P73512-001 HPE Broadcom BCM57608 2-Port 100GB QSFP112 Ethernet Adapter

Highlights of HPE P73512-001 Broadcom BCM57608 Adapter

The HPE P73512-001 Broadcom BCM57608 Ethernet Adapter is a high-performance, enterprise-grade networking solution designed to deliver ultra-fast 100Gb connectivity for modern data centers, virtualization platforms, and cloud computing environments. Featuring PCIe 5.0 x16 interface and Broadcom advanced controller technology, this stand-up network adapter ensures maximum bandwidth, low latency, and secure data transmission.

General Information

• Manufacturer: Hewlett Packard Enterprise (HPE)
• Part Number: P73512-001
• Host Interface: PCI Express 5.0 x16
• Product Type: Network Adapter
• Sub Type: 2-Port 100Gb Ethernet Adapter

Technical Specifications

Port and Interface Details

• Number of Ports: 2 × 100Gb Ethernet Ports
• Port Type: QSFP112
• Supported Speed Modes: 25Gb, 50Gb, and 100Gb
• Host Interface: PCI Express 5.0 x16
• Card Form Factor: Stand-Up Network Adapter

Chipset and Controller Specifications

• Network Controller: Broadcom BCM57608
• Chipset Type: Enterprise Ethernet ASIC
• Optimized for: High-performance server and data center networking

Power Requirements

• Maximum Power Consumption: 11 Watts
• Energy Efficient Design: Yes

Network Protocol and Feature Support

• Internet Protocol Support: IPv4 and IPv6
• RDMA Support: RoCEv2 (RDMA over Converged Ethernet)
• Tunnel Offload Support: VXLAN, NVGRE, and Geneve
• Receive Side Scaling (RSS): Supported
• Data Plane Development Kit (DPDK): Supported

Acceleration Capabilities

• Single Root I/O Virtualization (SR-IOV): Up to 128 Virtual Functions
• NPar Support: 8 Physical Functions per port (16 per adapter)
• VMware NetQueue Support: Yes
• Microsoft Virtual Machine Queue (VMQ): Supported
• Virtualization Optimization: Yes

Boot and Remote Boot Features

• UEFI PXE Boot: Supported
• Legacy BIOS PXE Boot: Not Supported (UEFI Only)
• iSCSI Remote Boot: Supported via UEFI

Security and Hardware Protection

• Root of Trust: Hardware-based security
• SPDM Support: Yes
• Secure Boot: Supported
• Authenticated Updates: Supported
• Audit Log Capability: Yes
• Secure Sanitization: Supported

Port and Connectivity Features

• 2 × QSFP112 Ethernet ports
• Supports auto-negotiation speeds of 25Gb, 50Gb, and 100Gb
• High-bandwidth connectivity for enterprise and cloud infrastructure
• Reliable and scalable networking performance

Advanced PCIe 5.0 x16 Performance

Equipped with next-generation PCIe 5.0 x16 interface, the HPE P73512-001 adapter ensures faster data transfer rates, improved system responsiveness, and optimized performance for high-speed networking applications.

Performance and Hardware Specifications

• PCI Express 5.0 x16 high-speed interface
• Broadcom BCM57608 advanced network controller
• Maximum power consumption of 11W
• Optimized for enterprise servers and data center deployments

Overview of HPE P73512-001 2 Port 100GB Ethernet Adapter

The HPE P73512-001 Broadcom BCM57608 2-Port 100GB PCIe 5.0 x16 QSFP112 Ethernet Adapter is designed to deliver exceptional networking performance, efficiency, and scalability for enterprise data centers, hyperscale computing environments, and modern cloud infrastructure. With dual 100Gb Ethernet connectivity, this advanced network adapter provides extremely high bandwidth capacity, enabling servers to communicate with network switches, storage arrays, and compute clusters at ultra-fast speeds. As enterprise applications continue to evolve and demand higher data throughput, reliable and high-performance network connectivity becomes essential for maintaining operational efficiency and ensuring consistent application responsiveness.

Dual-Port 100Gb Ethernet Connectivity for Maximum Bandwidth

The dual-port configuration of the HPE P73512-001 Ethernet adapter allows each port to operate independently at speeds of up to 100Gb per second, providing a combined bandwidth of up to 200Gb per second. This high-speed connectivity ensures that enterprise servers can handle large volumes of network traffic efficiently, reducing bottlenecks and improving overall application performance. Each port can be configured to support redundancy, load balancing, or network segmentation, providing flexibility in network design and improving system reliability. This ensures continuous network availability and prevents service disruptions in mission-critical environments.

Ultra-Low Latency and Packet Transmission

The Broadcom BCM57608 controller is engineered to provide ultra-low latency communication, ensuring efficient packet transmission across the network. Low latency is critical for applications that require real-time data processing, such as financial transactions, artificial intelligence workloads, and distributed computing systems. The adapter minimizes latency by using advanced hardware acceleration and intelligent traffic management technologies, ensuring faster data transfer and improved application responsiveness. Optimized packet transmission capabilities ensure efficient handling of network traffic, reducing packet loss and improving overall network stability. This ensures reliable communication between servers, storage systems, and network infrastructure.

PCI Express 5.0 x16 Interface for Data Transfer Efficiency

The PCI Express 5.0 x16 interface provides extremely high bandwidth connectivity between the network adapter and server system, ensuring that the adapter can operate at full performance without creating internal bottlenecks. PCIe Gen5 offers significantly higher bandwidth compared to previous PCIe generations, allowing faster communication between the adapter and server memory. This ensures efficient data transfer and improved overall system performance. The high-speed PCIe interface is essential for supporting modern enterprise workloads, including artificial intelligence, cloud computing, and large-scale virtualization. By providing direct high-speed connectivity to the server architecture, the adapter ensures efficient data exchange and optimized performance.

Improved System Performance and Reduced Bottlenecks

The PCIe Gen5 interface ensures efficient communication between the network adapter and server processor, reducing latency and improving overall system performance. This enables servers to handle large workloads efficiently.

QSFP112 Interface and Advanced Ethernet Connectivity

The QSFP112 interface provides high-speed Ethernet connectivity and supports modern networking standards. This ensures compatibility with advanced network infrastructure and high-speed switches. The interface supports high-speed optical transceivers and direct attach cables, providing flexible deployment options.

Enterprise-Class 100Gb Ethernet and Data Center Environments

The HPE P73512-001 Broadcom BCM57608 2-Port 100GB PCIe 5.0 x16 QSFP112 Ethernet Adapter delivers enterprise-grade networking performance designed to meet the demanding requirements of modern data centers, hyperscale cloud infrastructures, virtualization platforms, and high-performance computing environments. As organizations increasingly rely on real-time data processing, artificial intelligence applications, distributed storage systems, and high-throughput computing, the need for reliable, ultra-fast Ethernet connectivity becomes critical for maintaining system performance and operational continuity. This advanced network adapter enables servers to achieve extremely high-speed network communication, ensuring seamless connectivity between compute nodes, storage arrays, and network switches.

Dual-Port 100Gb Ethernet Architecture for Maximum Throughput and Redundancy

The dual-port design of the HPE P73512-001 network adapter allows each QSFP112 port to operate independently at speeds of up to 100Gb per second, providing a combined total bandwidth capacity of up to 200Gb per second. This high-speed connectivity ensures that servers can efficiently handle bandwidth-intensive workloads such as large-scale database processing, real-time analytics, virtualization traffic, and distributed computing operations. The availability of dual ports provides network administrators with flexibility in configuring network redundancy, load balancing, and failover mechanisms, ensuring continuous network availability and improved system resilience. In mission-critical environments where downtime can result in significant operational and financial impact, this redundancy capability ensures uninterrupted connectivity and reliable system performance.

Ultra-Low Latency Communication and Packet Handling

The Broadcom BCM57608 controller is specifically designed to provide ultra-low latency communication, ensuring rapid and efficient transmission of data packets across the network. Low latency is essential for real-time enterprise applications, artificial intelligence processing, financial transaction systems, and high-performance computing workloads where even minimal delays can impact performance. The adapter uses advanced packet processing and intelligent traffic management technologies to minimize transmission delays and ensure fast and efficient communication between servers and network infrastructure. This enhances application performance and improves overall system responsiveness.

PCI Express 5.0 x16 Interface for Maximum Internal Bandwidth

The PCI Express 5.0 x16 interface provides extremely high-speed connectivity between the network adapter and the server's internal architecture, ensuring maximum data transfer performance and eliminating internal bandwidth bottlenecks. PCIe Gen5 technology offers significantly higher throughput compared to previous PCIe generations, enabling faster communication between the adapter and system memory. This ensures that the network adapter can fully utilize its dual 100Gb Ethernet ports without limitations, providing optimal network performance and improved application efficiency.

Server Integration and High-Speed Data Exchange

The direct integration with the PCIe Gen5 x16 interface allows the network adapter to communicate efficiently with server components, reducing latency and improving data transfer efficiency. This ensures that servers can handle high-speed network traffic without performance degradation, enabling efficient workload processing and improved system productivity.

QSFP112 Interface Technology for Reliable High-Speed Ethernet

The QSFP112 interface provides advanced high-speed connectivity designed for modern 100Gb Ethernet networking environments. This interface supports high-speed optical transceivers and direct attach cables, providing flexible deployment options for different network configurations. The advanced signal integrity and high-speed transmission capabilities of QSFP112 ensure reliable and stable network connectivity, reducing the risk of data transmission errors and improving overall network reliability. The adapter ensures seamless integration with modern Ethernet switches and network infrastructure, enabling efficient communication across enterprise and cloud environments. This ensures consistent performance and reliable connectivity for mission-critical applications.

Advanced Hardware Acceleration

The Broadcom BCM57608 controller provides advanced hardware acceleration features that improve overall system efficiency by offloading network processing tasks from the server CPU. This reduces processor utilization and allows the server to focus on executing application workloads, improving overall system performance and scalability. Hardware-based network acceleration ensures efficient packet processing, reducing latency and improving data transfer efficiency. This capability is particularly beneficial in virtualized environments where multiple virtual machines share the same network interface. By reducing CPU overhead, the adapter improves virtualization performance and ensures efficient resource utilization.

Enterprise Reliability, Scalability, and Long-Term Infrastructure

The HPE P73512-001 Broadcom BCM57608 Ethernet Adapter is designed with enterprise-grade components to ensure reliable and continuous operation in demanding data center environments. Its robust architecture ensures stable network connectivity, reduced downtime, and consistent performance, making it suitable for mission-critical enterprise applications. The adapter supports scalable network infrastructure, enabling organizations to expand their IT environments without compromising performance. The scalable and future-ready design ensures compatibility with evolving networking technologies, protecting infrastructure investment and enabling long-term deployment.
