P83036-005 HPE AMD EPYC 16-Core 9115 2.6GHz 256GB DDR5 Server.

HPE P83036-005 Proliant DL385 AMD EPYC 16-Core Server

Explore the formidable HPE ProLiant DL385 Gen11, engineered with cutting-edge AMD EPYC Turin processors. This enterprise-grade computing solution, identified by part number P83036-005, is built for demanding data center workloads, offering exceptional core density, advanced memory technology, and robust storage in a 2U form factor.

Core Processing Specifications and CPU Details

Processor Configuration

• Processor Family: 5th Generation AMD EPYC 9115
• Core and Thread Count: 16-core, 32-thread per CPU
• CPU Quantity: 2 processors installed (supports up to 2)
• Base Clock Frequency: 2.6 GHz
• Maximum Boost Speed: Up to 4.1 GHz
• All-Core Boost Frequency: 3.3 GHz
• Thermal Design Power (TDP): 125W
• CPU Socket: SP5

Advanced CPU Architecture Features

• AMD Infinity Architecture for scalable, high-bandwidth connectivity
• AMD Infinity Guard for integrated security at the silicon level
• Fully upgradable processor design for future scalability

Memory and Cache Architecture

Installed RAM and Technology

• Total Installed Memory: 256 GB
• Maximum Supported Capacity: 6.0 TB
• Memory Technology: DDR5 RDIMM (Registered Dual In-Line Memory Module)
• Memory Speed: 6400 MHz (Effective & Rated)
• Memory Bandwidth per Socket: 614 GB/s
• DIMM Slots: 24 total (16 slots available)
• Current Configuration: 8 x 32 GB modules

HPE Smart Memory Features

• HPE DDR5 Smart Memory for optimized performance and reliability
• Registered (buffered) memory for enhanced signal integrity
• Note: Slots 13-24 are accessible in a dual-processor configuration only

Processor Cache Hierarchy

• Total Smart Cache: 128 MB
• Cache per Processor: 64 MB

Storage Subsystem and Expansion

Internal Drive Configuration

• Total Drive Bays: 8 x Hot-swap 2.5" SFF (Small Form Factor)
• Available Bays: 6 free
• Installed Storage: 2 x 480 GB SATA SSDs
• Total Installed Capacity: 960 GB
• Drive Interface: SATA 6 Gb/s
• Optical Drive: Not included

Storage Controller and RAID Capabilities

• Controller Model: HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
• Controller Interface: Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
• RAID Levels Supported: RAID 0, 1, 5, 6, 10, 50, 60
• Controller Cache: 4 GB
• Channel Quantity: 8

Networking and Connectivity Portfolio

Network Interface Card (NIC)

• Primary Adapter: Broadcom BCM57416 Ethernet 10Gb 2-port Base-T Adapter
• Ethernet Ports: 2 x Gigabit Ethernet (10Gb capable)
• Supported Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Advanced Features: Wake-on-LAN (WoL), PXE boot support

Server Management and Remote Access

• Remote Management Controller: HPE Integrated Lights-Out 6 (iLO 6)
• Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Dedicated Service Port: 1 x iLO port (front)

Expansion Slots and External Ports

• PCIe Expansion: 1 x PCIe 5.0 x16 slot (free)
• Video Output: 1 x VGA port
• USB Ports: 5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal)
• Card Reader: MicroSD card reader support

Power and Cooling Infrastructure

Power Supply Unit (PSU)

• Power Supply Type: Hot-plug, redundant power supply kit
• Installed Quantity: 2 power supplies
• Maximum Supported: 2
• Wattage per PSU: 800 Watt
• Efficiency Rating: 80 PLUS Platinum certified
• Input Voltage: AC 100-120/200-240 V (50/60 Hz)
• Redundancy Scheme: 1+1 configuration for continuous uptime

Thermal and Cooling System

• Included Cooling: 6 x standard high-performance fans
• Operating Temperature Range: 50°F to 95°F (10°C to 35°C)
• Operating Humidity Range: 8% to 90% RH (non-condensing)
• Compliance: ASHRAE Class A3 and A4 compliant for data center deployment

Physical Dimensions, Weight, and Compliance

• Form Factor: 2U Rackmount Server
• Height: 3.44 inches
• Width: 17.11 inches
• Depth: 25.44 inches
• Weight: 36.92 lbs

Regulatory and Environmental Certifications

• Energy Star Certified: Yes (Version 4.0)
• Security Standards: FIPS 140-2, AES, Triple DES, TLS v1.2, PCI DSS
• Environmental Directives: WEEE 2002/95/EC compliant
• General Compliance: ACPI 6.1, IPv6 Ready

HPE P83036-005 Proliant DL385 16-Core Server Overview

The HPE P83036-005 ProLiant DL385 Gen11 server category represents a new generation of enterprise-grade rack servers designed to handle compute-intensive, memory-heavy, and data-driven workloads with exceptional efficiency. Built on the AMD EPYC Turin 16-Core 9115 processor platform, this category is engineered for organizations seeking high core performance, advanced I/O capabilities, and future-ready scalability within a compact and power-optimized rack form factor. As part of the ProLiant DL300 series, this server category is tailored for businesses running virtualization platforms, private and hybrid cloud infrastructures, high-performance databases, and mission-critical enterprise applications.The DL385 Gen11 platform emphasizes balanced performance across compute, memory, storage, and networking. With support for DDR5 RDIMM memory, PCIe Gen5 expansion, and enterprise-class networking, this category addresses the evolving needs of modern IT environments where data throughput, latency reduction, and energy efficiency are equally important. Designed to integrate seamlessly into existing HPE ecosystems, this server category supports centralized management, enhanced security, and lifecycle optimization for data centers of all sizes.

AMD EPYC Turin 9115 Processor Performance and Efficiency

At the core of the HPE ProLiant DL385 Gen11 category is the AMD EPYC Turin 9115 16-Core processor operating at a base frequency of 2.6GHz. This processor architecture is optimized for single-threaded and multi-threaded workloads, delivering consistent performance across diverse enterprise use cases. The Turin generation enhances instruction throughput, memory access efficiency, and power management, making it suitable for workloads ranging from transactional databases to containerized microservices.The 16-core configuration offers an ideal balance for organizations that require strong per-core performance without excessive power consumption. This makes the category particularly attractive for virtualization clusters where predictable performance per virtual machine is critical. Advanced AMD Infinity Fabric technology ensures low-latency communication between cores and memory, while modern instruction sets accelerate analytics, encryption, and compression tasks. The result is a server category that delivers high compute density while maintaining operational efficiency.

Optimized for Virtualization and Cloud-Native Workloads

The DL385 Gen11 server category is purpose-built to support virtualization platforms such as VMware, Hyper-V, and KVM-based environments. The AMD EPYC Turin processor provides ample core resources to host multiple virtual machines with consistent performance, while advanced memory bandwidth ensures smooth operation under heavy load. Cloud-native workloads benefit from the processor’s scalability and efficient context switching, enabling rapid deployment and orchestration of containers and services.

Performance Consistency for Business-Critical Applications

Enterprise applications demand predictable performance, low latency, and high availability. This category is engineered to meet those demands by combining robust CPU architecture with high-speed memory and reliable I/O pathways. From ERP systems to customer-facing applications, the DL385 Gen11 category ensures sustained performance even during peak usage periods.

DDR5 RDIMM Memory Architecture and Capacity Expansion

Memory performance plays a pivotal role in modern server workloads, and the HPE ProLiant DL385 Gen11 category leverages DDR5 RDIMM technology to deliver higher bandwidth, improved power efficiency, and increased capacity compared to previous generations. With a factory configuration of 256GB DDR5 RDIMM memory, this category is well-suited for memory-intensive workloads such as in-memory databases, virtualization hosts, and real-time analytics platforms.

DDR5 technology introduces higher data transfer rates and enhanced reliability features, ensuring that applications can access data quickly and consistently. The scalable memory architecture allows organizations to expand capacity as workload demands grow, protecting initial investments while enabling long-term flexibility. Error correction and advanced memory management features further enhance system stability, reducing the risk of downtime caused by memory-related issues.

High-Bandwidth Memory for Data-Driven Server

Data-driven applications require rapid access to large datasets. The DDR5 RDIMM configuration in this category ensures that processors are never starved for data, maximizing compute efficiency and application responsiveness. This makes the DL385 Gen11 category particularly suitable for analytics engines, AI inference workloads, and large-scale transactional systems.

Reliability and Data Integrity Enhancements

Enterprise memory reliability is critical in mission-critical environments. The DDR5 RDIMM architecture includes advanced error detection and correction mechanisms, ensuring data integrity even under continuous operation. These features help organizations maintain high service availability and reduce maintenance overhead.

High-Speed Networking Broadcom BCM57416 10Gb Ethernet

Networking performance is a key differentiator for modern servers, and the HPE ProLiant DL385 Gen11 category integrates Broadcom BCM57416 Ethernet controllers with dual 10Gb ports. This high-speed networking capability ensures fast and reliable data transfer between servers, storage systems, and network infrastructure. The dual-port configuration supports redundancy, load balancing, and network segmentation, enhancing both performance and resilience.

The 10Gb Ethernet capability is ideal for virtualization clusters, software-defined storage, and high-throughput application environments. It enables rapid VM migration, efficient data replication, and low-latency communication across distributed systems. This networking architecture also supports future upgrades, allowing organizations to scale network performance as demands increase.

Optimized Network Throughput for Virtualized Data Centers

Virtualized environments rely heavily on network performance for VM mobility and inter-VM communication. The integrated Broadcom 10Gb Ethernet ensures that network bottlenecks are minimized, enabling smooth operation even in densely populated virtualization hosts.

Enterprise Network Reliability and Security

The networking components in this category support advanced features such as VLAN tagging, offloading, and secure boot integration. These capabilities enhance network security and efficiency, ensuring that data flows are protected and optimized throughout the infrastructure.

Read Intensive Storage for Performance-Critical Workloads

The HPE P83036-005 ProLiant DL385 Gen11 category is designed to support read intensive storage configurations, making it ideal for applications that prioritize fast data access and low latency. Read intensive workloads such as web services, content delivery platforms, analytics dashboards, and search engines benefit from optimized storage pathways and enterprise-grade SSD support.

The server architecture ensures that storage devices can operate at full performance without contention, leveraging modern controller designs and high-speed interfaces. This focus on read performance allows organizations to deliver responsive user experiences and maintain consistent application performance under heavy read loads.

Low Latency Data Access for User-Facing Applications

Applications that serve large volumes of read requests require fast and predictable storage performance. This category supports such use cases by ensuring efficient data paths from storage to memory and processor, reducing latency and improving overall responsiveness.

Scalability for Growing Data Volumes

As data volumes grow, storage requirements evolve. The DL385 Gen11 category provides flexible storage expansion options, allowing organizations to scale read intensive capacity without redesigning their infrastructure.

Power Efficiency with 800W Platinum Hot Plug Power Supply

Energy efficiency is a critical consideration in modern data centers, and the HPE ProLiant DL385 Gen11 category addresses this with an 800W Platinum-rated hot plug power supply kit. Platinum efficiency certification ensures reduced power loss, lower operating costs, and improved thermal management. The hot plug design enables power supply replacement without system downtime, supporting high availability requirements.

This power architecture is optimized to support high-performance components while maintaining energy efficiency. It enables organizations to deploy dense server configurations without exceeding power and cooling budgets, making it suitable for both enterprise data centers and colocation facilities.

Operational Continuity Through Redundant Power Design

The hot plug power supply supports redundancy configurations, ensuring continuous operation even in the event of a power supply failure. This feature is essential for mission-critical environments where uptime is a top priority.

Advanced Management and Security with HPE ProLiant Gen11 Platform

The HPE ProLiant DL385 Gen11 category integrates advanced management and security features that simplify administration and enhance system protection. HPE’s management ecosystem provides comprehensive visibility into server health, performance metrics, and firmware status, enabling proactive maintenance and efficient resource utilization.

Security is embedded at every level of the platform, from silicon root of trust to secure boot and firmware validation. These features protect against unauthorized access and firmware tampering, ensuring that systems remain trusted throughout their operational lifecycle.

Centralized Management for Scalable Operations

IT teams can manage multiple servers within this category from a centralized interface, streamlining deployment, monitoring, and updates. This capability is particularly valuable for organizations operating large-scale environments with limited administrative resources.

Built-In Security for Compliance and Reduction

The security features of the DL385 Gen11 category support compliance with industry standards and regulatory requirements. By protecting system integrity and data access, organizations can reduce risk and maintain trust with customers and stakeholders.
