to run resource-intensive applications, virtualize your infrastructure, or handle large data sets, the ML350 Gen11 Performance Tower Server provides the power, speed, and flexibility required for efficient and reliable operations.
