HPE P74440-005 MicroServer Gen11 E-2434 32GB-180W External NA Server

Product Overview of the HPE P74440-005 Proliant Microserver

General Information

• Brand: HPE
• Part Number: P74440-005
• Product Line: Proliant Microserver

Product Description

• Processor: Intel Xeon E-2434, 4-core, 3.4 GHz (Turbo up to 5 GHz)
• Memory: 32 GB DDR5 SDRAM ECC, expandable up to 512 GB
• Storage: 1x 4TB SATA HDD with support for up to 4 large form factor (LFF) HDDs
• Network Adapter: HPE EMB 1Gb 4-Port
• Power: 180W external adapter, non-redundant

Processor and Performance

Key Processor Features

• Intel Xeon E-2434, 4-core, clock speed of 3.4 GHz
• Turbo Boost Technology 2, enhancing speed up to 5 GHz
• 12 MB L3 Cache for efficient multitasking

Scalability

• Single-processor architecture
• Expandable CPU slot for future upgrades

Memory and Storage

Memory Specifications

• 32 GB installed, supporting advanced ECC
• 16 DIMM slots available, with a maximum capacity of 512 GB
• HP SmartMemory compatibility ensures performance reliability

Storage Highlights

• One 4 TB SATA HDD included
• Supports up to 4 large form factor drives
• SATA interface with 6Gb/s transfer speed

Networking and Connectivity

Networking Features

• Four Gigabit Ethernet ports
• Support for SNMP 3 and IPMI 2.0 for remote management
• Wake-on-LAN and PXE support

Connectivity Ports

• VGA and DisplayPort 1.1a
• Four USB 3.2 Gen 1 (rear) and two USB 3.2 Gen 2 (front)

Expansion and Graphics

Expansion Slots

• 1 PCIe 5.0 x16 (low-profile)
• 1 PCIe 4.0 x8 (x4 mode)

Graphics Controller

• 16 MB video memory
• Compatible with VGA and DisplayPort interfaces

Power and Environmental Features

Power Supply

• 180W external power adapter
• AC 100-240V input with 50/60Hz frequency

Environmental Parameters

• Operating temperature range: 50°F to 95°F
• Humidity range: 8% to 90% RH (non-condensing)

Certifications and Software

Compliance and Standards

• Energy Star 4.0 certified
• FCC Class B, EN55024, and other global certifications

Pre-installed Software

• HPE Intelligent Provisioning
• HPE iLO Management

Dimensions and Build

Physical Specifications

• Width: 26.1 inches
• Depth: 24.9 inches
• Height: 15.4 inches
• Weight: 19.07 lbs

Overview of the HPE P74440-005 Gen11 E-2434 MicroServer

The HPE P74440-005 Gen11 E-2434 MicroServer offers an exceptional balance of performance, scalability, and efficiency. Designed for small businesses, home offices, and edge computing environments, this server provides robust hardware with simplified management features, ensuring seamless operations for diverse workloads. Its compact form factor and reliable components make it an ideal choice for organizations requiring dependable server solutions at a competitive price.

Key Features and Specifications

Processor and Performance

At the heart of the HPE Gen11 MicroServer is the powerful Intel Xeon E-2434 processor. Featuring 4 cores and 8 threads, this CPU delivers efficient multitasking and computing power for demanding applications. With a base clock speed of 3.5 GHz and turbo boost up to 4.8 GHz, it ensures that workloads, from virtualization to data-intensive tasks, are handled with ease.

Memory and Storage

This MicroServer is equipped with 32GB of DDR4 ECC memory, providing stability and reliability for critical workloads. The Error Correcting Code (ECC) memory ensures that data integrity is maintained, reducing the risk of system crashes and data corruption.

The server comes with 4 Large Form Factor (LFF) Non-Hot Plug (NHP) drive bays, offering flexibility in storage configuration. It includes a pre-installed 4TB hard drive, making it ready for immediate deployment. These bays support additional drives for expanding storage as your business grows.

Power Supply

The 180W external power supply is designed to provide efficient and reliable energy management. This low-power unit supports the server's operations while maintaining energy efficiency, reducing operational costs and environmental impact.

Designed for Versatile Applications

Small Businesses and Home Offices

For small businesses and home office setups, the HPE P74440-005 Gen11 MicroServer provides the perfect solution for hosting essential business applications, file sharing, and collaboration tools. Its compact design allows it to fit comfortably in limited spaces while delivering enterprise-grade performance.

Edge Computing and Remote Sites

The server’s robust build and reliability make it ideal for edge computing environments and remote office deployments. Whether processing data locally or serving as a backup solution for larger data centers, it ensures smooth operations with minimal downtime.

Virtualization and Containerized Applications

The Intel Xeon E-2434 processor, combined with ample memory, supports light virtualization and containerized workloads. This makes the server a valuable asset for IT teams needing to test, deploy, and manage virtual environments efficiently.

Management and Security

Simplified Server Management

The HPE Gen11 MicroServer includes HPE iLO (Integrated Lights-Out) for simplified remote server management. This intuitive tool provides administrators with real-time monitoring, remote configuration, and troubleshooting capabilities, ensuring optimal server performance and uptime.

Enhanced Security Features

Security is a top priority for the HPE P74440-005. With features such as Silicon Root of Trust, secure boot, and firmware validation, this server safeguards against potential threats. These layers of protection ensure that your data and applications are secure from unauthorized access and malicious activities.

Scalability and Expandability

Flexible Storage Options

The 4 LFF-NHP drive bays offer significant storage expansion opportunities. Businesses can upgrade to larger capacity drives or implement RAID configurations to enhance data redundancy and performance.

Memory Upgrades

The server supports additional memory modules, allowing users to expand beyond the pre-installed 32GB. This scalability ensures the server remains capable of handling increased workloads as your business grows.

Energy Efficiency and Sustainability

Low Power Consumption

With its 180W external power supply, the HPE Gen11 MicroServer minimizes energy consumption while delivering consistent performance. This efficient power usage reduces operational costs, making it an eco-friendly choice for budget-conscious businesses.

Sustainable Design

HPE focuses on sustainability, ensuring that its servers are built with energy-efficient components and recyclable materials. The P74440-005 contributes to reducing your organization’s carbon footprint while maintaining high performance.

Comparison with Other MicroServers

Advantages of the Gen11 E-2434 MicroServer

Compared to previous generations and other models in the market, the HPE Gen11 MicroServer stands out for its balance of affordability, performance, and reliability. The inclusion of modern features like ECC memory and iLO management ensures it meets the demands of modern businesses.

Competitor Analysis

When compared to similar offerings from competitors, such as Dell EMC PowerEdge or Lenovo ThinkSystem servers, the HPE P74440-005 excels in energy efficiency and simplicity, particularly for small businesses and remote offices.

Practical Use Cases

File and Print Server

The HPE Gen11 MicroServer can efficiently manage file and print services for small to medium-sized teams. Its reliable storage and memory capabilities ensure quick access and seamless operations.

Backup and Disaster Recovery

With its scalable storage and secure design, the server is well-suited for backup and disaster recovery solutions. Businesses can safeguard critical data and ensure rapid recovery in case of system failures.

Lightweight Database Hosting

The powerful Intel Xeon E-2434 processor and ample memory make this server ideal for hosting lightweight databases. Its reliability ensures consistent performance for transactional or analytical tasks.

Technical Specifications Summary

Processor

• Model: Intel Xeon E-2434
• Base Clock Speed: 3.5 GHz
• Max Turbo Speed: 4.8 GHz
• Cores/Threads: 4/8

Memory

• Type: DDR4 ECC
• Capacity: 32GB (expandable)

Storage

• Bays: 4 LFF-NHP
• Included Drive: 4TB HDD
• Expandable Storage Options

Power Supply

• Power: 180W External

Management and Security

• Management Tool: HPE iLO
• Security Features: Silicon Root of Trust, Secure Boot

Support and Warranty

Comprehensive Support Options

HPE offers robust support for the Gen11 MicroServer, including software updates, technical assistance, and optional extended warranties. Businesses can rely on HPE’s expertise for seamless server maintenance and upgrades.

Warranty Coverage

The server comes with a standard warranty, covering parts and labor. Additional support packages are available for extended protection and priority service.
