P83278-005 HPE 6315P 2.8GHz DL20 Gen11 2x1TB HDD PS NA Server

Highlights of HPE P83278-005 ProLiant DL20 Gen11 Server

The HPE P83278-005 ProLiant DL20 Gen11 Smart Choice Server is a compact yet powerful 1U rack server, designed for small to medium businesses, edge deployments, and enterprise branch offices. Powered by the Intel Xeon 6315P processor and DDR5 memory, this server delivers reliable performance, scalability, and energy efficiency in a space-saving form factor.

General Information

• Manufacturer: Hewlett Packard Enterprise (HPE)
• Part Number: P83278-005
• Form Factor: 1U Rack-mount
• Product Type: HPE ProLiant DL20 Gen11 Rack Server
• Hot-Swap Drive Bays: 2 x LFF

Technical Specifications

High-Performance Intel Xeon CPU

• Processor Model: Intel Xeon 6315P (Raptor Lake)
• Core Count: 6 Cores
• Base Clock Speed: 2.8 GHz
• Maximum Turbo Frequency: Up to 5.2 GHz
• CPU Quantity: 1 Installed / 1 Maximum
• Bus Speed: 16 GT/s
• Thermal Design Power: 55W
• Server Scalability: Single-socket (1-way)

Advanced Processor Features

• Intel Turbo Boost Technology 2.0
• Intel Turbo Boost Max Technology 3.0
• Intel Smart Cache
• Upgradeable CPU Support

Chipset Details

• Chipset Type: Intel C262

Cache Memory Configuration

• L3 Cache Size: 12MB per Processor

System Memory (RAM)

DDR5 ECC Memory Support

• Installed Memory: 16GB DDR5 UDIMM ECC
• Maximum Supported Memory: Up to 128GB
• Memory Speed: 4800 MT/s
• Slots Available: 4 DIMM Slots (3 Free)
• Form Factor: 288-pin DIMM

Memory Features

• Error-Correcting Code (ECC)
• Unbuffered HPE Standard Memory
• Optimized for Enterprise Reliability

Internal Storage & Drive Bays

Preconfigured Storage Capacity

• Total Storage: 2TB
• Drive Type: SATA HDD
• Installed Drives: 2 x 1TB
• Drive Size: 3.5-inch LFF
• Spindle Speed: 7200 RPM
• Interface: SATA 6Gb/s

Drive Bay Configuration

• 2 x Hot-swap LFF Bays

Storage Controller & RAID Support

• Controller Type: SATA RAID Controller
• Channels: 6
• Supported RAID Levels: RAID 0, 1, 5, 10

Graphics & Video Output

• Graphics Controller: Matrox G200
• Video Memory: 16MB
• Display Interfaces: VGA, DisplayPort

Networking & Remote Management

Enterprise-Grade Connectivity

• Network Ports: 4 x Gigabit Ethernet (RJ-45)
• Ethernet Controller: Broadcom BCM5719
• Supported Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet

Management & Network Features

• HPE iLO Management Interface
• SNMP v3 & IPMI 2.0 Support
• Wake-on-LAN (WOL)
• PXE Boot & ACPI Support

Expansion Slots & Connectivity Options

Expansion Capabilities

• 1 x PCIe 5.0 x16 Slot (Full-height, Half-length)
• 1 x OCP 3.0 Mezzanine Slot

External & Internal Interfaces

• 1 x HPE iLO Service Port (Front)
• 5 x USB 3.2 Gen1 Type-A (1 Front, 4 Rear)
• 2 x USB 3.2 Gen2x2 (Internal)
• 1 x DisplayPort
• 1 x VGA Port
• 4 x LAN Ports

Power Supply & Energy Efficiency

• Power Supply: 290W Hot-Plug PSU
• Efficiency Rating: 80 Plus Platinum
• Power Efficiency: Up to 92%
• Input Voltage: AC 100–120V / 200–240V

Operating System & Software Compatibility

OS Support

• No Operating System Pre-installed
• Certified for Windows Server 2019 & 2022
• VMware ESXi 8.0 Update 2 Supported

Included HPE Software

• HPE Intelligent Provisioning
• HPE iLO Management Tools

Compliance, Security & Sustainability

• Energy Star Certified (Version 4.0)
• Compliant with AES, FIPS 140-2, TLS v1.2
• Supports Redfish API & UEFI 2.9
• ASHRAE Class A3 & A4 Certified

Environmental & Acoustic Characteristics

• Operating Temperature: 50°F to 95°F
• Humidity Range: 8% – 90% (Non-condensing)
• Noise Level: 22 dBA

Physical Dimensions & Weight

• Width: 17.11 inches
• Depth: 15.05 inches
• Height: 1.7 inches
• Weight: 19.84 lbs

Included Accessories

• HPE Easy Install Rail 12 Kit
• 3 x High-Performance Non-Hot Plug Fans

Overview of HPE P83278-005 Enterprise-Class Edge Server

The HPE P83278-005 6315P 2.8GHz DL20 Gen11 4c 1P 1x16GB-U 2LFF-NHP 2x1TB HDD 1x290W PS NA Server represents a compact yet enterprise-grade server platform designed to deliver dependable compute performance in space-constrained and cost-sensitive deployments. Built on the HPE ProLiant DL20 Gen11 foundation, this server category addresses the evolving requirements of small to mid-sized businesses, distributed enterprises, branch offices, retail environments, and dedicated hosting infrastructures. Its balanced configuration focuses on efficiency, reliability, and scalability while maintaining the enterprise standards that HPE ProLiant servers are known for worldwide.

AMD EPYC 6315P Processor Performance

At the heart of the HPE P83278-005 DL20 Gen11 server is the AMD EPYC 6315P processor, a modern data center CPU designed for single-socket platforms that prioritize performance per watt and cost efficiency. Operating at a base frequency of 2.8GHz and featuring four high-performance cores, this processor delivers consistent compute capability for transactional workloads, infrastructure services, and lightweight virtualization scenarios. The EPYC 6315P architecture benefits from AMD’s Zen core design, offering strong single-threaded and multi-threaded performance characteristics within a power-efficient envelope.

Single-Socket Server Design

The 1P architecture of the HPE DL20 Gen11 server category simplifies system design and thermal management, resulting in quieter operation and lower overall power consumption. By focusing on a single AMD EPYC 6315P processor, this category delivers predictable performance while minimizing complexity. This design approach supports environments where efficiency, uptime, and total cost of ownership are critical decision factors.

Memory Configuration and Data Handling

The HPE P83278-005 server configuration includes 1x16GB unbuffered memory, providing a solid foundation for operating systems and essential applications. This memory capacity is well-suited for entry-level server workloads, test environments, and dedicated service roles. The DL20 Gen11 server category supports scalable memory expansion, allowing organizations to increase capacity as application demands evolve. Unbuffered memory contributes to lower latency and efficient data access, making it suitable for workloads that rely on fast response times rather than extremely high memory density.

Scalability and Future-Proof Memory Architecture

Although the base configuration includes 16GB of memory, the DL20 Gen11 platform supports future upgrades that enable organizations to adapt the server to growing workloads. This scalability ensures that the HPE P83278-005 category remains relevant beyond initial deployment, offering flexibility for expanding virtualization, database growth, or application consolidation without requiring a complete hardware replacement.

Storage Subsystem with Dual Large Form Factor Drives

The storage configuration of the HPE P83278-005 6315P DL20 Gen11 server includes two 1TB hard disk drives housed in large form factor bays. This dual-drive setup provides ample local storage capacity for operating systems, application data, backups, and file repositories. The use of large form factor drives aligns with the category’s emphasis on cost-effective capacity rather than ultra-high IOPS performance, making it ideal for general-purpose server roles.

Data Reliability and Storage Flexibility

HPE ProLiant servers are known for their robust storage controllers and firmware integration, ensuring data integrity and consistent performance. The HPE P83278-005 server category benefits from these design principles, delivering reliable data handling for business-critical information. Storage expansion options enable organizations to evolve from basic file storage to more structured data management strategies as operational needs grow.

Compact 1U Form Factor and Physical Design Advantages

The HPE DL20 Gen11 server category is housed in a compact 1U rack-mount chassis, making it ideal for environments with limited rack space or shallow-depth cabinets. This form factor is particularly beneficial for edge deployments, remote offices, telecommunications closets, and colocation facilities where space efficiency is essential. Despite its compact size, the DL20 Gen11 maintains enterprise-grade build quality and thermal engineering. The short-depth design of this server category simplifies installation in non-traditional rack environments while maintaining proper airflow and cooling.

Cooling and Acoustic

Thermal management in the DL20 Gen11 server category is optimized to ensure consistent performance without excessive noise. Intelligent fan control and efficient airflow pathways contribute to stable operation across varying workload intensities. This makes the HPE P83278-005 server suitable for installations where acoustic levels must be kept within acceptable limits.

Power Supply Considerations

The HPE P83278-005 DL20 Gen11 server includes a 290W power supply designed to provide stable and efficient power delivery for the system’s components. This power rating aligns with the server’s single-socket architecture and modest storage configuration, ensuring energy-efficient operation without compromising reliability. Energy efficiency is a key consideration for organizations aiming to reduce operational costs and environmental impact. The power subsystem within this server category supports consistent uptime and protects critical components from power fluctuations. By optimizing power usage at both idle and load conditions, the DL20 Gen11 platform helps organizations achieve predictable energy consumption patterns across their IT infrastructure.

Design for Continuous Operation

The 290W power supply contributes to the overall cost-effectiveness of the HPE P83278-005 server category. This design supports continuous operation in always-on environments while keeping electricity costs manageable. It is particularly well-suited for businesses that operate multiple small servers across distributed locations.

Firmware and Management Integration

The HPE DL20 Gen11 server category integrates advanced security features at the firmware and hardware levels, helping protect systems from unauthorized access and malicious threats. Secure boot processes, firmware validation, and system integrity checks are part of the ProLiant Gen11 security framework. These features provide peace of mind for organizations handling sensitive data and mission-critical applications. Management capabilities within this category are designed to simplify server administration. Integrated management tools allow IT teams to monitor system health, configure settings, and perform updates remotely. This reduces the need for on-site intervention and supports centralized management across distributed server deployments.

Operational Visibility

Comprehensive lifecycle management features help extend the usable life of the HPE P83278-005 server category. Proactive monitoring and diagnostic capabilities enable early detection of potential issues, minimizing downtime and maintenance costs. These capabilities are especially valuable for organizations with limited IT staff or geographically dispersed infrastructure.

Use Case Alignment and Deployment Scenarios

The HPE P83278-005 6315P 2.8GHz DL20 Gen11 server category is well-aligned with a wide range of deployment scenarios. Its balanced configuration makes it suitable for edge computing, branch office infrastructure, small virtualization hosts, application servers, and dedicated network services. The combination of enterprise reliability and compact design ensures consistent performance across diverse operational contexts. This server category is also an excellent choice for service providers and system integrators seeking a dependable platform for standardized deployments. Its predictable performance profile and flexible configuration options simplify planning and scaling across multiple customer environments.

Edge Computing and Remote Office Applications

In edge computing scenarios, the DL20 Gen11 server category delivers local processing power where low latency and data sovereignty are critical. The HPE P83278-005 configuration supports on-site analytics, data aggregation, and localized services without relying entirely on centralized data centers. This capability enhances responsiveness and resilience in distributed architectures.

Dedicated Workload Hosting

For virtualization and dedicated workload hosting, this server category provides a stable platform for running multiple lightweight virtual machines or containers. The AMD EPYC 6315P processor and scalable memory support efficient resource allocation, enabling organizations to consolidate services while maintaining performance isolation.

Platform Longevity

The HPE DL20 Gen11 server category is designed with longevity in mind, offering a platform that can evolve alongside business needs. The HPE P83278-005 configuration serves as a reliable entry point into the Gen11 ecosystem, providing a foundation that supports future upgrades, software advancements, and expanding workloads while maintaining the trusted quality associated with HPE ProLiant servers.
