P83279-005 HPE 6325P 3.5GHz DL20 Gen11 1x16GB 2x1TB HDD 1x290W Server

Highlights of HPE P83279-005 ProLiant DL20 Gen11 Server

The HPE P83279-005 ProLiant DL20 Gen11 Server is a reliable and space-efficient 1U rack server engineered for growing businesses, remote offices, and edge computing workloads. Equipped with an Intel Xeon 6325P processor, fast DDR5 memory, and enterprise-grade storage, this server delivers excellent performance, efficiency, and scalability for modern IT environments.

General Information

• Manufacturer: Hewlett Packard Enterprise (HPE)
• Part Number: P83279-005
• Product Category: Rackmount Server
• Form Factor: 1U Rack Server
• Hot-Swap Drive Bays: 2 x LFF
• Sub Type: HPE ProLiant DL20 Gen11 6325P Smart Choice

Technical Specifications

Intel Xeon 6325P Processor Performance

• Processor Family: Intel Xeon Raptor Lake
• CPU Model: Xeon 6325P
• Total Cores: 4 Cores
• Server Architecture: Single-Socket (1-way)
• Base Clock Speed: 3.5 GHz
• Maximum Turbo Speed: Up to 5.2 GHz
• CPU Installed: 1 / Maximum 1
• Interconnect Speed: 16 GT/s
• Thermal Design Power: 55W

Advanced CPU Capabilities

• Intel Turbo Boost Technology 2.0
• Intel Turbo Boost Max Technology 3.0
• Intel Smart Cache Support
• Upgradeable Processor Design

Chipset Information

• Chipset: Intel C262

Cache Memory Details

• L3 Cache Capacity: 12MB per Processor

System Memory (RAM) Specifications

High-Speed DDR5 ECC Memory

• Installed Memory: 16GB DDR5 UDIMM ECC
• Maximum Memory Capacity: Up to 128GB
• Memory Speed: 4800 MT/s
• DIMM Slots: 4 Total (3 Available)
• Form Factor: 288-pin DIMM

Memory Features

• Error-Correcting Code (ECC) Support
• Unbuffered HPE Standard Memory
• Optimized for Stability and Uptime

Internal Storage and Drive Support

Preinstalled Storage Configuration

• Total Raw Capacity: 2TB
• Drive Type: SATA HDD
• Installed Drives: 2 x 1TB
• Drive Size: 3.5-inch LFF
• Rotation Speed: 7200 RPM
• Interface: SATA 6Gb/s

Drive Bay Layout

• 2 x Hot-Swap 3.5-inch LFF Bays

Storage Controller and RAID Options

• Controller Type: Integrated SATA RAID
• Interface: SATA 6Gb/s
• Channel Count: 6 Channels
• RAID Levels Supported: RAID 0, 1, 5, 10

Graphics and Display Capabilities

• Graphics Controller: Matrox G200
• Video Memory: 16MB
• Display Outputs: VGA, DisplayPort

Networking and Remote Management

Enterprise Networking Features

• Network Interfaces: 4 x Gigabit Ethernet
• LAN Controller: Broadcom BCM5719
• Supported Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet

Remote Management and Network Tools

• HPE iLO Remote Management
• SNMP v3 and IPMI 2.0
• Wake-on-LAN (WOL)
• PXE Boot and ACPI Support

Expansion Slots and Connectivity

Expansion Options

• 1 x PCIe 5.0 x16 Slot (Full-height, Half-length)
• 1 x OCP 3.0 Mezzanine Slot

External and Internal Interfaces

• 1 x HPE iLO Service Port (Front)
• 5 x USB 3.2 Gen1 Type-A (1 Front, 4 Rear)
• 2 x USB 3.2 Gen2x2 Internal Ports
• 1 x DisplayPort
• 1 x VGA Port
• 4 x RJ-45 Gigabit LAN Ports

Power Supply and Efficiency

• Power Supply Type: 290W Hot-Plug PSU
• Efficiency Certification: 80 Plus Platinum
• Energy Efficiency: Up to 92%
• Input Voltage: AC 100–120V / 200–240V

Operating System Compatibility and Software

Supported Operating Systems

• No Operating System Pre-installed
• Certified for Windows Server 2019
• Certified for Windows Server 2022
• VMware ESXi 8.0 Update 2 Compatible

HPE Management Software

• HPE Intelligent Provisioning
• HPE iLO Management Utilities

Security, Compliance, and Sustainability

• Energy Star Certified (Version 4.0)
• Compliant with AES and FIPS 140-2
• Supports TLS v1.2 and Redfish API
• ASHRAE Class A3 and A4 Compliance

Environmental and Acoustic Specifications

• Operating Temperature Range: 50°F to 95°F
• Operating Humidity: 8% – 90% RH (Non-condensing)
• Acoustic Output: 22 dBA

Physical Dimensions and Weight

• Width: 17.11 inches
• Depth: 15.05 inches
• Height: 1.7 inches
• Weight: 19.84 lbs

Included Accessories

• HPE Easy Install Rail 12 Kit
• 3 x High-Performance Non-Hot Plug, Non-Redundant Fans

Overview of HPE P83279-005 High-Frequency Enterprise Server

The HPE P83279-005 6325P 3.5GHz DL20 Gen11 4c 1P 1x16GB-U 2LFF 2x1TB HDD 1x290W PS NA Server belongs to a specialized category of compact enterprise servers engineered to deliver high clock-speed performance within a space-efficient 1U form factor. This category is designed for organizations that prioritize fast response times, low-latency processing, and dependable operation across a wide range of business-critical workloads. Built on the HPE ProLiant DL20 Gen11 platform, this server class combines modern processor architecture, enterprise-grade reliability, and streamlined manageability in a configuration well-suited for edge computing, branch offices, and performance-sensitive applications.

AMD EPYC 6325P Processor and Clock-Speed Advantage

The HPE P83279-005 DL20 Gen11 server is powered by the AMD EPYC 6325P processor, operating at a high base frequency of 3.5GHz. This four-core processor is designed for workloads that benefit from strong single-threaded performance and fast execution cycles. The EPYC 6325P leverages AMD’s advanced Zen architecture, delivering efficient instruction processing, optimized cache utilization, and robust memory handling within a power-conscious design. Within this server category, the focus on higher clock speed provides a tangible advantage for applications such as web servers, authentication services, ERP modules, and other software components that rely on rapid processing rather than parallelism.

Single-Processor for Predictable Performance

The one-processor design of the DL20 Gen11 category simplifies system architecture while delivering consistent and predictable performance. By centering the platform around a single AMD EPYC 6325P CPU, this category minimizes inter-socket latency and reduces overall system complexity. This approach ensures that workloads experience stable performance characteristics, which is especially important for applications sensitive to timing and response consistency.

Memory Configuration and Application Responsiveness

The HPE P83279-005 configuration includes 1x16GB of unbuffered memory, providing an efficient starting point for operating systems and essential business applications. This memory capacity is well-matched to the processor’s high-frequency design, enabling fast data access and responsive application behavior. Unbuffered memory contributes to lower latency, which aligns with the performance-oriented nature of this server category. The DL20 Gen11 platform supports memory scalability, allowing organizations to expand capacity as application demands increase. This ensures that the server category remains adaptable over time, accommodating growth in virtualization density, in-memory databases, or additional services without requiring a platform change.

Scalable Memory Path for Evolving Workloads

While the base configuration provides 16GB of memory, the server category supports future upgrades that enhance multitasking and data handling capabilities. This scalability allows the HPE P83279-005 server to transition from basic infrastructure roles to more demanding application workloads, extending its useful life and maximizing return on investment.

Dual Large Form Factor Storage Design for Business Data

The storage subsystem of the HPE P83279-005 DL20 Gen11 server includes two 1TB hard disk drives housed in large form factor bays. This configuration provides ample local storage for operating systems, application data, logs, and backups. The dual-drive design supports balanced data distribution and ensures sufficient capacity for small to medium-sized business workloads. The 2LFF storage layout emphasizes cost-effective capacity and reliability, making it suitable for file services, local databases, and application storage. This server category is designed to support a range of storage configurations, allowing organizations to adapt the system to their specific data requirements as needs evolve.

Reliable Storage Integration and Expansion Flexibility

HPE ProLiant storage integration ensures consistent performance and data integrity through firmware-level optimizations and controller compatibility. The DL20 Gen11 server category supports future storage enhancements, enabling organizations to refine their data strategy without replacing the entire system. This flexibility is critical for businesses that anticipate growth in data volume or changes in workload profiles.

Compact 1U Rack-Mount Form Factor and Physical

The HPE DL20 Gen11 server category is built within a compact 1U rack-mount chassis, making it an excellent choice for environments where space efficiency is essential. The short-depth design supports installation in shallow racks and edge locations, including retail back rooms, branch offices, and telecommunications enclosures. Despite its small footprint, the chassis maintains enterprise-grade durability and thermal efficiency. The physical design of this category prioritizes ease of deployment and serviceability. Components are arranged to facilitate airflow and simplify maintenance, reducing downtime and operational complexity. This design philosophy ensures that the HPE P83279-005 server can operate reliably across diverse physical environments.

Thermal Engineering and Acoustic Control

Advanced thermal management within the DL20 Gen11 platform ensures stable operation under sustained workloads. Intelligent fan control adjusts cooling based on system load, balancing performance and acoustic output. This makes the server category suitable for installations where noise levels must be managed without sacrificing reliability.

Power Supply Configuration

The HPE P83279-005 DL20 Gen11 server includes a 290W power supply engineered to deliver efficient and stable power for the system’s components. This power rating aligns with the server’s single-socket architecture and storage configuration, ensuring optimized energy consumption across idle and load conditions. Energy efficiency is a defining characteristic of this server category, supporting organizations seeking to control operational costs. The power subsystem is designed to provide consistent uptime and protect against electrical fluctuations. By optimizing power delivery, the DL20 Gen11 category contributes to predictable operating expenses and supports continuous operation in always-on environments.

Power Design for Distributed Deployments

The efficient 290W power supply makes this server category particularly suitable for distributed deployments where multiple small servers are deployed across various locations. Reduced power draw and heat output simplify infrastructure requirements and lower total cost of ownership.

Framework and Integrated

The HPE DL20 Gen11 server category incorporates a comprehensive security framework that protects systems at the hardware and firmware levels. Secure boot processes, firmware validation, and system integrity checks are integral to the ProLiant Gen11 architecture. These features help safeguard sensitive data and ensure compliance with organizational security policies. Integrated management tools provide centralized visibility and control over server operations. Administrators can monitor system health, apply updates, and configure settings remotely, reducing the need for on-site intervention. This management approach is especially beneficial for organizations with limited IT staff or geographically dispersed infrastructure.

Operational Resilience

Lifecycle management features within this server category support proactive maintenance and long-term reliability. Predictive diagnostics and monitoring capabilities enable early detection of potential issues, minimizing downtime and extending system lifespan. These capabilities enhance operational resilience and reduce unplanned maintenance costs.

Workload Suitability and Deployment Scenarios

The HPE P83279-005 6325P 3.5GHz DL20 Gen11 server category is well-suited for a variety of deployment scenarios that require high-frequency processing and dependable performance. Its configuration supports edge computing, branch office infrastructure, dedicated application hosting, and network services. The emphasis on clock speed makes it particularly effective for workloads where responsiveness and low latency are critical. This category also appeals to system integrators and managed service providers seeking a standardized, performance-oriented platform. The predictable behavior and enterprise-grade reliability of the DL20 Gen11 platform simplify deployment and scaling across multiple environments.

Edge Computing and Latency-Sensitive Applications

In edge computing environments, the DL20 Gen11 server category delivers local processing power that reduces dependence on centralized data centers. The high-frequency AMD EPYC 6325P processor enables fast decision-making and real-time data processing, improving responsiveness for applications deployed at the network edge.

Dedicated Application and Service Hosting

For dedicated application hosting, this server category provides a stable and efficient platform capable of running critical services with consistent performance. The combination of fast CPU speed, scalable memory, and reliable storage supports a wide range of enterprise and commercial software solutions.

Platform Longevity and Strategic Value

The HPE DL20 Gen11 server category is designed to deliver long-term value through a balance of performance, efficiency, and scalability. The HPE P83279-005 configuration represents a strategic investment for organizations seeking a compact yet powerful server that can adapt to changing business requirements while maintaining the trusted reliability of the HPE ProLiant ecosystem.
